Research Update on Cerebral Cavernous Malformations

1
Research Update on Cerebral Cavernous
Malformations

• Issam A. Awad, MD, MSc, FACS, MA(Hon)
• Professor and Vice Chairman
• Department of Neurosurgery
• Feinberg School of Medicine
• Northwestern University
• Evanston Northwestern Healthcare
• Evanston, Illinois

2
Cerebral Vascular Malformations ResearchA
Legacy of Collaborations During Two Decades

• The clinical foundations-- BNI and Cleveland
  Clinic
• (Spetzler, Little, Robinson, Estes,
  DeCorletto, et al.)
• The translational science-- Yale
• (Lifton, Kim, Gunel, Rothbart, Wong, Baev,
  White, Awadallah, et al.)
• Genomics of lesions-- the Colorado team
• (Uranishi, Gault, Shenkar, Lepsch, Hu,
  Sarin, Elliott, et al.)
• A new horizon-- ENH and NWU Integrational
  Neuroscience
• (Shenkar, Meade, Wyrwicz, Rowley, Zao,
  Kohlmeir, Batjer, Edelman, et al.)

Support by NIH (NINDS) R01NS36194 K24NS02153,
Butcher Family Foundation, ENH Research Institute
3
Categorization of Disease The Phenotype
Natural History
Clinical-Radiologic-Pathologic Correlations
4
Refining the Phenotype

• Structural and molecular dissection
• Angioarchitecture
• Ultrastructure
• Functional pathways -- angiogenesis

Regional venous dysmorphism
Hemorrhagic proliferative dysangiogenesis
(Robinson et al. 1989, 1992, 1993)
Arteriovenous shunting
5
Refining the Phenotype

• Structural and molecular dissection
• Angioarchitecture
• Ultrastructure
• Functional pathways -- angiogenesis

CCMs Defective inter-EC junctions and sub-EC
structure (Wong et al. 1998)
6
Refining the Phenotype

• Structural and molecular dissection
• Angioarchitecture
• Ultrastructure
• Functional pathways -- angiogenesis

Angiogenesis factor upregulation different
roles in AVMs vs. CCMs ? (Rothbart et al. 1997,
Uranishi et al. 2000)
7
Refining the Phenotype
SMA
Myosin
Smoothelin

• Structural and molecular dissection
• Smooth muscle maturation

AVM
Defective SMC maturation in CCMs (Uranishi et al.
2001)
CCM
8
The Genetic Substrate of CCMs

• 20-40 familial (multiple lesions)
• Three gene loci (7q, 7p, and 3q) in familial
  cases
• Hispanic Americans of Mexican descent are CCM1
  (Q455X with preserved haplotype)-- founder
  mutation
• CCM1 gene is KRIT1--all CCM1 mutations result in
  premature truncation
• CCM2 gene is MGC4607
• CCM 3 gene is XXXXX

(Gunel et al., Tournier-Lasserve et al., others
1995-2005, Marchuck 2003)
9
Mutations in KREV INTERACTION TRAPPED 1 (KRIT1)
cause CCM1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
3UT

















Truncating (73), 15 intron
5UT
Retinal
Cutaneous
Hispanic

Amino Acid
coding
NPXY motif binds icap-1A ( integrin cytoplasnic
domain-assoc protein-1) cell-cell adhesion
Ankyrin Repeats (protein-protein interaction)
FERM domain (links cytoplasmic and transmembrane
proteins)
10
Genetic Clues to Molecular Mechanism of Disease
CCM

• KRIT1 is related to cytoskeletal
  proteins--cellular adhesion pathway
• KRIT1 is associated with tube formation during
  angiogenesis
• Working hypothesis-- KRIT1 mediated defective
  inter-EC junctions predispose to CCM lesion
  genesis

Serebriiskii et al 1997 Zhang et al.
2001,2003 Zawistowski et al. 2002, 2003 Gunel et
al. 2002
11
Genetic Clues to Molecular Mechanism of Disease
CCM
Angiogenesis Growth Factors/Receptors (VEGF,
Angiopeotin, TGF-?, FGF-2)
Endothelial cells
Cell Adhesion Molecules (CD31)
Krev-1/rap1A (signaling)
Krit1-associated microtubules
ICAP-1?
Extracellular Matrix Proteins ?laminin,
?fibronectin,
12
Phenotype, Genotype and Clinical Behavior

• Solitary vs multiple lesions Gr Echo MR (T2) as
  surrogate endophenotype
• Venous angioma
• Previous irradiation
• Penetrance and aggressive behavior
• ( ? gene, mutation, promoter)
• Combined risk

13
Sporadic Lesions Hidden Germ Line or Somatic
Mutation ?

• Occult familiality--
• Incomplete penetrance--
• Rare in absence of family history or lesion
  multiplicity (0/gt100) MR with gradient echo
  excellent screen in suspected cases
• Somatic mutations--
• Two CCM cases reported (Kehrer-Sawatzki et al.,
  Gault et al , work in progress (CCM1, CCM2,
  transheterozygous?)
• Sporadic mutation in CVM genes or related
  pathways-- Working hypothesis

14
Somatic Mutation in Human CCM Lesion from Patient
with Germ Line Mutation in Second Copy of Same
Gene

• ? How common
• ? Transheterozygous
• ? Other second hits

Gault et al. (Stroke 2005) Somatic mutation in
endothelial cells (laser capture,
unpublished 2005)
15
Double Hits and Lesion Genesis Transgenic Mice

• CCM1 mutation alone does not seem to produce CCM
  lesions
• Combined genetic predisposition causes CCM
  lesions (ccm /-, P53 -/-)
• Opportunity to study CCM genesis and progression
  in vivo

T2 (GrEcho) MR of transgenic mouse brain 4.7 T
(collaboration Marchuk Awad, 2005)
16
Gene Interactions Differential Gene Expression
mRNA

• CCMs compared to AVMs and STAs
• 42 genes significantly upregulated
• 36 genes significantly downregulated
• AVMs compared to CCMs and STAs
• 48 genes significantly upregulated
• 59 genes significantly downregulated

Shenkar et al. 2003
17
Genomics Data Analysis
File containing mean
intensity for each gene
i
Scaling (equalize average intensity across chips)
File containing scaled data
Confirmation of
Gene Discovery
Differential Expression
of Known Genes
Matlab
GeneSpring
Genes that vary significantly
i
15 genes of interest
Compare groups
i
InStat
Genes differentially expressed
Statistical Analysis
i
Expression Levels and Significance
18
Gene Interactions Differential Gene Expression
19
Genes upregulated gt20X in CCM over controls
20
Immune Response in CCM ?

• Leaky vessels and antigenic challenge
• Organizing thrombus
• ? Cell type
• ? Monoclonal or oligoclonal

B Cells and Plasma Cells
IGG
21
High Field MR of CCM Lesions
1 mm
1 mm
10 mm
1 mm
0.1 mm

• Humans up to 4.5 T
• Animals up to 14 T
• Near histologic resolution

1.5 T
1.5 T
Wyrwicz, Edelman, Awad, Shenkar 2005
3.0 T
22
Imaging Cellular Events in CCM Lesions
23
Imaging Cellular Events in CCM Lesions
Resolution and Labeling
24
Dual Probes For Molecular Imaging of Individual
Cells
Meade et al. 2003-2005
25
Building Molecular Markers for MR imaging and
Histologic Validation
26
Modern Technical Applications to Microsurgical
Excision of CM

• Functional MR if lesion near eloquent areas
• Intraoperative brain mapping
• Image guided navigation

27
Consider and Respect Subcortical Tracts
Tensor Diffusion MR imaging
28
Case Study Transcallosal Approach to Thalamic
Lesion
29
Case Study Transsylvian Approach to Thalamic
Lesion
30

Research Future Integrated Teams for Efficient
Translation
31
Future DirectionsAn Evolving Story

• Explaining disease behavior
• Predicting disease behavior
• Modifying disease behavior
