Title: System Level Applications of Adaptive Computing


1
System Level Applications of Adaptive Computing
  • Brian SchottUSC Information Sciences Institute
  • DARPA TTO ACS PI, April 2000

2
SLAAC Technology
  • Goal ACS research insertion into deployed DoD
    systems.
  • Distributed ACS architecture for research lab and
    embedded systems.
  • Domain compiler tools and module generators.
  • Application/algorithm mapping to reconfigurable
    logic .

3
SLAAC Team
  • This talk covers a slice of SLAAC.

4
Application Challenges
  • SLAAC applications have a variety of physical
    form factors and scalability requirements.
  • However, most development will occur in
    university labs.

NVL IR/ATR
Sandia SAR/ATR
NUWC Sonar Beamforming
5
SLAAC Architectural Approach
  • SLAAC defines a scalable, portable, distributed
    systems architecture based on a high speed
    network of ACS accelerated nodes.
  • Use COTS
  • Use existing network and cluster computing
    technology.
  • Use comparable embedded systems technology.

6
Reference Platforms
  • SLAAC has defined two reference platforms
  • RRP is an NT/Linux cluster of ACS-accelerated
    workstations.
  • DRP is an ACS-accelerated embedded PowerPC
    Multicomputer.
  • The goal is to provide scalable, source-code
    compatibility between RRP and DRP.

7
How do you program?
  • You can use existing parallel libraries to move
    data from host to host and control ACS boards
    individually.
  • We have created an ACS system API that
    generalizes control functions and introduces a
    logical node number (rank).
  • Intended to augment (not interfere with) existing
    parallel libraries (MPI).
  • System creation and configuration functions.
  • ACS_System_Create(), ACS_Configure()
  • Memory access functions.
  • ACS_Read(), ACS_Write()
  • Streaming data functions.
  • ACS_Enqueue(), ACS_Dequeue()
  • Debugging functions.
  • ACS_Readback()

8
ACS System API
  • C-callable API hides a set of C classes.
  • Intended to make it easy to plug in different
    nodes and communicators.

Host C-callable API
ACS System Class
System creation, configuration, memory access,
and streaming data, and debugging methods.
Communicator Classes
MPI Communicator
Myrinet GM
Local Node
ACS Node Classes
CSRC/RCM
WildForce
SLAAC-1
SLAAC-1V
WildStar
SLAAC-2
9
Single Board API Benefits
  • Provides portability for host control code.
    Write your application once and migrate to newer
    ACS boards.
  • Open API w/ source code makes it easier to
    develop control software for new boards.
    Standardizes the minimum feature set for ACS
    hardware.
  • Extensible API provides common target for tool
    development. Encourages wider audience for your
    tool efforts.

10
Multiple Board Programming Model
  • Intended to reduce distributed ACS system
    programming complexity.
  • We define a system of hosts, nodes, and channels.
  • Hosts are user processes that run on GPPs .
  • Nodes are ACS boards with control threads.
  • Channels automatically stream data between FIFOs
    on host/nodes.

Hosts
Nodes
Network
11
Network Channels
  • Use network channels in place of physical
    point-to-point connections.
  • Boards operate on individual clocks, but are
    data-synchronous.
  • Channels can apply back-pressure to stall
    producers.

Network-channel
12
FPGA Design Paths
DEFACTO
High Level Compilers
HRT Express
Domain Specific Compilers
Streams C
JHDL
Low Level Design Tools
COTS VHDL
Domain Module Generators
Runtime System
SLAAC ACS API, Debugger, Runtime
ACS Hardware
WildForce
CSRC/RCM
SLAAC-1
SLAAC-1V
WildStar
SLAAC-2
13
SLAAC Hardware
14
SLAAC Hardware Approach
  • We want ACS researchers to develop on PCI
    platforms and seamlessly migrate to VME when
    necessary.
  • ACS API provides source-code compatibility on
    host. What is the moral equivalent for ACS
    boards?
  • FPGA designs sensitive to hardware architecture.
  • Variety of tools are used to generate bitfiles.
  • Bitfile compatibility is least-common
    denominator.
  • SLAAC approach is to provide bitfile compatible
    architectures in PCI and VME form factors.

15
SLAAC1 PCI Architecture
  • Full-sized PCI card.
  • One XC4085 and two Xilinx xc40150s (750K user
    gates).
  • Twelve 256kx18 ZBT synchronous SRAMs.
  • External I/O connectors.
  • Xilinx 4062 PCI interface.
  • Two 72-bit FIFO ports.
  • External memory bus.
  • 100mhz programmable clock.

72/
72 /
16
SLAAC1 Front
Memory Module (3)
SLAAC-1 PCI
17
SLAAC-1 Back
QC64 I/O
18
SLAAC-1 Status
  • We have 20 boards built.
  • BYU, UCLA, LANL, VT, LMGES, ISI. DoD (external).
  • We are in a maintenance cycle on SLAAC-1.
  • Incrementally improving software support.
  • Fixing bugs that application developers encounter.
  • SLAAC team working on S-1 apps for 6-8 months.
  • VHDL and JHDL development environments available.
  • Applications developed
  • NVL IR/ATR.
  • HTC Interfacing Stressmark.
  • ECMA modules.
  • Sonar Beamformer.

19
CSPI M2621/S Carrier
  • CSPI is a commercial VME multicomputer vendor
    used by Sandia and LMGES.
  • CSPI modified their M2641 Quad PowerPC baseboard.
  • Both PowerPC busses from baseboard brought to
    connectors.
  • Two PowerPCs on mezzanine replaced with SLAAC
    technology.

CSPI 2641Quad PowerPC Board 1.6 GFLOPS Quad
PowerPC Four Myrinet SANs in 6U Slot 1.28
GBytes/s I/O with 4 Myrinet SANs 64 to 256 MB
On-Board Memory I/O Front Panel VME64 PO
Backplane Active and Passive Multicomputing
Software MPI, ISSPL
20
CSPI Baseboard
PPC 603
Myricom LANai
Future PPC Connector
SAN connector
Myricom 8-port Switch
VME Myrinet P0 connector
21
CSPI M2621/S Carrier
  • This carrier is commercially available from CSPI.
  • Two 40MHz 64-bit PowerPC busses.
  • VxWorks OS.
  • PowerPC bus VHDL core.

22
SLAAC2 Architecture
  • Two independent SLAAC1 boards in single 6U VME
    mezzanine.
  • Four XC40150s, two XC4085s - 1.5M gates total.
  • Twenty 256Kx18 SSRAMs.
  • Sacrificed external memory bus.

40 /
40 /
72/
72/
23
SLAAC2 Front
24
SLAAC-2 Back
25
SLAAC-2 Status
  • We have four xc40150-based boards built (three
    older xc4085 prototypes retired).
  • Hardware operational and well tested.
  • Migrated SLAAC-1 control software to VxWorks.
  • Software and interface logic demonstration-ready
    , but not customer-ready.
  • We are in clean-up mode on control logic and
    software.
  • VxWorks is hard.
  • Applications developed
  • HTC interfacing Stressmark.
  • ECMA modules.
  • Expected customer deliveries this month.

26
2nd Gen SLAAC Hardware Goals
  • Create a SLAAC architecture migration path to
    faster/denser Virtex devices and larger memories.
  • Increase the number of available external I/O
    ports to three.
  • Tightly integrate user designs with 64/66 PCI
    interface.
  • Open platform to meet the needs of two ACS
    efforts
  • LOKI (Xilinx, VT). Provide experimental platform
    for fast partial runtime reconfiguration on
    Virtex.
  • Unified debug (BYU). Provide RTR and full
    board-state dump capability for checkpoint and
    debug.

27
SLAAC-1V Architecture
  • Three Virtex 1000.
  • 3M logic gates _at_ 200MHz.
  • Use Xilinx 64/66 core.
  • Virtex100 configuration controller, FLASH,
    SRAM.
  • Ten 256Kx36 ZBT SRAMs.
  • Bus switches allow single-cycle memory bank
    exchange between X0 and X1/X2.
  • Support up to 1Mx36.
  • Three I/O connectors.
  • Crossbar ports give access to external I/O
    connectors.

X1
X2
72
60
X
X
X
72
X0
IF
X0
72
72
User
Interface
CC
F
S
64/66 PCI
28
Detailed View of X0
  • X0 is Virtex 1000 (1M gates).
  • 72-bit left and right ring ports.
  • 72-bit crossbar ext IO port.
  • 60 pins to each memory card.
  • Utility bus to Virtex 100 configuration
    controller.
  • lt25 used for 64/66 Xilinx PCI core, and IF
    bridge.
  • Columns parallelto PCI core.
  • Configuration Controller (CC)
  • FLASH (boot configurations)
  • SRAM (readback and configuration cache).
  • SelectMAP registers for X0, X1, and X2.

L R
xbar
SelectMAP
X0
F
S
M0 M1
CC
UTL
PCI
IF
29
Detailed View of XP
  • X1 and X2 are identical.
  • Virtex 1000 (1M gates)
  • 72-bit left and right ring ports.
  • 72-bit crossbar ext IO port.
  • 240 pins to memory card.
  • Floor plan allows two virtual PEs per XP chip.
  • VPEs each have 1 memory and 36-bits of XBAR.
  • Horizontal long-lines need to left-to-right
    connectivity.
  • SelectMAP supports fast column configuration
  • 15ms for whole chip.
  • lt1ms single column configuration.

30
Configuration Controller
  • Board designed to maximize runtime
    reconfiguration efficiency.
  • Three parallel 8-bit _at_ 80 MHz SelectMAP ports.
  • Manages local FLASH for boot and SRAM for
    configuration/readback.
  • Four banks each of FLASH SRAM.
  • User clock accessed from CC for precise
    step,configure,step control.
  • State of entire board can be pulled for context
    switching / check pointing.

31
Memory Bank Switching
  • X0 can swap x0m0 with any memory on X1 and x0m1
    with any memory on X2.
  • Easy external memory bus implementation or
    user-level double-buffering.

32
External I/O Support
  • Bus exchange switch allows each FPGA to access
    either shared crossbar bus or local external I/O
    connector.

a)
b)
c)
33
SLAAC-1V Front
  • Two memory daughter cards, one for X1, one for
    X2, X0 connects to both.
  • Add an I/O card on front to get access to
    connector space.

Memory Card
Memory Card
I/O Card A
34
SLAAC-1V Back
  • Support LANL QC64 format I/O connectors for
    high-speed external I/O.
  • Combined with front panel, gives three external
    I/O ports!

I/O Card B (QC64 IN)
I/O Card C (QC64 OUT)
35
SLAAC-1V Status
  • SLAAC-1V is up and running.
  • Configuration, clock, LEDs, DMA demo (740
    Mb/sec).
  • Memory board is under test.
  • Interface and control software development
    continues.
  • Three boards presently exist.
  • Delivered one to BYU for JHDL integration,
    another marked for Xilinx/VT LOKI team.
  • We are building several more for SLAAC team, ACS
    community, and external customers over next few
    months.
  • Contact Lauretta Carter lcarter_at_east.isi.edu for
    details on availability and pricing.
