System R Based Query Execution Optimization for
Internet Information Gathering
MS Thesis Defense
Senthil Gnanaprakasam
MS Committee Dr Subbarao Kambhampati Dr Chitta
Baral Dr Susan D Urban
http//tsangpo.eas.asu.edu
2
Organization
Internet Information Gathering Internet
databases Join ordering issues Current methods
and algorithms Internet System R
Algorithm Implementation and conclusion
3
Internet Information Gathering

• Internet Information Gathering

4
Need to order pizzas!
5
Need to order pizzas!
6
Need to order pizzas!
7
Need to order pizzas!
8
Need to order pizzas!
9
Need to order pizzas!
Information Gatherer
Other Sources
10
Information Integration
Uniform query interface Uses mediated
schema/virtual relations Source descriptions
statistics
Global Data Model
Query rewriting
Wrapper
Query plan optimization
Wrapper
Query execution engine
Wrapper
11
Query Rewriting

• Sound Does all data returned satisfy given
  query?
• Complete Does the query return all possible
  sound results?

12
Query Plan Optimization
Duplicate sources

• Subsumption of sources
• Quality of data
• Cost of accessing sources
• Ordering for optimized cost

Pay-per-use, Network costs
13
Internet Databases

• Internet Databases

14
Types of internet databases
1
Form interfaced database
2
Text database
Intranet databases
3
15
Source Statistics

• Access and transfer time vary widely with
• Type of source local, intranet, Internet
• Time of the day
• Number and speed of servers
• Reliability of connection

16
Binding Constraints

• What attributes can be bound?
• Books isbn, title, author, publisher, price,
  pagesf
• YellowPages (lastNamef, firstName, zip, phoneb)
• YellowPages (lastNameb, firstName, zip, phonef)

17

• Join Ordering Issues

18
Importance of join ordering
P ? Q
Q ? P
a 100t
100a 10t
a 10t
10a 100t
Cost(P?Q) a 100t 100a 10t
Cost(Q?P) a 10t 10a 100t
Internet source access time
90a
Traditional Hard disk seek time
19
Internet Information Gathering
University (Intranet)
Administration
Student
Library (Machine)
Information Gatherer
Books
Lost
Borrow
20
Schema

• Books (isbnb, title, author, publisher, price,
  pages)
• Student (idb, firstName, lastName)
• Borrow (studentId, isbn, dateIssued)
• Lost (isbn)
• SELECT
• FROM Student, Books, Lost, Borrow
• WHERE
• Borrow.isbnLost.isbn AND Books.isbnLost.isbn
  AND Borrow.idStudent.id

21
Current Methods Algos

• Current Methods Algorithms

22
Bound Is Easier

• Binding values to attributes produces lesser
  number of results
• Valid heuristic in absence of source statistics
• Example
• UniversityStudent(Name, Age, Sex, Dept) 50,000
• UniversityStudent(Name, Age, Sex, CS)
  4,000
• UniversityStudent(Name, Age, M, CS)
  2,000

23
Greedy Algorithm

• Based on Bound-Is-Easier heuristic
• Gives importance to access costs keeping the
  Internet scenario
• Maintains a list of feasible binding patterns
• Views sources/binding patterns as either High
  Traffic Binding Pattern HTBP or Low Traffic
• Attempts are made at each iteration to access the
  most general feasible binding pattern if not in
  HTBP
• Sentinel checks ensure the algorithm proceeds to
  completion

24
Join Ordering Strategies
Bound is easier
UniversityStudent(Name, Age, Sex,
Dept) Student(Name, Id)
Greedy Algorithm
Student(Name, Id, Dept) UniversityStudent(Age,
Sex, Dept)
System R
Static query optimization algorithm Exhaustive
search Dynamic programming approach Retains
candidate trees with smallest cost and prunes
others
25
Shortcomings of System R
Binding restrictions not taken care of
?
Bushy
?
?
?
R4
?
R3
R4
?
R1
R2
R3
Left linear
R2
R1
Bushy trees not considered
26
ISR Algo

• Internet System R Algorithm

27
Internet System R

• Update bindings obtained from previous level of
  subplans
• Search all types of trees (left linear, bushy
  right linear)
• Use full set of statistics to estimate sizes
• Preserves graceful degradation property
• Trade off Planning vs. execution time

28
Algorithm

• INPUTS
• S 1..m Array of all subgoals expanded w.r.t
  binding patterns
• Associated data structure along with above
  which will help calculate costs
•
• Initialize NODE with
• PP nil Bindings f Cost0.
• IF S has a corresponding BestPlan
• return the corresponding join order
• ENDIF
• REPEAT
• FOR i 1 TO number of feasible leaf nodes
• FOR j 1 TO QCi DO
• LET LeftSubGoal jth element in
  QCi
• LET RightSubGoal S - LeftSubGoal
• Recursively call this algorithm with
  LeftSubGoal and RightSubgoal
• CurPlan Make a new plan by joining
  the above resultant plans
• IF it has a lower cost than current
  BestPlan THEN

Perform feasibility check
Bushy trees
Pruning
29
Example

• ISR (Student, Books, Borrow, Lost)
• ISR (Student, Books, Borrow) ? ISR (Lost)
• ISR (Student, Books, Lost) ? ISR (Borrow)
• ISR (Student, Lost, Borrow) ? ISR (Books)
• ISR (Books, Lost, Borrow) ? ISR (Student)
• ISR (Lost) ? ISR (Student, Books, Borrow)
• ISR (Borrow) ? ISR (Student, Books, Lost)
• ISR (Books) ? ISR (Student, Lost, Borrow)
• ISR (Student) ? ISR (Books, Lost, Borrow)
• ISR (Student, Books) ? ISR (Lost Borrow)
• ISR (Student, Lost) ? ISR (Books, Borrow)
• ISR (Student, Borrow) ? ISR (Books, Lost)
• ISR (Lost, Borrow) ? ISR (Student, Books)
• ISR (Books, Borrow) ? ISR (Student, Lost)
• ISR (Books, Lost) ? ISR (Student, Borrow)

30
Feasiblity Check

• Books (isbnb, title, author, publisher, price,
  pages)
• Student (idb, firstName, lastName)
• Borrow (studentId, isbn, dateIssued)
• Lost (isbn)
• ISR (Student, Books) ? ISR (Lost, Borrow)

31
Pruning

• Plan Cost
• (Student ? Borrow) ? (Books ? Lost) 2100
• (Books ? Lost) ? (Student ? Borrow) 2800

Pruned
32
Impl Conclusion

• Implementation Conclusion

33
Implementation

• Java 2 on Sun Solaris
• Simulated sources with variable statistics
• Measured time independent data

34
Experiments

• How important is access time?
• How big is the search space? How much is the
  overhead?
• Measure tradeoff between planning and execution
  time
• What if all statistics are not available?

35
Access Transfer Times
Measured for an intranet Internet source on a
T1 line intranet Access time 92ms Transfer
time 25ms/kb Internet Access time
4.8s Transfer time 25ms/kb
Access time is a large enough cost worth
spending time to optimize
36
ISR vs. SR

• Empirical evaluation of search space
• Trade off between planning time and execution time

Fast processors/slower network ? Lower total cost
It is worth exploring a larger search space
More optimal solution ? Lower execution cost
Larger search space? Higher planning cost
37
Effect of Binding Patterns

• Search space increases with number of sources
• Search space is more constrained and small as
  number of binding restrictions increase

Size of search space is a non-trivial function
of the given parameters
38
Graceful Degradation
Is searching a larger space a good idea when
statistics are not fully available?
Yes Preserves graceful degradation property of
traditional System R
39
Related Work

• Florescu, Levy et al
• Do not consider access costs being important
• Bottom up approach- build partial plans and check
  which ones lead to complete plans
• Consider planning time important and generate a
  best first method to produce before the algorithm
  runs to completion

40
Related Work

• Kabra and DeWitt
• Generate a seemingly optimal plan
• Difficult to gather statistics
• Run time collection of statistics and
  modification of plan

41
Related Work

• Urhan, Franklin et al
• Access costs are most important
• Concentrate on initial delays
• Change plan if delays exceed a limit

42
Contributions

• Analysis of importance of considering access
  costs
• Developed Internet System R Algorithm
• Included binding constraints over traditional
  System R
• Increased search space to include bushy trees
• Empirical evaluation of total cost compared to
  planning and execution costs
• Examined preservation of graceful degradation
  with a larger search space and partial statistics

43
Papers Published

• LKG99 Eric Lambrecht, Subbarao Kambhampati and
  Senthil Gnanaprakasam Optimizing Recursive
  Information Gathering Plans. In Proceedings of
  the IJCAI-99.
• KG99 Subbarao Kambhampati and Senthil
  Gnanaprakasam. Optimizing source-call ordering in
  information gathering plans. Proceedings of the
  IJCAI-99 Workshop on Intelligent Information
  Integration.

44
Thank You

• Questions?
