Title: MultiGigabit SerialLink Integrated Silicon Transceiver


1
Multi-Gigabit Serial-Link Integrated Silicon
Transceiver
  • M.Sc. Thesis
  • By
  • Mohyee Mikhemar
  • Under supervision of
  • Prof. Hani Fikry
  • Dr. Khaled Sharaf

2
Outline
  • Introduction to Optical Communications
  • Thesis objective and flow
  • TIA design
  • CDR system design
  • CDR circuit design
  • Conclusion and Future Work

3
Modern Optical Transmitter
4
Optical Fiber Link
5
Modern Optical Receiver
6
Thesis Objective
  • Design of integrated circuits and systems for
    optical communication transceivers on silicon.

Transceiver blocks
Laser Driver
High voltage swing prohibit Silicon implementation
Low noise, high gain, broadband amplifier
TIA
  • Design include
  • System Level design
  • Circuit Level design

A CDR will be designed on System and Circuit
levels
PLL-CDR
Future Work
7
Target Standard
  • SONET OC-192 line termination receiver for
    short-haul links.

Synchronous Optical Network (SONET) SONET defines
optical carrier (OC) levels and electrically
equivalent synchronous transport signals (STSs)
for the fiber-opticbased transmission hierarchy.
  • Short-haul links
  • Transmission distance less than 40 Km
  • No optical amplifiers are used to minimize the
    cost
  • Receiver sensitivity limits the transmission
    distance

8
Design Flow
Link specs of different blocks to receiver
sensitivity
Link specs of different blocks to receiver
sensitivity
Design TIA for target Rx
Design CDR circuits
9
Receiver Sensitivity
Sensitivity Minimum received power for a certain
BER
10
Design Flow
Link specs of different blocks to receiver
sensitivity
Analyze common TIA topologies
Compare the analyzed topologies
Design TIA for target Rx
Design CDR circuits
11
Common TIA Topologies (CB)
  • The photodiode capacitance is large (0.1-0.5)pF
    and does not scale with the technology.
  • The noise is mainly contributed by Q2, Rc.
  • Challenges
  • Severe trade-off on Rc.
  • Rc ?, Gain ? , Noise ? .
  • Rc ?, BW ?, Headroom ?.
  • Headroom ?, Cj ?.
  • Modern low voltage technologies suffer from
    headroom problems

12
Common TIA Topologies (CB w/ FB)
  • The FB loop of CB must include inverting
    amplifier.
  • Buffers drive the load capacitance.
  • The complexity of the circuit affects its noise
    and power performance.

13
Common TIA Topologies (CE w/ FB)
  • CE can not be used in open loop configuration
    because
  • The high input impedance will draw less current
    from the photo-detector.
  • The high gain will narrow the bandwidth.
  • FB is deployed to decrease the input impedance.
  • The load capacitance limits the bandwidth

14
Common TIA Topologies (CE w/ buff FB)
  • A CC buffer is added to isolate the main
    amplifier from the load capacitance.


A. Buchwald and K. Marin, Integrated
Fiber-Optic Receivers , Kluwer, 1995.
15
Design Flow
Link specs of different blocks to receiver
sensitivity
Analyze common TIA topologies
Compare the analyzed topologies
Design TIA for target Rx
Design CDR circuits
16
Figure of Merit
  • Proposed FoM


0.5 SiGe Process with fT60 GHz and 3.3 V supply
voltage
M. Mikhemar, K. Sharaf and H. Ragai, On the
Performance of Transimpedance Amplifier,
proceedings of the Midwest Symposium, Cairo,
Egypt. December 2003.
17
Design Flow
Link specs of different blocks to receiver
sensitivity
Analyze common TIA topologies
Compare the analyzed topologies
Design TIA for target Rx
Design CDR circuits
18
TIA for OC-192
  • AMS 0.35 SiGe technology with 3.3 V supply and
    fT60 GHz

19
Topology Analysis
20
Peaking Control
The second order system is designed to control
the peaking
21
Simulation Results
22
Comparison with publications
Based on only schematic level simulation
FoM10.log(1000.FoM) RCG Regulated Common
Gate 0.1 HEMT 0.1InGaAs/AlGaAs
23
Design Flow
Link specs of different blocks to receiver
sensitivity
Analyze common TIA topologies
Choose CDR architecture
Compare the analyzed topologies
Design CDR loops for target Rx
Design TIA for target Rx
Verify design using simulations
Design CDR circuits
24
CDR
  • CDR must provide two important functions
  • Clock Recovery
  • Data Regeneration
  • Target CDR must
  • Satisfy SONET jitter requirements
  • Achieve stable operation
  • Accommodate process variation

25
Architecture of Choice
26
Phase Detector of Choice
  • Alexander phase detector
  • If A B ? C, clock is early.
  • If A ? B C, clock is late.
  • If A B C, no transition.

27
Design Flow
Link specs of different blocks to receiver
sensitivity
Analyze common TIA topologies
Choose CDR architecture
Compare the analyzed topologies
Design CDR loops for target Rx
Design TIA for target Rx
Verify design using simulations
Design CDR circuits
28
Linear Model of the dual loop
29
Dual Loop Analysis
  • Third order, type II loop
  • The system produces 3 poles and a zero
  • The locations of the 3 poles and the zero are
    adjusted using Sz, Sp, K, N.
  • The target of the analysis is to express the
    closed loop poles in terms of loop parameters

30
Proposed Dual loop Analysis
Complex domain
31
Dual Loop stability Design
32
Design Equations
To Satisfy Jitter tolerance
To Suppress the unwanted activity on the control
line
Substituting in the developed model
33
Linear System Simulation Results
  • Jitter tolerance performance
  • Stability performance
  • Proposed model verification

34
Design Flow
Link specs of different blocks to receiver
sensitivity
Analyze common TIA topologies
Choose CDR architecture
Compare the analyzed topologies
Design CDR loops for target Rx
Design TIA for target Rx
Verify design using simulations
Design CDR circuits
35
Simulink System Simulation
  • Complete library of all CDR components was built
    using simulink.

36
Simulation Results
FLL Active
PLL Active
  • a) Mux Control signal b) VCO control voltage

37
Simulation Results (FLL acquisition)
During Acquisition
After Locking
38
Simulation Results (PLL acquistion)
During Acquisition
After Locking
39
Jitter Tolerance
Jitter Intolerant CDR
Jitter tolerant CDR
40
Jitter Tolerance Measurements
41
Design Flow
Link specs of different blocks to receiver
sensitivity
Analyze common TIA topologies
Choose CDR architecture
Compare the analyzed topologies
Design CDR loops for target Rx
Design TIA for target Rx
Verify design using simulations
Design CDR circuits
42
CDR circuit design
Low speed
High speed
Done
Done
Done
43
Alexander Phase Detector
44
Alexander Phase Detector (Cont.)
Differential Current Mode Logic
D-Flip Flop
XOR-gate
45
Complete PD simulation
Late Clock
Early Clock
46
CDR circuit design
Low speed
High speed
Done
Done
Done
Done
Done
47
Charge pump design
48
Upper current source
49
Lower current source
50
Common Mode Sensing Network
51
Charge Pump Simulation
  • Differential output current

52
CDR circuit design
Low speed
High speed
Done
Done
Done
Done
Done
Done
53
Loop Filter design
  • Given
  • K
  • ?z
  • ?p from system design and,
  • VCO gain
  • Charge pump current from circuit design
  • The loop parameters are

54
CDR circuit design
Low speed
High speed
Done
Done
Done
Done
Done
Done
Done
55
10 GHz VCO
  • A fully differential interpolating two stage
    ring-based VCO is used

56
Delay Cell
57
VCO Simulation Results
  • Wide tunning range 6 GHz
  • Phase noise -72.64 dBc _at_ 1 MHz offset

58
CDR circuit design
Low speed
High speed
Done
Done
Done
Done
Done
Done
Done
Done
59
Design Flow
Link specs of different blocks to receiver
sensitivity
Analyze common TIA topologies
Choose CDR architecture
Compare the analyzed topologies
Design CDR loops for target Rx
Design TIA for target Rx
Verify design using simulations
Design CDR circuits
60
Conclusion
  • Different TIA topologies have been thoroughly
    studied and a proposed FoM has been reported.
  • A differential CE with double buffered TIA
    circuit has been designed using 0.35 ?m SiGe
    technology for OC-192 featuring a FoM of 28.3.
  • A linear model based procedure has been
    formulated to speed up the design cycle of the
    CDR.

61
Conclusion (Cont.)
  • A dual loop CDR for OC-192 has been designed and
    simulated on behavioral level using the
    formulated procedure.
  • A jitter tolerance testbench has been developed
    to validate OC-192 jitter tolerance standard
    mask.
  • The circuits of the different building blocks for
    the dual loop CDR have been designed and
    simulated based on differential CML technique
    using 0.35 ?m SiGe technology .

62
Future Work
  • Fabricate the complete chip using AMS 0.35 ?m
    SiGe technology.
  • Integrate the digital framer on the same chip.
  • Study the capabilities of deep submicron CMOS
    technologies for 10/40 Gbit/s operation.
