Florida Public Service Commission Internal Affairs Briefing

1
Florida Public Service Commission Internal
Affairs Briefing

• Lynne Tejeda
• General Manager CEO

2
Keys Energy Services Facts

• Since 1943
• Serves Key West to Seven-Mile Bridge
• 28,000 customers
• 154 employees
• Entire Service Area Classified as Coastal
• Literally Most Hurricane Prone County
• Affected by 9 Hurricanes since 1992

3
Keys Energy Services Facts

• 142 MW system load
• 83 MW on-island local generation
• 8 substations with 35 feeders
• 257 miles distribution _at_ 13.8kV
• 90 of distribution is aerial
• 60 miles of transmission _at_ 69 138kV
• 1 radial line - interconnection to FKEC

4
Keys Energy Services Facts

• 5-members
• Elected by Citizens of Key West
• Responsive to Community
• Responsive to Staff

5
Generation
6
On Island Generation

• Utility Board requires 60 On-island Generation
• FMPA Maintains this requirement level
• 6 High Speed Diesels
• 2 Medium-Speed diesels
• 1 KEYS Combustion Turbine
• 3 FMPA Combustion Turbines

7
6 High Speed Diesels

• One Unit at Big Pine Key / 2.5 Mw / installed
  1969
• Two units at Cudjoe Key / 2.5 Mw 2.0 Mw/
  installed 1965
• Three units at Stock Island / 2.0 Mw each /
  installed 1965
• Black Start Units

8
Medium Speed Diesels

• Colt-Pielstick
• Located at Stock Island
• 8.7 Mw each
• Installed 1990
• Black Start Units

9
3 GE Frame V Combustion Turbines

• Stock Island
• CT 1 - 20 Mw / installed 1980 / Black Start Unit
• CT 2 - 18.6 Mw / installed 1998
• CT 3 - 18.1 Mw / installed 1998

10
LM6000 Combustion Turbine

• Stock Island
• 43 Megawatts
• Operational on June 28th

11
Fuel Supply

• 3.9 Million Gallons of Fuel Storage
• Maintain 14-day supply
• Hurricane Georges no barges took on 429,514
  gallons of oil by tankers over 2 days

12
Transmission
13
Transmission

• Keys Energy Services TieLine
• 138 kilovolts
• Sole Ownership to Marathon 60 miles
• FKEC and KEYS transmission Line
• 138 kilovolts
• Joint ownership to the Dade-Monroe
• Dual Lines
• 21 miles from Tavernier to the County Line
• Stock Island to Big Coppitt

14
Transmission

• All Concrete or Steel
• Wind Ratings Vary
• Inspections
• Constant
• Aerial 2 years
• Foundation/Anchors 3-4 years
• Stress analysis on transmission only
• Polymer Insulators - new since 1998

15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
Transmission

• Sailboat Issue

22
Distribution
23
Distribution

• Substations
• Poles
• Informal pole inspections
• Pole Replacements to concrete
• Attachments
• Stress analysis case-by-case depending on
  situation
• Transformers
• Elevated above Flood

24
(No Transcript)
25
m
26
(No Transcript)
27
(No Transcript)
28
Vegetation

• Transmission Trimming
• Twice Yearly
• 15 feet minimum on transmission lines
• Distribution Trimming
• Every Two Years
• 10 feet minimum on all open conductors greater
  than 600 volts
• 5 feet minimum clearance on all open conductors
  less than 600 volts.
• Unique agreement with BellSouth/ComCast
• Tree Commission

29
Recovery
30
Have a Plan

• Hurricane Plan that is updated yearly
• Success of our restoration based largely on
  following the plan
• Success of our restoration also based largely on
  good communications

31
KEYS Hurricane Plan

• Review Process Annually
• Updated After Each Storm

32
KEYS Hurricane Plan

• Employee Issues
• To Evacuate or Not to Evacuate
• Hospitals
• All Hands on Deck
• Review Process Annually

33
KEYS Hurricane Plan

• Mutual Aid / Contractors
• Hotels
• Caterers
• Laundry

34
(No Transcript)
35
(No Transcript)
36
KEYS Hurricane Plan

• In the Field
• Immediate Inspection
• Daily Crew Assignments
• Fully Energized
• 2nd Inspection
• Punchlist

37
Internal Communications

• Internal
• Radio
• Cell Phones
• Meetings
• Sense of Humor

38
(No Transcript)
39
KEYS Hurricane Plan

• Communications
• EOC
• Media
• Customers
• City Officials
• Chamber of Commerce

40
Every Storm is Different the Variables

• Generation
• Transmission
• Distribution
• Work Force

41
Hurricane Andrew

• Non- Event
• Generation fine
• Transmission down outside our service area
• Distribution fine
• Work Force all available
• No Mutual Aid/Contractors

42
Hurricane Georges

• Wind Event
• Generation slightly damage
• Transmission down in our service area
• Distribution severe damage
• Work Force all available
• Mutual Aid
• Contractors

43
Hurricane Georges TD

• Keys Energy Services
• Linemen from Key West to Key Haven
• Engineering Field Reps.
• Meter Services
• Outside Crews - 296 utility workers
• Duke Engineering
• All Others

44
Hurricane Georges

• List of Distribution Concerns
• Cross Arms 97
• Cracked Poles 82
• Leaning Poles 60
• Down Guy Repair or Replacement 566
• Sagging Line 301
• Street Light Repair 485
• Stub Pole Removal 373

45
Hurricane Georges 275 Poles Down and Broken
46
Transmission Improvement

• Constantly maintaining and improving
• Redundancy
• New Insulators
• 26.4 miles from Coco Plum to Islamorada
• Stock Island to Marathon

47
Improvements

• Transmission
• More redundancy
• New insulators
• Distribution
• Substation Upgrades
• 4.16 to 13.8 conversion
• Upgrade poles - wood to concrete
• Tree Trimming

48
Hurricane Wilma

• Wind and Flooding Event
• Generation fine
• Transmission fine
• Distribution damage
• Work Force partially available
• Mutual Aid/Contractors

49
Hurricane Wilma68 Poles Down and Broken
50
Hurricane Wilma Clean Up

• Guy Guard Attachment
• Guy Wire Tight
• Guy Wire Grounded
• Street Light Grounded
• Neutral Grounded
• Cross Arm Condition/Repair
• Poles replace cracked ones
• Tree Trimming
• Service Wedges Broken
• Street Light Audit
• Street Light Repair
• Critical Care Customer Field Tags

51
Looking Ahead

• Learned from experiences
• Still worry
• Worry is interest paid on trouble before it
  falls due -William Ralph Inge
