CD4MCu PUMP PROGRAM APPLICATIONS

1
CD4MCu PUMP PROGRAM APPLICATIONS
System One
2
CD4MCu

• DUPLEX SS (TWO PHASE METALLURGY WHERE 316 IS ONLY
  ONE)
• 300 SERIES FOR CORROSION RESISTANCE
• 400 SERIES FOR STRENGTH AND HARDNESS
• CORROSION RESISTANCE EQUAL TO OR BETTER THAN
  316SS
• DOUBLE THE YIELD STRENGTH OF 316SS
• EXCELLENT RESISTANCE TO ABRASION AND EROSION

2
3
CD4MCu

• EXCELLENT RESISTANCE TO
• PITTING AND CREVICE CORROSION
• STRESS CORROSION CRACKING IN CHLORIDE CONTAINING
  SOLUTIONS OR VAPORS
• SODIUM CHLORIDE - BRINE
• CALCIUM CHLORIDE
• METHYLENE CHLORIDE
• SEA WATER

3
4
CD4 APPLICATIONS

• BLACK LIQUOR IN PAPER MILLS
• WOOD DIGESTION
• SATURATED SOLN. SODIUM SULFATE AND SODIUM
  CARBONATE
• CORROSIVE BLEACHES AND DYES
• FERTILIZER PRODUCTION
• PHOSPHATE AND PHOSPHORIC ACID

4
5
CD4 APPLICATIONS..cont.

• FATTY ACIDS WITH SOLIDS
• LIME SLURRIES
• NITRIC ACID
• LESS THAN 1 MM/YR CORROSION FOR ALL
  CONCENTRATIONS
• UNDER 200 OF
• LESS THAN 60 CONCENTRATION

5
6
CD4 APPLICATIONSSULFURIC ACID

• 0-20 CONCENTRATION AT 140-160 OF
• 0-10 CONCENTRATION AT 185 OF
• TITANIUM DIOXIDE PLUS SULFURIC ACID
• TITANIUM SULFATE

6
7
CD4 IN SYSTEM ONE PUMPS

• CAVITATION CORROSION OCCURS WHEN LOW NPSH ALLOWS
  THE FORMATION OF VAPOR BUBBLES ON THE IMPELLER
• EXPLOSIVE FORCE OF BUBBLES RUPTURING
• REMOVE PROTECTIVE FILM OF SS LEADING TO
  CORROSION
• CAN REMOVE SMALL AMOUNTS OF METAL
• SYSTEM ONE PUMPS USE CD4 IMPELLERS TO WITHSTAND
  THE FORCES OF CAVITATION CORROSION AND EROSION
• GREATER HARDNESS, STRENGTH AND CORROSION
  RESISTANCE

7
8
CD4 IN SYSTEM ONE PUMPS..cont.

• CD4 BACKCOVERS AND CASINGS ARE AVAILABLE FOR
  EROSION AND ABRASION APPLICATIONS
• THE FACTORY WILL STOCK THE FRAME A
• 10 AND 13 IMPELLER SIZE WET ENDS
• PRICE IS GREATER DUE TO HIGHER CASTING COST AND
  SMALLER MACHINING QUANTITIES

8
