Chapter 53
Clutch Fundamentals
3
Contents

• Clutch principles
• Clutch construction

4
Automotive Clutch

• Used to connect and disconnect the engine and
  manual transmission or transaxle
• Allows the driver to control power flow between
  the engine and transmission or transaxle

5
Drive Trains
Front-WheelDrive Vehicle
Rear-WheelDrive Vehicle
6
Clutch Principles

• Vehicles with manual transmissions require a
  clutch
• Power flow from one unit to another can be
  controlled with a drive disc and a driven disc

7
Clutch Theory
Clutch is disengaged

• Clutch is engaged

8
Simplified Clutch
9
Basic Clutch Parts
10
Clutch Action (Disengaged)

• When driver presses the clutch pedal, clutch
  release mechanism pulls or pushes on the clutch
  fork
• Fork moves the release bearing into the center of
  the pressure plate
• Pressure plate face pulls away from the clutch
  disc
• Clutch disc and transmission input do not turn

11
Clutch Action (Disengaged)
12
Clutch Action (Engaged)

• When driver releases the clutch pedal, spring
  pressure inside the pressure plate pushes forward
  on the clutch disc
• This locks the flywheel, disc, pressure plate,
  and transmission input together
• Engine rotates the transmission input

13
Clutch Action (Engaged)
14
Clutch Construction

• Components
• pilot bearing
• flywheel
• clutch disc
• pressure plate
• release bearing
• clutch housing (bell housing)
• clutch release mechanisms
• clutch start switch

15
Pilot Bearing

• Pressed into the end of the crankshaft
• Supports the end of the transmission input shaft
• Made of a solid bronze bushing, roller or ball
  bearing
• Prevents the transmission shaft and clutch disc
  from wobbling when the clutch is released

16
Flywheel

• A mounting place for the clutch
• The pressure plate bolts to the flywheel face
• Flywheel face is precision machined to a smooth
  surface, where it contacts the clutch disc
• Normally made of iron for good wear and heat
  dissipation

17
Clutch Disc

• Consists of a splined metal hub and a round metal
  plate covered with friction material (lining)
• Splined to the transmission input shaft
• Disc is free to slide back and forth on the shaft

18
Clutch Disc
19
Clutch Disc Torsion Springs

• Help absorb some of the vibration and shock
  produced by clutch engagement
• Small coil springs located between the clutch
  disc hub and the friction disc

20
Clutch Disc Facing Springs

• Flat, metal springs located under the discs
  friction material
• Springs have a light wave (curve)
• allow the friction material to flex inward
  slightly during clutch engagement
• flexing smoothes engagement

21
Clutch Disc Friction Material

• Made of heat-resistant substances
• Grooves cut in the material aid cooling
• Rivets are commonly used to bond the friction
  material to both sides of the metal body of the
  disc

22
Pressure Plate

• Spring loaded device
• Locks or unlocks the clutch disc and the flywheel
• Clutch disc fits between the flywheel and
  pressure plate
• Two basic types
• coil spring
• diaphragm spring

23
Coil SpringPressure Plate
24
Components

• Small coil springs
• clamp clutch disc between face and flywheel
• Face
• large ring that contacts the clutch disc
• Release levers
• allow the release bearing to move the face
• hinged inside the pressure plate

25
Centrifugal Action

• Semi-centrifugal pressure plate uses weighted
  release levers or rollers to increase clamping
  pressure on the clutch disc
• As speed increases, their outward thrust acts on
  the release levers
• Extra force keeps the clutch from slipping, and
  allows the use of lighter springs, reducing pedal
  effort

26
Diaphragm Spring Pressure Plate

• Uses a single diaphragm spring instead of several
  coil springs
• Diaphragm spring is a large, round disc of spring
  steel which rides on a pivot ring part way in
  from the outer edge
• Pushing in on the center of the spring bends the
  outer edge away from the engine, releasing the
  clutch disc

27
Diaphragm Spring Pressure Plate
28
Release Bearing

• Usually a ball bearing and collar assembly that
  reduces friction between the pressure plate
  levers and the clutch fork
• A few imported vehicles use a graphite bearing
• ring shaped block of graphite presses on a
  smooth, flat plate on the clutch release levers

29
Release Bearing
30
Clutch (Bell) Housing

• Bolts to the rear of the engine
• Encloses the clutch assembly
• Made of aluminum, magnesium, or cast iron
• Transmission bolts to the back of the clutch
  housing

31
Clutch Assembly

• Diaphragm clutch with a hydraulicrelease
  mechanism

32
Hydraulic Clutch Release Mechanism

• Uses a simple hydraulic circuit to transfer
  clutch pedal action to the clutch fork
• Components
• clutch cylinder
• hydraulic line
• slave cylinder

33
Clutch Cylinder

• Produces hydraulic pressure for the system
• Mounted to the firewall or cowl
• Push rod links the clutch pedal and the cylinder
  piston
• Most systems use brake fluid

34
Clutch Cylinder
35
Slave Cylinder

• Uses hydraulic pressure to cause clutch fork
  movement

36
Clutch Linkage Mechanism

• Uses levers and rods to transfer motion from the
  clutch pedal to the clutch fork
• A bellcrank may be used to reverse the movement
  of the clutch pedal
• A release rod transfers motion to the fork and
  allows adjustment

37
Clutch Linkage Mechanism
38
Clutch Cable Mechanism

• Uses a steel cable inside a flexible housing to
  transfer pedal movement to the clutch fork
• One end usually has a threaded sleeve for clutch
  adjustment

39
Clutch Cable Mechanism
40
Automatic Clutch Adjuster

• Removes play from the clutch cable as components
  wear
• Pedal has a quadrant and pawl device
• Spring inside applies light tension on the cable
  to take up extra slack
• If there is too much play when the clutch is
  released, the pawl will ratchet over the quadrant
  teeth, taking up slack

41
Automatic Clutch Adjuster
42
Clutch Start Switch

• Prevents the engine from cranking unless the
  clutch pedal is depressed
• Safety device that keeps the engine from starting
  while in gear
• Usually mounted on the clutch pedal
• May control current from the ignition switch to
  the starter solenoid or may be an input to the
  engine computer

43
Clutch Installation

• Rear wheel drive transmission

44
Clutch Installation

• Front wheel drive transaxle
