Plate Tectonics

1
Plate Tectonics
2
Contents

• Plates and an introduction to plate boundaries
• Conservative Plate Boundaries
• Destructive Plate Boundaries
• Constructive Plate Boundaries
• Driving Mechanisms

3
Plates

• The Earths surface is divided up into rigid
  plates which move relative to one another
• The plate is the LITHOSPHERE, about 100 km
  thick consisting of the CRUST (oceanic or
  continental) and the UPPERMOST MANTLE.
• Plates are rigid and are conductors of heat.

4
Distribution of Plates today
5
Plate Boundaries
These are ACTIVE boundaries (across which one
plate moves relative to the other).
6
This is not a plate boundary! Its a PASSIVE
CONTINENTAL MARGIN where continental crust thins
into oceanic crust.
7
Plate Boundaries
Destructive Margins (plates converge) e.g.
Pacific Rim, Andes Constructive Margins (plates
diverge) e.g. Mid-Atlantic Ridge, East Pacific
Rise) Conservative Margins (plates slide past on
another) e.g. San Andreas Fault.
8
Conservative Plate Boundaries

• Sometimes known as TRANSFORM BOUNDARIES
• Crust is neither created nor destroyed.
• Movement is STRIKE-SLIP.

9
Slip-stick produces many earthquakes, generally
shallow and with horizontal slips
10
Case Study San Andreas Fault
11
N.American plate
Pacific Plate
