CS 2200

1
CS 2200

• Presentation 7b
• Pipelining Hazards

2

• R0 is always 0
• R1 Loop counter
• R2 Loop termination value
• R3 contains address of array A
• R4 contains address of array B
• add R1, R0, R0 Initialize loop
  counter
• addi R2, R0, 10 Termination val
• loop beq R1, R2, done Are we done?
• lw R5, 0(R3) Get Ai
• addi R5, R5, 7 Add 7
• sw R5, 0(R4) Store in Bi
• addi R3, R3, 1 Increment A
• addi R4, R4, 1 Increment B
• addi R1, R1, 1 Increment counter
• beq R0, R0, loop Go back do it
  again
• done halt

3
M X
?
1
P C
Instr Mem
DPRF
A
Data Mem
M X
M X
D
SE
WB
EX
MEM
ID
IF
4
???
beq
M X
?
1
P C
Instr Mem
DPRF
A
Data Mem
M X
M X
D
SE
WB
EX
MEM
ID
IF
5
Solution

• Branch Delay Slot

6

• R0 is always 0
• R1 Loop counter
• R2 Loop termination value
• R3 contains address of array A
• R4 contains address of array B
• add R1, R0, R0
• addi R2, R0, 10
• loop beq R1, R2, done
• nop Branch delay slot
• lw R5, 0(R3)
• addi R5, R5, 7
• sw R5, 0(R4)
• addi R3, R3, 1
• addi R4, R4, 1
• addi R1, R1, 1
• beq R0, R0, loop
• nop Branch delay slot
• done halt

7

• R0 is always 0
• R1 Loop counter
• R2 Loop termination value
• R3 contains address of array A
• R4 contains address of array B
• add R1, R0, R0
• addi R2, R0, 10
• loop beq R1, R2, done
• nop Delay slot
• lw R5, 0(R3)
• addi R5, R5, 7 Dependency
• sw R5, 0(R4)
• addi R3, R3, 1
• addi R4, R4, 1
• addi R1, R1, 1
• beq R0, R0, loop
• nop Delay slot
• done halt

8
opc
beq
addi
add
opc
M X
?
1
R1
P C
Instr Mem
DPRF
A
Data Mem
R2
M X
M X
D
SE
R1 value
R1
WB
EX
MEM
ID
IF
9
Extreme Closeup
DPRF
MUX
Rx
MEM
R1
Rx val
R1 value
Rx
Comparator (i.e. are they equal?)
R1
10
opc
beq
addi
add
opc
M X
?
1
R1
R2 value
P C
Instr Mem
DPRF
A
Data Mem
R2
M X
M X
D
SE
R1 value
R2
R1
WB
EX
MEM
ID
IF
11

• R0 is always 0
• R1 Loop counter
• R2 Loop termination value
• R3 contains address of array A
• R4 contains address of array B
• add R1, R0, R0
• addi R2, R0, 10
• loop beq R1, R2, done
• nop Delay slot
• lw R5, 0(R3)
• addi R5, R5, 7 Dependency
• sw R5, 0(R4)
• addi R3, R3, 1
• addi R4, R4, 1
• addi R1, R1, 1
• beq R0, R0, loop
• nop Delay slot
• done halt

12
addi
lw
???
M X
?
1
R5
P C
Instr Mem
DPRF
addr
A
Data Mem
M X
M X
D
SE
7
R5
WB
EX
MEM
ID
IF
13
addi
lw
M X
?
1
old R5 value
R5 value
P C
Instr Mem
DPRF
addr
A
Data Mem
M X
M X
7
D
SE
R5
WB
EX
MEM
ID
IF
14
addi
lw
???
STALL!
M X
?
1
R5
P C
Instr Mem
DPRF
addr
A
Data Mem
M X
M X
D
SE
7
R5
WB
EX
MEM
ID
IF
15
addi
bubble
lw
M X
?
1
R5
R5 value
P C
Instr Mem
DPRF
addr
A
Data Mem
M X
M X
D
SE
7
R5
WB
EX
MEM
ID
IF
16

• R0 is always 0
• R1 Loop counter
• R2 Loop termination value
• R3 contains address of array A
• R4 contains address of array B
• add R1, R0, R0
• addi R2, R0, 10
• loop beq R1, R2, done
• nop Delay slot
• lw R5, 0(R3)
• addi R5, R5, 7 Dependency
• sw R5, 0(R4) Dependency
• addi R3, R3, 1
• addi R4, R4, 1
• addi R1, R1, 1
• beq R0, R0, loop
• nop Delay slot
• done halt

17
sw
addi
M X
?
1
P C
R5 value
Instr Mem
DPRF
addr
A
Data Mem
M X
M X
D
SE
R5
R5
WB
EX
MEM
ID
IF
18

• R0 is always 0
• R1 Loop counter
• R2 Loop termination value
• R3 contains address of array A
• R4 contains address of array B
• add R1, R0, R0
• addi R2, R0, 10
• loop beq R1, R2, done
• nop Delay slot
• lw R5, 0(R3)
• addi R5, R5, 7 Dependency
  Delay
• sw R5, 0(R4)
• addi R3, R3, 1
• addi R4, R4, 1
• addi R1, R1, 1
• beq R0, R0, loop
• nop Delay slot
• done halt

19

• R0 is always 0
• R1 Loop counter
• R2 Loop termination value
• R3 contains address of array A
• R4 contains address of array B
• add R1, R0, R0
• addi R2, R0, 10
• loop beq R1, R2, done
• nop Delay slot
• lw R5, 0(R3)
• addi R5, R5, 7 Dependency
  Delay
• sw R5, 0(R4)
• addi R3, R3, 1
• addi R4, R4, 1
• addi R1, R1, 1
• beq R0, R0, loop
• nop Delay slot
• done halt

20

• R0 is always 0
• R1 Loop counter
• R2 Loop termination value
• R3 contains address of array A
• R4 contains address of array B
• add R1, R0, R0
• addi R2, R0, 10
• loop beq R1, R2, done
• lw R5, 0(R3) Delay slot
• addi R5, R5, 7 Dependency
  Delay
• sw R5, 0(R4)
• addi R3, R3, 1
• addi R4, R4, 1
• addi R1, R1, 1
• beq R0, R0, loop
• nop Delay slot
• done halt

21

• R0 is always 0
• R1 Loop counter
• R2 Loop termination value
• R3 contains address of array A
• R4 contains address of array B
• add R1, R0, R0
• addi R2, R0, 10
• loop beq R1, R2, done
• lw R5, 0(R3) Delay slot
• addi R5, R5, 7 Dependency
  Delay
• sw R5, 0(R4)
• addi R3, R3, 1
• addi R1, R1, 1
• beq R0, R0, loop
• addi R4, R4, 1 Delay slot
• done halt

22

• Optimized
• R0 is always 0
• R1 Loop counter
• R2 Loop termination value
• R3 contains address of array A
• R4 contains address of array B
• add R1, R0, R0
• addi R2, R0, 10
• loop beq R1, R2, done
• lw R5, 0(R3) Delay slot
• addi R3, R3, 1 No Dependency
• addi R5, R5, 7
• sw R5, 0(R4)
• addi R1, R1, 1
• beq R0, R0, loop
• addi R4, R4, 1 Delay slot
• done halt

23
With LC-2200 and a 5 stage pipeline with no
forwarding, squashing, or flushing

• RAW hazard
• 3 bubbles in pipeline
• BEQ
• 2 bubbles if branch not taken
• 3 bubbles if branch taken
• RAW with forwarding
• 0 bubbles if ALU instructions
• 1 bubble if load followed by ALU
• With branch determination in IDRR stage
• 1 bubble if branch not taken
• 2 bubbles if branch taken
• This can be reduced to 0 bubbles if branch not
  taken if the result of the comparison is not
  buffered through the Z register

24
Questions?
