CISCO NETWORKING ACADEMY PROGRAM CNAP

1
CISCO NETWORKING ACADEMY PROGRAM (CNAP) SEMESTER
1/ MODULE 5
Cabling LANs and WANs
2
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Networking Fundamentals
Objectives

• Upon completion of this module, the student will
  be able to perform tasks related to the
  following
• Cabling the LAN
• Cabling the WAN

3
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
LAN Physical Layer
4
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Ethernet in the Campus
5
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Ethernet Media Connector
6
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Connection Media
7
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
UTP Implementation

• Order of the wires in must follow EIA/TIA-T568-A
  or T568-B standards
• Three types of patch cables
• Straight-though cable
• Switch to router
• Switch to PC or server
• Hub to PC or server
• Crossover cable
• Switch to switch
• Switch to hub
• Hub to hub
• Router to router
• PC to PC
• Router to PC
• Rollover cable
• console cable

8
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
UTP Implementation
9
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Repeaters
10
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Hubs

• multiport repeaters (generally have from two to
  twenty-four ports)
• data arriving over the cables to a hub port is
  electrically repeated on all the other ports
  connected to the same network segment, except for
  the port on which the data was sent

11
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Bridges
12
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Switches

• Sometimes described multiport bridges
• Operate at data link layer of OSI reference model
• Switches use gathered information to build
  forwarding tables to determine the destination

13
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Switches
14
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Wireless

• Wireless signals are electromagnetic waves that
  travel through the air
• Wireless networks use Radio Frequency (RF),
  laser, infrared (IR), or satellite/microwaves to
  carry signals from one computer to another
  without a permanent cable connection
• Two most common wireless technologies used for
  networking are

• IR - line of sight
• RF - out of sight, two approaches used to
  implement spread spectrum for WLAN transmissions
  are Frequency Hopping Spread Spectrum (FHSS) and
  Direct Sequence Spread Spectrum (DSSS)

15
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Host Connectivity

• Host can connect to network using Network
  Interface Card (NIC)
• NIC is layer-2 device and each NIC carries a
  unique code called MAC address

16
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Peer-to-peer Client-server

• Peer-to-peer
• networked computers act as equal partners, or
  peers
• users control their own resources
• Client-server
• server is a central computer that respond to
  requests from clients for file, print,
  application, and other services

17
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Peer-to-Peer VS Client/Server
18
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Peer-to-Peer VS Client/Server
19
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
WAN Physical Layer
20
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
WAN Serial Connection
DTE Data Terminal Equipment DCE Data
Communications Equipment CSU Channel Service
Unit DSU Data Service Unit
21
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Routers and Serial Connections
22
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Routers and Serial Connections
23
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Routers and Serial Connections
24
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Routers and Serial Connections
port type slot number / port number
25
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Routers and ISDN BRI Connections

• With ISDN BRI, two types of interfaces may be
  used, BRI S/T and BRI U
• A BRI interface with an integrated NT1 is labeled
  BRI U
• A BRI interface without an integrated NT1 is
  labeled BRI S/T

26
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Routers and DSL Connections

• To connect a router for DSL service, use a phone
  cable with RJ-11 connectors.
• DSL works over standard telephone lines using
  pins 3 and 4 on a standard RJ-11 connector.

27
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Routers and Cable Connections

• Coaxial cable and a BNC connector are used to
  connect the router and cable system

28
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Setting Up Console Connections
29
CISCO NETWORKING ACADEMY PROGRAM SEMESTER 1/
MODULE 5
Cabling LANs and WANs
Summary
