Privacy Management in Ubiquitous Computing
Environment

• Jin Zhou
• Ho Geun An
• Priyanka Vanjani
• Kwane E. Welcher

2
Summary

• Introduction (Jin)
• Internet Privacy (Ho An)
• Privacy in E-Commerce (Priyanka)
• Privacy in Ubiquitous Computing (Jin)
• Policy-Based Control (Kwane)
• Trust and Reputation (Jin)
• Conclusion (Jin)

3
Introduction

• Ubiquitous Computing promises a world where
  computational artifacts embedded in the
  environment will continuously sense our
  activities and provide services based on what is
  sensed

• It is thought of third wave in computing and just
  beginning

4
Scenario
5
Properties of Ubicomp

• Ubiquity
• Invisibility
• Sensing
• Memory Amplification

6
Privacy Problems
7
Example Scenario

• Alice is visiting a city
• Use Bobs location service
• Alices location is stored in Bobs Server
• Bob may sell Alices information to Carol

8
Fair Information Practices

• Notice/Awareness
• Choice/Consent
• Access/Participation
• Integrity/Security
• Enforcement/Redress

9
Internet

• Internet is one of the biggest parts of
  ubiquitous computing environment.
• Based on End User Centric Architecture
• Benefits
• Flexibility / Generality / Openness
• Disadvantages
• End user care about the privacy protection
• the place where privacy violations occur most
  often today.

10
Personal Information on Internet

• Medium
• Web site / email / IM / Chat room / bulletin
  board / p2p network / voice / video communication
• Personal Information
• Name / Address / SSN /Credit Card Number / User
  behavior

11
Threats

• Four factors make data collector much easier to
  gain personal information In order to reach
  public, one must
• advertise
• use well-known protocols and standards
• reveal ones content
• accept that one may come under the scrutiny of
  the authorities

12
Threats

• The widely used protocols (e.g. TCP / IP / HTTP /
  DNS) and applications do not support any kind of
  protection for privacy.
• By using these factors, data collectors are
  gathering personal information over the network
  without notice and consent.
• There are several data storages/flows on network
  that contains personal information and being
  targeted by data collectors.
• DNS / URL / Cookie / Scripting

13
DNS Server

• A DNS server resolves the host names found in
  Uniform Resource Locators (URL) into a numeric
  Internet address RFC1035
• Since there is no assurance in the protocol that
  replies from DNS server are genuine and not have
  been tampered with, DNS spoofing would deceive
  users and extract sensitive information.
• Structural remedies for the DNS vulnerabilities
  are available but not widely deployed.
• The Domain Name System Security Extensions
  RFC2065

14
URL Leak

• URL http//www.personal.com?link_typeformform_i
  dxxxpassxxx contains user ID and password.
• There are many ways that referenced URLs leak
• History / referrer / logs
• Solution
• HTTPS

15
Cookie Exposure

• Cookie is a message given to web browser by a web
  server.
• Main purpose of cookie is to identify users and
  possibly prepare customized WebPages for them.
• Cookie is used for basically two ways tracking
  users and authenticating users.
• Unfortunately, there is no standard mechanism to
  establish the integrity of a cookie returned by a
  browser
• Best defense is to avoid shopping online or
  registering with online services that use unsafe
  cookie-based authentication.

16
Recommends

• RFC2964 recommends proper use of cookie
• the user is aware that cookie is being maintained
  and consent to it.
• The user has the ability to delete the cookie
  associated with such a session at any time.
• The information obtained through the cookies is
  not disclosed to other parties without the users
  explicit consent.
• Session information itself cannot contain
  sensitive information and cannot be used to
  obtain sensitive information.

17
Cross Site Scripting (CSS)

• CSS is a type of computer security vulnerability
  typically found in web application which allows
  malicious web users to inject client side script
  (Javascript or HTML) or ActiveX controls into the
  web pages, e-mail messages, instant messages,
  newsgroup posting, or various other media. Victim
  users may unintentionally execute the script
  without any notice.
• A CSS vulnerability could potentially be used to
  collect HTTP Cookies or the URL history and
  disseminate the data to an unauthorized party.

18
Prevent CSS

• Web administrator must filter a user-supplied
  data
• All non-alphanumeric client-supplied data
  (possibly contains malicious script) should be
  converted to HTML character entities before being
  re-displayed to other clients.
• For end users, the most effective way to prevent
  CSS attacks is to disable all scripting languages
  in their web browsers.
• They should be careful to click links on
  untrusted web pages or e-mails.
• Also they should not install any ActiveX controls
  from untrusted web sites.

19
Addressing Privacy in E-Commerce

• E-Commerce Business conducted over the internet
  using any of the applications that rely on
  internet
• Email, Web Services, Online Shopping

20
Data

• Implicit Personalization is gathered from
  information inferred from a user.
• Explicit Requires demographics, rating or other
  user information provided explicitly by the user.

21
Privacy Risks

• Users fear that their information might be shared
  with other organizations and/or companies. Fear
  of undesired marketing.
• Users are concerned about how the information
  they have provided would be used.
• Risk of a website not being run by a trusted
  organization and the information stored in their
  database.
• Information might be distributed amongst other
  unwanted websites, or may be used by other
  organizations
• Fear of online activities being tracked

22
User Concerns

• Most of the users do not care much about factors
  like
• If a site has privacy policy posted
• if the site has a data retention policy
• if the site has a privacy seal
• This is because hey are not well aware of the
  importance of the above factors

23
Protecting Privacy

• P3P
• One of the solutions in protecting privacy as far
  as E-Commerce is concerned Enables websites to
  express their privacy practices in a standard
  format which is convenient for user agents to
  retrieve and interpret.

24
HTTP Transaction with P3P added
25
Summary of P3P

• P3P is not an "Enforcement Mechanism"
• Facilitates better communication
• P3P Version 1.0 Goal of the specification
• To make user agents aware of the practices that
  websites follow to collect data.

26
TRUSTe

• TRUSTe Certifies, Monitors a websites privacy
  policies, email policies and is also aimed
  towards resolving consumer privacy problems.
• TRUSTe developed the first online privacy seal
  program
• the TRUSTe Watchdogan alternative dispute
  resolution mechanism that allows you to submit
  any privacy violations by an accredited site
  directly to TRUSTe via the Web.

27
Conclusion of E-Commerce Privacy

• Users nowadays have strong opinion regarding
  privacy online and they tend to make their own
  assumptions about the data collection and the
  results turn out to be quite unfavorable.
• It is vital to have more concrete and full-proof
  data nowadays regarding E-Commerce and privacy
  technologies in order to improve and win over
  users trust and expectations.

28
Privacy in Ubicomp Environment

• Principle of Minimum Asymmetry
• Anonymization and Pseudonymization
• P3P
• PawS
• Wearable
• Other Mechanisms

29
Principle of Asymmetry

• Negative externalities are often much harder to
  overcome in environments with significant
  asymmetry in both information and power between
  different parties.
• Principle of Minimum Asymmetry
• Decreasing the flow of information from data
  owners to data collectors and users
• Increasing the flow of information from data
  collectors and users back to data owners

30
Principle of Minimum Asymmetry
31
Approximate Information Flow

• Information Spaces
• Storage perspective
• Data Lifecycle
• Dataflow perspective
• Themes for minimizing Asymmetry
• End-user perspective

32
Information Spaces
Properties Lifetime Accuracy Confidence
Boundaries Physical Social Activity-based
Operations Addition/Deletion/Update Authorization
/Revocation Promotion/Demotion Composition/Decompo
stion Fusion/Inference
33
Data Lifecyle

• Collection
• Access
• Second Use

34
Themes for Minimizing Asymmetry

• Prevention
• Avoidance
• Detection

35
Design Space
36
Anonymization and Pseudonymization

• Anonymity precludes association of data or a
  transaction with a particular person.
• However, services which require presence of users
  are not possible with anonymity, in that case,
  pseudonymity is required.
• With user selected pseudonyms, users can interact
  with the environment in an anonymous way by
  having a pseudo identity.
• Nevertheless, pseudonymity can be compromised at
  times as the user is physically present there and
  be identified at times.

37
P3P

• A framework for standardized, machine readable
  privacy policies.
• Relieve the problem of time consuming process of
  reading policy.
• Enabled web browser can decide what to do by
  comparing this policy with the user's stored
  preferences.
• An XML file or in the HTTP header

38
An Example P3P File
39
Main Content of a Policy

• which information the server stores
• which kind of information is collected
  (identifying or not)
• which particular information is collected (IP
  number, email address, name, etc.)
• use of the collected information
• how this information is used (for regular
  navigation, tracking, personalization,
  telemarketing, etc.)
• who will receive this information (only the
  current company, third party, etc.)
• permanence and visibility
• how long information is stored
• whether and how the user can access the stored
  information (read-only, optin, optout).

40
Privacy Awareness System (PawS)

• Based on Fair Information Practices
• Mainly focuses on four principles
• Notice
• Policy announcement mechanisms
• Choice and Consent
• Machine readable policies
• Proximity and locality
• Access restriction based on location.
• Access and recourse
• Privacy proxies / privacy-aware databases

41
Overview of PawS
42
Wearable

• Instead of putting sensors and cameras in the
  room put them on the person.
• Suited to providing privacy and personalization.
• Have trouble with localized information,
  localized control and resource managemen

43
Other Approaches

• Location privacy policy
• Individual should be able to adjust the accuracy
  of his location, identity, time and speed and
  therefore have the power to enforce the
  need-to-know principle
• Privacy Mirror
• provides feedback to end-users, showing them what
  information is being collected, and what
  information has been accessed and by whom.

44
Policy Based Privacy
45
Personal Privacy Policies

• Policies defined
• Personal privacy policy defined
• Proposed personal privacy model

46
Personal Privacy Policy Model
47
Personal Privacy Policy Content

• Model Code for the Protection of Personal
  Information
• Privacy risk analysis questions

48
Model Code for the Protection of Personal
Information 10 Principles

• Accountability
• Identifying Purpose
• Consent
• Limiting Collection
• Limiting Use, Disclosure, Retention

49
Model Code for the Protection of Personal
Information 10 Principles

• Accuracy
• Safeguards
• Openness
• Individual Access
• Challenging Compliance

50
Personal Privacy Policy Sample
51
Usage Control Policies

• Usage control policy defined
• Usage control policy goal

52
Usage Control Policy Concept

53
Usage Control Policy Components

• Requirements
• Obligations
• Controllable
• Observable
• Compensation Actions

54
Usage Control Policy Components

• High-level policies
• Low-level policies

55
Usage Control Policy Process
56
Privacy Policy Discussion

• Personal Privacy Policy
• Usage Control Policy
• Technological Solutions
• Enhanced Privacy in UBICOMP

57
Trust and Reputation Based Control

• People use trust and reputation to manage their
  privacy.
• Not all people are untrustworthy.
• Some have higher reputation, someone we trust
  more and to whom we are willing to give more
  privacy information.
• trust networks and a reputation system to help
  users manage how, when, and where they share
  their personal information.

58
Advantages

• Policy based mechanism such as P3P and pawS
  assume that the user maintains only one privacy
  policy and this policy is applicable to all
  entities.
• Two advantages
• Adaptivity
• Flexibility

59
Conclusion

• Fair Information Practices should be served as
  guidelines for designing a ubicomp system.
• Internet vulnerabilities should also be
  considered.
• Minimizing Asymmetry.
• Machine readable policies.
• Trust and reputation based system for information
  sharing.

60
Questions?
