Title: CS 2200 Lecture 19 Parallel Processing


1
CS 2200 Lecture 19Parallel Processing
  • (Lectures based on the work of Jay Brockman,
    Sharon Hu, Randy Katz, Peter Kogge, Bill Leahy,
    Ken MacKenzie, Richard Murphy, and Michael
    Niemier)

2
Our Road Map
Processor
Memory Hierarchy
I/O Subsystem
Parallel Systems
Networking
3
The Next Step
  • Create more powerful computers simply by
    interconnecting many small computers
  • Should be scalable
  • Should be fault tolerant
  • More economical
  • Multiprocessors
  • High throughput running independent tasks
  • Parallel Processing
  • Single program on multiple processors

4
Key Questions
  • How do parallel processors share data?
  • How do parallel processors communicate?
  • How many processors?

5
TodayParallelism vs. Parallelism
  • Uni
  • Pipelined
  • Superscalar
  • VLIW/EPIC
  • SMP (Symmetric)
  • Distributed

TLP
ILP
6
Flynns taxonomy
  • Single instruction stream, single data stream
    (SISD)
  • Essentially, this is a uniprocessor
  • Single instruction stream, multiple data streams
    (SIMD)
  • Same instruction executed by multiple processors
    with different data streams
  • Each processor has own data memory, but 1
    instruction memory and control processor to
    fetch/dispatch instructions

7
Flynns Taxonomy
  • Multiple instruction streams, single data streams
    (MISD)
  • Can anyone think of a good application for this
    machine?
  • Multiple instruction streams, multiple data
    streams (MIMD)
  • Each processor fetches its own instructions and
    operates on its own data

8
A history
  • From a parallel perspective, many early
    processors SIMD
  • In recent past, MIMD most common multiprocessor
    arch.
  • Why MIMD?
  • Often MIMD machines made of off-the-shelf
    components
  • Usually means flexibility could be used as a
    single-user machine or multi-programmed machine

9
A history
  • MIMD machines can be further sub-divided
  • Centralized shared-memory architectures
  • Multiple processors share a single centralized
    memory and interconnect to it via a bus
  • works best with smaller of processors
  • B/c of centralization/uniform access time
    sometimes called Uniform Memory Access
  • Physically distributed memory
  • Almost a must for larger processor counts else
    bandwidth a problem

10
Ok, so we introduced the two kinds of parallel
computer architectures that were going to talk
about.Well come back to them soon enough. But
1st, well talk about why parallel processing is
a good thing
11
Parallel Computers
  • Definition A parallel computer is a collection
    of processing elements that cooperate and
    communicate to solve large problems fast.
  • Almasi and Gottlieb, Highly Parallel Computing
    ,1989
  • Questions about parallel computers
  • How large a collection?
  • How powerful are processing elements?
  • How do they cooperate and communicate?
  • How is data transmitted?
  • What type of interconnection?
  • What are HW and SW primitives for programmer?
  • Does it translate into performance?

(i.e. things you should have some understanding
of after class today)
12
The Plan
  • Applications (problem space)
  • Key hardware issues
  • shared memory how to keep caches coherence
  • message passing low-cost communication
  • See Board (intro. to cache coherency)

13
Current Practice
  • Some success w/MPPs (Massively Parallel
    Processors)
  • dense matrix scientific computing (Petrolium,
    Automotive, Aeronautics, Pharmaceuticals)
  • file servers, databases, web search engines
  • entertainment/graphics
  • Small-scale machines DELL WORKSTATION 530
  • 1.7GHz Intel Pentium IV (in Minitower)
  • 512 MB RDRAM memory, 40GB disk, 20X CD, 19
    monitor, Quadro2Pro Graphics card, RedHat Linux,
    3yrs service
  • 2,760 for 2nd processor, add 515
  • (Can also chain these together)

14
Parallel Architecture
  • Parallel Architecture extends traditional
    computer architecture with a communication
    architecture
  • Programmming model (SW view)
  • Abstractions (HW/SW interface)
  • Implementation to realize abstraction efficiently
  • Historically, implementations have been tied to
    programming models but that is changing.

15
Parallel Applications
  • Throughput-oriented (want many answers)
  • multiprogramming
  • databases, web servers
  • Latency oriented (want one answer, fast)
  • Grand Challenge problems
  • See http//www.nhse.org/grand_challenge.html
  • See http//www.research.att.com/dsj/nsflist.html
  • global climate model
  • human genome
  • quantum chromodynamics
  • combustion model
  • cognition

16
Programming
  • As contrasted to instruction level parallelism
    which may be largely ignored by the programmer...
  • Writing efficient multiprocessor programs is
    hard.
  • Wizards write programs with sequential interface
    (e.g. Databases, file servers, CAD)
  • Communications overhead becomes a factor
  • Requires a lot of knowledge of the hardware!!!

17
Speedupmetric for performance on
latency-sensitive applications
  • Time(1) / Time(P) for P processors
  • note must use the best sequential algorithm for
    Time(1) -- the parallel algorithm may be
    different.

linear speedup (ideal)
speedup
typical rolls off w/some of processors
1 2 4 8 16 32 64
occasionally see superlinear... why?
1 2 4 8 16 32 64
processors
18
Speedup Challenge
  • To get full benefit of parallelism need to be
    able to parallelize the entire program!
  • Amdahls Law
  • Timeafter (Timeaffected/Improvement)Timeunaffec
    ted
  • Example We want 100 times speedup with 100
    processors
  • Timeunaffected 0!!!
  • (see board notes for this worked out)

19
Hardware Two Main Variations
  • Shared-Memory
  • may be physically shared or only logically shared
  • communication is implicit in loads and stores
  • Message-Passing
  • must add explicit communication

20
Shared-Memory Hardware (1)Hardware and
programming model dont have to match, but this
is the mental model for shared-memory programming
  • Memory centralized with uniform access time
    (UMA) and bus interconnect, I/O
  • Examples Dell Workstation 530, Sun Enterprise,
    SGI Challenge
  • typical
  • 1 cycle to local cache
  • 20 cycles to remote cache
  • 100 cycles to memory

21
Sharing Data (another view)
Uniform Memory Access - UMA
Memory
Symmetric Multiprocessor SMP
22
Shared-Memory Hardware (2)
  • Variation memory is not centralized. Called
    non-uniform access time (NUMA)
  • Shared memory accesses are converted into a
    messaging protocol (usually by HW)
  • Examples DASH/Alewife/FLASH (academic), SGI
    Origin, Compaq GS320, Sequent (IBM) NUMA-Q

23
Sharing Data (another view)
Non-Uniform Memory Access - NUMA
24
More on distributed memory
  • Distributing memory among processing nodes has 2
    pluses
  • Its a great way to save some bandwidth
  • With memory distributed at nodes, most accesses
    are to local memory within a particular node
  • No need for bus communication
  • Reduces latency for accesses to local memory
  • It also has 1 big minus!
  • Have to communicate among various processors
  • Leads to a higher latency for intra-node
    communication
  • Also need bandwidth to actually handle
    communication

25
Message Passing Model
  • Whole computers (CPU, memory, I/O devices)
    communicate as explicit I/O operations
  • Essentially NUMA but integrated at I/O devices
    instead of at the memory system
  • Send specifies local buffer receiving process
    on remote computer

26
Message Passing Model
  • Receive specifies sending process on remote
    computer local buffer to place data
  • Usually send includes process tag and receive
    has rule on tag match 1, match any
  • Synch when send completes, when buffer free,
    when request accepted, receive wait for send
  • Sendreceive gt memory-memory copy, where each
    each supplies local address, AND does pairwise
    sychronization!

27
Two terms multicomputers vs. multiprocessors
28
Communicating between nodes
  • One way to communicate b/t processors treats
    physically separate memories as 1 big memory
  • (i.e. 1 big logically shared address space)
  • Any processor can make a memory reference to any
    memory location even if its at a different node
  • Machines are called distributed shared
    memory(DSM)
  • Same physical address on two processors refers to
    the same one location in memory
  • Another method involves private address spaces
  • Memories are logically disjoint cannot be
    addressed be a remote processor
  • Same physical address on two processors refers to
    two different locations in memory
  • These are multicomputers

29
Multicomputer
Proc Cache A
Proc Cache B
interconnect
memory
memory
30
MultiprocessorSymmetric Multiprocessor or SMP
Cache A
Cache B
memory
31
But both can have a cache coherency problem
Cache A
Cache B
Read X Write X
Read X ...
Oops!
X 1
X 0
memory
X 0
32
Simplest Coherence StrategyEnforce Exactly One
Copy
Cache A
Cache B
Read X Write X
Read X ...
X 1
X 0
memory
X 0
33
Exactly One Copy
Read or write/ (invalidate other copies)
INVALID
VALID
More reads or writes
Replacement or invalidation
  • Maintain a lock per cache line
  • Invalidate other caches on a read/write
  • Easy on a bus snoop bus for transactions

34
Exactly One Copy
  • Works, but performance is crummy.
  • Suppose we all just want to read the same memory
    location
  • one lousy global variable n the size of the
    problem, written once at the start of the program
    and read thereafter

Permit multiple readers (readers/writer lock per
cache line)
35
Cache consistency(i.e. how do we avoid the
previous protocol?)
36
Multiprocessor Cache Coherency
  • Means values in cache and memory are consistent
    or that we know they are different and can act
    accordingly
  • Considered to be a good thing.
  • Becomes more difficult with multiple processors
    and multiple caches!
  • Popular technique Snooping!
  • Write-invalidate
  • Write-update

37
Cache coherence protocols
  • Directory Based
  • Whether or not some physical memory location is
    shared or not is recorded in 1 central location
  • Called the directory
  • Snooping
  • Every cache w/entries from centralized main
    memory also has a particular blocks sharing
    status
  • No centralized state kept
  • Caches connected to shared memory bus
  • If there is bus traffic, caches check (or
    snoop) to see if they have the block being
    transferred on bus
  • Main focus of upcoming discussion

38
Side note Snoopy Cache
CPU
CPU references check cache tags (as
usual) Cache misses filled from memory (as
usual) Other read/write on bus must check tags,
too, and possibly invalidate
State Tag Data
Bus
39
Maintaining the coherence requirement
  • 1 way make sure processor has exclusive access
    to a data word before its written
  • Called the write invalidate protocol
  • Will actually invalidate other copies of the data
    word on a write
  • Most common for both snooping and directory
    schemes

40
Maintaining the coherence requirement
  • What if 2 processors try to write at the same
    time?
  • The short answer one of them will get
    permission to write first
  • The others copy will be invalidated,
  • Then itll get a new copy of the data with
    updated value
  • Then it can get permission and write
  • Probably more on how later, but briefly
  • Caches snoop on the bus, so theyll detect a
    request to write so whichever machine gets to
    the bus 1st, goes 1st

41
Write invalidate example
  • Assumes neither cache had value/location X in it
    1st
  • When 2nd miss by B occurs, CPU A responds with
    value canceling response from memory.
  • Update Bs cache memory contents of X updated
  • Typical and simple

42
Maintaining the cache coherency requirement
  • Alternative to write invalidate update all
    cached copies of a data item when the item is
    written
  • Called a write update/broadcast protocol
  • One problem bandwidth issues could quickly get
    out of hand
  • Solution track whether or not a word in the
    cache is shared (i.e. contained in another cache)
  • If the word is not shared, theres no need to
    broadcast on a write

43
Write update example
(Shaded parts are different than before)
  • Assumes neither cache had value/location X in it
    1st
  • CPU and memory contents show value after
    processor and bus activity both completed
  • When CPU A broadcasts the write, cache in CPU B
    and memory location X are updated

44
Comparing write update/write invalidate
  • What if there are multiple writes and no
    intermediate reads to the same word?
  • With update protocol, multiple write broadcasts
    required
  • With invalidation protocol, only one invalidation
  • Writing to multiword cache blocks
  • With update protocol, each word written in a
    cache block requires a write broadcast
  • With invalidation protocol, only 1st write to any
    word needs to generate an invalidate

45
Comparing write update/write invalidate
  • What about delays between writing and reading?
  • With update protocol delay b/t writing a word on
    one processor and reading a word in another
    usually less
  • Written data is immediately updated in readers
    cache
  • With invalidation protocol, reader invalidated,
    later reads/stalls

46
See example
47
Messages vs. Shared Memory?
  • Shared Memory
  • As a programming model, shared memory is
    considered easier
  • automatic caching is good for dynamic/irregular
    problems
  • Message Passing
  • As a programming model, messages are the most
    portable
  • Right Thing for static/regular problems
  • BW , latency --, no concept of caching
  • Model implementation?
  • not necessarily...

48
More on address spaces(i.e. 1 shared memory vs.
distributed, multiple memories)
49
Communicating between nodes
  • In a shared address space
  • Data could be implicitly transferred with just a
    load or a store instruction
  • Ex. Machine X executes Load 5, 0(4). 0(4)
    actually stored in the memory of Machine Y.

50
Communicating between nodes
  • With private/multiple address spaces
  • Communication of data done by explicitly passing
    messages among processors
  • Usually based on Remote Procedure Call (RPC)
    protocol
  • Is a synchronous transfer i.e. requesting
    machine waits for a reply before continuing
  • This is OS stuff no more detail here
  • Could also have the writer initiate data
    transfers
  • Done in hopes that a node will be a soon to be
    consumer
  • Often done asynchronously sender process can
    continue right away

51
Performance metrics
  • 3 performance metrics critical for communication
  • (1) Communication bandwidth
  • Usually limited by processor, memory, and
    interconnection bandwidths
  • Not by some aspect of communication mechanism
  • Often occupancy can be a limiting factor.
  • When communication occurs, resources wi/ nodes
    are tied up or occupied prevents other
    outgoing communication
  • If occupancy incurred for each word of a message,
    sets a limit on communication bandwidth
  • (often lower than what network or memory system
    can provide)

52
Performance metrics
  • (2) Communication latency
  • Latency includes
  • Transport latency (function of interconnection
    network)
  • SW/HW overheads (from sending/receiving messages)
  • Largely determined by communication mechanism and
    its implementation
  • Latency must be hidden!!!
  • Else, processor might just spend lots of time
    waiting for messages

53
Performance metrics
  • (3) Hiding communication latency
  • Ideally we want to mask latency of waiting for
    communication, etc.
  • This might be done by overlapping communication
    with other, independent computations
  • Or maybe 2 independent messages could be sent at
    once?
  • Quantifying how well a multiprocessor
    configuration can do this is this metric
  • Often this burden is placed to some degree on the
    SW and the programmer
  • Also, this metric is heavily application dependent

54
Performance metrics
  • All of these metrics are actually affected by
    application type, data sizes, communication
    patterns, etc.

55
Advantages and disadvantages
  • Whats good about shared memory? Whats bad
    about it?
  • Whats good about message-passing? Whats bad
    about it?
  • Note message passing implies distributed memory

56
Advantages and disadvantages
  • Shared memory good
  • Compatibility with well-understood mechanisms in
    use in centralized multiprocessors used shared
    memory
  • Its easy to program
  • Especially if communication patterns are complex
  • Easier just to do a load/store operation and not
    worry about where the data might be (i.e. on
    another node with DSM)
  • But, you also take a big time performance hit
  • Smaller messages are more efficient w/shared
    memory
  • Might communicate via memory mapping instead of
    going through OS
  • (like wed have to do for a remote procedure call)

57
Advantages and disadvantages
  • Shared memory good (continued)
  • Caching can be controlled by the hardware
  • Reduces the frequency of remote communication by
    supporting automatic caching of all data
  • Message-passing good
  • The HW is lots simpler
  • Especially by comparison with a scalable
    shared-memory implementation that supports
    coherent caching of data
  • Communication is explicit
  • Forces programmers/compiler writers to think
    about it and make it efficient
  • This could be a bad thing too FYI

58
More detail on cache coherency protocols with
some examples
59
More on centralized shared memory
  • Its worth studying the various ramifications of a
    centralized shared memory machine
  • (and there are lots of them)
  • Later well look at distributed shared memory
  • When studying memory hierarchies we saw
  • cache structures can substantially reduce memory
    bandwidth demands of a processor
  • Multiple processors may be able to share the same
    memory

60
More on centralized shared memory
  • Centralized shared memory supports private/shared
    data
  • If 1 processor in a multiprocessor network
    operates on private data, caching, etc. are
    handled just as in uniprocessors
  • But if shared data is cached there can be
    multiple copies and multiple updates
  • Good b/c it reduces required memory bandwidth
    bad because we now must worry about cache
    coherence

61
Cache coherence why its a problem
  • Assumes that neither cache had value/location X
    in it 1st
  • Both a write-through cache and a write-back cache
    will encounter this problem
  • If B reads the value of X after Time 3, it will
    get 1 which is the wrong value!

62
Coherence in shared memoryprograms
  • Must have coherence and consistency
  • Memory system coherent if
  • Program order preserved (always true in
    uniprocessor)
  • Say we have a read by processor P of location X
  • Before the read processor P wrote something to
    location X
  • In the interim, no other processor has written to
    X
  • A read to X should always return the value
    written by P
  • A coherent view of memory is provided
  • 1st, processor A writes something to memory
    location X
  • Then, processor B tries to read from memory
    location X
  • Processor B should get the value written by
    processor A assuming
  • Enough time has past b/t the two events
  • No other writes to X have occurred in the interim

63
Coherence in shared memory programs (continued)
  • Memory system coherent if (continued)
  • Writes to same location are serialized
  • Two writes to the same location by any two
    processors are seen in the same order by all
    processors
  • Ex. Values of A and B are written to memory
    location X
  • Processors cant read the value of B and then
    later as A
  • If writes not serialized
  • One processor might see the write of processor P2
    to location X 1st
  • Then, it might later see a write to location X by
    processor P1
  • (P1 actually wrote X before P2)
  • Value of P1 could be maintained indefinitely even
    though it was overwritten

64
Coherence/consistency
  • Coherence and consistency are complementary
  • Coherence defines actions of reads and writes to
    same memory location
  • Consistency defines actions of reads and writes
    with regard to accesses of other memory locations
  • Assumption for the following discussion
  • Write does not complete until all processors have
    seen effect of write
  • Processor does not change order of any write with
    any other memory accesses
  • Not exactly the case for either one reallybut
    more later

65
Caches in coherent multiprocessors
  • In multiprocessors, caches at individual nodes
    help w/ performance
  • Usually by providing properties of migration
    and replication
  • Migration
  • Instead of going to centralized memory for each
    reference, data word will migrate to a cache at
    a node
  • Reduces latency
  • Replication
  • If data simultaneously read by two different
    nodes, copy is made at each node
  • Reduces access latency and contention for shared
    item
  • Supporting these require cache coherence
    protocols
  • Really, we need to keep track of shared blocks

66
Detail about snooping
67
Implementing protocols
  • Well focus on the invalidation protocol
  • And start with a generic template for
    invalidation
  • To perform an invalidate
  • Processor must acquire bus access
  • Broadcast the address to be invalidated on the
    bus
  • Processors connected to bus snoop on addresses
  • If address on bus is in processors cache, data
    invalidated
  • Serialization of accesses enforces serialization
    of writes
  • When 2 processors compete to write to the same
    location, 1 gets access to the bus 1st

68
Its not THAT easy though
  • What happens on a cache miss?
  • With a write through cache, no problem
  • Data is always in main memory
  • In shared memory machine, every cache write would
    go back to main memory bad, bad, bad for
    bandwidth!
  • What about write back caches though?
  • Much harder.
  • Most recent value of data could be in a cache
    instead of memory
  • How to handle write back caches?
  • Snoop.
  • Each processor snoops every address placed on the
    bus
  • If a processor has a dirty copy of requested
    cache block, it responds to read request, and
    memory request is cancelled

69
Specifics of snooping
  • Normal cache tags can be used
  • Existing valid bit makes it easy to invalidate
  • What about read misses?
  • Easy to handle too rely on snooping capability
  • What about writes?
  • Wed like to know if any other copies of the
    block are cached
  • If theyre NOT, we can save bus bandwidth
  • Can add extra bit of state to solve this problem
    state bit
  • Tells us if block is shared, if we must generate
    an invalidate
  • When write to a block in shared state happens,
    cache generates invalidation and marks block as
    private
  • No other invalidations sent by that processor for
    that block

70
Specifics of snooping
  • When invalidation sent, state of owners
    (processor with sole copy of cache block) cache
    block is changed from shared to unshared (or
    exclusive)
  • If another processor later requests cache block,
    state must be made shared again
  • Snooping cache also sees any misses
  • Knows when exclusive cache block has been
    requested by another processor and state should
    be made shared

71
Specifics of snooping
  • More overhead
  • Every bus transaction would have to check
    cache-addr. tags
  • Could easily overwhelm normal CPU cache accesses
  • Solutions
  • Duplicate the tags snooping/CPU accesses can go
    on in parallel
  • Employ a multi-level cache with inclusion
  • Everything in the L1 cache also in L2 snooping
    checks L2, CPU L1

72
An example protocol
  • Bus-based protocol usually implemented with a
    finite state machine controller in each node
  • Controller responds to requests from processor
    bus
  • Changes the state of the selected cache block and
    uses the bus to access data or invalidate it
  • An example protocol (which well go through an
    example of)
Write a Comment
User Comments (0)
About PowerShow.com
