Prof. Ray Larson

1
Lecture 12 Database Design
SIMS 202 Information Organization and Retrieval

• Prof. Ray Larson Prof. Marc Davis
• UC Berkeley SIMS
• Tuesday and Thursday 1030 am - 1200 pm
• Fall 2003
• http//www.sims.berkeley.edu/academics/courses/is2
  02/f03/

2
Lecture Overview

• Review
• Databases and Database Design
• Database Life Cycle
• ER Diagrams
• Database Design
• Normalization
• Discussion Questions

3
Lecture Overview

• Review
• Databases and Database Design
• Database Life Cycle
• ER Diagrams
• Database Design
• Normalization
• Discussion Questions

4
Models (1)
5
Database System Life Cycle
6
Another View of the Life Cycle
Integration 4
Operations 5
Design 1
Physical Creation 2
Conversion 3
Growth, Change 6
7
Database Design Process
8
Entity

• An Entity is an object in the real world (or even
  imaginary worlds) about which we want or need to
  maintain information
• Persons (e.g. customers in a business,
  employees, authors)
• Things (e.g. purchase orders, meetings, parts,
  companies)

Employee
9
Attributes

• Attributes are the significant properties or
  characteristics of an entity that help identify
  it and provide the information needed to interact
  with it or use it (This is the Metadata for the
  entities)

10
Relationships

• Relationships are the associations between
  entities
• They can involve one or more entities and belong
  to particular relationship types
• One to One
• One to Many
• Many to Many

11
Relationships
12
Types of Relationships

• Concerned only with cardinality of relationship

1
1
n
1
n
m
Chen ER notation
13
More Complex Relationships
1/1/1
1/n/n
n/n/1
SSN
Project
Date
1
4(2-10)
Manages
1
Is Managed By
n
14
Weak Entities

• Owe existence entirely to another entity

15
Supertype and Subtype Entities
16
Many to Many Relationships
Employee
17
Lecture Overview

• Review
• Databases and Database Design
• Database Life Cycle
• ER Diagrams
• Database Design
• Normalization
• Discussion Questions

18
Database Design Process
19
Database Design Process
Application 1
Application 2
Application 3
Application 4
External Model
External Model
External Model
External Model
Application 1
Conceptual requirements
Application 2
Conceptual Model
Logical Model
Conceptual requirements
Internal Model
Application 3
Conceptual requirements
Application 4
Conceptual requirements
20
Requirements Analysis

• Conceptual Requirements
• Systems Analysis Process
• Examine all of the information sources used in
  existing applications
• Identify the characteristics of each data element
• Numeric
• Text
• Date/time
• Etc.
• Examine the tasks carried out using the
  information
• Examine results or reports created using the
  information

21
Database Design Process
Application 1
Application 2
Application 3
Application 4
External Model
External Model
External Model
External Model
Application 1
Conceptual requirements
Application 2
Conceptual Model
Logical Model
Conceptual requirements
Internal Model
Application 3
Conceptual requirements
Application 4
Conceptual requirements
22
Conceptual Design

• Conceptual Model
• Merge the collective needs of all applications
• Determine what Entities are being used
• Some object about which information is to
  maintained
• What are the Attributes of those entities?
• Properties or characteristics of the entity
• What attributes uniquely identify the entity
• What are the Relationships between entities
• How the entities interact with each other?

23
Developing a Conceptual Model

• Overall view of the database that integrates all
  the needed information discovered during the
  requirements analysis
• Elements of the Conceptual Model are represented
  by diagrams, Entity-Relationship or ER Diagrams,
  that show the meanings and relationships of those
  elements independent of any particular database
  systems or implementation details
• Can also be represented using other modeling
  tools (such as UML)

24
Database Design Process
Application 1
Application 2
Application 3
Application 4
External Model
External Model
External Model
External Model
Application 1
Conceptual requirements
Application 2
Conceptual Model
Logical Model
Conceptual requirements
Internal Model
Application 3
Conceptual requirements
Application 4
Conceptual requirements
25
Logical Design

• Logical Model
• How is each entity and relationship represented
  in the Data Model of the DBMS
• Hierarchic?
• Network?
• Relational?
• Object-Oriented?

26
Database Design Process
Application 1
Application 2
Application 3
Application 4
External Model
External Model
External Model
External Model
Application 1
Conceptual requirements
Application 2
Conceptual Model
Logical Model
Conceptual requirements
Internal Model
Application 3
Conceptual requirements
Application 4
Conceptual requirements
27
Physical Design

• Internal Model
• Choices of index file structure
• Choices of data storage formats
• Choices of disk layout

28
Database Design Process
Application 1
Application 2
Application 3
Application 4
External Model
External Model
External Model
External Model
Application 1
Conceptual requirements
Application 2
Conceptual Model
Logical Model
Conceptual requirements
Internal Model
Application 3
Conceptual requirements
Application 4
Conceptual requirements
29
Database Application Design

• External Model
• User views of the integrated database
• Making the old (or updated) applications work
  with the new database design

30
Terms and Concepts

• Key
• An attribute or set of attributes used to
  identify or locate records in a file
• Primary Key
• An attribute or set of attributes that uniquely
  identifies each record in a file
• Candidate Key
• An attribute or set of attributes that might be
  used as a primary key

31
Lecture Overview

• Review
• Databases and Database Design
• Database Life Cycle
• ER Diagrams
• Database Design
• Normalization
• Discussion Questions

32
Normalization

• Normalization theory is based on the observation
  that relations with certain properties are more
  effective in inserting, updating and deleting
  data than other sets of relations containing the
  same data
• Normalization is a multi-step process beginning
  with an unnormalized relation

33
Normal Forms

• First Normal Form (1NF)
• Second Normal Form (2NF)
• Third Normal Form (3NF)
• Boyce-Codd Normal Form (BCNF)
• Fourth Normal Form (4NF)
• Fifth Normal Form (5NF)

34
Normalization
35
Unnormalized Relations

• First step in normalization is to convert the
  data into a two-dimensional table
• In unnormalized relations data can repeat within
  a column
• (The following is a highly contrived example that
  actually bears only a slight resemblance to the
  current implementation of the Phone/Photo project
  database)

36
Unnormalized Relations
37
First Normal Form

• To move to First Normal Form a relation must
  contain only atomic values at each row and column
• No repeating groups
• A column or set of columns is called a Candidate
  Key when its values can uniquely identify the row
  in the relation

38
First Normal Form
39
1NF Storage Anomalies

• Insertion A new person has not yet taken a
  picture -- hence no Picture -- Since Picture
  is part of the key we cant insert
• Insertion If People is are known and likely to
  be photographed, but havent been yet -- there is
  be no way to include that person in the database
• Update If a Person changes status (e.g. Mary
  Jones becomes a Student) we have to change
  multiple rows in the database
• Deletion (type 1) Deleting a Person record may
  also delete all info about People in the pictures
• Deletion (type 2) When there are functional
  dependencies (like Object and Object_features)
  changing one item eliminates other information

40
Second Normal Form

• A relation is said to be in Second Normal Form
  when every nonkey attribute is fully functionally
  dependent on the primary key
• That is, every nonkey attribute needs the full
  primary key for unique identification

41
Second Normal Form
Person Table
42
Second Normal Form
People Table
43
Second Normal Form
Picture Table
44
1NF Storage Anomalies Removed

• Insertion Can now enter new Persons who havent
  yet taken pictures
• Insertion Can now enter People who havent been
  photographed
• Deletion (type 1) If Charles Brown withdraws his
  photos the corresponding tuples from Person and
  Picture tables can be deleted without losing
  information on David Rosen
• Update If John White takes a third picture, and
  has changed status (e.g., graduate), we only need
  to change the Person table in one place

45
2NF Storage Anomalies

• Insertion Cannot enter the fact that a
  particular object has a particular feature unless
  it is associated with a particular picture
• Deletion If John White describes some other
  object that Beth Little has while shopping, we
  lose the fact that the bookbag is blue
• Update If the features of an object change
  change we have to update multiple occurrences of
  object features

46
Third Normal Form

• A relation is said to be in Third Normal Form if
  there are no transitive functional dependencies
  between nonkey attributes
• When one nonkey attribute can be determined with
  one or more nonkey attributes there is said to be
  a transitive functional dependency
• The Obect_Feature column in the Picture table is
  determined by the Object
• Object_Feature is transitively functionally
  dependent on Object so Picture is not 3NF

47
Third Normal Form
Picture Table
48
Third Normal Form
Object Table
49
2NF Storage Anomalies Removed

• Insertion We can now enter the fact that an
  object has a particular feature
• Deletion If John White describes some other
  object that Beth Little has while shopping, we
  dont lose the fact that the bookbag is blue
• Update The features for each object appear only
  once

50
Boyce-Codd Normal Form

• Most 3NF relations are also BCNF relations
• A 3NF relation is NOT in BCNF if
• Candidate keys in the relation are composite keys
  (they are not single attributes)
• There is more than one candidate key in the
  relation, and
• The keys are not disjoint, that is, some
  attributes in the keys are common

51
Most 3NF Relations Are Also BCNF Is This One?
52
BCNF Relations
53
Additional Issues

• Why separate Person and People?
• They are really all People/Persons in different
  roles
• Shouldnt a picture have a unique ID regardless
  of Who is in it?
• Cant we have multiple people in the same
  picture, multiple objects, etc.?
• Cant objects have multiple characteristics?

54
BCNF Relations
55
BCNF Added Capabilities

• Can now have a picture with no (identified)
  people in it
• Can have multiple objects, activities, and people
  associated with each picture

56
Fourth Normal Form

• Any relation is in Fourth Normal Form if it is
  BCNF and any multivalued dependencies are trivial
• Eliminate non-trivial multivalued dependencies by
  projecting into simpler tables

57
Fifth Normal Form

• A relation is in 5NF if every join dependency in
  the relation is implied by the keys of the
  relation
• Implies that relations that have been decomposed
  in previous NF can be recombined via natural
  joins to recreate the original relation

58
Fifth Normal Form Relations
People Table
59
Normalizing to Death

• Normalization splits database information across
  multiple tables
• To retrieve complete information from a
  normalized database, the JOIN operation must be
  used
• JOIN tends to be expensive in terms of processing
  time, and very large joins are very expensive

60
Lecture Overview

• Review
• Databases and Database Design
• Database Life Cycle
• ER Diagrams
• Database Design
• Normalization
• Discussion Questions

61
Questions Brooke Maury

• Discussion Questions on Hoffer McFadden
• If the goal of the relational database model is
  to encode a conceptual design into a logical
  design, is it possible that improved technology
  and the development of new modeling techniques
  will supplant the RDBMS? Specifically, what
  impact will XML and the development of document
  engineering have on organizing information in
  multiple normalized tables?
• Conversely, what does the relational model have
  that would be lost if a conceptual design was
  encoded in another model?

62
Questions Brooke Maury

• The drive to develop the RDBM was in part
  motivated by a need to minimize the space
  required and improve the performance of database
  systems by removing redundancies. What impact
  will very inexpensive data storage and computing
  power have on the relational database model and
  the third normal form especially?

63
Questions Shane Ahern

• Discussion Questions for "Logical Database Design
  and the Relational Model"
• Is the normalization process described really
  necessary? When I design a database schema, I
  find that by thinking of tables in terms of they
  entities they represent (employees, sales,
  events), I avoid most of the problems of
  normalization that the process seeks to address
  (i.e. salesperson and region in Sales table,
  salesperson is clearly a distinct entity from
  sales). If the formal process described in the
  article is not followed, are there potential
  pitfalls that might lead to problems with your
  database schema?

64
Questions Shane Ahern

• The article points out that "the relational model
  does not yet directly support supertype/subtype
  relationships." Once the tables in a relational
  database have been decomposed to third normal
  form, the database is efficient from systems
  point-of-view, but the tables no longer represent
  a representation of the data that is intuitive to
  humans. The object-oriented model more accurately
  mirrors the way we think about the concepts that
  we wish to store in databases. So perhaps
  object-oriented database systems are worth
  considering. What about XML databases?

65
Questions Arthur Law

• The three models that we have been presented
  with, Entity Relationship Model, NIAM Model, and
  Object Oriented Model all enforce a specific
  thought process in the organization and
  relationship between items in a database. With
  all of our recent discussion of computers
  understanding natural language are these methods
  now out of date with how we should be organizing
  information? Should we use artificial
  intelligence or learning algorithms to
  statistically determine the relationship between
  entities or is there still value in using these
  models?

66
Questions Arthur Law

• Each model is approximately one decade apart in
  development and a quick Google search shows that
  companies are using databases with one of the
  three models. However, as new models arise there
  doesn't seem too much interest in migrating from
  one data model to another. Which makes sense
  given that an organization using a given model
  probably finds that it works. Now with the
  proliferation of XML, we see more information
  being shared between organizations, so are we
  fated for an expensive and lengthy translation
  process between databases? Or should all DB
  administrators be responsible for upgrading to
  the latest model?

67
Lecture Overview

• Review
• Databases and Database Design
• Database Life Cycle
• ER Diagrams
• Database Design
• Normalization
• Discussion Questions
• Next Time/Readings

68
Next Time

• Guest Lecture Bob Glushko on XML and Document
  Engineering
• Readings on Class website
• No assigned discussion questions (but bring your
  questions on the readings)
