Coalbed Methane and U'S' Fuel Supply in the U'S'

1
Coalbed Methaneand U.S. Fuel Supplyin the U.S.

• Presented to
• Virginia Center for Coal and Energy Research
• Southwest Virginia Higher Education Center
• Abingdon, Virginia

Presented by Marshall S. Miller Marshall Miller
Associates Bluefield, Virginia August 15, 2001
2
Fuel Supply in the U.S. and the Ever-Changing
Status of the Primary Related Fuels
3
Electricity Generation by Fuel Type
Coal 1.1 Growth
Gas7.7 Growth
Nuclear -1.1 Growth
Source E.I.A.
(Annual Energy Outlook 2001)
4

• Total U.S. Imports of Oil will reach an all-time
  high this year (2001) with a 3.5 jump. This
  will be sixth consecutive year have grown to meet
  strong U.S. demand.
• (Saudi Arabia remains leading source)

Oil Gas Journal July 2001
5
The Pendulum Ready to Swing?

• Environmental concerns and regulations
• No energy policy
• Government aloofness and neglect
• Natural gasfuel of choice

• Available low cost fuel
• Clean coal technology
• Consolidation industry
• Strong technologies
• Available capacity of existing power plants
• Rapidly escalating prices of competing fuels
• Education of government and citizensreality of
  global warming

Source Marshall Miller Presentation September
2000 Pittsburgh, PA
6
Natural Gas Consumption by Sector1970-2020
(trillion cubic feet)

• 34.7 Tcf by 2020?
• Gas consumption is expected to grow 1.8 to 2.0
  percent updated 2.3faster than any other major
  fuel source. (Mainly because of the growth in
  gas-fired electricity generation)
• (Latest forecast 3 economic growth)

Energy Information Agency Integrated Analysis and
Forecasting Department of Energy July 26,
2000 Updated January 2001
7
U.S. Natural Gas Supply
79.5 Bcf/d
71.8 Bcf/d
63.4 Bcf/d
57.0 Bcf/d
51.23 Bcf/d
51.1 Bcf/d
Source E.I.A.
(Annual Energy Outlook 2001)
8
Derived from Oil Gas Journal
9
Natural Gas Projection Needs at 2 Growth
Below 52 Bcf/d
At 2 growth a year, the industry will have to
produce more than 55 Bcf/d of gas in 2004, even
though production levels have failed to reach 52
Bcf/d for the past 6 years. (Graph courtesy of
Lehman Brothers).
10
Natural Gas Production
Oil Gas Journal / Jan. 22, 2001
11
Western Canada Status

• Reserves to production ratio has decreased
  considerably in western Canada
• Decline in RP ration has caused concern about
  future prospects for future increased production
• Record levels of gas drilling in 2000
• 8,000 new gas wells resulted in limited growth
• Future production will depend heavily on CBM,
  tight sands, shales

U.S. Export
Derived from Oil Gas Journal
12
Canadian Replacement Balance
Oil Gas Journal / Jan. 22, 2001
13
Coalbed Methane Proved Reserves1989-1999
Trillion Cubic Feet
Source E.I.A., Office of Oil and Gas
14
Proved Reserves
In trillions of cubic feet
Source Energy Information Administration
15
Natural Gas Production1955-2020 (trillion cubic
feet)
Source E.I.A. (July 2000)
16
The 30-Tcf Gas Economy

• The uncertainty surrounding recoverable gas
  resource estimates is reflected in the differing
  views on the subject

Mary Hutzler, Integrated Analysis and
Forecasting, EIA Hearing July 2000
17
Will require..

• 1.5 trillion in private sector financing
• More than 255,000 miles of distribution pipelines
  (27 more than exist today)
• More than 38,000 miles new transmission lines
  (14 increase)
• Number of wells drilled each year will have to
  double
• Number of drill rigs will have to increase by 60
• Thousands of new workers will be needed

Honorable T.J. Glouthiere Deputy Secretary
Dept. of Energy July 2000
18
Achieving Natural Gas Expectations

• Federal Lands A Big Issue
• Environmental RegulationsA Big Issue
• Technology Advancements A Big Issue
• Moderating Price Expectations A Big Issue
• Will have to drill deeper and in more difficult
  environmentsMeans Higher Costs
• Is there enough gas to meet demand at affordable
  prices?
• Available Labor A Big Issue

19
Oil and Gas Industry in Delimna for Labor,Human
Capital

• Massive downsizing
• Mergers and acquisitions
• Volatile and maturing industry with doubtful
  future
• The attractiveness of new economy and other high
  tech industries (DOT COMS) have captured talent
• Lack of job security
• Fewer students choosing energy disciplines
• Not being fed by universities as once was
• Oil and Gas Industry Lost 390,000 Jobs (1982-1995)

20

• While our demand for oil is expected to increase
  by one third over next two decades, we produce
  less oil than we did in 1970will continue unless
  we change course.
• While our demand for electricity will rise by
  45, demand for natural gas projected to rise
  62hard pressed to supply that demand.
• Only 4.2 increase in transmission lines over
  next 10 years

U.S. Energy InfrastructureTransmission Lines and
Pipelineswholly inadequate Spencer Abraham
July 19, 2001
21
U.S. CBM Resources
22
(No Transcript)
23
CBM Production
24
Factors to Consider

• Growth has been phenomenal
• 11 Bcf in 1985 (2 Basins)
• 550 Bcf in 1992
• 1.2 to 1.5 Tcf in 1998 (9 Basins)
• The 1998 level was not projected to occur
  until the year 2010

25
Relationship of Depth, Rank, and Gas Content
26
Relationship of Gas Content and Permeability to
Depth
27
Coalbed Methane...

• Requires understanding of both coal and petroleum
  and mining and reservoir engineering
• Important factors to address
• physical and chemical nature of the coal (rank,
  chemistry, depositional environment diagenesis,
  mineralization)
• composite thickness
• overburden
• geologic structure
• fractures
• hydrology
• reservoir pressure
• gas content
• permeability

28
E P Characteristics of CBM

• High success rates (generally 85)
• Low finding and development costs
• Higher compression cost
• Many felt industry would die with expiration of
  Section 29 Tax Credits
• Improving technology and resource understanding
  account for success

29
San Juan Basin

• New Mexico

30
San Juan Basin - Fruitland Formation Coal Rank
Map
31
San Juan Basin Fruitland Formation Overburden
32
Powder River Basin

• Wyoming and Montana

33
Powder River BasinAnderson-Wyodak Seam Thickness
Map
34
Generalized East-West Cross Section Across the
Powder River Basin, Wyoming
35
Powder River BasinCBM Well Characteristics
(Primary Fairway)

• Depths 200 to 1200 feet
• Costs 35,000 to 70,000 per well
• Water is generally fresh and useable at the
  surface
• Well depths greater than 800 feet can increase
  water handling costs. Water production normally
  5 to 20 gpm
• Majority of drilling to date within 10 to 12
  miles downdip from large surface mines

36
Powder River BasinCBM Production
37
Yearly production and number of producing wells
for coalbed methane in the Powder River Basin,
Wyoming, 1989 through 2000, with forecasts to
2010.
38
Appalachian Basin
39
Northern Appalachian BasinGeneralized
Stratigraphic Column
40
Northern Appalachian BasinCross Section A - A'
41
Northern Appalachian BasinCoal Thickness Map of
Pittsburgh Coal
42
Northern Appalachian BasinGas Content for the
Pittsburgh Coalbed
43
Northern Appalachian BasinDistribution of CBM
Resources
44
Northern Appalachian BasinGeology and
Characteristics

• Formations Monongahela, Allegheny, Pottsville
• Coal 20 to 35 feet thick
• No. of Seams 5 to 7
• Rank Predominantly High Vol
• Gas Content 50 to 200 CF/ton (max 300 CF/ton)
• Structural influence upon CBM productivity
• Gas In-Place 61 TCF

45
Northern Appalachian BasinCBM Well
Characteristics

• Depths 500 to 2000 feet
• Water 100 to 150 BBl/day
• Permeability 5 to 100 md
• Average Well Production 50 to 120 MCF/day
• Production from LW GOB wells and conventional
  CBMs

46
Northern Appalachian BasinCBM Production History

• Frontier Basin
• Producing Wells approximately 45
• CBM Fields
• WV Big Run, Pine Grove
• 1932 began production in Big Run, West of Federal
  No. 2

47
Northern Appalachian Basin Commercial CBM Fields
48
Northern Appalachian Basin Commercial CBM Field
Summary (Ranked by Total Number of CBM Wells)
49
Central Appalachian Basin

• Southern West Virginia

50
Central Appalachian Basin CBM Gas Content Map
51
Central Appalachian Basin Coal Rank Map
52
Central Appalachian BasinGeneralizedStratigraph
icColumn
53
Central Appalachian BasinCBM Well
Characteristics

• Depths 1500 to 2500 feet
• Seams/wells 8 to 10
• Water 3 to 5 BBl/day
• Well Spacing 60 to 80 acre
• Permeability 5 to 30 md
• Average Well Production 120 MCF/day
• Maximum Gob Well Production 10 MM CF/day

54
Central Appalachian BasinGeology and
Characteristics

• Formations New River and Pocahontas
• Coal 15 to 35 feet thick
• No. of Seams 5 to 25
• Rank Semi-Anthracite to High Vol
• Gas Content lt100 to 500 CF/ton
• Gas In-Place 15 TCF
• Strong structural influence upon productivity

55
Central Appalachian BasinCMB Production History

• Emerging CBM Basin
• 1988 began production
• 5 Fields
• VA Oakwood, Nora, Buck Knob
• WV Slab Fork, Welch
• Current Basin Production 0.1 BCF/day
• Pipeline construction having difficulty keeping
  up with production capacity
• Significant production from LW Gob wells, but
  conventional CBMs are highly productive

56
CBM Fields in Central Appalachian Basin
57
Central Appalachian Basin CBM Operators
58
Southern West Virginia CBM Production by Field
59
Southern West Virginia Annual CBM Production
60
(No Transcript)
61
Central Appalachian Basin CBM Completions by
Operator (1/1/2000)
62
Production Trends 1991 2000
Source Bob Wilson, VA Department of Mines,
Minerals and Energy - Division of Gas and Oil
August 2001
63
Production Trends1991 - 2000
Source Bob Wilson, VA Department of Mines,
Minerals and Energy - Division of Gas and Oil
August 2001
64
Production Trends1991 - 2000
Source Bob Wilson, VA Department of Mines,
Minerals and Energy - Division of Gas and Oil
August 2001
