Module 6 Relational Algebra

1
Module 6Relational Algebra

• Teknik Informatika Fakultas Teknik
• Universitas Dr. Soetomo Surabaya

2
database Modules

• Module 1 Database Systems
• Module 2 Relational Model
• Module 3 Entity Relationship Model
• Module 4 ER to Relational Mapping
• Module 5 FDs and Normalization
• Module 6 Relational Algebra
• Module 7 SQL
• Module 8 Database Systems Architecture

3
Module 6 - Motivation

• A data model must also provide a set of
  operations to manipulate the data

• The relational data model provides a means of
  defining the database structure and constraints

Find the names and departments of all employees
who earn more than 55K Increment the salary of
all employees in the printing department by
10 What is the address of employee Jones
The basic set of relational model
operations constitute the Relational Algebra
4
Module 6 - Contents

• Relational Algebra
• What is a Relational Query
• Relational Query Languages
• Relational Algebra Operations
• Query Formulation in Relational Algebra
• Exercises in Relational Algebra

5
What is a Relational Query

• Data in a relational database can be manipulated
  in the following ways
• INSERT New tuples may be inserted
• DELETE Existing tuples may be deleted
• UPDATE Values of attributes in existing
  tuples
• may be changed
• RETRIEVE Attributes of specific tuples,
  entire
• tuples, or even entire relations may be
  retrieved
• Relational Query Languages should provide all of
  the above

6
Relational Query Languages

• Relational Queries are formulated in Relational
• Query Languages
• Relational Algebra (RA)
• Formal query language for a relational
  database
• Structured Query Language (SQL)
• Comprehensive, commercial query language with
• widely accepted international standard
• Query by Example (QBE)
• Commercial, graphical query language with
• minimum syntax

7
SQL and Relational Algebra

• SQL
• Declarative language
• Users specify what the result of the query
  should be, DBMS decides operations and orderof
  execution
• Operations
• Provides commands to create and modify
  database structure and constraints (DDL)
• Provides commands to insert, delete, update
  and retrieve (DML)

• RA
• Procedural language
• Algebraic expressions specify an order of
  operations ie. How the query will be processed
• Operations
• Provides operators, that enable a user to
  specify retrieval requests only

8
Module 6 - Contents

• Relational Algebra
• What is a Relational Query
• Relational Query Languages
• Relational Algebra Operations
• Query Formulation in Relational Algebra
• Exercises in Relational Algebra

9
Relational Algebra Operations

• Relational algebra operations are applied on
• relations
• Result of relational algebra operations are also
• relations, i.e the algebra operations produce
• new relations from old
• A sequence of relational algebra operations
• forms a relational algebra expression, whose
• result will also be a relation

10
Types of RA Operations

• Set operations from mathematical set theory
  (Applicable because each relation is also a set
  of tuples)
• UNION
• INTERSECTION
• DIFFERENCE
• CARTESIAN PRODUCT
• Operations developed specifically for RDBs
• SELECT
• PROJECT
• JOIN
• DIVISION

11
Operators and Notation

• Specific Database
• Operators
• Select s
• Project ?
• Join ?
• Division

• Traditional Set
• Operators
• Intersection n
• Union ?
• Difference
• Cartesian Product

12
Understanding RA Operations

• SELECT
• PROJECT
• Assignment and Naming
• UNION
• INTERSECTION
• DIFFERENCE
• Properties of operators
• CARTESIAN PRODUCT
• JOIN
• DIVISION

13
Select

• s lt selection condition gt ( lt relation name gt )
• Select those rows which satisfy a given condition
  This operation is also called restriction

Selected Tuples
14
Select Example

• 1. List all details of employees working in
• department 4?
• EMPLOYEE Ename, SSN, DOB, Address, Sex,
• Salary, SuperSSN, Dno
• s Dno 4 (EMPLOYEE)

15
Select Example

• 2. List all details of employees earning more
  than 30000?
• EMPLOYEE Ename, SSN, DOB, Address, Sex,
• Salary, SuperSSN, Dno
• s Salary gt 30000 (EMPLOYEE)

16
Select Example

• 3. List all details about employees who work in
• department 4 and earn over 25000, or work
• in department 5 and earn over 30000?
• EMPLOYEE Ename, SSN, DOB, Address, Sex,
• Salary, SuperSSN, Dno
• s (Dno 4 ? Salary gt 25000) ?
• (Dno 5 ? Salary gt 30000)
  (EMPLOYEE)

17
Project

• ? lt attribute list gt (lt relation name gt)
• Produce a new relation with only some of the
  attributes of the original relation. Duplicate
  tuples are eliminated in the result relation

Duplicated Tuples
18
Project Example

• 4. For each employee, list their name, date of
  birth and salary.
• EMPLOYEE Ename, SSN, Bdate, Address, Sex,
• Salary, SuperSSN, Dno
• ? Ename,Bdate,Salary (EMPLOYEE)

19
Project Example

• 5. List the salaries paid to employees in each
  department and the department number.
• EMPLOYEE Ename, SSN, DOB, Address, Sex,
• Salary, SuperSSN, Dno
• ? Dno, Salary (EMPLOYEE)

20
Handling Complex Queries

• Formulation of complex queries may require
• several relational algebra operations one after
• the other
• Operations can be written as a single
  relational
• algebra expression by nesting the operations
• Operations can be applied one at a time by
• creating intermediate result relations
• Intermediate Results have to be assigned to
• temporary relations which must be named

21
Relation Assignment and Naming

• Relation Assignment
• Result Relation ? Relational Expression
• Relation Naming
• TEMP ?
• Attribute (re)Naming
• TEMP (dept, emp-salary) ?

22
Assignment Example

• 6. Create a new relation named RESULT, containing
  each employee and their date of birth. Label the
  resulting columns with Employee and DOB.
• EMPLOYEE Ename, SSN, Bdate, Address, Sex,
• Salary, SuperSSN, Dno
• RESULT(Employee,DOB ) ? ? Ename,Bdate (EMPLOYEE)

23
Assignment Example

• 7. List the names and salaries of all employees
  who work for department 5
• EMPLOYEE Ename, SSN, Bdate, Address, Sex,
• Salary, SuperSSN, Dno
• ? Ename,Salary ( s Dno 5 (EMPLOYEE ) )
• EMPS - DEP5 ? s Dno 5 (EMPLOYEE )
• RESULT ? ? Ename,Salary (DEP5 - EMPS)

Query with Expression
Query with Intermediate Relations
24
Understanding RA Operations

• SELECT
• PROJECT
• Assignment and Naming
• UNION
• INTERSECTION
• DIFFERENCE
• Properties of operators
• CARTESIAN PRODUCT
• JOIN
• DIVISION

25
Basic Set Operators

• Relation is a set of tuples (no duplicates)
• Set theory, and hence elementary set
• operators also apply
• to relations
• UNION
• INTERSECTION
• DIFFERENCE
• CARTESIAN
• PRODUCT

A
B
A
B
A
B
26
Union Compatibility in Relations

• Two relations R(A1, A2, ..., An) and S(B1, B2,
• ..., Bn) are union compatible iff
• They have the same degree n, (number of
• columns)
• Their columns have corresponding domains, i.e
• dom(Ai) dom(Bi) for 1 i n
• Applies to union, intersection and difference

27
Union Compatibility

• Although domains need to correspond they do
• not have to have the same name
• WORKS_ON ESSN, Pno, Hours
• WORKED_ON Employee, Project, Duration
• where dom (ESSN) dom (Employee)
• dom (Pno) - dom (project)
• dom (Hours) dom (Duration)

28
Union

• R1 ? R2
• Produces a relation that includes all tuples that
  appear only in R1, or only in R2, or in both R1
  and R2
• Duplicate Tuples are eliminated
• R1 and R2 must be union compatible

29
Union Example

• 8.Identify the employees who both work on
  projects and also have dependents
• WORKS_ON ESSN, PNo, Hours
• DEPENDENT ESSN, Dep_Name, Sex, DOB,
• Relationship
• WORKS_ON ? DEPENDENT
• The relations are not UNION compatible !

30
Union Example

• 9.List the ESSNs of employees who either have
  dependents or work on projects.
• WORKS_ON ESSN, PNo, Hours
• DEPENDENT ESSN, Dep_Name, Sex, DOB,
• Relationship
• ? ESSN ( DEPENDENT ) ? ? ESSN (WORKS_ON )

31
Intersection

• R1 n R2
• Produces a relation that includes the tuples that
  appear
• in both R1 and R2.
• R1 and R2 must be union compatible.

32
Intersection Example

• 10. List the ESSNs of employees who have
• dependents and work on projects.
• WORKS_ON ESSN, PNo, Hours
• DEPENDENT ESSN, Dep_Name, Sex, DOB,
• Relationship
• ? ESSN ( DEPENDENT ) n ? ESSN (WORKS_ON )

33
Difference

• R1 - R2
• Produces a relation that includes all the tuples
  that
• appear in R1, but do not appear in R2.
• R1 and R2 must be union compatible.

34
Difference Example

• 11. List the ESSNs of employees who have
• dependents but do not work on projects.
• WORKS_ON ESSN, PNo, Hours
• DEPENDENT ESSN, Dep_Name, Sex, DOB,
• Relationship
• ? ESSN ( DEPENDENT ) ? ESSN (WORKS_ON )

35
Properties of Operators

• Commutative and Associative Operators
• Precedence among operators in relational
• algebra expressions
• De Morgans Laws

36
Commutative and Associative
37
Operator Precedence

• , ?, lt, gt, ,
• not
• and
• or
• s, ?
• n, ?, , , , ?
• Operators performed left to right in the
  expression
• ( ) can be used to alter operator precedence,
  that is operations in ( ) will be performed
  before even if they have a lower precedence order

38
Precedence Example

• List all employees who are male, and either
• earn less than 40000 or work for deptment
  5.
• EMPLOYEE Ename, SSN, DOB, Address, Sex,
• Salary, SuperSSN,
  Dnum
• ? Ename (s (Sex M and (Salary lt 40000 or Dnum
  5)) (EMPLOYEE ))
• How does the above solution differ from the
  following?
• ? Ename (s (Sex M and Salary lt 40000 or Dnum
  5) (EMPLOYEE ))

39
De Morgans Laws

• ( p ? q ) p ? q
• ( p ? q ) p ? q
• where p and q are predicates, e.g Agegt20,
• DeptResearch, e.g
• (Salary gt 40000) ? (Dept Research) )
• (Salary gt 40000) ? (Dept Research)

40
DeMorgans Law Example

• 13. List all projects which are neither located
  in
• Brisbane, nor controlled by department 4.
• PROJECT PName, PNo, Plocation, Dnum
• ? Pname(s not (Plocation Brisbane) and not
  (Dnum4) (PROJECT))
• ? Pname (s not (Plocation Brisbane or Dnum4)
  (PROJECT))
• ? Pname (s not (Plocation ltgt Brisbane and Dnum
  ltgt 4) (PROJECT))

41
Cartesian Product

• R1 R2
• Also known as a cross-product or cross-join R1
  and R2 need NOT be union compatible
• The result of R1 (A1, A2, An) x R2 (B1, B2,
  Bm) is a relation Q with n m attributes Q (A1,
  A2, An, B1, B2, Bm) in that order
• Q has one tuple for each combination of tuples
  from R1 and R2, thus if R1 has r tuples and R2
  has t tuples, then Q will have r t tuples

42
Cartesian Product Example


43
Cartesian Product Example

• 14. For each female employee, list the names
• of all of her dependents.
• EMPLOYEE Ename,SSN,DOB,Address,Sex,Salary,SuperSS
  N, Dno
• DEPENDENT ESSN, DepName, Sex, DOB, Relationship
• FEMALE_EMPS ? s Sex F (EMPLOYEE)
• EMP_NAMES ? ? Ename, SSN (FEMALE_EMPS)
• EMP_DEPEND ? EMP_NAMES DEPENDENT
• ACTUAL_DEPEND ? s SSN ESSN (EMP_DEPEND)
• RESULT ? ? Ename, DepName (ACTUAL_DEPEND)

44
Understanding RA Operations

• SELECT
• PROJECT
• Assignment and Naming
• UNION
• INTERSECTION
• DIFFERENCE
• Properties of operators
• CARTESIAN PRODUCT
• JOIN
• DIVISION

45
Join Operations

• A Join is similar to Cartesian Product, but only
  selected pairs of tuples appear in the result
• It is used to combine related tuples from two
  relations into a single tuple in a new relation.
  This is needed when information is contained in
  more than one relation
• There are three types of Join Operations
• Thieta-Join
• Equi-Join
• Natural Join

46
Thieta-Join

• R1 ? lt join conditiongt R2
• A join condition(s) is of the form A ? B,
  where A ? R1 and B ? R2,
• and ? is one of , ¹, lt, , gt,

47
Thieta-Join Example

• 15. For each employee, list all the employees who

• earn more (than the first employee).
• EMPLOYEE Ename, SSN, DOB, Address, Sex, Salary,
• SuperSSN, Dno
• DEPARTMENT DName, DNumber, MgrSSN, MgrStart
• A ? EMPLOYEE
• B ? EMPLOYEE
• RESULT ? ? A.Ename, B.Ename (A? A.Salary lt
  B.Salary B)

48
Equi-Join

• R1 ? lt join conditiongt R2
• Specialization of Join
• Join condition only has equality comparisons only

49
Equi-Join Example

• 16. List the names of the managers of each
• department.
• EMPLOYEE Ename, SSN, DOB, Address, Sex, Salary,

• SuperSSN, Dno
• DEPARTMENT DName, DNumber, MgrSSN, MgrStart
• DEPT_MGR ? DEPARTMENT ? MGRSSN SSN EMPLOYEE
• RESULT ? ? Ename (DEPT_MGR)

50
Natural Join

• R1 R2
• Similar to equi-join except that the attributes
  that are used for the join are those that have
  the same name in each relation
• Consequently, they are not explicitly specified
• The duplicate column is eliminated

51
Natural Join Example


52
Natural Join Example

• 17. What is the result schema of the following
• query? What attributes is the join
  performed
• on?
• DEPARTMENT DName, DNumber, MgrSSN, MgrStart
• DEPT_LOCS DNumber, Dlocation
• DEPARTMENT DEPT_LOCS

53
Natural Join Example

• 18. What is the difference between the results of

• the following queries? What attributes are
  the
• joins performed on?
• EMPLOYEE Ename, SSN, DOB, Address, Sex, Salary,
  SuperSSN, Dno
• DEPARTMENT DName, DNumber, MgrSSN, MgrStart
• EMPLOYEE DEPARTMENT
• and
• EMP(MgrSSN ,Dnumber) ? ? SSN,Dno (EMPLOYEE)
• RESULT ? EMP DEPARTMENT

54
Division

• R1 R2
• Result relation contains columns in R1, but not
  in R2
• Relations R1 and R2 must be division compatible,
  i.e last n columns of R1 must be identically
  named to columns in R2, where n is the degree of
  R2
• The result relation contains tuples t, such that
  a value in t appears in R1, in combination with
  every tuple in R2

55
Division Example


56
Division Example

• 22. Retrieve the names of employees who work on
• all projects that John Smith works on.
• EMPLOYEE Ename, SSN, DOB, Address, Sex, Salary,
  SuperSSN, Dno
• WORKS_ON ESSN, Pno, Hours
• SMITH ? s EnameJohn Smith (EMPLOYEE)
• SMITH_PNOS ? ? Pno (WORKS_ON ? ESSNSSN SMITH)
• SMITH_PNOS ? ? ESSN, Pno (WORKS_ON)
• SMITH_PNOS ? SSN_PNOS SMITH_PNOS
• RESULT ? ? Ename (SSNS EMPLOYEE)

57
Module 6 - Contents

• Relational Algebra
• What is a Relational Query
• Relational Query Languages
• Relational Algebra Operations
• Query Formulation in Relational Algebra
• Exercises in Relational Algebra

58
Query Formulation in RA

• Understand what the English query means
• Identify which relations, tuples (SELECT) and
  attributes (PROJECT) that will be required for
  the query
• Identify the relationships between required
  relations and accordingly which binary operators
  can be used
• (JOIN, PRODUCT, UNION, DIVISION, )
• Formulate the query keeping in mind operator
  properties (Commutative/Associative, Order
  precedence, De Morgans Laws)

59
Which RA Operator to use ?

• Use unary operators SELECT / PROJECT when
  choosing tuples / attributes respectively froma
  single relation
• Use binary operators UNION, PRODUCT, JOIN, when
  defining the relationship between 2 or more
  relations

• SELECT ?
• PROJECT ?
• UNION ?
• INTERSECTION
• DIFFERENCE ?
• CARTESIAN PRODUCT ?
• JOIN
• DIVISION

s ? ? Complete Set of Operations
60
Complete Set of RA Operators

• It has been proved that s, ?, ?, , is a
  complete set of RA operators
• Each remaining relational algebra operator can be
  expressed as a sequence of operations from this
  set
• These remaining operators have been defined
• primarily for convenience !

61
Expressing other operators

• Intersection
• R n S ( R ? S ) (( R S ) ? ( S R )
• (Thieta/Equi) Join
• R ltconditiongt S s ltconditiongt ( R S)
• Natural Join
• R1 (B1, A2, A3, . . . An) ? ? (A1, A2, A3, . .
  . An) R
• R S ? (B1, A2, A3, ... An, B2, ... Bm) s
  ltR.B1 S.B1gt( R1S)

62
Expressing other operators

• Division
• T1 ? ? Y ( R )
• T2 ? ? Y ( ( S T1 ) R )
• R S T1 T2

63
Module 6 - Contents

• Relational Algebra
• What is a Relational Query
• Relational Query Languages
• Relational Algebra Operations
• Query Formulation in Relational Algebra
• Exercises in Relational Algebra

64
Relational Algebra Exercises

• These exercises use the Company database as an
  example to illustrate relational algebra queries
  that require the use of multiple relational
  algebra operators
• EMPLOYEE Ssn, Fname, Mit, Lname, Dob, Address,
  Sex,
• Salary, Dno, SuperSSN
• DEPARTMENT Dnumber, Dname, MGRSSN,MgrStart
• PROJECT Pno, PName, Plocation, DNum
• DEPENDENT ESSN,DepName, Sex, DOB, Relationship
• WORKS_ON ESSN, PNo, Hours
• DEPT_LOCS DNumber, DLocation

65
RA Exercise

• 23. Retrieve the name and address of all
  employees
• who work for the Research Department.
• EMPLOYEE Ename, SSN, DOB, Address, Sex, Salary,
  SuperSSN, Dno
• DEPARTMENT Dname, Dnumber, MgrSSN, MgrStart
• RESEARCH_DEPT ? s DnameResearch (DEPARTMENT)
• RESEARCH_DEPT_EMPS ? (RESEARCH_DEPT? DnumberDno
  EMPLOYEE)
• RESULT ? ? Ename,Address (RESEARCH_DEPT_EMPS)

66
RA Exercise

• 24. For every project located in Ipswich, list
  the project
• number, the controlling department number,
  and the
• department managers name, address birth
  date.
• EMPLOYEE Ename, SSN, DOB, Address, Sex, Salary,
  SuperSSN, Dno
• DEPARTMENT Dname, Dnumber, MgrSSN, MgrStart
• PROJECT PName, Pnumber, Plocation, Dnum
• IPSWICH_PROJS ? s Plocationipswich (PROJECT)
• CONTR_DEPT ? (IPSWICH_PROJS ? DnumDnumber
  DEPARTMENT)
• PROJ_DEPT_MGR ? (CONTR_DEPT? MgrSSNSSN EMPLOYEE)
• RESULT ? ? Pnumber,Dnum,Ename,Address,Bdate
  (PROJ_DEPT_MGR)

67
RA Exercise

• 25. Find the names of employees who work on all
• projects controlled by department 5.
• EMPLOYEE Ename, SSN, DOB, Address, Sex, Salary,
  SuperSSN, Dno
• PROJECT PName, Pnumber, Plocation, Dnum
• WORKS_ON ESSN, Pno, Hours
• DEPT5_PROJS(Pno) ? ? Pnumber (s Dnum5 (PROJECT))
• EMP_PROJ(SSN,Pno) ? ? ESSN,Pno (WORKS_ON)
• RESULT_EMP_SSNS ? EMP_PROJ DEPT5_PROJS
• RESULT ? ? Ename (RESULT_EMP_SSNS EMPLOYEE )

68
RA Exercise

• 26. List project numbers for projects that
  involve an employee
• whose name is Smith, either as a worker or
  as a manager of
• the department that controls the project.
• EMPLOYEE Ename, SSN, DOB, Address, Sex, Salary,
  SuperSSN, Dno
• PROJECT PName, Pnumber, Plocation, Dnum
• DEPARTMENT Dname, Dnumber, MgrSSN, MgrStart
• WORKS_ON ESSN, Pno, Hours
• SMITHS(ESSN) ? ? SSN (s EnameSmith (EMPLOYEE))
• SMITH_WORKER_PROJS ? ? Pno (WORKS_ON SMITHS)
• MGRS ? ? Ename,Dnumber (EMPLOYEE ? SSNMgrSSN
  DEPARTMENT)
• SMITH_MGRS ? s EnameSmith (MGRS)
• SMITH_MANAGED_DEPTS(Dnum) ? ? Dnumber
  (SMITH_MGRS)
• SMITH_MGR_PROJS(Pno) ? ? Pnumber
  (SMITH_MANAGED_DEPTS PROJECT)
• RESULT ? SMITH_WORKER_PROJS ? SMITH_MGR_PROJS

69
RA Exercise

• 27. Retrieve the names of employees who have no
• dependents.
• EMPLOYEE Ename, SSN, DOB, Address, Sex, Salary,
  SuperSSN, Dno
• DEPENDENT ESSN, Dep_Name, Sex, DOB,
  Relationship
• ALL_EMPS ? ? SSN (EMPLOYEE)
• EMPS_WITH_DEPS(SSN) ? ? ESSN (DEPENDENT)
• EMPS_WITHOUT_DEPS ? ( ALL_EMPS EMPS_WITH_DEPS)
• RESULT ? ? Ename (EMPS_WITHOUT_DEPS EMPLOYEE )

70
RA Exercise

• 28. List the names of managers who have at least
• one dependent.
• EMPLOYEE Ename, SSN, DOB, Address, Sex, Salary,
  SuperSSN, Dno
• DEPARTMENT Dname, Dnumber, MgrSSN, MgrStart
• DEPENDENT ESSN, Dep_Name, Sex, DOB,
  Relationship
• MGR(SSN) ? ? MgrSSN (DEPARTMENT)
• EMPS_WITH_DEPS(SSN) ? ? ESSN (DEPENDENT)
• MGRS_WITH_DEPS ? (MGRS n EMPS_WITH_DEPS)
• RESULT ? ? Ename (MGRS_WITH_DEPS EMPLOYEE)

71
Module 6 - Review

• Relational algebra gives the theoretical
  foundations for Relational Query Languages
• Relational algebra operations operate on
  entire relations,
• and produce results which are also
  relations
• Relational algebra expressions, consisting of
  a sequence
• of relational algebra operators, specify a
  high-level
• procedure to achieve a query result
• However, relational algebraic query formulation
  is procedural, and therefore focuses on how a
  query result can be achieved
• Declarative query languages, e.g., SQL, allow the
  user to specify what info the user wants rather
  than how the result is to be obtained

72
Recommended Readings

• Elmasri Navathe
• Chapter 7

73
Next ...

• Module 7
• Structured Query
• Language (SQL)
