Encoding formal systems, logics and calculi in CTT

1
Encoding formal systems, logics and calculi in CTT
FORMALWARE Engineering CISM Udine (Italy),
September 24-28, 2001

• Furio Honsell
• Professor of Foundations of Informatics
• Università di Udine, Italyhonsell_at_dimi.uniud.it

2
The protocols

• 3 paradigms for encoding formal systems, program
  logics and calculi in Logical Frameworks (LF),
  based on Constructive Type Theory
• Higher Order Abstract Syntax (HOAS)
• Higher Order Natural Deduction
• Theory of Contexts (stemming from an axiomatic
  viewpoint)

3
Examples

• FOL
• Hoares Logic
• l-calculus
• p-calculus
• Pick your choice

4
Logical Frameworks

• Use higher order (co-inductive) type theories
• i.e. higher order, dependent typed l-calculus
• as specification languages for representing
• Syntax
• h.o. (co)inductive dependent types
• Operational semantics Inferentail machinery
• Proof Theory
• h.o. (impredicative) type of propositions
• of formal/logical systems
• provide a setting for formal development of the
  METATHEORY of formal logics and calculi
• possibly using suitable non-logical axioms

5
Higher order recursive types

• We want to capitalize on (co)-inductive types for

• syntax datatypes
• Proof theory predicates
• Higher order(impredicative) quantification on
  propositions is probably enough for defining
  (co)-inductively predicates (Relation induction)
• We need precise correspondence statements between
  objects and encodings
• Adequacy Theorems

6
General computational paradigm

• judgements as types
• hypothetical jdg. as h.o.types
• general jdg. As h.o.types
• proofs as l-terms
• object systems as signatures

7
Basic encoding principles I

• Syntactic categories of the object logic are
  represented by (inductive) sets
• Judgements of the object logics are rendered as
  predicates over the sets
• Rules and axioms are encoded as constructors for
  the predicates

8
Basic encoding principles II

• A metalanguage variable of type A plays the role
  of a generic object of type A
• hence
• a metalanguage object of type i?o plays the role
  of a context of type o over i
• HIGHER ORDER ABSTRACT SYNTAX (HOAS)
• (Church,Martin- Löf, Plotkin,
  Honsell,Miculan,)
• this allows for 2 imporant techniques
• HIGHER ORDER NATURAL DEDUCTION
• (Gentzen, Martin-Löf, Shröder-Heister,)

9
Higher Order Abstract Syntax

• Provides algebraic account of context sensitive
  features of languages which manipulate
• variables
• names
• Identifiers
• All the above are conflated to metalanguage
  variables
• Languages with binders, restriction operators,
  new name operators, assignment are treated on a
  par with languages with only ?variable, name,
  identifier?-free expressions

10
HOAS (cntd.)

• Schemata (contexts) are represented as higher
  order objects
• Substitution/instantiation is encoded by
  breduction
• hence HOAS sets a standard for
• a-conversion
• capture avoiding substitution
• both are delegated to the metalanguage

11
Higher Order Natural Deduction

• The Consequence relation connecting hypotheses to
  conclusions in an object logical system is
  modeled by the arrow type constructor of the
  metalanguage types structural rules such as
• weakening
• contraction
• substitutivity
• are inherited from the metalanguage

12
Further features

• Both at syntax and judgement level one can
• DELEGATE to the FRAMEWORK the mechanisms for
  keeping track of scope dependencies,
• DISTRIBUTE over the FRAMEWORK context object
  system (run-time) data structures which behave
  according to a stack discipline e.g. environments

13
The Calculus of Inductive Constructions CIC

• Notation
• E (environments) sequence of constants with type
• G (context) sequence of variables with type
• Two mutually defined judgements
• WF(EG)G is a well-formed context in the
  environment E
• EG- MTM has type T in the context E and
  environment G

14
The Calculus of Inductive Constructions

• CIC is a conservative extension of lC.
• Sorts SSet,Prop,Type(i), i integer
• Set is the type of specifications, i.e. terms
  with a computational content programs, datatypes
  such as booleans, naturals, lists etc.
• Prop is the type of logical propositions. A term
  m belonging to M witnesses the fact that M is
  true.
• Set,PropType(0) and Type(i)Type(i1).
• Indexes are dropped from the user point of view
  PropType and TypeType.

15
CIC some rules

• EG - T s1     EG(xT) - U
  s2s1ÎProp, Set or  s2ÎProp, Set
• EG - (xT)U s2
• EG - (xT)U s     EG(xT) - t U
• EG - xTt (xT)U
• EG - t (xU)T    EG - u U
• EG - (t u) Tx/u
• EG - t T   c Ï EÈ G
• WF(EDef(G)(ctT))G

Prod
Abs
App
Def
16
Coq LanguagesGallina and the Vernacular

• Specification language Gallina
• representation of l-terms of CIC with structured
  data types, recursive functions, inductive
  predicates,
• Command language the Vernacular
• Definitions of terms, parameters, functions,
  predicates, axioms, rules, lemmata
• Interactive proof development (tactics)
• State management (loading of libraries, reset)

17
Some Gallina

• Abstraction
• lxA.t is noted xAt
• Application
• (M N) is noted (M N)
• Universal quantification
• PxA.B is noted (xA)B
• When x does not occur (free) in B, it can be also
  written as A-gtB

18
More Gallina

• Definition by case analysis
• ltAgtCases M of p1 gt t1 pn gt tnend
• Recursive and corecursive terms, possibly mutual
• Fix F F A MCoFix F F A M
• Only well-typed terms are accepted.The
  conditions in the typing rules ensure soundness
  of the system

19
Inductive Definitions

• Inductive Sets (datatypes) (possibly mutual).
• Inductive nat Set O nat S nat -gt
  nat.
• Elimination schemata (induction and recursion
  principles) are automatically generated and
  proved.
• Nat_ind (Pnat-gtProp)(P O)-gt((nnat)(P n)-gt(P
  (S n)))-gt(nnat)(P n)

20
Mutual Inductive definitions

• CIC allows for mutual inductive definitions
• Mutual Inductive tree  Set  node  forest -gt tr
  ee
• with forest  Set emptyf  forestconsf  tree
   -gt forest -gt forest.
• In order to preserve soundness of CIC, not all
  inductive definitions are allowed. E.g., the
  following is not allowedInductive D Set
  (D-gtD)-gtD.

21
Destructing inductive objects by case analysis

• A term inhabiting an inductive type can be used
  for defining terms in other types, by so-called
  case analysis. E.g.
• Definition iszero nat-gtProp nnatCases n
  of O gt True (S m) gt Falseend.
• Then, (iszero O) i-reduces to True.

22
Destructing inductive objects by fixed point

• Objects of inductive types are built by fixpoint
  definitions. E.g., for the inductive set
• Inductive listn Set nil listn cons nat
  -gt listn -gt listn.lgth  Fix lgth  lgth l(l
  istn)  nat      Cases l of       nil gt O
      (cons _ l') gt (S (lgth l'))     end
   listn-gtnat

23
Logical connectives

• All logical connectives but forall and
  implication are defined as inductive predicates.
  EgInductive and AProp BProp Prop
  conj A-gtB-gt(and A B).From the induction
  principles one obtains the logical rules of the
  connective
• Also the constant False is inductiveInductive
  False Prop .The case analysis yields the
  usual absurdity rule QProp
  pFalseltQgt(Case p of end) Q

24
Coinductive Types (1)

• Objects inhabiting coinductive types may be non
  well-founded. Canonical exampleCoInductive
  Stream cons nat -gt Stream -gt Stream.
• Inductive principles do not hold anymore
• Definition of coinductive objects by giving a
  (non-ending) method of constructionCoFixpoint
  zeros Stream (cons O
  zeros).represents (O,O,O,O,)

25
Coinductive Types (2)

• Destruction Only by case analysisCases s of
  (cons n s) gt end.
• Coinductive objects are unfolded only when appear
  as the argument of a Cases
• For instanceDefinition hd Stream -gt A
  xStream Cases x of (cons a _) gt a
  end.Definition tl Stream -gt Stream
  xStream Cases x of (cons _ y) gt y end.

26
Coinductive Types (3)

• Not all coinductive definitions are allowed, in
  order to avoid non converging terms
• Guardedness condition In CoFixpoint definitions,
  any recursive call in the definition must be
  protected i.e, be an argument of some
  constructor
• Some non valid definitionsCoFixpoint foo
  Stream foo.CoFixpoint bar Stream Case
  bar of (cons x s) gt s end.

27
Coinductive Types (4)

• Also proofs can be non well-founded objects
  (coinductive proofs). Most typical proofs are
  bisimulation proofs.
• This allows for reasoning over processes,
  protocols and evolving systems
• Coinductive features of Coq have been used for
  verifications of protocols (ABP), processes (CCS,
  p-calculus),
• Still, the issue is not completely satisfactory
  (guardedness condition is too strong)

28
Induction Principles and Recursion

• Any inductive type induces a Recursor and an
  Induction Principle over it for Pnat ?Prop.
• The general type of a Recursor,
• NatrecPPnat ? Set.
• (P0)?(Pnnat.P (n) ? P(S(n)) ?
  ?(Pnnat.P (n))
• is the induction principle (over Set)

29
(Co)inductively defined predicates (relations)

• Relation induction is essentially built in the
  higher-order impredicative definition
• T (A ?A?Prop) ? (A ?A?Prop)
• m R.T(R) (x)
• ?P (A ?A?Prop). (TP? P)?P(x)
• n R.T(R) (x)
• ?P (A ?A?Prop). (P? TP)P(x)

30
Representing binding operators

• How to represent binding operators (e.g, the l of
  l-calculus)?
• First-order syntax (explicit names)
• Lam var -gt term -gt term.
• High representation overhead one must deal
  with a-equivalence, capture-avoiding
  substitution, generation of fresh names,

31
Representing binding operators

• Higher Order Abstract Syntax
• App term -gt term -gt term
• Lam (term -gt term) -gt term
• lx.t is represented by (Lam xtermt)
• Variables of the language variables of the
  metalanguage
• Bound variable bound variable
• a-equivalent terms have automagically the same
  representation!

32
Representing binding operators

• Capture avoiding substitution can be obtained for
  free from the metalanguage
• eval term -gt term -gt Prop
• Beta (Mterm-gtterm)(Nterm)(eval (App (Lam M)
  N) (M N))
• Very low overhead no need to worry about
  explicit variables, substitutions, a-equivalence

33
Using Coq as a LF for specifing First Order Logic
(1)

• Two syntactic sorts
• Inductive i Set zero i one isum
  i -gt i -gt i.
• Inductive o Set equ i -gt i -gt oimp i
  -gt i -gt iforall (i -gt o) -gt i.
• One judgement (truth or derivability)Paramete
  r T o -gt Prop.

34
Using Coq as a LF for specifing First Order Logic
(2)

• Four rules for deriving the judgement
• Axiom impI (A,Bo)((T A) -gt (T B)) -gt (T (imp
  A B)).
• Axiom impE (A,Bo)(T A) -gt (T (imp A B)) -gt (T
  B).
• Axiom forallI (Ai-gto)((xi)(T (A x)))-gt(T
  (forall A)).
• Axiom forallE (Ai-gto)(ti)(T (forall A)) -gt
  (T (A t)).

35
HOAS and Inductive Types

• HOAS cannot be directly used in Coq in
  combination with inductive definitions
• Inductive L Set App L -gt L -gt L Lam
  (L -gt L) -gt L.
• is not accepted by CIC typing rules, due to the
  occurrence of L in negative position
• Shall we lose either HOAS or induction principles?

36
HOAS and Inductive Typesdelegating only
a-equivalence

• HOAS with a separate set of (unstructured)
  objects, variables (names)
• Parameter var Set.
• Inductive L Set
• Var var -gt L App L -gt L -gt L Lam
  (var -gt L) -gt L.
• lx.t is represented by Lam xvart
• delegates only a-equivalence and substitution of
  names for names

37
HOAS and Inductive Types delegating only
a-equivalence

• Substitution (of terms for variables) is no more
  delegated to the metalanguage
• Inductive subst NL (var-gtL)-gtL subst_Var
  (subst N Var N)subst_void(yvar)(subst N
  _vary y) subst_App subst_Lam
  (Mvar-gtvar-gtL)(Nvar-gtL) ((yvar)(subst (M y)
  (N y))) -gt (subst xvar(Lam yvar(M y x))
  (Lam N)).

38
HOAS and Inductive TypesExotic Terms

• Var can be declared as an inductive set.
• Substitution and properties over contexts derive
  from induction and recursion principles
• But we get exotic terms terms which do not
  correspond to any object language term
• Definition var nat.Definition weird Lam
  xvar(Case x of O gt (Var O) (S n) gt (App
  (Var n) (Var n)) end).

39
HOAS and Inductive TypesRuling out Exotic Terms

• Exotic term are dangerous when reasoning over the
  object logic (e.g., by structural induction on
  the terms)
• They can be ruled out by extra judgements of
  well-formedness
• Valid L -gt Prop.
• Innatural encoding (extra judgement everywhere)
  and higher overhead on the user

40
HOAS and Inductive TypesAvoiding Exotic Terms

• Our proposal we can leave Var unspecified
• Parameter Var Set.
• No more exotic terms!
• BUT No more metalogical properties over context,
  either!
• Solution add only those axioms we need for
  dealing with names and contexts, and prove
  separately their soundness

41
HOAS and Inductive TypesA Theory of Contexts

• Inductively define the predicate
• notin var -gt L -gt Prop
• Three axioms (schemata) to add
• Unsat (tL)(Ex xvar(notin x t))
• Expan (tL)(xvar)(Ex svar-gtL
  (t(s x))/\(notin x s)))
• Ext (t1,t2L)(xvar)(notin x t1) -gt (notin x
  t2) -gt(t1 x)(t2 x) -gt t1t2.

42
HOAS and Inductive TypesA Theory of Contexts

• These axioms are quite expressive we have used
  them for metareasoning over many logics and
  calculi for concurrent and mobile systems
• p-calculus
• l-calculus
• First Order Logic
• Spi-calculus
• Soundness of the axioms has been proved recently
  by building a model of presheaves.

43
Nominal algebras

• A names set is an infinite set of different
  atomic objects with a decidible equality
• A nominal algebra N is a triple (V, I, C) where
• V is a finite set of names sets
• I is a set of basic types
• C is a set of constructors, which are typed
  constants ca where a is a constructor arity a
  type of the form t1??tn ? i, where n?0 and for i
  1 n, the type ti is either in V or it is of
  the form u1??um ? i. (Notice that only types
  of names may occur in negative position).If m
  ?0, then c is said to be a binding constructor,
  or simply a binder.

44
Nominal algebras examples

• Untyped l-calculus Nl (u, L, varu?L,
  appL?L?L, lam(u?L)?L)
• p-calculus Np (u, i, 0i, i?i?i, ti?i,
  u?u?i?i, n(u?i)?i, inu?(u?L)?L, outu?u?i?i)
• Also FOL, ambient calculus, n-calculus, CCS,
  simply typed l-calculus,
• But languages with polyadic binders escape the
  class of nominal algebras.

45
Encoding p-calculus I

• Parameter nameSet
• Inductive Proc Set
• nil proc
• tau proc
• nu (name?proc)?proc
• In name?(name?proc)?proc
• Out name?name?proc?proc
• Mutual Inductive
• ftrans proc?f_act?proc?Prop
• btrans proc?b_act?(name?proc)?Prop

46
Encoding p-calculus II

• Suitable constructors for the judgement ftrans
• fRES (p1,p2name?proc)(af_act)(LNlist)
• ((yname)(notin y (nu p1nu p2))?
• (Nlist_notin y L)?(f_act_notin y a)?
• (ftrans (p1 y) a (p2 y)))
• ? (ftrans (nu p1) a (nu p2))
• etc.

47
Developing the metatheory of p-calculus

• Using the theory of contexts the development of
  the metatheory of p-calculus in
  Milner,Parrow,Walker 1992, was formally derived
  in Honsell,Miculan,Scagnetto2001
• E.g. Lemma 6
• (p,qname?Proc)(zname)(notin z (nu p nu q))?
• (Stbisim (p z) (q z))?
• (wname)(notin w (nu p nu q))?
• (Stbisim (p w) (q w))
