A Fully Distributed Framework for Cost-sensitive Data Mining

1
A Fully Distributed Framework for Cost-sensitive
Data Mining Wei Fan, Haixun Wang, and Philip S.
Yu IBM T.J.Watson, Hawthorne, New York Salvatore
J. Stolfo Columbia University, New York City, New
York
2
Inductive Learning
Training Data
Learner
Classifier
1. Decision trees 2. Rules 3. Naive Bayes ...
(43.45,retail,10025,10040, ...,
nonfraud) (246,70,weapon,10001,94583,...,fraud)
Transaction fraud,nonfraud
Test Data
Classifier
Class Labels
nonfraud fraud
(99.99,pharmacy,10013,10027,...,?) (1.00,gas,100
40,00234,...,?)
3
(No Transcript)
4
Distributed Data Mining

• data is inherently distributed across the
  network.
• many credit card authorization servers are
  distributed. Data are collected at each
  individual site.
• other examples include supermarket customer and
  transaction database, hotel reservations, travel
  agency and so on ...
• In some situations, data cannot even be shared.
• many different banks have their data servers.
  They rather share the model but cannot share the
  data due to many reasons such as privacy, legal,
  and competitive reasons.

5
Cost-sensitive Problems

• Charity Donation
• Solicit to people who will donate large amount of
  charity.
• Costs 0.68 to send a letter.
• A(x) donation amount.
• Only solicit if A(x) gt 0.68, otherwise lose
  money.
• Credit card fraud detection
• Detect frauds with high transaction amount
• 90 to challenge a potential fraud
• A(x) fraudulant transaction amount.
• Only challenge if A(x) gt 90, otherwise lose
  money.

6
Different Learning Frameworks
7
Fully Distributed Framework (training)
D2
D2
D1
K sites
MLt
ML2
ML1
generate K models
Ck
C2
C1
8
Fully-distributed Framework (predicting)
D
Test Set
Sent to k models
C1
C2
Ck
P1
P2
Pk
Compute k predictions
Combine
Combine to one prediction
P
9
Cost-sensitive Decision Making

• Assume that records the benefit
  received by predicting an example of class to
  be an instance of class .
• The expected benefit received to predict an
  example to be an instance of class
  (regardless of its true label) is

• The optimal decision-making policy chooses the
  label that maximizes the expected benefit,
  i.e.,
• When and is a traditional
  accuracy-based problem.
• Total benefits

10
Charity Donation Example

• It costs .68 to send a solicitation.
• Assume that is the best estimate of the
  donation amount,

• The cost-sensitive decision making will solicit
  an individual if and only if

11
Credit Card Fraud Detection Example

• It costs 90 to challenge a potential fraud
• Assume that y(x) is the transaction
  amount

• The cost-sensitive decision making policy will
  predict a transaction to be fraudulent if and
  only if

12
Adult Dataset

• Downloaded from UCI database.
• Associate a benefit factor 2 to positives and a
  benefit factor 1 to negatives

• The decision to predict positive is

13
Calculating probabilities

• For decision trees, n is the number of examples
  in a node and k is the number of examples
  with class label , then the probability is

• more sophisticated methods
• smoothing
• early stopping, and early stopping plus smoothing
• For rules, probability is calucated in the same
  way as decision trees
• For naive Bayes, is the score for
  class label , then

• binning

14
(No Transcript)
15
Combining Technique-Averaging

• Each model computes an expected benefit for
  example over every class label

• Combining individual expected benefit
  together
• We choose the label with the highest combined
  expected benefit


16
Why accuracy is higher?
1. Decision threshold line 2. Examples on the
left are more profitable than those on the
right 3. "Evening effect" biases towards big
fish.
17
Partially distributed combining techniques

• Regression
• Treat base classifiers' outputs as indepedent
  variables of regression and the true label as
  dependent variables.
• Modify Meta-learning
• Learning a classifier that maps the base
  classifiers' class label predictions to that the
  true class label.
• For cost-sensitive learning, the top level
  classifier output probability instead of just a
  label.

18
Communication Overhead Summary
19
Experiments

• Decision Tree Learner C4.5 version 8
• Dataset
• Donation
• Credit Card
• Adult

20
Accuracy comparision
21
Accuracy comparison
22
Accuracy comparison
23
Detailed Spread
24
Credit Card Fraud Dataset
25
Adult Dataset
26
Why accuracy is higher?
27
Summary and Future Work

• Evaluated a wide range of combining techniques
  include variations of averaging, regression and
  meta-learning for scalable cost-sensitive (and
  cost-insensitive learning).
• Averaging, although simple, has the highest
  accuracy.
• Previously proposed approaches have significantly
  more overhead and only work well for tradtional
  accuracy-based problems.
• Future work ensemble pruning and performance
  estimation
