Foundations of Software Design

1
Foundations of Software Design
Lecture 26 Text Processing, Tries, and Dynamic
Programming  Marti Hearst Fredrik
Wallenberg Fall 2002
2
Problem String Search

• Determine if, and where, a substring occurs
  within a string

3
Approaches/Algorithms

• Brute Force
• Rabin-Karp
• Tries
• Dynamic Programming

4
Brute Force Algorithm
5
Worst-case Complexity
6
Best-case Complexity, String Found
7
Best-case Complexity, String Not Found
8
Rabin-Karp Algorithm

• Calculate a hash value for
• The pattern being searched for (length M), and
• Each M-character subsequence in the text
• Start with the first M-character sequence
• Hash it
• Compare the hashed search term against it
• If they match, then look at the letters directly
• Why do we need this step?
• Else go to the next M-character sequence

(Note 1 Karp is a Turing-award winning prof. in
CS here!) (Note 2 CS theory is a good field to
be in because they name things after you!)
9
Karp-Rabin Looking for 31415

• 31415 mod 13 7
• Thus compute each 5-char substring mod 13 looking
  for 7
• 2 3 5 9 0 2 3 1 4 1 5 2 6 7 3 9 9 2 1
• -----------
• 8
• 2 3 5 9 0 2 3 1 4 1 5 2 6 7 3 9 9 2 1
• -----------
• 9
• 2 3 5 9 0 2 3 1 4 1 5 2 6 7 3 9 9 2 1
• -----------
• 3
• 2 3 5 9 0 2 3 1 4 1 5 2 6 7 3 9 9 2 1
• -----------
• 7

Found 7! Now check the digits
10
Rabin-Karp Algorithm

• Worst case time?
• N is length of the string
• O(N) if the hash function is chosen well
• http//orca.st.usm.edu/suzi/stringmatch/rk_alg.ht
  ml
• http//www.mills.edu/ACAD_INFO/MCS/CS/S00MCS125/St
  ring.Matching.Algorithms/animations.html

(Note 1 Karp is a Turing-award winning prof. in
CS here!) (Note 2 CS theory is a good field to
be in because they name things after you!)
11
Tries

• A tree-based data structure for storing strings
  in order to make pattern matching faster
• Main idea
• Store all the strings from the document, one
  letter at a time, in a tree structure
• Two strings with the same prefix are in the same
  subtree
• Useful for IR prefix queries
• Search for the longest prefix of a query string Q
  that matches a prefix of some string in the trie
• The name comes from Information Retrieval

12
Trie Example

• The standard trie over the alphabet a,b for
  the set aabab, abaab, babbb, bbaaa, bbbab

13
A Simple Incremental Algorithm

• To build the trie, simple add one string at a
  time
• Check to see if the current character matches the
  current node.
• If so, move to the next character
• If not, make a new branch labeled with the
  mismatched character, and then move to the next
  character
• Repeat

14
Trie-growing Algorithm
buy bell hear see bid bear stop bull sell stock
15
Tries, more formally

• The path from the root of T to any node
  represents a prefix that is equal to the
  concatenation of the characters encountered while
  traversing the path.
• An internal node can have from 1 to d children
  where d is the size of the alphabet.
• The previous example is a binary tree because the
  alphabet had only 2 letters
• A path from the root of T to an internal node i
  corresponds to an i-character prefix of a string
  S
• The height of the tree is the length of the
  longest string
• If there are S unique strings, T has S leaf nodes
• Looking up a string of length M is O(M)

16
Compressed Tries

• Compression is done after the trie has been
  built up cant add more items.

17
Compressed Tries

• Also known as PATRICIA Trie
• Practical Algorithm To Retrieve Information Coded
  In Alphanumeric
• D. Morrison, Journal of the ACM 15 (1968).
• Improves a space inefficiency of Tries
• Tries to remove nodes with only one child
• (pardon the pun)
• The number of nodes is proportional to the number
  of strings, not to their total length
• But this just makes the node labels longer
• So this only helps if an auxiliary data structure
  is used to actually store the strings
• The trie only stores triplets of numbers
  indicating where in the auxiliary data structure
  to look

18
Compressed Trie
b
s
e
u
to
e
hear

ar
ll
id
ll
y
p
ck
ll
e
19
Suffix Tries

• Regular tries can only be used to find whole
  words.
• What if we want to search on suffixes?
• build, mini
• Solution use suffix tries where each possible
  suffix is stored in the trie
• Example minimize

Findimi
i
m
i
20
Dynamic Programming

• Used primarily for optimization problems.
• Not just a good solution, but an optimal one.
• Brute force algorithms
• Try every possibility
• Guarantee finding the optimal solution
• But inefficient
• DP requires a certain amount of structure,
  namely
• Simple Subproblems (and simple break-down)
• Global optimum is a composition of subproblem
  optimums
• Subproblem Overlap optimal solutions to
  unrelated problems can contain subproblems in
  common.
• In other words, can re-use the results of solving
  the subproblem

21
Longest Common Subsequence

• LCS find the longest string S that is a
  subsequence of both X and Y, where
• X is of length n
• Y is of length m
• Example what is the LCS of
• supergalactic
• galaxy
• (The characters do not have to be contiguous)

22
Dynamic Programming Applied to LCS Problem
Lets compare X GTG
X0i Y CGATG Y0j We
represent the longest subsequence as Li,j
Longest Common Subsequence
23
Dynamic Programming for LCS

• Note that the longest string of X and Y (Li,j)
  must be equal to the longest string of ...
• X0i-1 GT (removing the last G) Y0j-1
  CGAT (removing the last G)
• plus 1, since the matching Gs at Xi,Yj will
  increase the length by one.

24
Dynamic Programming for LCS

• If Xi,Yj had NOT matched, Li,j would have to be
  equal to the longest string in Li-1,j or
  Li,j-1.
• If this is true for Li,j, it must be true for
  all L.
• We know that L-1,-1 0 (since both strings are
  empty)
• Finally we know that Li,j cannot be larger than
  max(i,j)1

25
Dynamic Programming for LCS
For each position, take the max of Li-1,j or
Li,j-1 Add 1 when a new match is found.
26
Dynamic Programming

• Running Time/Space
• Strings of length m and n
• O(mn)
• Brute force algorithm 2m subsequences of x to
  check against n elements of y O(n 2m)

27
Dynamic Programming vs. Greedy Algorithms

• Sometimes they are the same.
• Sometimes not
• What makes an algorithm greedy?
• Globally optimal solution can be obtained by
  making locally optimal choices
• Dynamic Programming
• Solves subproblems, that can be re-used
• Trickier to think of
• More work to program

28
Greedy Vs. Dynamic Programming

• The famous knapsack problem
• A thief breaks into a museum. Fabulous
  paintings, sculptures, and jewels are everywhere.
  The thief has a good eye for the value of these
  objects, and knows that each will fetch hundreds
  or thousands of dollars on the clandestine art
  collectors market. But, the thief has only
  brought a single knapsack to the scene of the
  robbery, and can take away only what he can
  carry. What items should the thief take to
  maximize the haul?

29
The Knapsack Problem

• More formally, the 0-1 knapsack problem
• The thief must choose among n items, where the
  ith item worth vi dollars and weighs wi pounds
• Carrying at most W pounds, want to maximize value
• Note assume vi, wi, and W are all integers
• 0-1 b/c each item must be taken or left in
  entirety
• A variation, the fractional knapsack problem
• Thief can take fractions of items
• Think of items in 0-1 problem as gold ingots, in
  fractional problem as buckets of gold dust

30
The Knapsack Problem Optimal Substructure

• Both variations exhibit optimal substructure
• To show this for the 0-1 problem, consider the
  most valuable load weighing at most W pounds
• If we remove item j from the load, what do we
  know about the remaining load?
• The remainder must be the most valuable load
  weighing at most W - wj that the thief could take
  from museum, excluding item j

31
Solving The Knapsack Problem

• The optimal solution to the fractional knapsack
  problem can be found with a greedy algorithm
• The optimal solution to the 0-1 problem cannot be
  found with the same greedy strategy
• Greedy strategy take in order of dollars/pound
• Example 3 items weighing 10, 20, and 30 pounds,
  knapsack can hold 50 pounds
• Suppose item 2 is worth 100. Assign values to
  the other items so that the greedy strategy will
  fail

32
The Knapsack Problem Greedy Vs. Dynamic

• The fractional problem can be solved greedily
• The 0-1 problem cannot be solved with a greedy
  approach
• It can, however, be solved with dynamic
  programming
