Title: Welcome to the Quebec JDF Tutorial


1
Welcome to the Quebec JDF Tutorial
2
Tutorial Session Speakers
  • Henny van Esch - Optichrome
  • Rainer Prosi - Heidelberg

3
Outline
  • Architectural Overview of JDF
  • Experience with JDF

4
JDF on One Slide
  • JDF is a Graphic Arts Job Ticket Data
    Interchange Format Specification - JDF is not an
    Application or System
  • JDF is encoded in XML
  • Content is referenced, not embedded
  • JDF is extensible
  • JDF is based on semantic structures originally
    defined by
  • Adobe PJTF
  • CIP3 PPF
  • JDF Job Definition JMF Messaging JDF
    Capabilities ICS Documents define the JDF
    Framework

5
JDF on Another Slide- Goals and Requirements -
  • Why JDF?
  • Automation increases Efficiency
  • Digital information reduces errors compared to
    paper job jackets
  • Information allows for informed decisions
  • We have a digital content workflow with a paper
    based management workflow there is room for
    improvement!
  • What does JDF enable?
  • Setup a Job in the graphic arts from the view
    point of
  • Technical Applications
  • Management Information Systems
  • Customers
  • Collect data that is relevant to a Job from
    origination to delivery
  • Business Data
  • Technical Data

6
CIP4 Reference Model
7
JDF Encoding
  • XML Encoding
  • External references via URI/URL
  • XML Schema for Data Type Definitions
  • Extensibility using XML name spaces

8
The Building Blocks of the JDF Framework
  • JDF Node
  • Description of a Process, Process Group, Gray Box
    or Product
  • JDF Resource
  • Description of a parameter set or physical entity
  • JDF ResourceLink
  • Link between JDF Nodes and Resources
  • JDF Capabilities Descriptions
  • Limitation of a JDF interface
  • JMF Messages
  • Real time data interchange format
  • ICS Documents
  • Specification of Limits of the JDF for individual
    purposes

9
The JDF Node
  • Description of a generic Process
  • The Verb in JDF
  • Do something at a given time
  • Structured container for Scheduling and Auditing
  • One JDF node type for both Products and Processes
  • Less Precise Product Intentat the Job Root Node
  • Abstract ProcessGroup Nodes or Gray Box nodes
    in between
  • Detailed individual or combined Processes in the
    Leaf Nodes

10
Product Intent vs. Process Modeling
  • Goal of Product Intent Description
  • Customers view of the thing they want to
    manufacture
  • Contract Negotiation
  • Process Independent

11
Product Intent vs. Process Modeling
  • Goal of Process Modeling
  • Interface between MIS and Production
  • Process interdependencies
  • Manufacturing Instruction Details

12
Gray Boxes
  • Incomplete Model of a Process
  • The MIS View of the process
  • Its only important if it affects the cost!
  • Thus, parameters not affecting costs are not
    important
  • Exact Process execution is potentially undefined
  • Ordering of steps is not necessarily predefined
  • Detailed Work Steps may be left out
  • E.g. MIS knows RIPping, but not Trapping or
    ColorSpaceConversion

13
Audit Objects
  • Logging of Job Execution
  • Actual times
  • Start time
  • End time
  • Job Phases
  • Logging of Changes
  • Resources
  • used 85g Paper instead of 80g
  • Used Roll inventory 123, not 456
  • Consumables
  • Actual Amounts produced or consumed
  • Status Summary
  • Event Log

14
Job / Customer Information
  • CustomerInfo
  • Map Subcontracting via Localized Customer
    Information in any JDF Node
  • Customer ID
  • Addresses (Delivery, Invoice, )
  • NodeInfo
  • Scheduling
  • Deadlines
  • Processing Time Estimation

15
JDF Node simple Example
  • ltJDF IDN1" Type"Product" JobID"HDM1"
    JobPartIDp1 StatusWaiting" Version1.3"gt
  • ltResourcePoolgt
  • ltNodeInfo Class"Parameter"
    StatusAvailable ID"Link0001" /gt
  • ltSomeInputResource ID"Link0002"
    Class"Parameter" StatusAvailable"/gt
  • ltComponent ID"Link0003" Class"Quantity"
    StatusUnavailable" DescriptiveName"SomeOutputRe
    source"/gt
  • lt/ResourcePoolgt
  • ltResourceLinkPoolgt
  • ltNodeInfoLink rRef"Link0001" UsageInput"/gt
  • ltSomeInputResourceLink rRef"Link0002"
    UsageInput"/gt
  • ltComponentLink rRef"Link0003"
    UsageOutput"/gt
  • lt/ResourceLinkPoolgt
  • ltAuditPool/gt
  • lt/JDFgt

16
The JDF Node Node Type
  • Individual process types and their respective
    resources are defined e.g.
  • Interpreting
  • Trapping
  • ConventionalPrinting
  • DigitalPrinting
  • Cutting
  • Folding
  • Verification
  • Delivery

17
Combination of JDF Nodes
  • Dont recreate a new Process Type for
    Permutations of known Processes!
  • Create combinations of multiple defined processes
    into one process, e.g.
  • online finishing printing folding cutting
  • in-RIP trapping trapping RIPping
  • Three types of Combination Nodes
  • Combined Node All internal interfaces are hidden
  • Smart multi-function device
  • ProcessGroup Internal nodes are accessible
  • Without Sub elements (Gray Box)
  • MIS view
  • With Sub elements
  • Workflow group in a department
  • Subcontract

18
Combined vs. ProcessGroup
  • Combined Node orGray Box

Combined Node
Res
Res
Res1
Res2
  • ProcessGroup

ProcessGroup
Res
Res
Res1
Res2
19
JDF Resources
  • Specification of Parameters of
  • Product Intent description
  • Logical Entities, e.g RIP Parameters, Imposition
    setup
  • Physical Entities, e.g. Media, Devices, Plates
  • Based on Adobe PJTF and CIP3 PPF
  • Intent Resources for product intent nodes
  • Prepress Adobe PJTF
  • Press, Finishing CIP3 PPF
  • Internal to JDF or External Links to well-defined
    Formats
  • Thumbnails, Preview Files, ICC Profiles, Content
    Data

20
JDF RunList Resource Simple Example
  • ltRunList ID"Link0003" Class"Parameter"
    StatusAvailable PartIDKeysRungt
  • ltRunList Run1 Pages"0 10"gt
  • ltLayoutElement ElementType"document"gt
  • ltFileSpec URLFile///File1.pdf
    MimeType"application/PDF"/gt
  • lt/LayoutElementgt
  • lt/RunListgt
  • ltRunList Run2 Pages2 -1"gt
  • ltLayoutElement ElementType"document"gt
  • ltFileSpec URLFile///File2.pdf
    MimeType"application/PDF"/gt
  • lt/LayoutElementgt
  • lt/RunListgt
  • lt/RunListgt

21
JDF Resources - Intent Resources
  • Parameters are not attributes but rather
    structured Span Elements with the following
    attributes
  • Range list of allowed values
  • Names
  • Numbers
  • Ranges of Numbers / Strings
  • OfferRange list of proposed values
  • Preferred one preferred value
  • Actual The selected value from Range or
    Preferred

22
JDF Resources - Details
  • Special handling of multiple Parts, e.g.
  • Sheets
  • Separations
  • Waste
  • Tiles
  • Versions
  • Redo one part of a large resource
  • Only the yellow plate of the front surface of
    sheet 17
  • Parallel processing of partitioned resources
  • Selection of devices / operators

23
JDF Resources - Partitioning
  • One Resource may specify multiple entities
  • Multiple Partition type levels, e.g. Sheet,
    Side, Separation
  • Inheritance model
  • specify common attributes once
  • Overwrite individual attributes / elements
  • Select individual or multiple parts with a
    ResourceLink

24
Partitioning and Nodes
Partitioned Resources with matching partition
keys are connected.
25
Partitioned Ink Resource Example
  • ltInk IDInkID" BrandProcessBrand"
    Class"Consumable" StatusAvailable"
    MediaType"Coated" PartIDKeys"Separation"gt
  • ltInk Separation"Cyan"gt
  • ltColor CMYK"1 0 0 0"/gt
  • lt/Inkgt
  • ltInk Separation"Magenta"gt
  • ltColor CMYK"0 1 0 0"/gt
  • lt/Inkgt
  • ltInk Separation"Yellow"gt
  • ltColor CMYK"0 0 1 0"/gt
  • lt/Inkgt
  • ltInk Separation"Black"gt
  • ltColor CMYK"0 0 0 1"/gt
  • lt/Inkgt
  • ltInk BrandSpotBrand" Separation"Heidelberg
    Spot Blau"gt
  • ltColor CMYK"0.7 0.7 0.3 0.7"
    ColorantUsage"spot"/gt
  • lt/Inkgt
  • lt/Inkgt

26
ResourceLink
  • Bind a Resource to a Node
  • Define Resource Usage (input or output)
  • Link to a Subset / Part of a Resource
  • E.g. Cyan Plate of the Front of Sheet 1
  • Define the Amount
  • Allow reuse of Resources by multiple processes
  • One resource may be linkedby multiple
    ResourceLinks
  • Links define the process network

27
ResourceRef
  • Used to reference a Resource from within another
    JDF Element
  • May contain one Part element to select individual
    partition
  • Equivalent to an inline occurence of the
    referenced resource
  • Name mangling ResourceRef

28
JDF RunList Resource Simple Example with
ResourceRef
  • ltRunList ID"Link0003" Class"Parameter"
    StatusAvailable PartIDKeysRungt
  • ltRunList Run1 Pages"0 10"gt
  • ltLayoutElementRef rRefL1gt
  • lt/RunListgt
  • ltRunList Run2 Pages12 -1"gt
  • ltLayoutElement ElementType"document"gt
  • ltFileSpec URLFile///File2.pdf
    MimeType"application/PDF"/gt
  • lt/LayoutElementgt
  • lt/RunListgt
  • lt/RunListgt
  • ltLayoutElement IDL1 ElementType"document
    Class"Parameter" StatusAvailablegt
  • ltFileSpec URLFile///File1.pdf
    MimeType"application/PDF"/gt
  • lt/LayoutElementgt

The ResourceRef
Inline Resource
The Referenced Resource
29
ConventionalPrinting JDF Node Example
ConventionalPrinting
ExposedMedia (Plate)
  • NodeInfo
  • Planned StartTime
  • Planned EndTime

Media
AuditPool Actual Resource Usage Actual Time
Summary
Ink
InkZoneProfile
Resource Links
Component (including amount)
Parameters Layout (Control Marks)
30
The JDF Node Execution Requirements
  • A Node is executable when all required input
    resources are available
  • Serial Processing -- Standard
  • Parallel Processing -- Partial Resources
  • Overlapping Processing -- Pipes
  • Iterative Processing -- Draft Resources
  • Node dependencies allow process configuration
  • A proof node can create an Approval which is
    needed for the press node to operate

31
Node Executability
Resource ResourceLink JDF Node
Not Available
Not Executable
Available
Resource Links
Available
32
Node Executability
Resource ResourceLink JDF Node
Available
Executable
Available
Resource Links
Available
33
Node ExecutabilityAnd Networks
Waiting
Available
Not Available
Links
Not Executable
Available
Links
Available
Available
Not Available
34
Node ExecutabilityAnd Networks
Running
Available
Not Available
Links
Not Executable
Links
Available
Available
Available
Available
35
Node ExecutabilityAnd Networks
Completed
Available
Available
Links
Executable
Available
Links
Available
Available
Available
36
Job Description Models supported by JDF I
  • Product Definition
  • No Process
  • Customer view
  • Segmentation by Product Components
  • Serial Processing

RIP
Print
Bind
37
Job Description Models supported by JDF II
  • Parallel Processing
  • Overlapping Processing

Fold
Bind
Print
Fold
38
Job Description Models supported by JDF III
  • Iterative Processing
  • Informal Iterative Processing using Draft
    Resources
  • Formal Iterative Processing using JMF Messages

Edit
Proof
Layout
39
JDF Tree / Network Structure
40
JDF - Spawning and Merging
  • Spawn individual nodes of the JDF Tree for
    independent processing
  • Parallel Processing
  • Subcontracting
  • Support for Partitioning e.g. only sheet 1
  • Merge back after processing
  • Retain information source Context
  • Audits
  • Modified Resources

41
Spawning Merging
Master JDF
Executable Sub-JDF 1
Executable Sub-JDF 2
Step 1 - Prior to Spawning
42
Spawning Merging
Master JDF
Executable Sub-JDF 1
Locked Sub-JDF 2
Step 2 - Spawned, Prior to Execution
Spawned Executable Sub-JDF
43
Spawning Merging
Master JDF
Executable Sub-JDF 1
Locked Sub-JDF 2
Step 3 - Spawned, After independent Execution Pr
ior to merging
Spawned completed Sub-JDF
44
Spawning Merging
Master JDF
Executable Sub-JDF 1
Merged Sub-JDF 2
Step 4 - After Execution After Merging
45
JMF Messaging
  • Real-time data interchange format
  • Small XML structures
  • JDF is referenced via URL, not bound into message
  • Idea is to minimize network traffic and delay
    transmission of data until it is actually needed
  • Send potentially interesting information as soon
    as it is available

46
JMF Messaging
  • Used for
  • Snapshots of Job / Device status
  • Dynamic job update
  • Job submission and Queue/QueueEntry handling
  • Capabilities discovery
  • Plug Play bootstrapping (Future)
  • Generally used within an Intranet

47
JMF Message Families
  • JMF messages fall into six categories
  • Command
  • Receiver is instructed to take an action, or to
    modify the state of something
  • Query
  • Receiver is instructed to return information
    about something. No action is taken, no states
    are changed
  • Response
  • Used to immediately return result of command or
    query
  • Synchronous messaging command/query and
    response are exchanged on same open connection

48
JMF Message Families
  • JMF message categories (contd)
  • Acknowledge
  • Used to return the result of a command after some
    time has passed
  • Asynchronous messaging empty response returned
    immediately on same connection as command with
    indication that Acknowledgement will be sent
    later
  • Signal
  • Used to send notifications of events or change in
    status
  • Typically result of a query with a subscription
    embedded in it
  • Subscription sets up persistent channel
  • Registration
  • Request for commands
  • Used to set up triangular workflows
  • E.g. MIS tells prepress to send a Command to Press

49
Example SubmitQueueEntry message
  • ltJMF DeviceID"SP013" SenderID"MIS1TimeStamp"2
    006-05-05T123248-0600"gt
  • ltCommand ID"m3829" Type"SubmitQueueEntry"gt
  • ltQueueSubmissionParams URL"http//jobserv
    er/getJob?job10047"
  • ReturnJMF"http//jobserver/jmfservice"
  • Priority"50"/gt
  • lt/Commandgt
  • lt/JMFgt

50
JMF Message Types
  • Examples of JMF message that fall within the six
    categories
  • Command
  • SubmitQueueEntry, AbortQueueEntry,
    ReturnQueueEntry, HoldQueue, ResumeQueue
  • Query
  • KnownControllers, KnownDevices, Status
  • Response
  • Various related to various commands/queries
  • Acknowledgement
  • Various related to various commands/queries
  • Signal
  • Status, Resource, Occupation
  • Registration
  • Resource

51
JDF Capabilities Ahead
  • Interoperability
  • Capabilities
  • Workflow
  • PPDs and Schemas
  • Capabilities Theory
  • Capabilities Overview

52
Its all about Interoperability !!!
If you dont know about capabilities, you wont
be able to interoperate
53
Its all about Interoperability!!
But if you do, you can use the right tools
54
What are Capabilities?
  • Capabilities allow actors in the workflow to
    determine what some other actor can do...

55
What are Capabilities?
Of course, theres no requirement that any of the
actors actually be people
56
Who are the actors?
  • Job submission utilities (both to a print shop
    and within the print shop)
  • Print shops
  • MIS systems
  • Prepress workflow managers
  • Applications
  • Individual pieces of equipment
  • Operators of offline equipment
  • And the list goes on

57
What can Capabilities be used For?
  • Determining what products a print shop could
    produce.
  • Allows the creation of JDF Intent (product
    descriptions).
  • Determining what equipment is available in a
    shop.
  • Allows MIS systems to take JDF Intent and
    determine production steps to produce job.
  • Creating a UI to allow configuration of job
    processing for a piece of equipment or
    application.
  • Preflighting a JDF before processing by a JDF
    consumer.

58
An example workflow
RIP
Color Adjust
Prepress Workflow Controller
Trap
Impose
59
An example workflow
RIP
Color Adjust
Ask for capabilities
Prepress Workflow Controller
Trap
Impose
60
An example workflow
Capabilities File
RIP
Color Adjust
Prepress Workflow Controller
Trap
Impose
61
An example workflow
RIP
Color Adjust
Prepress Workflow Controller
Trap
Impose
62
An example workflow
RIP
Color Adjust
The JDFPDF
Prepress Workflow Controller
Trap
Impose
63
Official Warning
Details Ahead!!
64
What about PPDs and Schemas?
  • PPDs (PostScript Printer Driver)
  • Provide basic capabilities information about a
    printer
  • Allow printer options to be configured by
    specifying PostScript snippets
  • Provide a simple constraints mechanism for UI
  • Allow controls to be localized (but typically
    just for the advanced dialog)

65
What about PPDs and Schemas?
  • Schemas
  • Describe the aggregated capabilities of JDF
    (processes resources)
  • Do not support constraints definitions
  • Do not support localizations
  • Do not allow a device to specify a subset of the
    aggregated capabilities

66
So what are Capabilities?
  • XML-based
  • Of course
  • The capabilities description directly reflects
    the structure of the JDF itself.
  • Constrains a device implementation against the
    schema
  • Either the JDF schema or an extension schema
  • Does not require the schema to be used to work

67
But that's not all !!!
68
Capabilities Theory
  • JDF defines a Capabilities Model based on....
  • A Device is the Thing that executes one or more
    JDF Nodes
  • A JDF Node is defined by its resources resource
    links
  • e.g. A Press has a set of allowed Media and a
    set of press parameters

69
Capabilities Theory
  • JDF Parameters are either.....
  • independent of one another, or
  • can be expressed as a list of allowed independent
    sets
  • e.g. a Scanner can scan at 1000 dpi grayscale, or
    500 dpi color
  • May be further constrained by logical boolean
    expressions
  • The Device can print Duplex
  • The Device can print Transparencies
  • Setting Duplex and Transparency at the same time
    is constrained

70
Capabilities Theory
  • Performance may be specified
  • Maximum Average
  • Depending on further Job parameters
  • Allow specification of current and persistent
    capabilities
  • Define defaults and (un)/supported features
  • JMF messages for plug and play in heterogeneous
    environments
  • Specify Localization

71
Device Parameter Space
Area covered by device capabilities

Restriction to 3 dimensions for display purposes
only
72
Capabilities Overview
  • Feature Macros (JDF 1.2)
  • Allows a set of multiple JDF controls to be
    represented by a single abstract control in a
    user interface.
  • ScannerQuality (draft, good, best)
  • sets resolution, color mode,

73
Capabilities Overview
  • Localizations (JDF 1.2)
  • Feature names and individual values can be
    localized (even true and false)
  • Also used with constraints to provide localized
    descriptions (for UI) of the error described when
    the constraint test fails

74
Capabilities Overview
  • Feature Availability (JDF 1.2)
  • The feature is installed on the device and is
    available for use.
  • The feature has not been installed on the device.
  • The feature has been installed on the device, but
    may not be used until licensed.
  • The feature is installed and licensed on the
    device, but has been disabled.

75
Capabilities Overview
  • UI Hints (JDF 1.2)
  • Feature grouping
  • Unit type
  • Angle, length, weight,
  • Whether a feature should be displayed
  • The feature should be displayed.
  • The feature should not be displayed.
  • The feature should be displayed only for
    administrators.
  • The feature should be conditionally displayed.
  • The feature should be displayed only in vendor
    support situations.
  • Icons to represent the device

76
Capabilities Overview
  • JMF (Job Messaging Format) capabilities
  • Which JMF messages are supported
  • Specifics for each message
  • JMF Bootstrapping for Device Discovery

77
Capabilities Overview
  • Performance Data
  • Minimum/Maximum/Average setup time
  • Minimum/Maximum/Average cleanup time
  • Average/Worst case run rate

78
Capabilities Link the Workflow Together !
79
PrintTalk www.printtalk.org
  • JDF describes the product to be produced
  • PrintTalk describes the business context of the
    product
  • Request For Quote
  • Quotation
  • Purchase Order
  • Invoice
  • Change Order
  • PrintTalk also contains Pricing Information

80
CIP4 Open Source Development Tools
  • XML Schema
  • C API
  • Java API
  • JDF Editor
  • Visualise JDF JMF
  • Send Messages
  • Update or Validate JDF JMF
  • Elk Project
  • Reference Device
  • Alces Project
  • Reference Manager
  • CheckJDF JDF Validator web service
  • FixJDF - JDF update web service

81
History of JDF
  • 1999 Adobe, Agfa, MAN and Heidelberg form the
    GAT initiative with the goal of defining a job
    ticket for the Graphic Arts that also integrates
    MIS.
  • 2000 The CIP3 Consortium takes ownership of the
    standard.
  • 2001 JDF 1.0 is released.
  • 2002 JDF 1.1 is released.
  • Ambiguities/Bugs found in implementation were
    removed
  • Additional Processes were added
  • Consistency between diverse areas was enhanced
  • 2004 JDF 1.2 is released
  • More additional processes
  • Even more mature and consistent
  • 2005 First set of ICS documents are published
  • JDF 1.3 is released

82
Experience with JDF - Advantages
  • Single grammar for specifying job data in the
    graphic arts industry
  • Integration of Production, Customer and MIS
  • Multiple views for Production, Customer and MIS
  • Definition of production networks
  • Combined Processes
  • Defined communication protocol, not only data
    structures
  • Extensible Model
  • Interaction with other Standards in GA

83
Experience with JDF - Challenges / Obstacles
  • Number of processes in the graphic arts
  • Creative
  • Prepress
  • Press
  • Finishing
  • Fulfillment
  • Complexity of the standard
  • Size of the Specification
  • Moving from the Abstract Idea to a Concrete
    Implementation
  • Flexibility of the Specification
  • Unclear Role of Production networks in
    Interfacing with Devices
  • private extensions
  • Definition of abstract coordinate systems
  • Legacy System Longevity

84
Why ICS ?
JDF A ICS JDF B
Product A
Product B
InteroperabilityConformanceSpecifications
85
Interoperability Conformance Specifications
  • Define a set of Interoperability Conformance
    Specifications ICS
  • The term JDF Compliant does not immediately
    imply that two arbitrary applications will
    communicate.
  • Sending RIP instructions to a Folding Machine is
    not useful
  • Two applications that comply with a given ICS
    will communicate in a meaningful way.
  • Product Certification will be based on ICS
    Compliance
  • Avoid multiple, incompatible JDF Dialects

86
ICS Document Structure
87
ICS documents
  • Provide the basis for certification
  • Ensure that products MUST read / write / accept
    certain conditions
  • Interoperability between applications
  • Limited functionality in the initial ICS versions
  • Additional functionality is optional but not
    certifiable
  • Multiple levels
  • More functionality will be added in future ICS
    versions

88
Read Write Conformance
  • JDF Specification Describes the valid
    cardinality of parameters in a JDF or JMF
    instance
  • ICS Specifies conformance requirements for an
    application or device
  • W Must write. The application only conforms, if
    it always writes the parameter
  • W? May Write. Not a Conformance requirement
  • W? Conditional write conformance. External
    conditions exist the require an application to
    write.
  • !W Must NOT write. The application does not
    conform, if it writes the parameter.
  • R Must read. The Information must be parsed and
    appropriately processed
  • R? May Read. Not a Conformance requirement

89
JDF Tutorial
Thank you very much for your attention!
Write a Comment
User Comments (0)
About PowerShow.com
