Earth observation data for everyone: the CBERS experience

1
Earth observation data for everyone the CBERS
experience

• Gilberto Câmara
• Director, National Institute for Space Research

2
The need for global land observation

• The world is changing rapidly
• Climate Change is here to stay
• Global land observation is a crucial need for the
  world, but its future is uncertain
• MODIS is very useful,but has no future
• What will happen to LANDSAT?
• Global land observation systems are a public good

3
Altamira (Pará) LANDSAT Image 22 August 2003
4
Altamira (Pará) MODIS Image 07 May 2004
5
Imagem Modis de 2004-05-21, com excesso de nuvens

Altamira (Pará) MODIS Image 21 May 2004
6
Altamira (Pará) MODIS Image 07 June 2004
7
Altamira (Pará) MODIS Image 22 June 2004
6.000 hectares deforested in one month!
8
Altamira (Pará) LANDSAT Image 07 July 2004
9
Go to the field....
10
...and get the bad guys!
11
Land Remote Sensing 20 to 50 meter resolution
12
Land Remote Sensing 50 300 m resolution
13
The 300 million dollar question

• How do we obtain support for funding Earth
  Observation Missions?
• Our answer Make all sectors of society use
  publically funded EO data...
• ...by providing EO data for free!

14
Uncle Scrooge and the Internet

• Uncle Scrooge
• A penny saved is a penny earned
• The anti-Uncle Scrooge principle
• A pixel saved is a penny wasted
• Why is that so?

15
The Internet paradox

• The Internet has reduced the cost of data
  distribution to very close to zero
• Society responds very quickly to open
  availability of free data and good on the Web

16
Brazilian and Chinese Strategy for CBERS

• CBERS images received in Brasil are freely
  available on the Internet for Brazilian and Latin
  American users
• CBERS images received in China are freely
  available on the Internet for Chinese users
• A high-quality image processing software (SPRING)
  is also available free on the Internet in Brazil

17
CBERS China-Brazil Earth Resources Satellite

• Brief History
• Initial agreement signed in July 6th, 1988,
  covering CBERS-1 and 2.
• In 2002, both governments decided to expand the
  initial agreement by including CBERS-3 and 4.
• Program objectives
• Build a family of remote sensing satellites to
  support the needs of users in earth resources
  applications
• Improve the industrial capabilities of space
  technology in Brazil and China

18
CBERS Program Timeline
19
CBERS-2
CBERS-2 Launch (21 October 2003)
20
CBERS 1,2 Sensor Configuration
WFI 260 m (890 km)
MSS 80 m (120 km)
CCD 20 m (120 km)
0.4
2.5
0.7
1.1
0.9
0.5
1.5
1.7
2.3
mm
Built by China
Built by Brazil
21
CBERS-2B Sensor Configuration
WFI 260 m (890 km)
CCD 20 m (120 km)
PAN 2.5 m (27 km)
0.4
2.5
0.7
1.1
0.9
0.5
1.5
1.7
2.3
mm
Built by China
Built by Brazil
22
CBERS-2 CCD, Minas Gerais, Brazil
23
CBERS-2 CCD Sobradinho Dam, Brazil Dez 2003
24

• CBERS-2 image from Louisiana, EUA
• Obtained from on-board data recorder

25
(No Transcript)
26
CBERS 3 4 Sensor Configuration
WFI 73 m (860 km)
MSS 40 m (120 km)
CCD 20 m (120 km)
MUX 10 m (60 km)
PAN 5 m (60 km)
2.1
0.4
2.3
0.7
1.1
0.9
0.5
1.5
1.7
Built by China
Built by Brazil
mm
27
CBERS 3/4 x LANDSAT-8
TM 30 m (180 km)
PAN 15 m (180 km)
WFI 73 m (860 km)
MSS 40 m (120 km)
CCD 20 m (120 km)
MUX 10 m (60 km)
PAN 5 m (60 km)
2.1
0.4
2.3
0.7
1.1
0.9
0.5
1.5
1.7
mm
28
Work Share for CBERS 3-4(50 China, 50 Brazil)

• Service Module
• Structure Brazil
• Thermal Control China
• Attitude and Orbit Control China
• Power supply Brazil
• On-board computer China
• Telemetry Brazil
• Payload Module
• CCD Camera 5/10 m China
• CCD Camera 20 m Brazil
• IRMSS 40m China
• AWFI 70m Brazil
• Data Transmission China
• Data collection Brazil

29
CBERS Image Distribution in Brazil (1st May 2004
to 1st May 2006)
30
Time to respond an image request
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
FTP area for User
36
User Distribution()
37
Private Farm Management
38
Tax Enforcement in Agriculture
39
Oil Spill Monitoring (Large Swath Data)
40
Propaganda and Marketing
41
What do we get from free data?

• With zero cost data access, technology
  dissemination has a much greater impact.
• CBERS brought the freedom to have data
  immediately available when you need it.
• Free EO data and free EO technology create new
  users and new applications
• Increases the need for other types of EO data

42
What do the private companies say about free
CBERS data?

• Enables new business development
• Facilitates trial uses for new clients
• Planning new applications becomes easier
• Creates jobs by reducing cost of data buys
• Increases work quality by adding data previously
  unavailable

43
What have we learned?

• There is an enormous demand for remote sensing
  data in developing countries
• Free on-line data access can significantly
  increase the number of users of earth observation
  data
• The CBERS data policy has been extremely
  well-received by government and society in Brazil

44

• One world, one dream...

Free Earth Observation data for all!
45
One world, one dream...

• A consortium of Earth Observation satellites for
  global land observation (5m)
• A network of cooperating ground stations
• EO data free on the Internet, with global weekly
  coverage

46
Cooperative Ground Station Network
47
Key questions (Donna Coutts and Achache)

• How do we develop services from Earth Observation
  data?
• How does the system change when everyone has
  ready access to space-based Earth observation?

48
Key questions (Donna Coutts and Achache)

• How do we develop services from Earth Observation
  data?
• How does the system change when everyone has
  ready access to space-based Earth observation?
• Create a market for services and high-resolution
  data by providing EO data at a massive scale!

49
thank you ! ??!
