GOES Product Applications

1
GOES Product Applications

• Jaime Daniels
• NESDIS/ORA/Forecast Products Development Team
• Camp Springs, Maryland
• Gary Gray
• Raytheon Information Technology and Scientific
  Services
• Lanham, Maryland

2
Topics

• Issues important for the effective utilization of
  satellite products
• Conclusions from the 1999 NWS Field Assessment of
  GOES sounder products
• Operational GOES Products at NESDIS
• Experimental Products Under Development
• Challenges Current Future

3
Issues Important for the Effective Utilization of
Satellite Products

• Timeliness
• Accuracy
• Coverage
• Horizontal, vertical, temporal
• Information content
• Format and/or Presentation

4
Conclusions from 1999 NWS Field Assessment of
GOES Sounder Products

• Purpose Assess the operational value of GOES
  sounder products to the NWS Forecast and
  Warning Program
• Conducted July 19 August 30, 1999

• Heightened the forecasters situational awareness
  to potential watch/warnings scenarios
• Led to the issuance of improved forecast products
  in over 79 of all active weather situations
• GOES sounder products especially useful for
• Locating maximum instability atmospheric
  moisture axes prior to convective development
• Observing temporal changes in stability
  moisture
• Judging the validity of NWP forecasts

5
Operational GOES Products at NESDIS
GOES Product Inst Res Coverage Freq Format Delivery Users/Use
Temp sounding Moisture sounding Clear-sky radiances Stability Indices Skin temp S 50km CONUS Adj. Ocean Hourly BUFR DPI AWIPS FTP NCEP NWP NWS/ WFOs Forecasting NESDIS/SAB Sat precip estimation
Cloud-top pressure Cloud-top temp Effective cloud amt S 10km CONUS Adj. Ocean Hourly BUFR DPI AWIPS FTP NCEP NWP NWS/ WFOs Forecasting NESDIS/SAB Sat precip estimation
ASOS-SCP S/I 50km ASOS sites over CONUS, Puerto Rico Hawaii Hourly Text GTS NWS State Wx roundups
Cloud-drift winds Water Vapor motion winds I IR 60km WV 60km VZ 30km NHEM SHEM 8x/day BUFR AWIPS GTS NCEP NWP NWS/ WFOs Forecasting NCEP TPC
Cloud-drift winds Water Vapor motion winds S WV 70km NHEM SHEM 8x/day BUFR AWIPS GTS NCEP NWP NWS/ WFOs Forecasting NCEP TPC
6
GOES Products Distributed Over AWIPSSignificant
milestone for NOAA!!

• All NOAA/NWS offices now or will soon have
  digital access to several GOES products and
  sounder imagery
• NWS field forecasters can use these data in their
  daily forecast preparations
• AWIPS workstations allow forecasters to easily
  integrate GOES wind products with other data
  sources (model output, ACARS, rawinsondes, etc)

AWIPS Build/Deploy Date Product 5.2.2 October
2002 Soundings (BUFR) OB1 April
2003 GOES-12 data/products OB2 July
2003 Satwinds (BUFR) OB3 Feb 2004 Sounder
imagery OB5 Feb 2005 Sounder DPI Cloud amount

7
TPW
Lifted Index
Skin Temperature
Operational GOES Sounder DPI Products prepared
for AWIPS
http//www.ssd.noaa.gov/PS/PCPN/pcpn-na.html
8
Experimental Products

• Full resolution GOES sounder retrievals
• Cloud-drift Water Vapor Motion Winds
• GOES MODIS

9
Full Resolution GOES Sounder Retrieval System

• Funded GOES Product Systems Development and
  Implementation (PSDI) task (ORA/CIMSS/OSDPD)
• Operational implementation (late 2004 or early
  2005)
• Pixel level retrievals
• Integration of temp/moisture retrieval, cloud
  retrieval (includes ASOS SCP), and DPI product
  processing systems
• More consistency amongst products (ie., cloud
  determination)
• Improved resolution (horiz, vertical, temporal)
  of first guess (model) data

10
(No Transcript)
11
GOES Sounder Retrieval Products Experimental
SFOV Products

• Experimental production and validation at FPDT
  CIMSS (point image)
• Increased horizontal coverage offers exciting
  possibilities for enhanced use of product in
  mesoscale forecasting
• Improved depiction of gradients in retrieved
  products (PW, LI, etc)
• Focus attention to localized areas of interest
  (instability)

12
Single FOV soundings (10km resolution) offer
significantly improved coverage. Derived SFOV
quantities, such as atmospheric stability, can be
plotted over imagery or can be placed in image
format and used by NWS for severe storm
forecasting
13
GOES SOUNDER CONVECTIVE AVAILABLE POTENTIAL
ENERGY (CAPE) INDEX
3x3 FOV
5x5 FOV
1x1 FOV
Derived Product Image of CAPE from single FOV
retrievals
14
GOES SOUNDER TOTAL PRECIPITABLE WATER
5x5 FOV
3x3 FOV
1x1 FOV
Derived Product Image of TPW from single FOV
retrievals
15
GOES SOUNDER LIFTED INDEX
5x5 FOV
3x3 FOV
Derived Product Image of Lifted Index from single
FOV retrievals
1x1 FOV
16
GOES-12 Total Precipitable Water DPI
Operational product (5x5)
Experimental product (1x1)
17
Clear/Cloudy Designation
18
Tightened several cloud-clearing tests to produce
significantly improved histogram
19
VALUE ADDED THERMODYNAMIC DIAGRAMS SHOWING GOES
VERTICAL TEMPERATURE AND MOISTURE PROFILES
DERIVED FROM GOES SOUNDER
Generated at hundreds of sites across US every
hour Used extensively by NWS field forecasters
for severe weather forecasting Product can be
looped over a 24 hour period to show trends of
atmospheric stability
STABLE
UNSTABLE
http//orbit-net.nesdis.noaa.gov/goes/soundings/sk
ewt/html/skewloop.html
20
Experimental Watch Area SFOV Sounder Products

• Use NWS FOS text product to find severe Wx watch
  boxes define corner points
• Subsect sounder image about watch area(s)
• Quickly generate SFOV sounder GOES products
  (stability) and disseminate ASAP
• Reduced latency
• Potential for improved utility in field

21
GOES Sounder Retrieval Products Experimental
SFOV Products

• The IHOP Experience

22
GOES Sounder SFOV Retrieval Products for the
International H20 Project (IHOP) 2002
May 13 June 25, 2002

• Product latency
• Key factor for increasing the utility of the
  sounder products
• IHOP offered us an opportunity to demonstrate
  these products could be produced with reduced
  latency
• SFOV product processing requires significantly
  more processing
• stream-lined software
• software ported to new H/W
• FPDT successfully delivered GOES-8 GOES-11 SFOV
  PW and cloud products to FSL for use in the Local
  Analysis Prediction System (LAPS)

( HH56)
( HH102)
IHOP SFOV Products available to FSL at HH24
38-min latency from start time of sounder scan
to time product is available
23
GOES Sounder TPW SFOV Product Accuracy
24
GOES Sounder TPW SFOV Product Accuracy
25
GOES Sounder TPW SFOV Product Accuracy
26
GOES Sounder TPW SFOV Product Accuracy
27
May 29 Sept 16, 2002
28
GOES-8 TPW vs. Raob
May 29 Sept 16, 2002
29
May 29 Sept 16, 2002
30
GOES-10 TPW vs. Raob
May 29 Sept 16, 2002
31
Considerations for Full Resolution GOES Sounder
Products

• Calibration
• Detector-to-detector differences
• Product timeliness
• Data volumes
• Product quality

32
Experimental Products

• Cloud-drift water vapor motion winds
• Hourly production over CONUS and PACUS sectors
  using highest temporal frequency imagery
  available (15-min or 7.5-min)
• MODIS cloud-drift and water vapor motion winds

33
(No Transcript)
34
Rapid Scan Winds Lower Troposphere 25 Feb 2001
35
GOES-10 Rapid-Scan IR Cloud-Drift Winds during
PACJET
36
High-resolution RUC forecasts for
PACJET Real-time NWS guidance and retrospective
data impact tests Steve Weygandt1, Stan
Benjamin1, Chris Velden2 Jason Burks3, and
Louisa Nance4,5 1NOAA/Forecast Systems
Laboratory, Boulder, CO 2CIMSS, University of
Wisconsin, Madison, WI 3NOAA/National Weather
Service Western Region, Salt lake City,
UT 4NOAA/Environmental Technology Laboratory,
Boulder, CO 5CIRES, University of Colorado,
Boulder, CO
The remainder of the presentation will on
focus initial results from the retrospective test
designed to quantify the forecast impact from the
special rapid-scan satellite winds. In this
test, two parallel sets of 1-h cycled RUC
forecasts were produced for a meteorologically
active period. The first experiment utilized all
conventional observations (rawinsonde, 404 and
915 MHz profiler, RASS, VAD, ACARS, and surface
reports), while the second experiment,
supplemented the conventional observations with
the rapid-scan satellite winds. Initial
results from the retrospective test indicate that
inclusion of the rapid-scan satellite wind
observations improved short-range (0-12 h) wind
predictions by up to 10 for this case.
(Excerpt from Abstract Submitted to USWRP 4th
Science Symposium)
37
TERRA/MODIS Cloud-Drift Winds
MODIS band 31 (11 mm)
38
TERRA/MODIS Water Vapor Channel (One Day of
Arctic Orbits)
MODIS band 27 (6.7 mm)
39
GOES Satellite Wind Product Validation
http//orbit-net.nesdis.noaa.gov/goes/winds/html/t
series.html
40
GOES Satellite Wind Product Validation
http//orbit-net.nesdis.noaa.gov/goes/winds/html/t
series.html
41
GOES Satellite Wind Product Validation
42
GOES Satellite Wind Product Validation
43
GOES Satellite Wind Product Validation
44
Challenges Current Future

• Need to reduce product latency
• Streamlined product processing
• Faster scanning strategies adaptable scanning
  strategies
• Improved product quality control monitoring to
  assure the reliability of high quality products
• Getting experimental satellite products into the
  hands of NWS forecasters
• AWIPS
• Other ways (ie., internet etc.)

45
Challenges Current Future (contd)

• Data fusion, new display capabilities
  forecaster tools
• Derived Product Imagery (DPIs) information will
  become increasingly important
• Expansion of applications
• Pre-convective storm location/intensity, fog,
  wild fires, icing, etc
• Real-time model verification
• Easy to interpret
• Easily integrated with Nowcasting products
• Combine the best of all observing systems
• Combine Raob, Aircraft, Profiler winds, and GOES
  RH to produce moisture flux
• Real-time model verification
• Continued need for training
• New instruments
• Improved vertical resolving power
• Improved depiction of vertical distribution of
  moisture

46
Web Site Contact Information

• http//orbit-net.nesdis.noaa.gov/goes/soundings
• GOES sounder retrieval products
• http//orbit-net.nesdis.noaa.gov/goes/sdpi/html/sd
  piimgnewt.html
• Contains the experimental SFOV Sounder Derived
  Product Imagery
• Products are categorized as cloud, fire,
  moisture, severe weather, and temperature
• http//orbit-net.nesdis.noaa.gov/goes/winds
• GOES wind products
• Jaime.Daniels_at_noaa.gov 301-763-8204 x143

47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
GOES-12 ECA Operational DPI System
57
GOES-12 ECA Merged Sounder Product System
