1
CSC 830 Computer GraphicsLecture 6 Texture more
Course Note Credit Some of slides are extracted
from the course notes of prof. Mathieu Desburn
(USC) and prof. Han-Wei Shen (Ohio State
University).
2
Announcements
  • Term Project Proposal Due April 14th (next
    class)
  • Assignment 4 Shading 5 texture

3
Can you do this
4
(No Transcript)
5
Texture Mapping
  • Surfaces in the wild are very complex
  • Cannot model all the fine variations
  • We need to find ways to add surface detail
  • How?

6
Texture Mapping
  • Particles and fractals
  • gave us lots of detail information
  • not easy to model
  • mathematically and computationally challenging

7
Texture Mapping
  • Of course, one can model the exact micro-geometry
    material property to control the look and feel
    of a surface
  • But, it may get extremely costly
  • So, graphics use a more practical approach
    texture mapping

8
Texture Mapping
  • Solution - (its really a cheat!!)
  • How?

MAP surface detail from a predefined
multi-dimensional table (texture) to a simple
polygon
9
Slide Courtesy of Leonard McMillan Jovan
Popovic, MIT
10
OpenGL functions - demo
  • During initialization read in or create the
    texture image and place it into the OpenGL state.
  • glTexImage2D (GL_TEXTURE_2D, 0, GL_RGB,
    imageWidth, imageHeight, 0, GL_RGB,
    GL_UNSIGNED_BYTE, imageData)
  • Before rendering your textured object, enable
    texture mapping and tell the system to use this
    particular texture.
  • glBindTexture (GL_TEXTURE_2D, 13)

11
OpenGL functions
  • During rendering, give the cartesian coordinates
    and the texture coordinates for each vertex.
  • glBegin (GL_QUADS)
  • glTexCoord2f (0.0, 0.0)
  • glVertex3f (0.0, 0.0, 0.0)
  • glTexCoord2f (1.0, 0.0)
  • glVertex3f (10.0, 0.0, 0.0)
  • glTexCoord2f (1.0, 1.0)
  • glVertex3f (10.0, 10.0, 0.0)
  • glTexCoord2f (0.0, 1.0)
  • glVertex3f (0.0, 10.0, 0.0)
  • glEnd ()

12
What happens when outside the 0-1 range?
  • (u,v) should be in the range of 01
  • What happens when you request (1.5 2.3)?
  • Tile repeat (OGL) the integer part of the value
    is dropped, and the image repeats itself across
    the surface
  • Mirror the image repeats itself but is mirrored
    (flipped) on every other repetition
  • Clamp to edge value outside of the range are
    clamped to this range
  • Clamp to border all those outside are rendered
    with a separately defined color of the border

13
Methods for modifying surface
  • After a texture value is retrieved (may be
    further transformed), the resulting values are
    used to modify one or more surface attributes
  • Called combine functions or texture blending
    operations
  • Replace replace surface color with texture color
  • Decal replace surface color with texture color,
    blend the color with underlying color with an
    alpha texture value, but the alpha component in
    the framebuffer is not modified
  • Modulate multiply the surface color by the
    texture color (shaded textured surface)

14
Okay, then how can you implement?
Slide Courtesy of Leonard McMillan Jovan
Popovic, MIT
15
Texture and Texel
  • Each pixel in a texture map is called a Texel
  • Each Texel is associated with a (u,v) 2D texture
    coordinate
  • The range of u, v is 0.0,1.0 due to
    normalization

16
(u,v) tuple
  • For any (u,v) in the range of (0-1, 0-1)
    multiplied by texture image width and height, we
    can find the corresponding value in the texture
    map

17
How do we get F(u,v)?
  • We are given a discrete set of values
  • Fi,j for i0,,N, j0,,M
  • Nearest neighbor
  • F(u,v) F round(Nu), round(Mv)
  • Linear Interpolation
  • i floor(Nu), j floor(Mv)
  • interpolate from Fi,j, Fi1,j, Fi,j1,
    Fi1,j
  • Filtering in general !

18
Interpolation
19
Filtering Textures
Texture
Texture gt Image
Image gt Texture
Footprint changes from pixel to pixel no single
filter
Resampling theory Magnification Interpolation Mi
nification Averaging
We would like a constant cost per pixel
20
Mip Mapping Williams
MIP Multim In Parvo Many things in a small
place
d
R
R
G
B
v
G
B
u
Trilinear interpolation
21
Mip Mapping - Example
  • Courtesy of John hart

22
(No Transcript)
23
Was it working correctly?
24
Perspective Correction
No perspective Correction
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
Probably the most common form of perspective
texturing is done via a divide by Z. Its a very
simple algorithm. Instead of interpolate U and
V, we instead interpolate U/Z and V/Z. 1/Z is
also interpolated. At each pixel, we take our
texture co-ords, and divide them by Z. Hang on,
you're thinking - if we divide by the same
number twice (Z) don't we get back to where we
started - like a double reciprocal? Well, sort
of. Z is also interpolated, so we're not
dividing by the same Z twice. We then take the
new U and V values, index into our texture map,
and plot the pixel. Pseudo-code might be su
Screen-U U/Z sv Screen-V V/Z sz
Screen-Z 1/Z for xstartx to endx u su /
sz v sv / sz PutPixel(x, y,
texturevu) su deltasu sv deltasv
sz deltasz end Very simple, and
very slow.
29
(No Transcript)
30
Are correct_s correct_t integer?
31
Useful links (Google perspective correct
texture)
  • http//www.whisqu.se/per/docs/graphics16.htm
  • http//p205.ezboard.com/fyabasicprogrammingfrm20.s
    howMessage?topicID20.topic (Perspective
    correction with Z-buffering)
  • http//csdl2.computer.org/persagen/DLAbsToc.jsp?re
    sourcePath/dl/proceedings/toccomp/proceedings/c
    giv/2005/2392/00/2392toc.xmlDOI10.1109/CGIV.2005
    .58 (Perspective Correct Normal Vectors for Phong
    Shading )
  • http//easyweb.easynet.co.uk/mrmeanie/tmap/tmap.h
    tm

32
Procedural Texture
  • Periodic

Checkerboard Scale s 10 If (u s) 20 (v
s)20 texture(u,v) 0 // black Else texture
(u,v) 1 // white
33
Slide Courtesy of Leonard McMillan Jovan
Popovic, MIT
34
Slide Courtesy of Leonard McMillan Jovan
Popovic, MIT
35
t
Slide Courtesy of Leonard McMillan Jovan
Popovic, MIT
36
Slide Courtesy of Leonard McMillan Jovan
Popovic, MIT
37
Environment Maps
  • Use texture to represent reflected color
  • Texture indexed by reflection vector
  • Approximation works when objects are far away
    from the reflective object

38
Environment Maps
  • Using a spherical environment map

Spatially variant resolution
39
Environment Maps
  • Using a cubical environment map

40
Environment Mapping
  • Environment mapping produces reflections on shiny
    objects
  • Texture is transferred in the direction of the
    reflected ray from the environment map onto the
    object
  • Reflected ray R2(NV)N-V
  • What is in the map?

Environment Map
Viewer
Reflected ray
Object
41
Approximations Made
  • The map should contain a view of the world with
    the point of interest on the object as the eye
  • We cant store a separate map for each point, so
    one map is used with the eye at the center of the
    object
  • Introduces distortions in the reflection, but the
    eye doesnt notice
  • Distortions are minimized for a small object in a
    large room
  • The object will not reflect itself
  • The mapping can be computed at each pixel, or
    only at the vertices

42
Environment Maps
  • The environment map may take one of several
    forms
  • Cubic mapping
  • Spherical mapping (two variants)
  • Parabolic mapping
  • Describes the shape of the surface on which the
    map resides
  • Determines how the map is generated and how it is
    indexed
  • What are some of the issues in choosing the map?

43
Example
44
Refraction Maps
  • Use texture to represent refraction

45
Opacity Maps
  • Use texture to represent opacity

Useful for billboarding
46
Illumination Maps
  • Use texture to represent illumination footprint

47
Illumination Maps
  • Quake light maps

48
Bump Mapping
  • Use texture to perturb normals
  • - creates a bump-like effect



original surface
bump map
modified surface
Does not change silhouette edges
49
Bump Mapping
  • Many textures are the result of small
    perturbations in the surface geometry
  • Modeling these changes would result in an
    explosion in the number of geometric primitives.
  • Bump mapping attempts to alter the lighting
    across a polygon to provide the illusion of
    texture.

50
Bump Mapping
  • This modifies the surface normals.

51
Bump Mapping
52
Bump Mapping
53
Bump Mapping
  • Consider the lighting for a modeled surface.

54
Bump Mapping
  • We can model this as deviations from some base
    surface.
  • The questionis then how thesedeviations change
    thelighting.

55
Bump Mapping
  • Step 1 Putting everything into the same
    coordinate frame as B(u,v).
  • x(u,v), y(u,v), z(u,v) this is given for
    parametric surfaces, but easy to derive for other
    analytical surfaces.
  • Or O(u,v)

56
Bump Mapping
  • Define the tangent plane to the surface at a
    point (u,v) by using the two vectors Ou and Ov.
  • The normal is then given by
  • N Ou ? Ov

57
Bump Mapping
  • The new surface positions are then given by
  • O(u,v) O(u,v) B(u,v) N
  • Where, N N / N
  • Differentiating leads to
  • Ou Ou Bu N B (N)u ? Ou Ou Bu N
  • Ov Ov Bv N B (N)v ? Ov Ov Bv N
  • If B is small.

58
Bump Mapping
  • This leads to a new normal
  • N(u,v) Ou ? Ov - Bu(N ? Ov) Bv(N ? Ou)
  • Bu Bv(N ? N)
  • N - Bu(N ? Ov) Bv(N ? Ou)
  • N D

D
N
59
Bump Mapping
  • For efficiency, can store Bu and Bv in a
    2-component texture map.
  • The cross products are geometry terms only.
  • N will of course need to be normalized after the
    calculation and before lighting.
  • This floating point square root and division
    makes it difficult to embed into hardware.

60
Displacement Mapping
  • Use texture to displace the surface geometry



Bump mapping only affects the normals, Displacemen
t mapping changes the entire surface (including
the silhouette)
61
3D Textures
  • Use a 3D mapping

Usually stored procedurally
Can simulate an object carved from a material
62
3D Textures - Noise
  • Pseudo-random
  • Bandlimited
  • few high or low frequencies
  • Controllable

63
3D Textures - Noise
  • Create a nD integer-aligned lattice of random
    numbers
  • For any nDPoint p, noise is defined as

noise(nDPoint p) Find 2 neighbors of p
Linearly interpolate neighbors table values
Return interpolated value
64
Turbulence
  • Noise with self-similarity

Add together many octaves of noise
65
Turbulence
66
Animating Turbulence
  • Use an extra dimension as time

67
Slide Courtesy of Leonard McMillan Jovan
Popovic, MIT
68
Slide Courtesy of Leonard McMillan Jovan
Popovic, MIT
69
Slide Courtesy of Leonard McMillan Jovan
Popovic, MIT
Write a Comment
User Comments (0)
About PowerShow.com
