Hyper Text Transfer Protocol

1
Hyper Text Transfer Protocol

• (HTTP)

2
HTTP

• HTTP defines how Web pages are requested and
  served on the Internet
• Early servers and browsers used an ad-hoc
  approach
• A standardized protocol, called HTTP/1.0, was
  derived from this
• The earlier approach is now called HTTP/0.9
• Later, HTTP/1.0 was extended to HTTP/1.1
• The protocol versions are upwardly compatible
• servers and browsers which can handle HTTP/1.1
  can also handle HTTP/1.0 and HTTP/0.9

3
History HTTP/0.9

• HTTP/0.9 was very simple
• A browser would send a request like this to a
  server
• GET /hobbies.html
• In response, the server would send the contents
  of the requested file.
• Only GET requests were supported
• Only a file path and name could appear in a GET
  request
• The response had to be a HTML document.

4
Got here on 14/jan/2003
5
History (contd.)

• Different browsers/servers soon extended this
  basic scheme in various ways
• To achieve some standardization, the HTTP/1.0
  protocol was specified, in 1996, in a document
  called RFC1945
• (for historical reasons, an Internet standard
  spec is called a Request for Comment or RFC)
• This was soon extended to HTTP/1.1, in RFC2068,
  released in January 1997
• An update to RFC2068 was produced in June 1999,
  as RFC2616
• Various other protocols, based on HTTP, have been
  produced from time-to-time
• we will see a cookie protocol, based on HTTP,
  which was specified in February 1997, in RFC2109

6
How HTTP Works

• HTTP sits on TCP, which, in turn, sits on IP
• Usually, HTTP servers are configured to listen to
  TCP/IP Port 80
• although sometimes a different port is used,
• particularly if two HTTP servers are running on
  one machine
• You can see how HTTP works by pretending to be a
  browser yourself
• Using telnet to connect to a server, you can
  issue a request and see the response

7
Example

• If you were to point a browser at the URL
• http//student.cs.ucc.ie
• you would get a HTML home-page which provides
  links to various pages for students, etc.
• The server on student.cs.ucc.ie uses the standard
  HTTP port, Port 80, so you can get the same page
  by
• telnetting to Port 80 on student.cs.ucc.ie
• and typing a GET request

8
Connecting to the HTTP server on student.cs.ucc.ie

• On any machine, say interzone, specify the
  address and port in a telnet command
• interzone.ucc.iegt telnet student.cs.ucc.ie 80
• You will get the following response
• Trying 143.239.211.125...
• Connected to student.cs.ucc.ie.
• Escape character is ''.
• The HTTP server is now listening

9
Requesting the home page

• Issue the following HTTP/1.0 request, noting
  that you must type two carriage returns
• GET / HTTP/1.0 RETURN
• RETURN
• The response consists of
• a status line,
• a sequence of headers and
• the requested home page
• Then you are told that the telnet connection was
  closed by the server,
• as you will see on the next slide

10
Cs 607 got here on 14 dec 2004
11
The reply to your request

• The servers response
• HTTP/1.1 200 OK
• ...
• Content-Type text/html
• ltHTMLgt
• ...
• lt/HTMLgt
• Then your local telnet program tells you that the
  connection was closed by the server
• Connection closed by foreign host.
• interzone.ucc.iegt

12
Getting a different page

• Consider the page whose URL is
• http//student.cs.ucc.ie/cs1064/jabowen/
• Telnet to the server
• interzone.ucc.iegt telnet student.cs.ucc.ie 80
• When the server is listening, ask for the page
  like this
• GET /cs1064/jabowen/ HTTP/1.0 RETURN
• RETURN

13
What was going on above

• Once connected to a HTTP server, we can
• send a HTTP request line,
• optionally followed by request headers.
• In the cases above,
• GET / HTTP/1.0
• and
• GET /cs1064/jabowen/ HTTP/1.0
• were request lines
• Each request line was terminated by pressing
  RETURN
• In each case, the second RETURN marked the end
  of an empty list of request headers

14
GET requests

• In GET / HTTP/1.0
• the / is the resource the client wants to get
• the HTTP/1.0 tells the server that the client is
  using the HTTP/1.0 protocol
• In GET /cs1064/jabowen/ HTTP/1.0
• the /cs1064/jabowen/ is the resource the client
  wants to get
• the HTTP/1.0 tells the server that the client is
  using the HTTP/1.0 protocol
• In each case, the server responds by sending a
  status line, a number of response headers and the
  content of the requested resource.

15
Consider the response

• HTTP/1.1 200 OK
• ...
• Content-Type text/html
• ltHTMLgt
• ...
• lt/HTMLgt
• The first line, HTTP/1.1 200 OK , is a status
  line
• The next few lines, ending in the line
  Content-Type text/html, are header lines
• The lines bounded by ltHTMLgt and lt/HTMLgt form
  the content of the requested resource.

16
HEAD requests

• HEAD requests were new in HTTP/1.0
• A HEAD request is similar to a GET, the only
  difference being the use of the word HEAD instead
  of the word GET, for example
• HEAD /cs1064/jabowen/ HTTP/1.0 RETURN
• RETURN
• The server sends the same status line and the
  same response headers as if it had received a GET
  request,
• but does not send the actual content of the
  resource mentioned in the request.
• Thus, human clients can use HEAD requests to
• access easily information about a resource on a
  server
• without being overwhelmed by the mass of detail
  that would be received if the resource content
  were sent in the response

17
Example HEAD request

• Suppose, for example, we wanted to see
  information about
• http//student.cs.ucc.ie/cs1064/jabowen/
• such as its size, when it was last edited, etc.
• We can send the request
• HEAD /cs1064/jabowen/ HTTP/1.0

18
Response to example HEAD request

• HTTP/1.1 200 OK
• Date Wed, 13 Dec 2000 122135 GMT
• Server Apache/1.3.14 (Unix) PHP/4.0.3pl1
• Last-Modified Thu, 07 Dec 2000 131618 GMT
• ETag "2160-29c6-3a2f8da2"
• Accept-Ranges bytes
• Content-Length 10694
• Connection close
• Content-Type text/html

19
Analysis of response

• The first line in the response
• HTTP/1.1 200 OK
• is the status line in which
• HTTP/1.1 indicates that the server can use
  HTTP/1.1 (although it can accept requests in
  earlier HTTP forms)
• 200 is a code which indicates the status the
  request was given by the server
• OK is an English language phrase giving the
  meaning of the status code
• The other lines in the response give information
  either about the server or the resource

20
Analysis (contd.)

• Date Wed, 13 Dec 2000 122135 GMT
• gives date/time of the response
• Server Apache/1.3.14 (Unix) PHP/4.0.3pl1
• gives details on server
• Last-Modified Thu, 07 Dec 2000 131618 GMT
• says when resource was last modified
• ETag "2160-29c6-3a2f8da2"
• provides a supposedly-unique string to identify
  this entity
• Accept-Ranges byte
• says that this server could serve up pieces of
  this resource, pieces specifiable to the nearest
  byte
• Content-Length 10694
• gives the size of the resource
• Connection close
• says that the server does not regard this as a
  persistent connection
• Content-Type text/html
• gives the type of data in the resource

21
Another example

• Suppose, we wanted to learn about the resource
  with URL
• http//student.cs.ucc.ie/cs1064/jabowen/vh40.gif
• We can send the request
• HEAD /cs1064/jabowen/vh.gif HTTP/1.0
• Response is
• HTTP/1.1 200 OK
• Date Wed, 13 Dec 2000 122304 GMT
• Server Apache/1.3.14 (Unix) PHP/4.0.3pl1
• Last-Modified Fri, 24 Nov 2000 114600 GMT
• ETag "3133-361-3a1e54f8"
• Accept-Ranges bytes
• Content-Length 865
• Connection close
• Content-Type image/gif

22
Cs 607 got here on 21 Jan 2003
23
HTTP/1.1

• A (fairly) detailed description

24

• We have just seen some example HTTP/1.0
  interactions
• The same kinds of concepts we saw in these
  interactions will arise as we examine HTTP/1.1 in
  more detail
• The versions of HTTP have a great deal in common,
  so, in what follows, much of what is said will be
  true of all three versions
• Therefore,, any mention of just HTTP will mean
  that the statement applies to HTTP/0.9, HTTP/1.0
  and HTTP/1.1

25
Overall Operation of HTTP

• The HTTP protocol is a request/response protocol.
• request
• An HTTP message sent by a client to a server
• response
• An HTTP message sent by a server to a client
  which has made a request.
• client
• A program that establishes connections for the
  purpose of sending requests.
• server
• A program that accepts connections in order to
  service requests by sending back responses.
• As we shall see, a program may act as both a
  client and a server.

26
Message from a client

• A client sends, over a connection, to a server
• a request line in the form of
• a request method,
• a URI (Uniform Resource Identifier), and
• a protocol version,
• possibly followed by a message containing
• request modifiers,
• information about the client,
• and (possibly) body content.

27
Response from a server

• The server responds with
• a status line, in the form of
• the message's protocol version,
• a success or error code and
• an English phrase explaining the code
• possibly followed by a message containing
• server information,
• information about the entity in the body content
  (if any)
• and (possibly) body content.

28
HTTP Communication

• Most communication
• is started by a user agent and
• consists of a request to be applied to a resource
  on some origin server.
• user agent
• A client (browser, spider, etc.) which initiates
  a request.
• resource
• A data object or service that can be identified
  by a URI.
• origin server
• The server on which a resource resides or is to
  be created.

29
Cs 607n got here on 11 jan 2005
30
Simple communication

• Involves single connection between user agent
  (UA) and origin server (O)
• This connection is denoted, in diagrams on this
  and future slides, by -------
• request chain gt
• UA -----------------------------------O
• ltresponse chain

31
More complicated case

• Intermediaries present in request/response chain.

• request chain gt
• UA ----------- A ----------- B ----------- C
  ----------- O
• ltresponse chain
• Above, 3 intermediaries (A, B, and C) lie
  between user agent and origin server.
• Intermediaries act as both clients and servers
• Request or response message that travels the
  whole chain passes through 4 separate
  connections
• UA-A connection
• A-B connection
• B-C connection
• C-O connection

32
Simple versus complicated

• Distinction is important because some HTTP
  options may apply
• only to the connection with the nearest
  neighbour,
• only to the end-points of the chain,
• or to all connections along the chain.

33
3 forms of intermediary

• proxy, an agent which
• receives a request for a resource whose URI is in
  its absolute form and,
• if necessary, rewrites all or part of the message
  and forwards the reformatted request toward the
  server identified by the URI.
• gateway, an agent which
• acts as a translation interface to a server for
  another protocol, such as WAP, etc.
• tunnel, an agent which
• acts as a relay point between two connections
  without changing messages
• tunnels are used, for example, in security
  firewalls

34
Caching
35
Caching

• User agents, proxies and gateways (but not
  tunnels) may use a local cache to handle
  requests, instead of forwarding them on to an
  origin server
• A request/response chain is shortened if one of
  the parties along the chain has a cached response
  applicable to the request.

36
Example Network topology

• The example caching scenarios in the next few
  slides will use this network
• UA3____________D
• UA2_____
• UA1_____A______B________C_________O

37
Caching Example 1

• request chain gt
• UA1 ----------- A ----------- B -------- C
  --------- O
• ltresponse chain
• In the example above
• the user has made a request for a resource on
  origin server O
• neither UA1 nor any of the proxies A, B or C has
  an appropriate cached response
• so the request has been forwarded all the way to
  O
• Four connections are involved in servicing the
  request

38
Caching Example 2

• request
• chain
• UA1.... A ... B .. C O
• response
• chain
• In the example above
• the user has repeated the same request for a
  resource on O
• UA1 has a cached response to the earlier request
  and gives this to the user without sending the
  request anywhere
• No connection is involved in servicing the
  request

39
Caching Example 3

• request chain gt
• UA2 -----------------
• UA1 ........ A .. B .. C ... O
• ltresponse chain
• In the example above
• the user at UA2 has requested the same resource
  on origin server O that was earlier requested by
  the user at UA1
• UA2 has forwarded the request to proxy A
• proxy A has an appropriate cached response, from
  when it serviced the earlier request from UA1
• Only one connection is involved in servicing the
  request

40
Caching Example 4

• request chain gt
• UA3 ---------- D --------
• UA1 ..... A .. B .. C ... O
• ltresponse chain
• In the example above
• the user at UA3 has requested the same resource
  on origin server O that was earlier requested by
  the user at UA1
• UA3 has forwarded the request to proxy D, which
  has forwarded it to proxy B
• proxy B has an appropriate cached response, from
  when it serviced the earlier request from UA1
• Two connections are involved in servicing the
  request

41
To cache or not?

• Not all responses are usefully cacheable
• As we will see later, some requests may contain
  modifiers which place special requirements on
  cache behavior.
• The same is true of responses

42
Cs 607 ngot here on 28 january 2003
43
Caching/Proxy architectures

• A wide variety of cache and proxy
  architectures/configurations exist, including
• national hierarchies of proxy caches to save
  inter-national and/or inter-continental
  bandwidth,
• systems that broadcast or multicast cache
  entries,
• organizations that distribute subsets of cached
  data via CD-ROM,
• and so on.

44
Connections
45
Temporary Connections

• In most implementations of HTTP/1.0, a server
  closed a connection after it had serviced the
  request received on that connection
• We saw this earlier, when the server on
  student.cs.ucc.ie closed the telnet connection
  that we had established, after it had sent its
  response to the HTTP/1.0 GET request we had sent
• The use of inline images, sound files, etc., in
  web pages often requires a client to make
  multiple requests of the same server when loading
  one document
• Thus the temporary connections provided by
  HTTP/1.0 meant that loading even one web page
  required many separate TCP connections (one to
  to fetch each inline image, each sound file etc.)

• This imposed a significant unnecessary load on
  HTTP servers and caused congestion on the
  Internet.

46
Advantages of Persistent Connections

• Persistent HTTP connections offer a number of
  advantages
• By opening and closing fewer TCP connections, CPU
  time is saved
• HTTP requests and responses can be pipelined on a
  connection, allowing a client to make multiple
  requests without waiting for each response
• Network congestion is reduced by reducing the
  number of packets caused by TCP opens,
• Latency on subsequent requests is reduced since
  there is no time spent in TCP's
  connection-opening handshake.

47
Persistent Connections in HTTP/1.1

• Unlike HTTP/1.0 and earlier, persistent
  connections are the default behavior of any
  HTTP/1.1 connection.
• This means that, in HTTP/1.1, when a connection
  has been opened to service a request, it is kept
  open for further possible requests from the same
  client
• This is true even if the initial request
  triggered an error response from the server
• But, when no further request has been received
  after some time-out period, the server may close
  the connection
• However, a client can indicate, when making a
  request, that it wants the connection closed
  after the request is serviced

48
Connection Persistency Negotiation

• HTTP/1.1 provides a mechanism by which a client
  and a server can signal the close of a TCP
  connection.
• the Connection header field.
• If a HTTP/1.1 client wants a connection closed
  after it receives a response to its request, it
  should include, in the request, a Connection
  header containing the token "close" .
• Similarly, if a HTTP/1.1 server intends to close
  a connection closed after it sends a response to
  a request, it should include, in the response, a
  Connection header containing the token "close"
  .
• If either the client or the server sends the
  close token in a Connection header, that request
  becomes the last one for the connection.

49
Example 1 Introduction

• A human, using a telnet client, sends a HTTP/1.0
  request to a HTTP/1.1 server
• The server assumes that the client, because it is
  using HTTP/1.0, cannot handle persistent
  connections and, in its response, signals its
  intention to close the connection
• After printing the response, the telnet client
  says that the connection was closed by the
  foreign host

50
Example 1

• interzone.ucc.iegt telnet student.cs.ucc.ie 80
• Trying 143.239.211.125...
• Connected to student.cs.ucc.ie.
• Escape character is ''.
• HEAD /cs1064/jabowen/ HTTP/1.0
• HTTP/1.1 200 OK
• Date Sat, 06 Jan 2001 175644 GMT
• Server Apache/1.3.14 (Unix) PHP/4.0.3pl1
• Last-Modified Wed, 20 Dec 2000 113446 GMT
• ETag "2160-2dee-3a409956"
• Accept-Ranges bytes
• Content-Length 11758
• Connection close
• Content-Type text/html
• Connection closed by foreign host.

51
Example 2 Introduction

• A human, using a telnet client, sends a HTTP/1.1
  request to a HTTP/1.1 server
• The server assumes that the client, because it is
  using HTTP/1.1, wants a persistent connection
• thus, there is no Connection header in the
  response
• The telnet client prints the response for the
  human to see
• After a significant delay (the time-out period),
  the server realizes the client has no further
  request and closes the connection
• The telnet client then tells the human that the
  connection was closed by the foreign host

52
Example 2

• interzone.ucc.iegt telnet student.cs.ucc.ie 80
• Trying 143.239.211.125...
• Connected to student.cs.ucc.ie.
• Escape character is ''.
• HEAD /cs1064/jabowen/ HTTP/1.1
• Host student.cs.ucc.ie
• HTTP/1.1 200 OK
• Date Sat, 06 Jan 2001 175708 GMT
• Server Apache/1.3.14 (Unix) PHP/4.0.3pl1
• Last-Modified Wed, 20 Dec 2000 113446 GMT
• ETag "2160-2dee-3a409956"
• Accept-Ranges bytes
• Content-Length 11758
• Content-Type text/html
• A time-out period elapses before server closes
  connection
• Connection closed by foreign host.

53
Example 3 Introduction

• A human, using a telnet client, sends a HTTP/1.1
  request to a HTTP/1.1 server
• The client knows that, because it is using
  HTTP/1.1, the server will think it wants a
  persistent connection
• Since the client does not want a persistent
  connection it sends a Connection header with a
  close token in the request
• Seeing this, the server indicates its intention
  to close the connection immediately, by including
  a Connection header with a close token in its
  response
• The telnet client prints the response for the
  human to see and, immediately thereafter, tells
  the human that the connection was closed by the
  foreign host

54
Example 3

• interzone.ucc.iegt telnet student.cs.ucc.ie 80
• Trying 143.239.211.125...
• Connected to student.cs.ucc.ie.
• Escape character is ''.
• HEAD /cs1064/jabowen/ HTTP/1.1
• Host student.cs.ucc.ie
• Connection close
• HTTP/1.1 200 OK
• Date Sat, 06 Jan 2001 175758 GMT
• Server Apache/1.3.14 (Unix) PHP/4.0.3pl1
• Last-Modified Wed, 20 Dec 2000 113446 GMT
• ETag "2160-2dee-3a409956"
• Accept-Ranges bytes
• Content-Length 11758
• Connection close
• Content-Type text/html
• Connection closed by foreign host. (No time-out
  delay before this from telnet client)

55
Pipelining Requests

• A client that supports persistent connections may
  "pipeline" its requests (i.e., send multiple
  requests without waiting for each response).
• A server must send its responses to those
  requests in the same order that the requests were
  received.

56
Example 4 Introduction

• A human, using a telnet client, sends two
  HTTP/1.1 requests to a HTTP/1.1 server, sending
  the second request before it even receives a
  response to the first request
• Since he has only two requests, the client sends
  a Connection header with a close token in the
  second request
• The server responds to both requests and, because
  of the close token in the 2nd request, indicates
  its intention to close the connection
  immediately, by including a Connection header
  with a close token in its response to the 2nd
  request.
• The telnet client prints the responses for the
  human to see and, immediately thereafter, tells
  the human that the connection was closed by the
  foreign host

57
Example 4 the pipelined requests

• interzone.ucc.iegt telnet student.cs.ucc.ie 80
• Trying 143.239.211.125...
• Connected to student.cs.ucc.ie.
• Escape character is ''.
• HEAD http//student.cs.ucc.ie/cs1064/jabowen/
  HTTP/1.1
• Host student.cs.ucc.ie
• HEAD http//student.cs.ucc.ie/cs4400/jabowen/
  HTTP/1.1
• Host student.cs.ucc.ie
• Connection close

58
Example 4 the sequence of responses

• HTTP/1.1 200 OK
• Date Wed, 31 Jan 2001 200141 GMT
• Server Apache/1.3.14 (Unix) PHP/4.0.3pl1
• Last-Modified Thu, 25 Jan 2001 132632 GMT
• ETag "2160-2e25-3a702988"
• Accept-Ranges bytes
• Content-Length 11813
• Content-Type text/html
• HTTP/1.1 200 OK
• Date Wed, 31 Jan 2001 200141 GMT
• Server Apache/1.3.14 (Unix) PHP/4.0.3pl1
• Last-Modified Wed, 20 Dec 2000 124239 GMT
• ETag "13d3a-2b60-3a40a93f"
• Accept-Ranges bytes
• Content-Length 11104
• Connection close
• Content-Type text/html

59
Pipelining Requests (contd.)

• Clients which assume persistent connections and
  pipeline immediately after connection
  establishment should be prepared to retry their
  connection if the first pipelined attempt fails.
• If a client does such a retry, it must NOT
  pipeline before it knows the connection is
  persistent.
• Clients must also be prepared to resend their
  requests if the server closes the connection
  before sending all of the corresponding responses.

60
Pipelining Requests (contd.)

• Care must be taken when pipelining
• because some requests (called non-idempotent
  requests) may change the state of the server (for
  example, by changing a database used by the
  server)
• Clients should NOT pipeline such requests
• Otherwise, a premature termination of the
  transport connection could lead to indeterminate
  results.
• A client wishing to send a non-idempotent request
  should wait to send that request until it has
  received the response status for the previous
  request.

61
Cs 607 got here on 18 jan 2005
62
Uniform Resource Identifiers
63
Uniform Resource Identifiers

• URIs have been known by many names
• WWW addresses,
• Universal Document Identifiers,
• Universal Resource Identifiers,
• Uniform Resource Locators (URL)
• Uniform Resource Names (URN).
• For HTTP, URIs are simply formatted strings
  which identify (by name, location, or any other
  characteristic) a resource.

64
CS 607 got here on 4/Feb/2003
65
General URI Syntax

• URIs in HTTP can be represented in absolute form
  or relative to some known base URI.
• The two forms are differentiated by the fact that
  absolute URIs always begin with a scheme name
  followed by a colon.

66
http-scheme URIs

• A URI which is based on the http scheme must be
  of the syntactic form
• "http" "//" host "" port abs_path "?"
  query
• where items enclosed in are optional
• If the port is not given, Port 80 is assumed.

67
Meaning of a http-scheme URI

• The meaning of a http-scheme URL is that the
  identified resource is on the server at that port
  of the host, and the Request-URI for the resource
  is abs_path.
• Thus, for example, pointing a browser at
• http//student.cs.ucc.ie/cs1064/jabowen/
• is the same as opening a TCP/IP connection to
  Port 80 on student.cs.ucc.ie and sending either
• the HTTP/1.0 request
• GET /cs1064/jabowen/ HTTP/1.0
• or the HTTP/1.1 request
• GET /cs1064/jabowen/ HTTP/1.1
• Host student.cs.ucc.ie
• (As we shall see later, all HTTP/1.1 requests
  must include a Host header field)

68
Meaning of a http-scheme URI (contd.)

• The lectures on HTML forms given earlier in this
  course used a method called POST to send
  user-supplied data to a server
• The POST method was not defined in HTTP/0.9,
  which only provided one method, the GET method
• The convention used in HTTP/0.9 to send data to a
  server was to encode the data in the Request-URI,
  in the form of a query at the end
• The convention is still supported in HTTP/1.1.
  Consider the following form
• ltform action"http//student.cs.ucc.ie/myProg.cgi"
  method"get"gt
• Home town ltinput type"text" name"hometown gt
• ltbutton type"submit"gt Send data lt/buttongt
• lt/formgt
• If the user entered cork in the input box and
  submitted the form, the browsers request would
  include this request line
• GET http//student.cs.ucc.ie/myProg.cgi?hometown
  cork HTTP/1.1

69
Meaning of a http-scheme URI (contd.)

• The query in a URL can include several
  equations. Consider the following form
• ltform action"http//student.cs.ucc.ie/myProg.cgi"
  method"get"gt
• Surname ltinput type"text" namesurname gt
• Home town ltinput type"text" name"hometown gt
• ltbutton type"submit"gt Send data lt/buttongt
• lt/formgt
• If the user entered sullivan and cork in the
  input boxes and submitted the form, the browsers
  request would include this request line
• GET http//student.cs.ucc.ie/myProg.cgi?surnames
  ullivanhometowncork HTTP/1.1
• Equations in a query are separated by the
  character

70
Meaning of a http-scheme URI (contd.)

• Some characters in user-supplied data have to be
  specially handled when a browser is writing the
  query in a Request-URI
• The following characters, called the reserved
  characters, have a special usage in URIs
• / _at_ ?

• They have to be URL encoded, to send them in
  URI query
• Consider the following form
• ltform action"http//abc.com/prog.cgi"
  method"get"gt
• Name of company ltinput type"text"
  namecompany gt
• Home town ltinput type"text" nameplace gt
• ltbutton type"submit"gt Send data lt/buttongt
  lt/formgt
• If the user entered BlackDecker and Cork in
  the input boxes, the browsers request would
  include this request line
• GET http//abc.com/prog.cgi?companyBlack26Decke
  rplaceCork HTTP/1.1
• where the URL encoded form of is 26, the 26
  being the headecimal ASCII code for

71
Meaning of a http-scheme URI (contd.)

• URL escape codes for the reserved characters
• colon 3A
  slash 2F
• at (_at_) 40
  question-mark 3F
• equals 3D
  ampersand 26
• semi-colon() 3B

72
CS4400 got to here at 1600 ON 7/12/2001
73
Meaning of a http-scheme URI (contd.)

• The following characters, called the unsafe
  characters, should also be URL-encoded in URIs,
  using the hex codes specified
• space 20
  quotation mark 22
• less than 3C
  greater than 3E
• hash () 23
  percent 25
• left brace 7B
  right brace 7D
• pipe () 7C
  Backslash 5C
• Caret () 5E
  Tilde 7E
• Left Sq Bracket 5B
  Right Sq Bracket 5D
• Grave accent () 60
• These characters are unsafe for different reasons

74
Length of URI

• Since a browser which is sending user-supplied
  data to a server includes these data in the query
  part of a URL, URLs can get quite long
• The HTTP protocol does not place any a priori
  limit on the length of a URI
• Servers must be able to handle the URI of any
  resource they serve up
• Servers should be able to handle URIs of
  unbounded length if they serve up GET-based forms
  that could generate such URIs.
• A server should return 414 (Request-URI Too
  Long) status if a URI is longer than the server
  can handle.

75
Host names in http-scheme URIs

• A fully-qualified host name of a host means
• either the fully-qualified domain name (i.e., a
  completely specified domain name ending in a
  top-level domain such as .com or .ie),
• or the numeric Internet Protocol (IP) address of
  the host.
• The fully qualified domain name is preferred
  use of numeric IP addresses in URIs is strongly
  discouraged. and should be avoided whenever
  possible.

76
Proxy handling of host names

• If a proxy receives a fully qualified domain
  name, the proxy must NOT change the host name.
• But, if a proxy receives a host name which is not
  a fully qualified domain name, it may add its
  domain to the host name it received.

77
Example

• Suppose we use the host name cosmos in a URL
  sent to the proxy student.cs.ucc.ie
• Then the proxy can extend this to
  cosmos.cs.ucc.ie
• EG
• http//cosmos/jabowen/prog1.php
• becomes
• http//cosmos.cs.ucc.ie/jabowen/prog1.php

78

• http//www.independent.co.uk
• http//www.independent.co.uk/printer.php?storyID1
  4356
