In Situ Stabilization of Pavement Base Courses

1
In Situ Stabilization of Pavement Base Courses
Roads Pavement Forum Thursday, May 17, 2001
2
Introduction

• Clients
• Gautrans
• CCI
• SANRAL
• Laboratory and Heavy Vehicle Simulator results
  from R243/1
• One building block in a long-term process
• Focus on mechanical properties and structural
  bearing capacity

3
Layout of presentation

• Purpose of the study
• Materials
• Experimental plan
• Results for each laboratory test
• Conclusions

4
Purpose

• Assess the benefits of in situ stabilization in
  terms of improvements in the mechanical
  properties and structural bearing capacity of the
  treated material
• Mechanical properties
• Resilient modulus
• Compressive and tensile strength
• Flexibility
• Shear strength
• Bearing capacity
• Effective fatigue
• Permanent deformation

5
Materials

• Basic material
• Ferricrete milled from HVS test site, including
  existing surfacing and upper portion of subbase
• Treatment processes
• Cement (Laboratory)
• 2 cement
• Foam and cement (Laboratory and HVS)
• 2 cement, 1.8 residual binder
• Emulsion and cement (Laboratory and HVS)
• 2 cement, 1.8 residual binder

6
Materials Untreated

• Nominal maximum aggregate size 37.5 mm

7
Materials Untreated

• Classification
• Grading G4
• Atterberg limits G5
• CBR G7

8
UCS, ITS, Flexural Beam Test

• Treated materials only
• Foam and emulsion tested at 2 binder contents
• 1.8 residual binder content 2 cement
• 3.0 residual binder content 2 cement

9
Flexural beam test

• Strain at crack initiation
• Indication of flexibility

10
Triaxial Tests

• Untreated and treated materials
• 1.8 residual binder content, 2 cement
• Variables
• Density
• Saturation
• Confining pressure
• Stress ratio

11
Triaxial tests

• Static triaxial tests
• Shear strength parameters
• Dynamic triaxial tests
• Resilient modulus
• Permanent deformation response

12
Compressive strength UCS Results

• Cement-treated ferricrete has highest UCS
• Addition of binder reduces the UCS

13
Tensile strength ITS Results

• Cement-treated ferricrete has highest ITS
• Addition of binder reduces the ITS

14
Tensile strength ITS Results

• Samples dried to equilibrium MC at ambient temp
• 72 h in oven at 40º C

15
Flexibility Flexural beam test

• Flexibility only increases at higher binder
  content

16
Elastic stiffness (Mr) Dynamic triaxial tests

• Estimation of stiffness values
• Use regression model for untreated ferricrete
• Use ranges for treated materials

17
Comparative results Average strain-at-break
18
Comparative results Effective fatigue life

• SAMDM transfer functions
• Working strain of 125 ??
• ?bvalues from flexural beam test

19
Comparative results Cohesion
20
Comparative results Friction angle
21
Comparative results Shear strength at ?3 50 kPa
22
Comparative results Bearing capacity (9 PD)
23
HVS tests Pavement structure

• 30 mm Asphalt
• 250 mm FTG / ETG
• - 1,8 residual
• bitumen
• - 2 cement
• In situ material
• In situ subgrade

24
HVS tests Materials
25
HVS tests Programme

• 2 x 100 m long experimental sections
• Foam-treated
• Emulsion-treated
• 1st Phase of HVS testing
• 80/100 kN tests (350 000/150 000 repetitions)
• Completed
• 2nd Phase of HVS testing
• 40 kN tests (750 00000 repetitions)
• In process

26
HVS tests Deflection result
27
Conclusions UCS, ITS and Flexibility

• Complex relationship between UCS, ITS and
• Percentage binder
• Cementation
• Curing procedure
• Flexibility
• No increase in flexibility at low binder content
• Increase in flexibility and effective fatigue
  life at higher binder content
• Strain-at-break slightly higher for
  foam-treatment at higher binder content
• Effective fatigue life models to be validated
  with HVS results

28
Conclusions Resilient modulus

• Increase in resilient modulus with treatment
• Untreated ferricrete
• Resilient modulus influenced by
• Relative density and saturation
• Stress state
• Treated ferricrete
• Resilient modulus dictated by the stabilizing
  agent and largely insensitive to the above
  parameters
• No significant difference between stabilizing
  agents
• Resilient modulus values to be validated by HVS
  back-calculation results

29
Conclusions Shear strength and plastic strain

• Shear strength increases with treatment
• Vastly improved bearing capacity in terms of
  permanent deformation
• Cement-treatment shows highest benefit
• No significant difference between foam- and
  emulsion-treatment
• Models need to be calibrated with HVS results

30
Conclusions General

• Only considered mechanical properties
• Other properties to investigate
• Permeability and erodibility
• Workability
• Shrinkage cracking
• Time to opening the road early strength
• Improved understanding of mechanical properties
  and behaviour
• Properties of stabilized material significantly
  different from untreated material even at low
  binder content
• First structural design models for these types of
  materials
