Foundations

1
Foundations

• Section 5

2
Partial Foundation
3
Post And Pier Foundation
4
Interior Posts and Girders
5
Continuous Interior Footing
6
Two Pour System
Pour 2
Pour 1
7
Failure of Two-Pour Joint
8
Foundation Materials

• Concrete
• Concrete Block
• Brick
• Stone

9
Unreinforced Brick Foundation Wall
10
Stone Foundation
11
Check Foundation Condition

• Deterioration
• Cracking

12
Deteriorated Mortar Joints
13
Foundation Crack
14
What Causes Cracking?
15
Consult a Professional When...

• Crack is gt 1/8
• You can see through the crack
• It appears to be the result of expansion or
  settlement

16
Foundation Embedment
POOR
GOOD
17
Capping Existing Foundations
18
Foundation Replacement
19
Parallel System
