Bone Disease in Renal Failure

1
Bone Disease in Renal Failure

• Dr Anne Kleinitz and
• Dr Cherelle Fitzclarence
• renalgp_at_kamsc.org.au

2
Overview

• Pathogenesis
• Normal Bone Remodeling
• Hyperparathyroidism
• Classifications of bone disease
• Diagnosis of bone disease
• Treatment of bone disease in CKD
• Case Studies

3
Pathogenesis

• Kidney failure disrupts systemic calcium and
  phosphate homeostasis and affects the bone, GIT
  and parathyroid glands.
• In kidney failure there is decreased renal
  excretion of phosphate and diminished production
  of calcitriol (1,25-dihydroxyvitamin D)
• Calitriol increases serum calcium levels
• The increased phosphate and reduced calcium,
  feedback and lead to secondary hyperparathyroidism
  , metabolic bone disease, soft tissue
  calcifications and other metabolic abnormalities

4
?PO4
?Ca
?GFR
?1,25 DHCC
?PTH
Calcitriol
5

• Although bone disease and abnormal PTH are a
  major feature, CVD and excess calcification
  (extra-skeletal) are important causes of
  morbidity and mortality

6

• Pathogenesis
• Normal Bone Remodeling

7
Normal Bone Remodelling Cycle
Resorption osteoclasts
Formation osteoblasts ? matrix
Quiescence
Mineralisation
8

• Pathogenesis
• Normal Bone Remodeling
• Hyperparathyroidism

9
Hyperparathyroidism

• Increase PTH is hallmark of secondary
  hyperparathyroidism
• The major factors leading to its increase are
• Decreased production of Vit D3 (calcitriol)
• Decreased serum calcium
• Increased serum phosphorous

10
?PO4
?Ca
?GFR
?1,25 DHCC
?PTH
Calcitriol
11

• 4 or more small glands on the posterior surface
  of the thyroid gland.
• Can function without neural control so can
  transplant to another part of the body
• 2 types of cells
• Chief cells produce parathyroid hormone
• Oxyntic cells function unknown

12
Role of PTH

• Responsible for maintaining serum calcium in a
  narrow range (2.15-2.6)
• Does this by
• acting directly on the distal tubule of the
  kidney to increase calcium reabsorption
• Increases calcitriol production (D3)
• D3 increases GIT absorption of Ca and Phos and
  promotes osteoclast formation.
• Acting on bone to increase calcium and phosphate
  efflux

13

• The net effect of PTH is to create positive
  calcium balance necessary to maintain
  homeostasis.
• To balance out the increased phos from skeletal
  effects, and GIT effects of calcitriol, PTH acts
  secondarily to increase renal phos excretion
• By decreasing activity of sodium phosphate
  co-transporter in prox renal tubule.

14
Uraemic Secondary Hyperparathyroidism

• Cause PO4 retention
• Low 1,25 Vit D synthesis
• Effects Proximal weakness, Bone pain (late)
• ?Alk Phos, bone erosions
• Rx Diet, PO4 binders
• Calcitriol, PTHx (usually for 3o)

15
Secondary hyperparathyroidism

• In renal failure driven by
• Hypocalcaemia
• Decreased vitamin D
• hyperphosphataemia

16
?PO4
?Ca
?GFR
?1,25 DHCC
?PTH
Calcitriol
17
(No Transcript)
18
hyperPTH in CKD

• In CKD is a progressive disorder.
• Involves both increased secretion PTH
  hyperplasia
• Can occur once eGFR lt 60
• PTH levels increase progressively as renal
  function declines and by CKD stage 5(lt15) most
  pts expected to have this.
• Usually the 1st sign and occurs before lab tests
  pick up ? phosphatemia, ? Vit D3 and ? calcium
• Presumably as PTH is maintaining homeostasis.
• Unless treated, progresses and frequency of
  parathyroidectomy proportional to yrs on dialysis

19
Overview

• Pathogenesis
• Normal Bone Remodeling
• Hyperparathyroidism
• Classifications of bone disease in CKD

20
Classification of Bone Disease in CKD

• The circulating level of PTH is primary
  determinant of bone turnover in CKD
• Type of bone disease depends upon
• Age of pt
• Duration of kidney failure
• Severity of hyperPTH
• Type of dialysis
• PTH Vit D receptors, as well as calcium sensors
  are present on osteoblasts

21
(No Transcript)
22
Types of Renal Bone Disease

• Traditionally classified according to degree of
  abnormal bone turnover
• High Turnover (osteitis fibrosa)
• Hyperparathyroidism
• Low turnover
• Adynamic - Osteomalacia
• Beta 2 MG amyloidosis
• Osteoporosis
• Post-menopausal - Post-transplant

23
Uraemic Bone Remodelling Cycle
Accelerates High PO4 or Low Ca2, Vit D3,
Resorption osteoclasts
Formation osteoblasts ? matrix
Mineralisation
Quiescence
Retards Vit D3, Age, Diabetes, Al3, PTHx
24
Uraemic Bone Remodelling Cycle
Accelerates High PO4 or Low Ca2, calcitriol,
HCO3, oestrogen
Via PTH, IL-1,6 TNF
Resorption osteoclasts
Formation osteoblasts ? matrix
Mineralisation
Quiescence
Retards Calcitriol, Age, Diabetes, Al3, PTHx
Acts via osteoblasts
25
High turn over bone disease

• Due to excess PTH
• Increased bone turnover activity (greater number
  of osteoclasts and osteoblasts) and defective
  mineralization.
• Associated with bone pain and increased risk of
  fractures.
• Severe symptomatic disease is currently uncommon
  with modern therapy.

26
Mixed uraemic bone disease

• Mixture of high turn over bone disease and
  osteomalacia

27
Osteomalacia

• Formally linked to aluminium toxicity
• From aluminium based phosphate binders
• From contamination of water in diasylate solutions

28
Adynamic bone disease

• Characterized by low osteoblastic activity and
  bone formation rates
• Seen in up to 40 HD and 50 PD
• May be due to excess suppression of the
  parathyroid gland with therapies, particularly
  calcium-containing phosphate binders and vitamin
  D analogues.
• Typically maintain a low serum intact PTH
  concentration, which is frequently accompanied by
  an elevated serum calcium level.
• Felt to represent a state of relative
  hypoparathyroidism

29
Clinical manifestations of bone disease

• Most with CKD and mildly elevated PTH are
  asymptomatic
• When present classified as either
• Musculoskeletal
• Extra-skeletal

30
Musculoskeletal

• Fractures, tendon rupture and bone pain from
  metabolic bone disease, muscular pain and
  weakness.
• Most clinically significant is hip fracture, seen
  in CKD 5 (and is associated with increase risk of
  death)
• NB. In dialysis pts there is already a 4.4 x
  increase risk of hip fracture.

31
Extra-skeletal

• Important to recognise disordered bone and
  mineral metabolism is a systemic disorder
  affecting soft tissues, particularly vessels,
  heart valves and skin.
• CVD accounts for around half of all deaths of
  dialysis patients.
• Coronary artery and vascular calcifications occur
  frequently in CKD 5 (and increase each year on
  dialysis)

32
Types of calcification

• Focal calcification associated with lipid laden
  atherosclerotic plaques
• Increases fragility and risk of plaque rupture
• Diffuse calcification
• not in atherosclerotic plaques and occurs in
  media of vessels
• Called Monckebergs sclerosis
• Increases blood vessel stiffness and reduces
  vascular compliance
• Results in widened pulse pressure
• Increased afterload
• LVH
• Contributing to CVD morbidity

33
(No Transcript)
34

• As per Cherelle If we X-Ray most of our
  patients, theyve got tram tracks we hardly
  need an angiogram!

35
Types of calcification

• Calciphylaxis or calcemic uremic arteriopathy
• Seen primarily in CKD 5
• Occurs in 1-4 of dialysis patients
• Presents with extensive calcification of the
  skin, muscles and SC tissues.
• Extensive medial calcification of small arteries,
  arterioles, capillaries and venules.
• Clinically they may have skin nodules, skin
  firmness, eschars, livedo reticularis and painful
  hyperaesthesia of the skin.
• May lead to non healing ulcers and gangrene

36
calciphylaxis

• A, Confluent calf plaques (borders shown with
  arrows). Parts of the skin are erythematous,
  which is easily confused with simple cellulitis.
  B, Gross ulceration in the same patient 3 months
  later. The black eschar has been surgically
  débrided. C, Calciphylactic plaques, a few of
  which are beginning to ulcerate. (Photographs
  courtesy of Dr. Adrian Fine. Up To Date)

37
Angulated black eschar with surrounding livedo.
Note the bullous change at the inferior edge of
the eschar. (courtesy Up To Date)
38
Amyloidosis

• Pts on dialysis for 7- 10 years can develop
  osteoarticular amyloid deposits.
• May present with carpel tunnel syndrome and
  arthritis

39
Overview

• Pathogenesis
• Normal Bone Remodeling
• Hyperparathyroidism
• Classifications of bone disease
• Diagnosis of bone disease

40
Diagnosis of CKD bone disease

• Blood
• PTH
• Random circulating PTH (1/2 life 2-4 mins)
• Excreted renally so present for longer in RF
• Calcium
• Phosphate
• Bone biopsy
• no longer frequently performed
• Imaging
• In general not indicated

41
PTH levels

• Normal (Pathwest) 0.7 7.0 pmol/L
• In CKD there is end-organ resistance
• Hence, recommended levels are 2 3 x normal.

42
Overview

• Pathogenesis
• Normal Bone Remodeling
• Hyperparathyroidism
• Classifications of bone disease
• Diagnosis of bone disease
• Treatment of bone disease in CKD

43
Treatment of CKD bone disease

• Directed towards normalising serum calcium,
  phosphate and PTH, while minimizing the risks
  associated with Rx

44
Treatment of CKD bone disease

• Various Rx for secondary hyperPTH and
  hyperphosphataemia include
• Dietary phosphorous restriction
• Calcium and non-Ca phosphate binders
• Calcitriol or other Vit D analogues
• Calcimimetics
• Parathyroidectomy

45
?Coke dairy food
CaCO3 with meals
?PO4
?Ca
?GFR
?1,25 DHCC
?PTH
Calcitriol
46
Phosphorus (oxidized form is phosphate)

• 80 in the bone
• Food products include nuts, beer, chocolate,
  coca-cola
• Normal level 0.8 1.5mmol/L (Pathwest)
• Passes into glomerular filtrate and 90
  reabsorbed
• Reabsorption decreased by PTH and by calcitonin
  and increased if PTH is absent
• Low levels if hyperparathyroidism with excessive
  losses in urine
• High levels in hypoparathyroidism or renal failure

47
Phosphate binders

• Calcium-based phosphate binders
• Calcium carbonate (Cal-Sup/Caltrate)
• Only Cal-Sup i PBS/S100
• Varies, eg. 1 BD, 1-4 TDS
• Must be chewed with food to maximize binding of
  ingested phosphorous.

48
Phosphate binders

• Non-calcium phos binder
• Sevelamer (available for 12 months)
• Often used in conjunction with Cal-sup
• Used when phos still high despite max Cal-Sup (2
  TDS)
• More costly

49
Phosphate binders

• Aluminium-containing phos binders
• Alu-tabs/aluminium hydroxide
• Most effective, but ceaesd use around 12 months
  ago when sevelamer and cinacalcet available.
• Systemic absorption with subsequent neurological,
  haematological and bone toxicity.

50
Calcitriol

• 1,25-(OH)2 Vitamin D3 or other analogues bind to
  receptor on PT tissue and suppress PTH production

51
?PO4
?Ca
?GFR
?1,25 DHCC
?PTH
Calcitriol
52
Calcitonin

• Produced by parafollicular or C cells of the
  thyroid gland
• Secreted when plasma calcium level rises
• Main action is the lowering of plasma calcium by
  limiting bone resorption and it increases
  phosphate excretion in the urine

53
Calcimimetics

• Calcium receptor-sensing agonists
• Act on PT gland and increase sensitivity of
  receptor to calcium
• Cinacalcet (Sensipar)
• Significant decrease PTH, w/o ? Ca or phos
• Avoids calcification

54
?PO4
?Ca
?GFR
?1,25 DHCC
?PTH
Calcitriol
55
Parathyroidectomy

• Last option
• Considered when other methods fail to ? PTH
• Either total or sub-total
• Used to re-implant in forearm.

56
Summary of Rx

• Dietary phosphate restriction
• Phosphate binders
• Calcitriol or other Vit D analogues
• Calcium supplementation/calcimimetics
• Parathyroidectomy

57
Prevention of osteodystrophy
?Coke dairy food
CaCO3 with meals
?PO4
?Ca
?GFR
?1,25 DHCC
?PTH
Calcitriol
58
Transplant

• Bony changes improve post Tx, but if severe
  increased PTH, levels can persist for up top 10
  years.
• Although Tx corrects many conditions leading to
  disordered mineral metabolism,
• Steroids may lead to bone fragility, osteoporosis
  and increased fractures.

59
Case Studies
60
Case 1

• MC
• Diabetic nephropathy Haemodialysis
• Hypothyroidism
• Pancreatic pseudocyst
• Epilepsy
• Anaemia
• Hypertension

61
Case 1

• Currently PTH 104
• Ca corrected 2.04
• Po4 1.77
• Medications
• Calcium carbonate 2 three times with meals
• Calcitriol 1mic 3 times a week

62
Case 1

• What do we do?
• Thoughts?

63
Case 1

• This lady is non compliant!
• No point changing her regime if she is not taking
  what you have written up
• Encourage compliance
• Explain the essential nature of compliance with
  this therapy

64
Case 2

• RJ
• Diabetes
• Anaemia
• Dementia
• Alcoholism
• End stage kidney disease CAPD
• IHD/cardiomyopathy recent massive AMI
• Syphilis

65
Case 2

• PO4 3.77
• Ca 1.82
• Product 6.86
• PTH 166
• Thoughts?

66
Case 2

• Again non compliance
• Recent finding of around 20 webster packs in his
  room

67
Case 3

• DB
• Diabetes
• End stage kidney disease HD
• Hypothyroidism
• Hypertension
• Anaemia
• Recurrent laryngeal palsy
• IHD
• Constipation
• Depression
• Cerebrovasvcular disease

68
Case 3

• Ca 2.72
• PO4 1.39
• PTH 20.1
• Product 3.7
• Thoughts?

69
Case 3

• Has had parathyroidectomy (hence the recurrent
  laryngeal palsy) and parameters are exactly where
  we want them
• Meds
• Calsup 2 tds with food
• Calcitriol 6 (1.5mics) twice a week at dialysis

70
Case 4

• ID
• Usual litany of problems
• HD
• Po4 1.0
• Ca 2.6
• PTH 3.1
• Thoughts?

71
Case 4

• Oversuppressed
• Need the PTH to be 2-3 times normal or patient
  will likely get adynamic bone disease
• Back off Vit D and Calcium
• In this case pt was on Calsup 2 tds and
  Calcitriol 6 (1.5mics) twice a week. Decrease
  Calcitriol eg 1.5mics once a week and decrease
  Calsup to 1 tds
• Monitor

72
Thank you!

• renalgp_at_kamsc.org.au

73
Calcium and Phosphorus Homeostasis

74
References

• Dr Mark Thomas, Nephrologist, Royal Perth
  Hospital
• Primer on Kidney Diseases, 5th Edition.
  Greenberg, National Kidney Foundation. 2009
