Needs and Requirements of Blind Pedestrians at Signalized Intersections

1
Needs and Requirements of Blind Pedestrians at
Signalized Intersections

• Workshop on Accommodating Pedestrians at
  Signalized Intersections
• Janet M. Barlow
• Accessible Design for the Blind
• January 11, 2009

2
Blind may not mean totally blind
3
Intersection as seen by someone with normal
vision
4
Central vision loss
5
Peripheral Vision Loss
6
Overall acuity loss
7
Totally blind
8
How do people who are blind or who have low
vision travel?

• Sighted (human) guide
• White cane
• Dog guide
• Telescope or other low vision aids
• No aid

9
Pedestrians who are blind or who have low vision

• May travel to unfamiliar destinations for
  shopping, errands, visiting friends, childrens
  activities, work, or other purposes, just like
  those who are fully sighted
• May have to figure out intersections and
  intersections crossings when they arrive at them

10
Street crossing tasks

• Locate edge of the street
• Determine where to begin crossing (locate
  crosswalk)
• Establish crossing direction and alignment
• Determine traffic control and use pushbutton, if
  necessary
• Decide when to begin crossing
• Maintain alignment during crossing

11
Traditional strategies

• Walk up to corner
• Maintain travel direction
• Listen through a signal cycle
• Cross with the surge of traffic traveling
  parallel to crosswalk
• Maintain direction by listening to vehicles and
  other cues

12
Problems in the current intersection environment

• Curb ramps
• Rounded corners (large radius)
• Wide streets
• Complex intersection geometry
• Actuation and complex signalization
• Need to use pedestrian pushbutton

13
Street crossing tasks

• Locate edge of the street
• Determine where to begin crossing (locate
  crosswalk)
• Establish crossing direction and alignment
• Determine traffic control and use pushbutton, if
  necessary
• Decide when to begin crossing
• Maintain alignment during crossing

14
Locate edge of the street

• Detectable warnings
• Also called truncated domes or truncated dome
  detectable warnings
• Required on curb ramps or blended transitions
  at crossings
• Not yet installed everywhere

15
NOT detectable warnings
16
Detectable warning
17
Detectable warning at curb ramps
24 in direction of travel at back of curb Full
width of ramp or level area
18
Street crossing tasks

• Locate edge of the street
• Determine where to begin crossing (locate
  crosswalk)
• Establish crossing direction and alignment
• Determine traffic control and use pushbutton, if
  necessary
• Decide when to begin crossing
• Maintain alignment during crossing

19
Crosswalk in line with sidewalk
20
Crosswalk offset from corner can be problematic
21
May not cross at crosswalk
Adding planter strip could help
22
Street crossing tasks

• Locate edge of the street
• Determine where to begin crossing (locate
  crosswalk)
• Establish crossing direction and alignment
• Determine traffic control and use pushbutton, if
  necessary
• Decide when to begin crossing
• Maintain alignment during crossing

23
Crossing direction and alignment

• Still working on solutions
• Detectable warnings dont provide alignment info
• Ramp design
• Two ramps per corner where possible
• Align ramp with travel direction
• BUT.requirement for ramp to be perpendicular to
  the curb and gutter requires ramp to angle toward
  the street at large radius corners
• Provide edge that is aligned with travel
  direction?
• Sound of accessible signal may provide alignment
  information

24
Example of curb ramp designs that provide
alignment cues
25
Pedestrian pushbuttons can also affect alignment

• Have to deviate to push button
• Must cross on next pedestrian phase
• cant listen to parallel traffic phase to realign

26
Street crossing tasks

• Locate edge of the street
• Determine where to begin crossing (locate
  crosswalk)
• Establish crossing direction and alignment
• Determine traffic control and use pushbutton, if
  necessary
• Decide when to begin crossing
• Maintain alignment during crossing

27
Pedestrian Pushbuttons

• Is there a pushbutton?
• Where is it?
• Have I found the pushbutton for the street Im
  crossing?

28
Decide when to begin crossing

• Traditional cues to time to cross
• Stopped traffic on cross street
• Surge of traffic in parallel lane closest to
  crosswalk

29
Traffic cues may not be available where there are

• Low volumes of traffic parallel to crosswalk
• Crossing major street
• T intersections (crossing top of T)
• Heavy turning traffic volumes
• Exclusive pedestrian phases
• Leading pedestrian phases

30
Newer type of Accessible Pedestrian Signals (APS)

• Features provide information about pushbutton and
  pedestrian signal indications
• Pushbutton Locator tone
• Audible and Vibrotactile Walk indications
• Tactile arrow
• Automatic volume adjustment

31
Speakers at the pushbutton
32
Pushbutton Locator Tone

• Sound comes from the pushbutton
• Provides information about pushbutton presence
  and location
• 1 tone per second, each tone less than 0.15
  seconds in duration
• Volume set to be heard within 6 12 feet, or at
  the building line, whichever is less
• Different sounds acceptable (click, beep, etc)

33
Tactile arrow

• Raised arrow
• May be on the pushbutton, on part of the device,
  or on sign above the pushbutton
• aligned with direction of travel on the
  crosswalk controlled by the pushbutton

34
Tactile Arrow examples
35
Recommended WALK indications

• A rapid tick WALK indication (sound on slide 6)
  at locations where the speakers for APS for two
  different crosswalks are separated by at least 10
  feet
• Vibrotactile WALK indication - arrow (or other
  surface on pushbutton unit) that vibrates during
  WALK

36
Pushbutton-integrated APS

• Continuous pushbutton locator tone with rapid
  tick WALK indication

Sounds attached click on photo to hear sounds
37
Pushbutton-integrated APS

• Continuous pushbutton locator tone followed with
  speech walk indication

Sounds attached click on photo to hear sounds
38
Automatic volume adjustment

• Volume of pushbutton locator tone and audible
  walk indications adjusts in response to ambient
  sound
• Louder when traffic is loud or there is other
  noise at the intersection
• Quiet when traffic or other sounds are quieter
  (night)

39
APS Location is critical

• Provide information to the user through proximity
  to the departure point
• Signal can be quieter due to proximity

40
Installation recommendations

• Beside the landing of the curb ramp
• Separated by more than 10 feet from other APS on
  corner
• MUTCD says within 5 feet of crosswalk line and
  within 10 feet of the curb

41
Installation example - APS separated by 10 feet
(3m)

• Reachable from level landing, within 10 ft of
  curb, within 5 feet of crosswalk lines

42
Installation example - APS aligned with crosswalk
lines
43
Street crossing tasks

• Locate edge of the street
• Determine where to begin crossing (locate
  crosswalk)
• Establish crossing direction and alignment
• Determine traffic control and use pushbutton, if
  necessary
• Decide when to begin crossing
• Maintain alignment during crossing

44
Maintaining alignment

• Listen to traffic, waiting and moving
• Road slope and camber

45
Features that help pedestrians who are blind

• Simple geometry
• Shorter crossings
• Landscaping or barriers to direct to crossing
  location and prevent crossing at the wrong place
• Curb ramp that is aligned as closely as possible
  to direction of travel on the crosswalk
• Detectable warning at street edge and edge of
  splitter island cut-throughs
• Raised splitter islands with edges aligned in
  crosswalk travel direction
• Accessible pedestrian signals, with new features,
  for crossings

46
Modifications that make intersections accessible
to pedestrians who are blind are helpful to ALL
pedestrians
47
Acknowledgements

• Some photos courtesy of Lukas Franck, Michael
  Ronkin, Lois Thibault, and Billie Louise (Beezy)
  Bentzen
• Graphics from Accessible Pedestrian Signals A
  Guide to Best Practice

48
Questions??For more information, contact

• Janet M. Barlow
• Accessible Design for the Blind
• 770-317-0611
• jmbarlow_at_accessforblind.org
