Project Management

1
Project Management

• Risk Management

2
Outline

• Introduction
• Definition of Risk
• Tolerance of Risk
• Definition of Risk Management
• Certainty, Risk, and Uncertainty
• Risk Management Process
• Risk Planning
• Risk Assessment
• Risk Identification

3
Outline

• Risk Analysis
• The Monte Carlo Process
• Risk Handling
• Selecting the Appropriate Response Mechanism
• Risk Monitoring
• Some Implementation Considerations
• The Use of Lessons Learned
• Dependencies between Risks
• The Impact of Risk Handling Measures
• Risk and Concurrent Engineering

4
Basic Concept

• Risk management focuses on
• Known unknowns
• Proactive management

5
The alternative to proactive management is
reactive management, also called crisis
management. This requires significantly more
resources and takes longer for problems to
surface.
Basic Concept
6
Risk Management

• Risk management focuses on the future
• Risk and information are inversely related

7
Risk Management (CONT.)

• Historically, we focused our attentions on
  schedule and cost risk management.
• Today, our primary emphasis is on technological
  risk management
• Can we design it and build it?
• What is the risk of obsolescence?

8
Definition Of Risk(1/2)
Risk f(Likelihood, Impact)
event

• Likelihood is the probability of occurrence
• Impact is the amount at stake

9
Definition of Risk(2/2)
Risk f(Hazard, Safeguard)
10
Risk is a Function of its Components
11
Tolerance For Risk

• Risk avoider
• Risk neutral
• Risk lover

12
Risk Types
13
Definition of Risk Management

• Risk management is the act or practice of dealing
  with risk.
• It includes
• planning for risk,
• assessing risk issues,
• developing risk handling strategies, and
• monitoring risk to determine how they have
  changed.

14
Decision-Making Categories

• Complete uncertainty
• Relative uncertainty (partial information)
• Complete certainty

15
Developing and Using Payoff Tables
Establishing the procedure to follow
Construct the Payoff table
Decision-making under complete uncertainty
Decision-making under risk
Decision-making under certainty
Maximin Approach Maximax Approach Minimax regret
Approach Insufficient Reason Approach
Expected Monetary Value (EMV) Approach Expected
Opportunity Loss (EOL) Approach Expected Value of
Perfect Information (EVPI) Approach
16
Five Steps To Develop Payoff Table

• List all the alternatives.
• List the future consequences of each alternative.
• Identify the payoffs associated with each
  combination.
• Assess the degree of certainty that these
  combinations will materialize
• Decide on a decision criterion.

17
Decision-Making under Certainty(1/2)

• A company wish to invest 50 M to develop a new
  product
• Three possible demand
• Strong, Even, and Low
• Three ways or not to develop product
• A, B, and C

18
Decision-Making under Certainty(2/2)
Note 1. Profit in Million 2. S3 is the best
regarding how market is
19
Decision-Making under Risk (1/2)

• A company wish to invest 50 M to develop a new
  product
• Three possible demand
• Strong, Even, and Low
• Three ways or not to develop product
• A, B, and C
• Probabilities are assigned to each possible state
  of nature

20
Decision-Making under Risk (2/2)
Note 1. E156, E252, and E366 2. S3 is the
best choice
21
Decision-Making under Uncertainty (1/9)

• Uncertainty
• Meaningful assignment of probabilities are not
  possible
• No single dominant strategy
• Maximax (Hurwicz)
• Maximin (Wald)
• Minimax (Savage)
• Laplace
• Decision Tree

22
Decision-Making under Uncertainty (2/9)

• Maximax (Hurwicz)
• Optimistic
• Choose the strategy with maximum profit
• Suitable for large company
• Choose S3 because maximum profit (100M) is S3

23
Decision-Making under Uncertainty (3/9)

• Maximin (Wald)
• Concerns how much he can afford to lose
• Pessimistic
• Suitable for small company
• Choose S2 because maximize the minimum payoff
  (50M) from 40, 50, -50

24
Decision-Making under Uncertainty (4/9)

• Minimax (Savage)
• Sore loser
• Minimize maximum regret
• Subtract all elements in each column from the
  largest element
• Maximum regret is the largest regret for each
  strategy
• Minimize the maximum regret
• Choose S2 or S2because minimize the maximum
  regret from 50, 50, 140

25
Decision-Making under Uncertainty (5/9)
26
Decision-Making under Uncertainty (6/9)

• Laplace
• Transform the decision making under uncertainty
  into decision making under risk
• Make priori assumption based on Bayesian
  statistics
• Assuming the probability for each strategy is 1/3
• Choose S1 because maximize the expected value
  from 60, 53.3, 43.3

27
Decision-Making under Uncertainty (7/9)
1/3
1/3
1/3
28
Decision-Making under Uncertainty (8/9)

• Decision Tree

29
Decision-Making under Uncertainty (9/9)

• Decision Tree Example

Direction of computation
30
Risk Management Processes

• Risk planning
• Risk assessment
• Risk identification
• Risk analysis/quantification
• Risk handling
• Risk monitoring

31
Risk Planning
Poor Risk Management
Customer Expectations
TechnicalInability
Actual Performance
32
Risk Assessment

• The problem definition stage of risk management
• Identify and analyze program issues in terms of
  probability and consequences

33
Life Cycle Risk Analysis
34
Types Of Risks (General)

• Business risks
• Insurable (pure) risk
• Direct property damage
• Indirect consequential loss
• Legal liability
• Personnel

35
Types Of Risk (PMI Method)

• External unpredictable
• External predictable
• Internal non-technical
• Internal technical
• Legal

36
Risk Types at Boeing

• Financial risks
• Market risks
• Technical risks
• Production risks

37
Risk Quantification
STAGE I
STAGE II
GUID-
WARHEAD
ANCE
PROGRAM
SUMMARY
DESIGN
LEGEND
TEST
HIGH
MANU.
MEDIUM
COST
LOW
38
Risk Handling

• Assumption (retention)
• Avoidance
• Control (mitigation)
• Transfer

39
Future Risks
Inexperienced
INCREASING RISKS
CustomersKnowledge
Experienced
Simple
Complex
Contract Type
40
How Much Risk Is Acceptable?

• High tolerance for risk
• Medium tolerance for risk
• Low tolerance for risk

41
Degrees of Downstream Risk
Low Risk
RD
Manufacturing
Marketing
Time
42
Degrees of Downstream Risk
Moderate Risk
RD
Information Exchange

Manufacturing
Marketing
Time
43
Degrees of Downstream Risk
High Risk
RD
Manufacturing
Marketing
Time
44
The Risk-Reward Matrix
45
Which Method to Use?
Project ProceduralDocumentation
Guidelines
High
Low
Tolerance for Risk
46
Prioritization of Risks
TechnicalPerformanceor Quality
Schedule
Cost
First (Highest)Priority
Second Priority
ThirdPriority
47
Risk Interdependencies
48
Interacting Risks
Desirable
Specification LimitOn Characteristic B
Product Feature A
Undesirable
Undesirable
Desirable
Product Feature B
49
Risk Categories at Boeing
50
Tolerance for Risk
51
Risk Control Measures
Extreme
StandardControls
Intensity of Controls
Low
High
Low
Risk Intensity
52
Investment in Risk Management
53
Risk Controls
TooLong
Appropriate
Schedule Length
Low
High
Risk Controls
