Study of Topographic and Equiprobable Mapping
with Clustering for Fault Classification

• Ashish Babbar
• EE645 Final Project

2
Introduction

• A typical control system consists of four basic
  elements
• Dynamic plant
• Controllers
• Actuators
• Sensors
• Any kind of malfunction in these components can
  result in unacceptable anomaly in overall system
  performance.
• They are referred to as fault in a control
  system. The Objective of fault detection and
  identification is to detect, isolate and identify
  these faults so that system performance can be
  recovered
• Condition Based Maintenance (CBM) is the process
  of executing repairs when objective evidence
  indicates need for such actions or in other words
  when anomalies or faults are detected in a
  control system.

3
Motivation

• Model based CBM can be applied when we have a
  mathematical model of the system to be monitored.

• When CBM needs to be performed based on just the
  data available from sensors, data driven
  methodologies are utilized for this purpose.
• SOM is widely used in data mining as a tool for
  exploration and analysis of large amounts of
  data.
• It can be used for data reduction or vector
  quantization so that we can analyze the system
  data for anomalies by using only the data
  clusters formed from the trained map instead of
  the large initial data sets.

4
Competitive Learning

• Assume a sequence of input samples v(t) in
  d-dimensional input space and a lattice of N
  neurons, labeled i 1,2,..,N and with the
  corresponding weight vectors
• wi(t) wij(t) .
• If v(t) can be simultaneously compared with each
  weight vector of the lattice then the best
  matching weight, for example wi can be
  determined and updated to match or even better
  the current input.
• As a result of the competitive learning,
  different weights will become tuned to different
  regions in the input space.

Output layer
i
i
v
V
Input layer
5
Self Organizing Maps

• SOM is an unsupervised neural network technique
  which finds application in
• Density estimation e.g. clustering or
  classification purposes
• Blind Source Separation
• Visualization of data sets
• It projects the input space on prototypes of
  low-dimensional regular grid that can be
  effectively utilized to visualize and explore
  properties of data.
• The SOM consists of a regular, two dimensional
  grid of map units (neurons).
• Each unit i is represented by a prototype vector
• wi(t) wi1(t), , wid(t) where d is
  input vector dimension

6
Self Organizing Maps (Algorithm)

• Given a data set the number of map units
  (neurons) is first chosen.
• The Map units can be selected to be approximately
  equal to vN to 5vN, where N is the number of data
  samples in the given data set.
• The SOM is trained iteratively. At each training
  step, a sample vector v is randomly chosen from
  the input data set.
• Distances between v and all prototype vectors are
  computed. The Best Matching Unit (BMU) or the
  winner, which is denoted here by b is the map
  unit with prototype closest to v.
• v wb
  mini v wi

7
Self Organizing Maps

• The BMU or winner and its topological neighbors
  are moved closer to the input vector in the input
  space
• wi(t1) wi(t) a(t)hbi(t)v-wi(t)
• t time
• a(t) adaptation coefficient
• hbi(t) neighborhood kernel centered on
  winner unit
• where rb and ri are positions of neurons b
  and i on the SOM grid. Both a(t) and s(t)
  decrease monotonically with time.

8
Clustering- The Two Level Approach

• Group the input data into clusters where the data
  is grouped into same cluster if its similar to
  one another.
• A widely adopted definition of clustering is a
  partitioning that minimizes the distances within
  and maximizes the distance between clusters.
• Once the neurons are trained the next step is
  clustering of SOM. For clustering of SOM the two
  level approach is followed.
• First a large set of neurons much larger than the
  expected number of clusters is formed using the
  SOM.
• The Neurons in the next step are combined to form
  the actual clusters using the k-means clustering
  technique .
• The number of clusters is K and number of Neurons
  is M.
• KltltMltltN

9
Two level Approach
Level 1
Level 2
Data Samples
K Clusters
M Prototypes of the SOM
N Samples
K lt M lt N
10
Advantage of using the two level approach

• The primary benefit is the reduction of
  computational cost. Even with relatively small
  number of data samples many clustering algorithms
  become intractably heavy.
• For e.g. By using two level approach the
  reduction of computational load is about vN /15
  or about six fold for N10,000 from the direct
  clustering of data using k-means
• Another benefit is noise reduction. The
  prototypes are local averages of data and
  therefore less sensitive to random variations
  than the original data.

11
K-means decision on number of clusters

• K-means algorithm was used at level 2 for
  clustering of the trained SOM neurons.
• K-means algorithm clusters the given data into k
  clusters where we define k.
• To decide the value of k one method is to run the
  algorithm from k2 to k vN where N is the
  number of data samples.
• K-means algorithm minimizes the error function
• Where C is the number of clusters and ck is
  the center of cluster k.
• The approach followed in this project was to pick
  the number of clusters as the value k which makes
  the error E 0.10E to 0.15E or 10 to 15 of E
  where E is the error when k2

12
Selection of number of clusters
13
Reference Distance Calculation

• The clusters thus formed using training/nominal
  data sets are used to calculate the reference
  distance (dRef).
• Knowing the cluster centers calculated from the
  k-means algorithm and the prototypes/Neurons
  which formed a particular cluster, we calculate
  the reference distance for each cluster.
• Reference distance specific to a particular
  cluster is equal to the distance between the
  cluster center and the prototype/Neuron belonging
  to this cluster that is at the maximum distance
  from this cluster center.
• Similarly the reference distance for each of the
  clusters formed from the nominal data set is
  calculated and serves as a base for fault
  detection.
• To classify the given data cluster as nominal or
  faulty this underlying structure of the initial
  known nominal data set is used.

14
Fault Identification

• The assumption made in this case is that the
  nominal data sets available which are used to
  form the underlying cluster structure spans the
  space of all information that is not faulty.
• The same procedure is then repeated for the
  unknown data sets (no idea if nominal or in
  fault) i.e. first the N data points are reduced
  to a mapping of M neurons and then clustered
  using k-means algorithm.
• Now taking the training data clusters as centers
  and knowing the reference distance for each
  cluster, we see if the clusters from the unknown
  data set are a member of the region spanned by
  the radius equal to the specific reference
  distance for that training cluster.
• Any unknown data set cluster which is not a part
  of the region spanned by taking the training data
  cluster as center and radius equal to reference
  distance for that cluster is termed as faulty.

15
Block Diagram
Mapping Algorithm
Training Data
Reference Distance
Clustering
N samples
K clusters
M Neurons
Mapping Algorithm
Unknown Data
Distance Deviation
Fault Identification
Clustering
N samples
M Neurons
K clusters
KltltMltltN
16
SOM Using Nominal data
17
Clustering of nominal data
18
SOM using Unknown data
19
Clustering of unknown data
20
Fault Identification
21
SOM Performance
22
Equiprobable Maps

• For Self Organizing feature maps the weight
  density at convergence is not a linear function
  of the input density p(v) and hence the neurons
  of the map will not be active with equal
  probabilities (i.e. the map is not
  equiprobabilistic).
• For a discrete lattice of neurons, the weight
  density will be proportional to
• Regardless of the type of neighborhood function
  used SOM tends to undersample the high
  probability regions and oversample the low
  probability regions

23
Avoiding Dead Units

• SOM algorithm converges to a mapping which yields
  neurons that are never active (dead units).
• These units do not contribute to the minimization
  of the overall (MSE) distortion of the map.
• To produce maps in which the neurons would have
  an equal probability to be active
  (Equiprobabilistic Maps) the idea of adding
  conscience to the winning neuron was introduced.
• Techniques of generating Equiprobabilistic Maps
  discussed are
• Conscience Learning
• Frequency Sensitive Competitive Learning (FSCL)

24
Conscience Learning

• When a neural network is trained with
  unsupervised competitive learning on a set of
  input vectors that are clustered into K
  groups/clusters then a given input vector v will
  activate neuron i that has been sensitized to
  the cluster containing the input vector.
• However if some region in the input space is
  sampled more frequently than the others, then a
  single unit begins to win all competitions for
  this region.
• To counter this defect, one records for each
  neuron i the frequency with which it has won
  competition in the past, ci, and adds this
  quantity to the Euclidean distance between the
  weight vector wi and the current input v.

25
Conscience Learning

• In Conscience learning two stages are
  distinguished
• First the winning neuron is determined out of the
  N units
• i
• Second, the winning neuron i is not necessarily
  the one that will have its weight vectors
  updated.
• Which neurons need to be updated depends on an
  additional term for each unit, which is related
  to the number of times the unit has won the
  competition in recent past.
• The rule of update is that for each neuron the
  number of times it has won the competition is
  recorded and a scaled version of this quantity is
  added to the distance metric used in minimum
  Euclidean distance rule

26
Conscience Learning

• Update rule
• With ci the number of times neuron i has won the
  competition, and C the scaling factor
  (Conscience Factor).
• After determining the winning neuron i its
  conscience is incremented
• The weight of the winning neuron is updated using
• where is the learning rate and its value
  is equal to small positive constant

27
Conscience learning using nominal data
28
Clusters shown with neurons
29
Clustering of nominal data
30
Conscience learning on new data set
31
Clustering of unknown data set
32
Clusters represented on data set
33
Fault Identification
34
Conscience learning Performance
35
Frequency Sensitive Competitive Learning

• Another competitive learning scheme which is used
  is the Frequency Sensitive Competitive Learning
• This learning scheme keeps a record of the total
  number of times each neuron has won the
  competition during training.
• The distance metric in the Euclidean distance
  rule is then scaled as follows
• After selection of winning neuron its conscience
  is then incremented and the weight vector updated
  using the UCL rule

36
FSCL using Nominal data
37
Clustering of nominal data
38
Clusters shown with neurons
39
FSCL using the unknown data set
40
Clustering using unknown data
41
Clusters of unknown data
42
Fault Identification
43
FSCL performance
44
Conclusions

• As shown in the results the performance of SOM
  algorithm was not as good as compared to the CLT
  and FSCL approaches.
• As SOM produces dead units even if the
  neighborhood function converges slowly so it was
  not able to train the neurons well according to
  the available data sets.
• Due to undersampling of high probability regions,
  SOM was able to detect only two faulty clusters
  out of the four and thus its performance was not
  good.
• Using CLT and FSCL approach all four faulty
  clusters were detected using the reference
  distance as the distance measure.
• Thus the equiprobable maps perform much better
  than the SOM by avoiding the dead units and
  training the neurons by assigning a conscience
  with the winning neuron

45
References

• Marc M. Van Hulle, Faithful Representations and
  Topographic maps From Distortion to Information
  based Self Organization, John Willey sons 2000
• T. Kohonen, Self Organizing Maps, Springer 1997
• Anil K. Jain and Richard C. Dubes, Algorithms
  for Clustering Data, Prentice Hall 1988
• Juha Vesanto and Esa Alhoniemi, Clustering of
  the Self Organizing Map, IEEE Trans. Neural
  Networks, Vol 11, No 3, May 2000

46
Questions/Comments ?
