Title: Synthesis of Embedded Software for Reactive Systems


1
Synthesis of Embedded Software for Reactive
Systems
  • Jordi Cortadella
  • Universitat Politècnica de Catalunya, Barcelona
  • Joint work with
  • Robert Clarisó, Alex Kondratyev, Luciano
    Lavagno, Claudio Passerone and Yosinori
    Watanabe (UPC, Cadence Berkeley Labs,
    Politecnico di Torino)

2
System Design
Platform provider (e.g. Semiconductor company)
MethodologyforPlatform-basedSystem Design
External IP provider(e.g. software modem)
Internal IP provider (e.g. MPEG2 engine)
Requirements specification, Testbench
Functional and performance models (with
agreed interfaces and abstraction levels)
3
Metropolis Project
etropolis
  • Goal develop a formal design environment
  • Design methodologies abstraction levels, design
    problem formulations
  • EDA formal methods for automatic synthesis and
    verification,
  • a modeling mechanism heterogeneous
    semantics, concurrency
  • Participants
  • UC Berkeley (USA) methodologies, modeling,
    formal methods
  • CMU (USA) formal methods
  • Politecnico di Torino (Italy) modeling, formal
    methods
  • Universitat Politècnica de Catalunya (Spain)
    modeling, formal methods
  • Cadence Berkeley Labs (USA) methodologies,
    modeling, formal methods
  • Philips (Netherlands) methodologies
    (multi-media)
  • Nokia (USA, Finland) methodologies (wireless
    communication)
  • BWRC (USA) methodologies (wireless
    communication)
  • BMW (USA) methodologies (fault-tolerant
    automotive controls)
  • Intel (USA) methodologies (microprocessors)

4
Metropolis Framework
Architecture Specification
Design Constraints
  • Metropolis Infrastructure
  • Design methodology
  • Meta model of computation
  • Base tools
  • - Design imports
  • - Meta model compiler
  • - Simulation

5
Outline
  • The problem
  • Synthesis of concurrent specificationsfor
    sequential processors
  • Compiler optimizations across processes
  • Previous work Dataflow networks
  • Static scheduling of SDF networks
  • Code and data size optimization
  • Quasi-Static Scheduling of process networks
  • Petri net representation of process networks
  • Scheduling and code generation
  • Open problems

6
Embedded Software Synthesis
  • Specification concurrent functional netlist
    (Kahn processes, dataflow actors, SDL processes,
    )
  • Software implementation (smaller) set of
    concurrent software tasks
  • Two sub-problems
  • Generate code for each task
  • Schedule tasks dynamically
  • Goals
  • minimize real-time scheduling overhead
  • maximize effectiveness of compilation

7
Environmental controller
Temperature
Humidity
ENVIRONMENTAL CONTROLLER
AC
Dehumidifier
Alarm
8
Environmental controller
TEMP-FILTER float sample, last last
0 forever sample READ(TSENSOR) if
(sample - last gt DIF) last sample
WRITE(TDATA, sample)
TSENSOR
HSENSOR
TEMP FILTER
HUMIDITY FILTER
HDATA
TDATA
CONTROLLER
AC-on
DRYER-on
ALARM-on
9
Environmental controller
TEMP-FILTER float sample, last last
0 forever sample READ(TSENSOR) if
(sample - last gt DIF) last sample
WRITE(TDATA, sample)
TSENSOR
HSENSOR
TEMP FILTER
HUMIDITY FILTER
HDATA
TDATA
HUMIDITY-FILTER float h, max forever h
READ(HSENSOR) if (h gt MAX) WRITE(HDATA, h)
CONTROLLER
AC-on
DRYER-on
ALARM-on
10
Environmental controller
CONTROLLER float tdata, hdata forever
select(TDATA,HDATA) case TDATA tdata
READ(TDATA) if (tdata gt TFIRE)
WRITE(ALARM-on,10) else if (tdata gt
TMAX) WRITE(AC-on, tdata-TMAX) case HDATA
hdata READ(HDATA) if (hdata gt HMAX)
WRITE(DRYER-on, 5)
TSENSOR
HSENSOR
TEMP FILTER
HUMIDITY FILTER
HDATA
TDATA
CONTROLLER
AC-on
DRYER-on
ALARM-on
11
Environ.
Processes
OS
Tsensor
T-FILTERwakes up
Operating system
T-FILTERexecutes
T-FILTERsleeps
Hsensor
H-FILTERwakes up
H-FILTERexecutes sends datato HDATA
H-FILTERsleeps
CONTROLLERwakes up
CONTROLLERexecutes reads datafrom HDATA
. . .
12
Compiler optimizations
  • Instruction level
  • Basic blocks
  • Intra-procedural(across basic blocks)
  • Inter-procedural
  • Inter-process ?
  • a b16 ? a b gtgt 4
  • common subexpr.,copy propagation
  • loop invariants,induction variables
  • inline expansion,parameter propagation
  • channel optimizations,OS overhead reduction

Each optimization enables further optimizations
at lower levels
13
Partial evaluation (example)
Specification subsets (n,k) n! / (k!
(n-k)!) __________________________________________
______ int subsets (int n, int k) return
fact(n) / (fact(k) fact(n-k)) int pairs
(int n) return subsets (n,2) ... print
(pairs(x1)) ... ... print (pairs(5)) ...
Partial evaluation (compiler optimizations)
14
Partial evaluation (example)
Specification subsets (n,k) n! / (k!
(n-k)!) __________________________________________
______ int subsets (int n, int k) return
fact(n) / (fact(k) fact(n-k)) int pairs
(int n) return subsets (n,2) ... print
((x1)x / 2) ... ... print (pairs(5)) ...
Partial evaluation (compiler optimizations)
15
Partial evaluation (example)
Specification subsets (n,k) n! / (k!
(n-k)!) __________________________________________
______ int subsets (int n, int k) return
fact(n) / (fact(k) fact(n-k)) int pairs
(int n) return subsets (n,2) ... print
((x1)x / 2) ... ... print (10) ...
16
Inter-process partial evaluation
forever n read (A) write (B,n)
write (C, n-2) write (D, 2)
A
forever x read (E) y read (F) z
read (G) write (H, x/(yz))
n
x!
x!
x!
H
pairs (n)
17
Inter-process partial evaluation
forever n read (A) write (B,n)
write (C, n-2) write (D, 2)
A
forever x read (E) y read (F) z
read (G) write (H, x/(yz))
x!
x!
x!
H
No chances for optimization
18
Inter-process partial evaluation
forever n read (A) write (B,n)
write (C, n-2) write (D, 2)
A
forever x read (E) y read (F) z
read (G) write (H, x/(yz))
x!
x!
x!
H
2...2
2...2
19
Inter-process partial evaluation
forever n read (A) write (B,n)
write (C, n-2) write (G, 2)
A
forever x read (E) y read (F) z
read (G) write (H, x/(yz))
x!
x!
H
2...2
2...2
20
Inter-process partial evaluation
forever n read (A) write (B,n)
write (C, n-2) write (G, 2)
A
forever x read (E) y read (F) z
read (G) write (H, x/(yz))
x!
x!
H
2...2
2...2
21
Inter-process partial evaluation
forever n read (A) write (B,n)
write (C, n-2) write (G, )
A
forever x read (E) y read (F)
read (G) write (H, x/(y2))
x!
x!
H
  • Copy propagation across processes
  • Channel G only synchronizes (token available)

22
Inter-process partial evaluation
forever n read (A) write (B,n)
write (C, n-2) write (G, )
A
forever x read (E) y read (F)
read (G) write (H, x/(y2))
x!
x!
H
By scheduling operations properly, FIFOs may
become variables (one element per FIFO, at most)
23
Inter-process partial evaluation
forever n read (A) v1 n v3
n-2
A
x v2 y v4 write (H,
x/(y2))
x!
v1
v2
x!
v3
v4
H
24
Inter-process partial evaluation
A
forever n read (A) v1 n
v2 fact (v1) x
v2 v3 n-2 v4 fact (v3)
y v4
write (H, x/(y2))
H
And now we can apply conventional compiler
optimizations
25
Inter-process partial evaluation
A
forever n read (A) x fact (n)
y fact (n-2) write (H, x/(y2))
H
If some clever theorem prover could realize
that fact(n) n(n-1)fact(n-2) the following
code could be derived ...
26
Inter-process partial evaluation
forever n read (A) write
(H,n(n-1)/2)
A
H
27
Inter-process partial evaluation
forever n read (A) write (B,n)
write (C, n-2) write (D, 2)
A
forever x read (E) y read (F) z
read (G) write (H, x/(yz))
x!
x!
x!
H
This was the original specification of the system
!
28
Inter-process partial evaluation
forever n read (A) write
(H,n(n-1)/2)
A
H
  • This is the final implementation after
    inter-process optimization
  • Only one process (no context switching overhead)
  • Channels substituted by variables (no
    communication overhead)

29
  • Goal improve performance, code size
    power consumption, ...
  • Reduce operating system overhead
  • Reduce communication overhead
  • How? Do as much as possible statically
    and automatically
  • Scheduling
  • Compiler optimizations

Operating system
TSENSOR
HSENSOR
TEMP FILTER
HUMIDITY FILTER
HDATA
TDATA
CONTROLLER
AC-on
DRYER-on
ALARM-on
30
Outline
  • The problem
  • Synthesis of concurrent specifications
  • Compiler optimizations across processes
  • Previous work Dataflow networks
  • Static scheduling of SDF networks
  • Code and data size optimization
  • Quasi-Static Scheduling of process networks
  • Petri net representation of process networks
  • Scheduling and code generation
  • Open problems

31
Dataflow networks
  • Powerful mechanism for data-dominated systems
  • (Often stateless) actors perform computation
  • Unbounded FIFOs perform communication via
    sequences of tokens carrying values
  • (matrix of) integer, float, fixed point
  • image of pixels, ..
  • Determinacy
  • unique output sequences given unique input
    sequences
  • Sufficient condition blocking read
  • (process cannot test input queues for emptiness)

32
A bit of history
  • Kahn process networks (58) formal model
  • Karp computation graphs (66) seminal work
  • Dennis Dataflow networks (75) programming
    language for MIT DF machine
  • Lees Static Data Flow networks (86) efficient
    static scheduling
  • Several recent implementations(Ptolemy, Khoros,
    Grape, SPW, COSSAP, SystemStudio, DSPStation,
    Simulink, )

33
Intuitive semantics
  • Example FIR filter
  • single input sequence i(n)
  • single output sequence o(n)
  • o(n) c1 i(n) c2 i(n-1)

i(-1)
i
? c1
? c2

o
34
Examples of Dataflow actors
  • SDF Static Dataflow fixed number of input and
    output tokens
  • BDF Boolean Dataflow control token determines
    number of consumed and produced tokens

1

1
1
T
F
select
merge
F
T
35
Static scheduling of DF
  • Key property of DF networks output sequences do
    not depend on firing sequence of actors (marked
    graphs)
  • SDF networks can be statically scheduled at
    compile-time
  • execute an actor when it is known to be fireable
  • no overhead due to sequencing of concurrency
  • static buffer sizing
  • Different schedules yield different
  • code size
  • buffer size
  • pipeline utilization

36
Balance equations
  • Number of produced tokens must equal number of
    consumed tokens on every edge (channel)
  • Repetitions (or firing) vector v of schedule S
    number of firings of each actor in S
  • v(A) np v(B) nc
  • must be satisfied for each edge

np
nc
A
B
37
Balance equations
A
2
3
2
1
1
1
B
C
1
1
  • Balance for each edge
  • 3 v(A) - v(B) 0
  • v(B) - v(C) 0
  • 2 v(A) - v(C) 0
  • 2 v(A) - v(C) 0

38
Balance equations
  • M v 0
  • iff S is periodic
  • Full rank (as in this case)
  • no non-zero solution
  • no periodic schedule
  • (too many tokens accumulate on A?B or B?C)

39
Balance equations
  • Non-full rank
  • infinite solutions exist (linear space of
    dimension 1)
  • Any multiple of v 1 2 2T satisfies
    the balance equations
  • ABCBC and ABBCC are minimal valid schedules
  • ABABBCBCCC is non-minimal valid schedule

40
Static SDF scheduling
  • Main SDF scheduling theorem (Lee 86)
  • A connected SDF graph with n actors has a
    periodic schedule iff its topology matrix M has
    rank n-1
  • If M has rank n-1 then there exists a unique
    smallest integer solution v to
  • M v 0

41
Deadlock
  • If no actor is firable in a state before reaching
    the initial state, no valid schedule exists
    (Lee86)

A
1
1
2
2
B
C
1
1
Schedule (2A) B C
42
Deadlock
  • If no actor is firable in a state before reaching
    the initial state, no valid schedule exists
    (Lee86)

A
1
1
2
2
B
C
1
1
Schedule (2A) B C
43
Deadlock
  • If no actor is firable in a state before reaching
    the initial state, no valid schedule exists
    (Lee86)

A
1
1
2
2
B
C
1
1
Schedule (2A) B C
44
Deadlock
  • If no actor is firable in a state before reaching
    the initial state, no valid schedule exists
    (Lee86)

A
1
1
2
2
B
C
1
1
Schedule (2A) B C
45
Deadlock
  • If no actor is firable in a state before reaching
    the initial state, no valid schedule exists
    (Lee86)

A
1
1
2
2
B
C
1
1
Schedule (2A) B C
46
Deadlock
  • If no actor is firable in a state before reaching
    the initial state, no valid schedule exists
    (Lee86)

A
1
1
2
2
B
C
1
1
Schedule (2A) B C
47
Compilation optimization
  • Assumption code stitching
  • (chaining custom code for each actor)
  • More efficient than C compiler for DSP
  • Comparable to hand-coding in some cases
  • Explicit parallelism, no artificial control
    dependencies
  • Main problem memory and processor/FU allocation
    depends on scheduling, and vice-versa

48
Code size minimization
  • Assumptions (based on DSP architecture)
  • subroutine calls expensive
  • fixed iteration loops are cheap
  • (zero-overhead loops)
  • Global optimum single appearance schedule
  • e.g. ABCBC ? A (2BC), ABBCC ? A (2B) (2C)
  • may or may not exist for an SDF graph
  • buffer minimization relative to single appearance
    schedules
  • (Bhattacharyya 94, Lauwereins 96, Murthy 97)

49
Buffer size minimization
  • Assumption no buffer sharing
  • Example
  • v 100 100 10 1T
  • Valid SAS (100 A) (100 B) (10 C) D
  • requires 210 units of buffer area
  • Better (factored) SAS (10 (10 A) (10 B) C) D
  • requires 30 units of buffer area, but
  • requires 21 loop initiations per period (instead
    of 3)

50
Scheduling more powerful DF
  • SDF is limited in modeling power
  • More general DF is too powerful
  • non-Static DF is Turing-complete (Buck 93)
  • bounded-memory scheduling is not always possible
  • Boolean Data Flow Quasi-Static Scheduling of
    special patterns
  • if-then-else, repeat-until, do-while
  • Dynamic Data Flow run-time scheduling
  • may run out of memory or deadlock at run time
  • Kahn Process Networks quasi-static scheduling
    using Petri nets
  • conservative schedulable network may be declared
    unschedulable

51
Outline
  • The problem
  • Synthesis of concurrent specifications
  • Compiler optimizations across processes
  • Previous work Dataflow networks
  • Static scheduling of SDF networks
  • Code and data size optimization
  • Quasi-Static Scheduling of process networks
  • Petri net representation of process networks
  • Scheduling and code generation
  • Open problems

52
Quasi-Static Scheduling
  • Sequentialize concurrent operations as much as
    possible
  • less communication overhead (run-time task
    generation)
  • better starting point for compilation
    (straight-line code from function blocks)
  • Must handle
  • data-dependent control
  • multi-rate communication

53
The problem
  • Given a network of Kahn processes
  • Kahn process sequential function ports
  • communication port-based, point-to-point,
    uni-directional, multi-rate
  • Find a single sequential task
  • functionally equivalent to the originalnetwork
    (modulo concurrency)
  • threads driven by input stimuli(no OS
    intervention)

TSENSOR
HSENSOR
TEMP FILTER
HUMIDITY FILTER
HDATA
TDATA
CONTROLLER
AC-on
DRYER-on
ALARM-on
54
Event-driven threads
Init() last 0
Reset
Tsensor() sample READ(TSENSOR) if
(sample - last gt DIF) last sample
if (sample gt TFIRE) WRITE(ALARM-on,10)
else if (sample gt TMAX)
WRITE(AC-on,sample-TMAX)
Hsensor() h READ(HSENSOR) if (h gt MAX)
WRITE(DRYER-on,5)
55
The scheduling procedure
  • 1. Specify a network of processes
  • process C communication operations
  • netlist connection between ports
  • 2. Translate to the computational model Petri
    nets
  • 3. Find a schedule on the Petri net
  • 4. Translate the schedule to a task

56
TSENSOR
TSENSOR
TEMP FILTER
last 0
TDATA
sample READ(TSENSOR)
TEMP-FILTER float sample, last last 0 while
(1) sample READ(TSENSOR) if (sample -
lastgt DIF) last sample
WRITE(TDATA, sample)
F
T
last sample WRITE(TDATA,sample)
TDATA
57
HSENSOR
HSENSOR
HUMIDITY FILTER
HDATA
h READ(HSENSOR)
HUMIDITY-FILTER float h, max last 0 while
(1) h READ(HSENSOR) if (h gt MAX)
WRITE(HDATA, h)
F
h gt MAX ?
T
WRITE(HDATA,h)
HDATA
58
CONTROLLER while(1) select(TDATA,HDATA)
case TDATA tdata READ(TDATA) if
(tdata gt TFIRE) WRITE(ALARM-on, 10)
else if (tdata gt TMAX) WRITE(AC-on,
tdata-TMAX) case HDATA hdata READ(HDATA,
hdata) if (hdata gt HMAX)
WRITE(DRYER-on, 5)
TDATA
HDATA
hdata READ(HDATA)
tdata READ(TDATA)
tdata gt TFIRE?
hdata gt HMAX?
F
F
T
T
WRITE(ALARM-on,10)
WRITE(DRYER-on,5)
h gt MAX ?
F
tdata gt TMAX?
T
WRITE(AC-on,tdata-TMAX)
59
TSENSOR
HSENSOR
last 0
sample READ(TSENSOR)
h READ(HSENSOR)
F
sample-last gt dif ?
F
h gt MAX ?
T
T
last sample WRITE(TDATA,sample)
WRITE(HDATA,h)
TDATA
HDATA
hdata READ(HDATA)
tdata READ(TDATA)
tdata gt TFIRE?
hdata gt HMAX?
F
F
T
T
WRITE(ALARM-on,10)
WRITE(DRYER-on,5)
h gt MAX ?
F
tdata gt TMAX?
T
WRITE(AC-on,tdata-TMAX)
60
Petri nets for Kahn process networks
Sequential processes (1 token per process)
Input/Output ports (communication with the
environment)
Channels (point-to-point communication between
processes)
61
Petri nets for Kahn process networks
True
True
False
False
  • Data-dependent choices
  • Conservative assumption (any outcome is possible)

62
Schedule
  • Infinite state space
  • Schedule properties
  • Finite (no infinite resources)
  • Inputs served infinitely often
  • All choice outcomes covered

63
Schedule
  • Finding the optimal schedule is
    computationally expensive
  • Heuristics are required
  • token count minimization
  • guidance by T-invariants (cycles)

64
Code generation
Initialization
I1
system
Await state
I1
I2
I2
  • Generated code
  • ISRs driven by input stimuli (I1 and I2)
  • Each tasks contains threads from one await
    state to another await state

Choice
I1
I2
T
F
F
T
I1
I2
65
Code generation
I1
system
I1
I2
I2
  • Generated code
  • ISRs driven by input stimuli (I1 and I2)
  • Each tasks contains threads from one await
    state to another await state

I1
I2
T
F
F
T
I1
I2
66
Code generation
C0
I1
system
I1
I2
I2
C9
C1
C4
  • Generated code
  • ISRs driven by input stimuli (I1 and I2)
  • Each tasks contains threads from one await
    state to another await state

C5
C2
C3
C11
F
I2
I1
I1
I2
C8
C6
C10
C7
T
67
Code generation
enum state S1, S2, S3 S
68
Code generation
enum state S1, S2, S3 S Init () C0() S
S1 return
C0
I1
I2
C9
C1
C4
C5
C2
C3
C11
F
I2
I1
I1
I2
C8
C6
C10
C7
T
69
Code generation
enum state S1, S2, S3 S ISR1 ()
switch(S) case S1 C1() C2() SS2
return case S2 C3() C2() return case
S3 C6() C7() C11() C5() return
C0
I1
I2
C9
C1
C4
C5
C2
C3
C11
F
I2
I1
I1
I2
C8
C6
C10
C7
T
70
Code generation
enum state S1, S2, S3 S
ISR2 () switch(S) case S1 C4()
C5() SS3 break case S2 C10() C11()
C5() SS3 return case S3 if (C8())
C7() C11() C5() return
else C9() S
S1 return
C0
I1
I2
C9
C9
C1
C4
C4
C5
C5
C2
C3
C11
C11
F
I2
I2
I1
I1
I2
I2
C8
C8
C6
C10
C10
C7
T
C7
71
Code generation
enum state S1, S2, S3 S Init () C0() S
S1 return ISR1 () switch(S) case
S1 C1() C2() SS2 return case S2 C3()
C2() return case S3 C6() C7() C11()
C5() return ISR2 () switch(S)
case S1 C4() C5() SS3 break case S2
C10() C11() C5() SS3 return case S3 if
(C8()) C7() C11() C5()
return else
C9() S S1 return
C0
I1
I2
C9
C1
C4
C5
C2
C3
C11
F
I2
I1
I1
I2
C8
C6
C10
C7
T
72
Code generation
enum state S1, S2, S3 S Init () C0() S
S1 return ISR1 () switch(S) case
S1 C1() C2() SS2 return case S2 C3()
C2() return case S3 C6() C7() C11()
C5() return ISR2 () switch(S)
case S1 C4() C5() SS3 break case S2
C10() C11() C5() SS3 return case S3 if
(C8()) C7() C11() C5()
return else
C9() S S1 return
Reset
Init ()
S
I1
ISR1 ()
I2
ISR2 ()
73
Environmental controller
Temperature
Humidity
ENVIRONMENTAL CONTROLLER
AC
Dehumidifier
Alarm
74
TSENSOR
HSENSOR
last 0
sample READ(TSENSOR)
h READ(HSENSOR)
F
sample-last gt dif ?
F
h gt MAX ?
T
T
last sample WRITE(TDATA,sample)
WRITE(HDATA,h)
TDATA
HDATA
hdata READ(HDATA)
tdata READ(TDATA)
tdata gt TFIRE?
hdata gt HMAX?
F
F
T
T
WRITE(ALARM-on,10)
WRITE(DRYER-on,5)
h gt MAX ?
F
tdata gt TMAX?
T
WRITE(AC-on,tdata-TMAX)
75
TSENSOR
p0
HSENSOR
p3
A
p6
p8
p1
B
G
p2
p7
Cf
Ct
Hf
p9
TDATA
HDATA
I
D
p4
p10
Ef
Jf
Et
Jt
h gt MAX ?
p5
F
76
(p0 p8 p9)
await state
A
(p1 p8 p9)
TSENSOR
HSENSOR
(p1 p3 p8 p9)
(p1 p6 p8 p9)
B
G
Cf
Hf
(p2 p8 p9)
(p2 p7 p9)
Ct
Ht
(p1 p8 p9 TDATA)
(p1 p8 p9 HDATA)
D
I
Jf
Et
Jt
(p1 p4 p8)
(p1 p8 p10)
Ef
F
(p1 p5 p8)
77
(p0 p8 p9)
A
(p1 p8 p9)
TSENSOR
HSENSOR
(p1 p3 p8 p9)
(p1 p6 p8 p9)
B
G
Cf
Hf
(p2 p8 p9)
(p2 p7 p9)
Ct
Ht
(p1 p8 p9 TDATA)
(p1 p8 p9 HDATA)
D
I
Jf
Et
Jt
(p1 p4 p8)
(p1 p8 p10)
Ef
F
(p1 p5 p8)
78
(p0 p8 p9)
TEMP-FILTER
HUMIDITY-FILTER
A
(p1 p8 p9)
TSENSOR
HSENSOR
(p1 p3 p8 p9)
(p1 p6 p8 p9)
B
G
Cf
Hf
(p2 p8 p9)
(p2 p7 p9)
Ct
Ht
(p1 p8 p9 TDATA)
(p1 p8 p9 HDATA)
D
I
Jf
Et
Jt
(p1 p4 p8)
(p1 p8 p10)
Ef
F
(p1 p5 p8)
CONTROLLER
79
Code generation and optimization
Tsensor() sample READ(TSENSOR) if
(sample - last gt DIF) last sample
WRITE (TDATA,sample) tdata READ (TDATA)
if (tdata gt TFIRE) WRITE(ALARM-on,10)
else if (tdata gt TMAX)
WRITE(AC-on,tdata-TMAX)
Channel elimination
80
Code generation and optimization
Tsensor() READ(TSENSOR,sample,1) if
(sample - last gt DIF) last sample
WRITE (TDATA,sample,1) READ
(TDATA,tdata,1) if (tdata gt TFIRE)
WRITE(ALARM-on,10) else if (tdata gt TMAX)
WRITE(AC-on,tdata-TMAX)
tdata sample
Copy propagation
81
Code generation and optimization
Tsensor() READ(TSENSOR,sample,1) if
(sample - last gt DIF) last sample
WRITE (TDATA,sample) tdata READ (TDATA)
if (sample gt TFIRE) WRITE(ALARM-on,10)
else if (sample gt TMAX)
WRITE(AC-on,sample-TMAX)

82
Event-driven threads
Init() last 0
Reset
Tsensor() sample READ(TSENSOR) if
(sample - last gt DIF) last sample
if (sample gt TFIRE) WRITE(ALARM-on,10)
else if (sample gt TMAX)
WRITE(AC-on,sample-TMAX)
Hsensor() h READ(HSENSOR) if (h gt MAX)
WRITE(DRYER-on,5)
83
Application example ATM Switch
  • No static schedule due to
  • Inputs with independent rates (need Real-Time
    dynamic scheduling)
  • Data-dependent control (can use Quasi-Static
    Scheduling)

84
Functional Decomposition
Accept/discard cell
Output time selector
4 Tasks ( 1 arbiter)
Clock divider
Output cell enabler
85
Minimal (QSS) Decomposition
Input cell processing
2 Tasks
Output cell processing
86
Real-time scheduling of tasks
Task 1
RTOS
Task 2
Shared Processor
87
ATM experimental results
Functional partitioning
QSS
41 Tasks
88
Producer-Filter-Consumer Example
init
controller
Ack
Coeff
Req
Pixels
Pixels
pixels
producer
consumer
filter
89
Experimental Results
of clock cycles
4-task implementation
1-task implementation
size of channels
90
Open problems
  • Is a system schedulable ? (decidability)
  • False paths in concurrent systems(data
    dependencies)
  • Synthesis for multi-processors
  • Abstraction / partitioning
  • and many others ...

91
Schedulability
  • A finite complete cycle is a finite sequence of
    transition firings that returns the net to its
    initial state
  • infinite execution
  • bounded memory
  • To find a finite complete cycle we must solve the
    balance (or characteristic) equation of the Petri
    net

t1
t2
t2
t3
2
2
t1
t3
2
1 0
-2 1
D
f D 0
0 -2
f D 0 has no solution
f (4,2,1)
  • No schedule

92
Schedulability
  • Can the adversary ever force token overflow?

t6
t3
t5
t2
t1
t7
t4
t8
t6
93
Schedulability
  • Can the adversary ever force token overflow?

t6
t3
t5
t2
t1
t7
t4
t8
94
Schedulability
  • Can the adversary ever force token overflow?

t6
t3
t5
t2
t1
t7
t4
t8
t8
95
Schedulability
  • Can the adversary ever force token overflow?

t3
t5
t2
t7
t1
t4
t6
96
Schedulability
  • Can the adversary ever force token overflow?

t3
t5
t2
t7
t1
t4
t6
97
Schedulability
  • Can the adversary ever force token overflow?

t3
t5
t2
t7
t1
t4
t6
98
Schedulability
  • Schedulability of Free-choice PNs is decidable
  • Algorithm is exponential
  • What if the resulting PN is non-free
    choice?(synchronization-dependent control)
  • What if the PN is not schedulable for all choice
    resolutions? (correlation between choices)

99
(Quasi) Static Scheduling approaches
  • Lee et al. 86 Static Data Flow cannot specify
    data-dependent control
  • Buck et al. 94 Boolean Data Flow undecidable
    schedulability check, heuristic pattern-based
    algorithm
  • Thoen et al. 99 Event graph no schedulability
    check, no task minimization
  • Lin 97 Safe Petri Net no schedulability check,
    single-rate, reachability-based algorithm
  • Thiele et al. 99 Bounded Petri Net partial
    schedulability check, reachability-based
    algorithm
  • Cortadella et al. 00 General Petri Net maybe
    undecidable schedulability check, balance
    equation-based algorithm

100
False paths
Choices are correlated
WRITES READS ? i j
101
Multi-processor allocation
enum state S1, S2, S3 S Init () C0() S
S1 return ISR1 () switch(S) case
S1 C1() C2() SS2 return case S2 C3()
C2() return case S3 C6() C7() C11()
C5() return ISR2 () switch(S)
case S1 C4() C5() SS3 break case S2
C10() C11() C5() SS3 return case S3 if
(C8()) C7() C11() C5()
return else
C9() S S1 return
Reset
Init ()
S
I1
ISR1 ()
I2
ISR2 ()
  • State and data are shared
  • Mutual exclusion required

102
Conclusions
  • Reactive systems
  • OS required to control concurrency
  • Processes are often reused in different
    environments
  • Static and Quasi-Static Scheduling minimize
    run-time overhead by automatic partitioning the
    system functions into input-driven threads
  • No context switch required (OS overhead is
    reduced)
  • Compiler optimizations across processes
  • Much more research is needed
  • strategies to find schedules (decidability ?)
  • false paths in concurrent systems
  • what about multiple processors?
  • ...
About PowerShow.com
