Data Security Issues in the Cellular Revolution- Discretix View

1
Data Security Issues in the Cellular Revolution-
Discretix View

• July 6th, 2005
• Aharon Aharon - Chairman of the Board

2
Agenda

• Corporate overview
• Product offering
• Market trends and strategy
• Summary

3
Objectives

• Cellular data security whats all about
• Get familiar with the buzzwords
• Understand possible solutions and their
  complexity
• Check your travel habits
• Have some fun

4
Belize a former British Colony, Central America
Similar size to Israel, 270,000 people Jungles,
Rain Forests, Beaches, Islands

• Picture 1

5
Discretix at a Glance

• US Headquarters Fully-owned subsidiary in
  Israel
• Focus on robust security in low resource
  environments
• Strongly financed by tier-one VCs

Founded 2000
ProductPortfolio

• Secure Mobile and Secure Flash
• Hardware, Firmware, Infrastructure Software,
  Device Toolkits
• Built upon strong intellectual property (15
  patents)

6
Discretix Traction
Baseband Application Processor / Flash
Customers
Partners
SecuritySpecialist
7
Discretix Customers Worldwide Devices
Penetration (handsets and flash cards)

• Application Processor
• SonyEricssonSmartphones soldglobally

• Baseband (2G,2.5G, 3G)
• 50 of Samsungmobile (GSM)
• China, Korea andEurope OEMs

• Embeddedmemeory
• 40 of globalembedded flashmarket

• Baseband(GSM, EDGE,WCDMA)
• Sold globally(Sony EricssonSharp,
  TLC,Amoi,Bellwave, Flextronics,HTC, Lite-On)

• ApplicationProcessor andBaseband
• 50 of Samsungmobile (GSM)
• European andAsian OEMs

• Application Processorand Baseband
• Japan dominance(50 of NTT DoCoMoFOMA, strong
  in PDC)
• Very strong in Asia
• Tier-one Europeand US OEMs

• Flash storage cardssold globally
• All cards formFactors
• Used by key OEMsand retail stores(handsetmanufa
  cturers,carriers. SIs)

In 2006 over 33 of handsets will include
Discretix inside
8

• Guatemala Tikal

• Picture 2

9
Growing Threats
Handset malfunctioning
Malicious messaging(SMS/MMS/Java)
Theft and Fraud
Viruses
Bluesnarfing
Denial of Service
Spam

• Costly consequences
• Handset replacements
• Device downtime airtime lost
• Legal settlements

Network malfunctioning
10
Its time for Security!

• Security is an essential building blockfor any
  application
• Enables revenue generating applications
• Prevents revenue leakage
• Safeguards against attacks
• Reduces operational expenses

We chose the EMP U100 platform for it's
security, and small size. Masafumi Matsumoto,
Group GM, Sharp Corporation
11

• Barcelona - Gaudi

• Picture 3

12
Mobile Client Security Needs
Digital RightsManagement(DRM)
FirmwareOver The AirUpdate
Phone SIM LockProtection
Device Security
DeviceManagement
Commerce Payment
Firewall,VPN
EnterprisesMobility
Anti-Virus Anti-Spam
13
Standards Committees Mapping
Carriers
DRM
Applications Schemes
Industry Bodies
Device Mgmt
Industry Bodies
CMLA Warner Brothers, mm02, Intel, Nokia,
Matsushita, Samsung, Real Networks
DRM
Commerce/Banking
Vodafone Orange, TelefonicaT-Mobile
Hardware
14

• Costa Rica - Arenal

• Picture 4

15
DRM Market Projections

• Schemes
• Current OMA
• Emerging Windows Media, CPRM
• Future DVB-H/T, FairPlay
• Digital Tech Consulting (DTC)
• Some 300 Million Mobile DRM Phones Will Ship in
  09, license revenues from DRM technologies will
  likely surpass 500 million by 2009.
• Juniper Research projections for 2009
• Mobile music market 9.3B
• Mobile gaming market 19.3B
• Mobile Video market - 5B

16
Phone (IMEI) SIM Lock Protection

• Vodafone (Tim Wright)
• Vodafone Group is loosing Euro 150m per year due
  to device theft problems. Most OEMs fail to
  implement robust security.
• Vodafone formal requirements
• Device shall support reprogramming protection,
  SIM Lock and IMEI protection that are of
  equivalent strength to that provided by
  appropriate use of hardware security modules.

17
Simple IMEI and SimLock Crack
18
Commerce Payment

• Mobile phone based services are rapidly expanding
• Phone embedded security provides smart card
  equivalent security at a lower cost
• Contactless technology driven
• Leading services
• Felica (Japan)
• E-commerce, Transportation, ID authentication
• Moneta (Korea)
• E-commerce, e-money, m-Banking
• paypass (US)
• E-commerce

19
Anti-Virus

• The problem is growing faster than expected
• Known viruses to date
• Symbian Cabir, Skulls, Metal Gear, SEXXXY.sis,
  Gavno.a
• WinCE Duts.A, Brador
• Palm source Phage.Dropper

20
Device Management

• From OMA DM Specification
• Every session MUST employ robust end-to-end
  security between the client and the DM server,
  including mutual authentication and data
  encryption, either by using an adequate transport
  layer mechanism or by implementing application
  level security.
• Provisioning, storage and maintenance of the
  credentials on servers and on devices SHALL be
  done securely.
• OTAFF priorities
• Maintaining Mobile Device Integrity
• FOTA Security

21

• Costa Rica - Arenal

• Picture 5

22
Security Stakeholders
23
Operators Security Requirements
OMA DRM music service
OMA DRM music pilots
Phone theft protection
Over The Air updates
Mobile commerce
IPSec for VoIP
Security cannot be added as a magic dust it
must be part of the phone infrastructure
24
Possible Security Solutions

• Client security can be
• Software only
• Combined software and hardware

Don't trust magic security words like "256-bit
AES. The devil is in the details, and it's easy
to screw up security. Bruce Schneier, Oct 04
25
Device Security Trends
26
Why Hardware-based Security

• Extremely hard to create Root of Trust in
  software
• Real key protection can be done only in hardware
• Software countermeasures have limited
  capabilities
• Software hacks are easily distributed
• Protect the device most vulnerable assets the
  firmware and its credential (keys)

Security

• User experience is key
• Off loads CPU and Bus to handle applications
• Improves power consumption
• Software overhead cannot enable robust and
  secure boot verifications

Resources Performance
27

• Athens Acropolis

• Picture 6

28
CryptoCell Modular Configuration
SecureStorage
DeviceMgmt.
DRMAgent
IMEI SIM LockProtection
IPSec(VPN)
Java STIPSecurity
SecureBoot
Security Middleware Layer - CRYS Firmware
Hardware Crypto Engines
Software Crypto Engines
Root of Trust Secret CryptoKey, RNG, Secure Boot
29
CryptoCell Security Building Blocks
DeviceToolkits
SecureStorage
IMEI SIM LockProtection
Device Management
Middleware
SSL / TLSWTLS
WIMToken
CertificateHandling
IPsec(VPN)
KeyManagement
CRYS API
PKCS 11
Symbian CryptAlg
MS CAPI
OpenSSL
Countermeasures
OS Abstraction Layer
Context Management and Input Alignment
Hardware Abstraction Layer
HW Blocks
PKI Engine RSA, ECC, DSS, DH
Symmetric Engine3DES, AES, RC4, C2
Hash Engine SHA-1/2, MD5, HMAC
DigitalRNG
Secret CryptoKey
Integrity Validation
AttackResistant
30

• Rome Coliseum

• Picture 7

31
Market Trends Strategy
32
Handset Sales

• 684M handsets sold in 2004
• Increase of about 30 from 2003
• Strong replacement sales inmature markets
• Rapid uptake in emerging markets
• Motorola, Sony-Ericsson LG increased market
  share atthe expense of Nokia, Siemens and
  Samsung
• Chinese, Taiwanese OEMs, ODMs

33
Handsets and Memory Trends

• Handsets are driving growth in removable and
  embedded memory
• Over 60 of the phones sold in Europe by 2008
  will have a slot for a memory expansion card
• By 2008 typical 3G phone will have 128MB of
  embedded storage, typical 2.5G phone - 64MB
• More than 10 of handsets will include HDDs of
  4GB (sub 1.8)
• Most handsets will support multiple DRM systems
  for music, video and other content

34
Our Vision
Content Security
Application Security
Infrastructure Security
Infrastructure Security
Cryptography
2002
2003
2004
2005
2006
35

• Cambodia Angkor

• Picture 8

36
Alliances Strategy - 1
DeviceHardware
EmbeddedSoftware
DeliveryMethods
Charging
Content
Carrier gradeback-end
End-to-end Security
Client
Server

• Value chain requires end-to-end solutions
• Robust security is the cornerstone of any
  application
• DRM
• Protected Storage
• Device Management and Over-The-Air updating

37
Alliance Strategy - 2

• Jointly sell Device Toolkits
• Even on competing hardware
• Technical alliances
• Intimacy with open and real time Operating
  Systems
• Standards Committees
• Act as security advisers
• Carriers
• Assist in security needs definition

38
Summary

• Minimal BOM
• Highest performance
• Shortest time-to-market

Superior Security with
Security across the entire value chain

• Hardware
• Firmware
• Infrastructure software
• Device toolkits

Complete Solution

• Field proven
• Certified
• Implemented in multiple environments

39

• Vietnam Sapa

• Picture 9

40
Thank you for your attention!

• www.Discretix.com
