The Relational Model and Relational Algebra

1
The Relational Model and Relational Algebra

• Srinath Srinivasa,
• Indian Institute of Information Technology,26/C
  Electronic City,Hosur Road, Bangalore 560100
• sri_at_iiitb.ac.in

2
Background

• Introduced by Ted Codd of IBM Research in 1970.
• Concept of mathematical relation as the
  underlying basis.
• The standard database model for most
  transactional database today.

3
Relational Model Concepts

• A relational database is a collection of
  relation.
• A relation resembles a Table or a Flatfile of
  records.
• Each row in such a table represents a collection
  of such related data values ( an instance of
  the relation depicted by the table)

Table 1 A example relation called STUDENT

• Each row or a relation instance is called a
  tuple and
• each column is called attribute of the relation

4
Some Definitions

• A data value is said to be atomic if it cannot be
  subdivided into smaller data values. For example,
  the age of a person in years is an atomic value.
• A Domain is a set of atomic values. Examples are
  the set of all Integers, the set of all valid
  student roll number, the set of all Indian cities
  with population above 6 million etc.
• A Relation Schema denoted by R(A1,A2,A3,An) is
  made up of relation name R and a list of
  attributes A1,A2,A3,An . Each Ai is the name of
  role played some domain D in the schema R. The
  domain Ai is denoted by dom(Ai).

5
Some Definitions

• The Degree of the relation is the number of
  attributes of its relation schema.
• A relation r of a relation schema
  R(A1,A2,A3,An), is a set of n-tuples of the
  form t1,t2,.,tn where each ti ? dom(Ai).
• The Relation can be defined as
• r(R) ? (dom(A1) x dom(A2) x dom(An)),
  where x is the cartesian product over sets.

6
Characteristics of Relation

• Ordering of Tuples Mathematically tuples in
  relation dont have ordering (although in
  reality they do have order when stored in files
  or disk)
• Ordering of attributes Attributes within a tuple
  have to maintain order if they are stored as
  tuples. However a relation need not necessarily
  be maintained as a set of ordered tuples as long
  as a mapping between attribute and value is
  maintained in each relation instance.
• Values of Tuples Each value that makes up a
  tuple is atomic and cannot be further subdivided.
  This is also called the first normal form
  assumption.

7
Relational Constraints

• Domain constraints domain constraints specify
  that value of each attribute A must be atomic and
  a member of dom(A).
• Key constraints Given a relational schema R
  (Ai), i 1n , a subset of attributes K is
  called a superkey if the values of attributes
  in K is distinct for every relation instance.
  This is, for any two tuples ti , tj , (ti ? tj)
  ? (ti K ? tjK).
• A key k of a relation is a subset of the
  superkey, k ? K,such that removal of any
  attribute in k removes the superkey property for
  k. They are also called Minimal superkeys.

8
Relational Constraints

• In STUDENT table (Roll no, Name) is a superkey,
  while (Roll no) is a minimal key.
• A relation schema may have more than one key.
  Each key is called a candidate key.
• Usually one of the candidate key is chosen to
  uniquely identify tuples in a relation. such a
  key is called primary key for a relation.
• In STUDENT relation, Roll no is a good primary
  key.

9
Relational Constraints

• Entity Integrity Constraint The primary key of a
  tuple may never be null.
• Referential Integrity Constraint Informally, a
  tuple that refers to another tuple from another
  relation should refer to an existing tuple.
• In a given relation R1 a set of attributes
  FK is said to be a foreign key of R1 referencing
  another relation R2, if the following rules hold
• The attribute in FK have the same domain as the
  primary key of R2.
• For every tuple in R1, the attributes in its
  Foreign Key FK either reference a tuple in R2 or
  is null.

10
Relational Constraints
Employee
Department
Foreign Keys are diagrammatically depicted as
arrows. Note that foreign key can be from a
relation to itself.
11
Relational Constraints

• Semantic Integrity Constraint Constraints on the
  values of attributes.
• Example The salary of the employee cannot
  be more than of his/her supervisor.
• The minimum age of an employee is 18 and
  maximum is 65.
• Semantic Integrity constraints are application
  specific and not part of the relational model,
  strictly speaking. Such constraints are specified
  and enforced using general purpose constraint
  specification languages.

12
Basic Relational Algebra Operations

• Operations of relational model can be categorized
  into retrievals and updates.
• Updates can be either insert of new tuple ,
  update( or modify) an existing tuple or delete an
  existing tuple.
• Retrieval is handled mostly by select (denoted by
  ?) and project (denoted by ?) operations.

13
The Select Operation

• The SELECT operation is used to select (retrieve)
  a subset of the tuples from a relation that
  matches the selection condition .
• ?salary gt 3000 (Employee)
• selects all tuples of relation Employee which
  matches the criteria
• Employee.Salary gt 3000

14
The Select Operation

• The general syntax of SELECT is as follows
• ? ltConditiongt (Relation)
• where condition is of the form
• Condition? (Expression) logicaloperator condition
  Expression
• Expression ? attributename operator constant
  attributename operator attributename
• Logicaloperator ? AND OR
• Operator ? lt gt ? ? ?

15
Properties of SELECT operation

• The SELECT operation is unary. It operates on
  only one relation.
• Selection conditions are applied to each tuple
  individually in the relation. Hence the condition
  cannot be span more than one tuple.
• The degree of the relation resulting from ?c(R)
  is the same as that of R.
• ?c(R) ? R
• The SELECT operation is commutative
  ?c1 (?c2(R)) ? ?c2 (?c1(R))
• Hence, SELECT operation can be cascaded in any
  fashion.

16
The Project Operation

• The project operation selects specific
  columns from the specified relation.
• ?Name, Salary ( Employee)
• returns a relation comprising of only the
  Employee.Name and Employee.Salary attributes. The
  operation has said to have projected Employee
  relation onto the required relation.

17
The Project Operation

• The general form of PROJECT is as follows
• ? ltattributeslistgt (Relation)
• where attributelist is a comma-separated
  list of attributes belonging to the specified
  relation.
• The result of the PROJECT is in the same order as
  the specified list of attributes.

18
Properties of Project operation

• The PROJECT operation removes duplicate in its
  results.
• The number of tuples returned by PROJECT is less
  than or equal to number of tuples in the
  specified relation.
• When attrubute list of PROJECT includes the
  superkey then the number of tuples returned is
  equal to the number of tuples in the specified
  relation.
• PROJECT is not commutative.
• ?l1?l2(R) ?l1 (R) if l1 is a substring of l2.
  Else the operation is an incorrect expression.

19
Composition and Assignment

• Since the input and output of the relational
  operator is a single relation, they can be
  composed in any fashion with the output of one
  operation being the input of the other.
• ? Name, Salary (?Salary gt 3000 (Employee ) )
• returns Name and Salary field of all records of
  Employee, where salary is greater than 3000.
• Results of a query can also be assigned to a name
  to form a relation by that name.
• SalaryStatement ? ? Name, Salary (? Salary gt
  3000( Employee ))
• create a new relation SalaryStatement out of the
  specified query.

20
Cartesian Join ( x)

• PROJECT and SELECT operators expect a single
  relation.
• When PROJECT and SELECT need to be run on a
  multiple relation, a single relation can be
  generated using the cartesian join ( x )
  operator.

TABLE Student
TABLE Lab
Consider the Relational Query ? Student.Lab
Lab.Name (Student x Lab)
21
Cartesian Join (x)
Columns matching the query are shown in PINK.
22
Query Result
23
Properties of Cartesian Join ( x )

• The Cartesian Join represents a Canonical Join of
  two or more relations.
• If relation R having R tuples and relation S
  having S tuples are joined using x, then R
  x S R ? S
• Cartesian join is too inefficient for most
  queries involving multiple relations.

24
Relational Algebra (contd)

• Join operators and additional relational operators

25
Relational Algebra Summary

• Based on the concept of mathematical relation
• Building block a relation comprising of
  attributes within domains
• Tuples Schema Relation
• Properties Ordering, Duplicates
• Constraints Key constraints, entity constraints,
  referential integrity constraints
• Basic retrieval operators Select, Project
• Composability of relational operators and
  Cartesian join

26
Theta Join Operator (??? )

• Theta join is used to combine related tuples
  from two or more relations ( specified by the
  condition theta ), to form a single tuple.
• Consider the earlier relation Student and Lab.
• The relation
• Student ?? Student.Lab Lab.Name Lab
• returns the same result as
• ? Student.Lab Lab.Name (Student x Lab)
• However, the number of tuples generated by Join
  is 4 rather than 12 as in the Cartesian join.
• Note that Student.lab is a foreign key into Lab
  (and Lab.Name is a primary key of Lab) and
  referential Integrity has to be maintained to
  perform this join.

27
Theta Join Operator

• The general form of theta join is as follows
• R ?? join condition S
• where R and S are relation and join condition is
  a logical expression over attributes of R and S .
• Tuples whose join attributes are null do not
  appear in the final result.

28
Theta Join Operator

• Theta join where the only comparison operator
  used is the equals () sign, are called equijoins
  .
• A natural join denoted by is an equijoin,where
  the attribute names at both ends of the equality
  sign are the same. In this case, the attribute is
  not repeated in the final result.
• Consider the Student and the Lab example. Let
  the Student relation schema be modified as
  Student(RollNo,Name,Labname) and Lab relation
  schema be modified as Lab(LabName,Faculty,Dept).
• The natural join Student Lab has a scheme
• (Roll No, Name, LabName, Faculty, Dept)

29
Renaming

• TA(id,LabName) ? ?Roll No,Lab(Student)
• The above relation projects RollNo and Lab
  attributes from Student and renames them as id
  and LabName respectively in the output relation.
  It also names the output relation as TA.
• The above can also be achieved by rename (?)
  operator as
• ? TA(id,LabName) (? Roll No,Lab( Student ))

30
Renaming

• The general form of the rename operator is as
  follows
• ? S(B1, B2, .Bn) (R)
• Or
• ? S (R)
• Or
• ? (B1, B2, .Bn) ( R)
• The first form renames both relation name and
  attribute names, the second form renames only the
  relation name and the third form renames only
  attribute names.

31
Set Theoretic Operations

• Set theoretic operation like UNION ( U ),
  INTERSECTION ( ) and SET DIFFERENCE can be
  applied to compatible relations.
• Compatibility Two relations R ( A1,A2An) and
  S ( B1,B2,.Bn) are compatible if they have the
  same number of attributes and for all

• The Union operator R U S returns the set of all
  tuples that are present in either R or S or both.
  Duplicate tuples will be eliminated.
• The Intersection operator R S returns the
  set of all tuples are present in both R and S.
• The Set Difference operator R S returns the
  set of all tuples in R but not in S.
• Note that
  , but

32
The Division Operator

• The Division operator ( ) is used to denote
  the conditions where a given relation R is to be
  split based on whether its association with every
  tuple in an other relation S.
• Let the set of attributes of R be Z and set of
  attributes of S be X. Let
• Y Z X, that is the set of all
  attributes of R that are not in S.
• The result of the operation is as
  follows. For every tuple
  ,

R
S
33
Other Relational Operators

• Outer Join A normal join operation ?? requires
  referential integrity.
• Every attribute in R that refers S should refer
  to an existing tuple in S. If either the
  referencing attribute of S is null, the tuple is
  not returned.
• Outer join is used when all tuples are required
  even when referential integrity is not met. Left
  outer join includes tuples even when the
  referencing attribute is null and Right outer
  join includes tuples even when the referenced
  attribute is null or referenced tuple does not
  exist.
• An outer join which is both left and right is
  called a Full outer join.
• Outer Union Outer Union computes the union of
  partially compatible relations. Two relations
  R(X) and S(Z) are said to be partially compatible
  if there exists W ? X and Y ? Z such that
  for every Ai ? W and Bi ? Y, dom(Ai)
  dom(Bi).
• Outer Union of R and S creates a new relation
  that includes all attributes from
  both relation. Null values fill up all undefined
  attributes.

34
The Complete Set of the Operators

• The following set of relational operators
  , , U , -- , x is called the complete
  set of the relational operators because all
  other operators can be mathematically expressed
  as a sequence of the above operators.
• For Example
• Similarly

35
Relational Operators on Bags

• A bag or a multi-set is a set that may have
  multiple occurrences of a given element
• Bags are necessary when aggregation (sum,
  average,) has to be performed over query results
• Tolerating bags while answering queries reduces
  unnecessary overheads

36
Set-theoretic operations on bags
Consider two bags R where tuple t occurs n times
and S, where
tuple t occurs m times. The union of bags or
disjoint union of sets denoted by R S is a
bag that contains R S tuples or mn
occurrences of tuple t. In the intersection of
bags R ? S, tuple t occurs min(n,m) times. In
the set difference of bags R S, tuple t
occurs max(0, n-m) times.
37
Other operators on Bags

• The select operator on bags is applied to each
  tuple in the bag independently and duplicates are
  not removed from the result
• The project operator on bags is applied to each
  tuple independently and duplicates are not
  removed from the result. Faster than project
  operator on sets.
• Cartesian product on bags If tuple t occurs m
  times in relation R and tuple s occurs n times in
  relation S, then tuple ts occurs mn times in RxS.

38
Algebraic expressions on bags
The following algebraic expressions are valid
when R and S are sets, but invalid when they are
bags (R ? S) T (R T) ? (S T)
1-1-1 principle R ? (S ? T) (R ? S) ?
(R ? T) 2-1-2 principle ?C OR D (R) ?C
(R) ? ?D (R)
39
Relational Operators Example
Consider the following schema Employee
(FNAME,MINIT,LNAME,PAN,DOB,ADDR
GENDER,SALARY,SUPERVISOR,DNO) Department
(DNAME, DNUMBER, MGRPAN,
MGRSTARTDATE) Dept_Locations
(DNUMBER, DLOCATION) Project (PNAME, PNUMBER,
PLOCATION, DNUM) Works_on (EPAN, PNO, HOURS)
40
Relational Operators Example
Query 1 Retrieve the name and address of all
employees who work for Research department
Research_dept ? ?DNAMEResearch
(Department) Research_emps ?
(Research_dept ??DNUMBERDNO EMPLOYEE) Result ?
?FNAME,LNAME,ADDRESS (Research_emps)
41
Relational Operators Example
Query 2 Find the names of employees who work on
all projects controlled by department no. 5
Dpt5_proj ? ?PNUMBER (?DNUM5
(Project)) Emp_Prj(PAN,PNUMBER) ? ?EPAN,PNO
(Works_on) Result_Pans ? Emp_Prj ? Dpt5_proj
Result ? ?FNAME,LNAME (Result_Pans Employee)
42
Relational Operators Example
Query 3 List the names of all employees who are
not working on any projects All_Pans ? ?PAN
(Employee) Prj_Pans ? ?EPAN (Works_on) NoPrj_Pan
s ? All_Pans Prj_Pans Result ? ?FNAME,LNAME
(NoPrj_Pans Employee)
43
Summary

• Definition of relation schema, relation, domain,
  attributes.
• Difference between the mathematical concept of
  relation and their implementation as tables or
  files.
• Constraints in relational model Domain
  Constraints, Key constraints (Super key,
  Candidate key, Primary key definition), Entity
  Integrity constraint, Referential integrity
  constraint .
• Basic relational algebra operation ,

• Relational Algebra operators
  outer join, outer union.
• The complete set of relational operators.
