Improving Cache Performance

1
(No Transcript)
2
Improving Cache Performance
AMAT Hit time Miss rate Miss penalty

• Four categories of optimisation
• Reduce miss rate
• Reduce miss penalty
• Reduce miss rate or miss penalty using
  parallelism
• Reduce hit time

3
5.5. Reducing Miss Rate

• Three sources of misses
• Compulsory
• cold start misses
• Capacity
• Cache is full
• Conflict
• Set is full/block is occupied

Increase block size
Increase size of cache
Increase degree of associativity
4
Larger Block Size

• Bigger blocks reduce compulsory misses
• Spatial locality
• BUT
• Increased miss penalty
• More data to transfer
• Possibly increased overall miss rate
• More conflict and capacity misses as there are
  fewer blocks

5
Effect of Block Size
6
Larger Caches

• Reduces capacity misses
• Increases hit time and cost

7
Higher Associativity

• Miss rates improve with higher associativity
• Two rules of thumb
• 8-way set associative caches are almost as
  effective as fully associative
• But much simpler!
• 21 cache rule
• A direct mapped cache of size N has about the
  same miss rate as a 2-way set associative cache
  of size N/2

8
Way Prediction

• Set-associative cache predicts which block will
  be needed on next access to the set
• Only one tag check is done
• If mispredicted the whole set must be checked
• E.g. Alpha 21264 instruction cache
• Prediction rate gt 85
• Correct prediction 1 cycle hit
• Misprediction 3 cycles

9
Pseudo-Associative Caches

• Check a direct mapped cache for a hit as usual
• If it misses, check a second block
• Invert MSB of index
• One fast and one slow hit time

10
Compiler Optimisations

• Compilers can optimise code to minimise miss
  rates
• Reordering procedures
• Aligning basic blocks with cache blocks
• Reorganising array element accesses

11
5.6. Reduce Miss Rate or Miss Penalty via
Parallelism

• Three techniques that overlap instruction
  execution with memory access

12
Nonblocking caches

• Dynamic scheduling allows CPU to continue with
  other instructions while waiting for data
• Nonblocking cache allows other cache accesses to
  continue while waiting for data

13
Hardware Prefetching

• Fetch data/instructions before they are requested
  by the processor
• Either into cache or another buffer
• Particularly useful for instructions
• High degree of spatial locality
• UltraSPARC III
• Special prefetch cache for data
• Increases effectiveness by about four times

14
Compiler Prefetching

• Compiler inserts prefetch instructions
• Two types
• Prefetch register value
• Prefetch data cache block
• Can be faulting or non-faulting
• Cache continues as normal while data is prefetched

15
SPARC V9

• Prefetch

prefetch rs1 rs2, fcn prefetch rs1
imm13, fcn
fcn Prefetch function 0 Prefetch for
several reads 1 Prefetch for one read 2
Prefetch for several writes 3 Prefetch
for one write 4 Prefetch page
16
5.7. Reducing Hit Time

• Critical
• Often affects CPU clock cycle time

17
Small, simple caches

• Small usually equals fast in hardware
• A small cache may reside on the processor chip
• Decreases communication
• Compromise tags on chip, data separate
• Direct mapped
• Data can be read in parallel with tag checking

18
Avoiding address translation

• Physical caches
• Use physical addresses
• Address translation must happen before cache
  lookup
• Virtual caches
• Use virtual addresses
• Protection issues
• High context switching overhead

19
Virtual caches

• Minimising context switch overhead
• Add process-identifier tag to cache
• Multiple virtual addresses may refer to a single
  physical address
• Hardware enforces anti-aliasing
• Software requires less significant bits to be the
  same

20
Avoiding address translation (cont.)

• Choice of page size
• Bigger than cache index offset
• Address translation and tag lookup can happen in
  parallel

21
Pipelining cache access

• Split cache access into several stages
• Impacts on branch and load delays

22
Trace caches

• Blocks follow program flow rather than spatial
  locality!
• Branch prediction is taken into account by cache
• Intel NetBurst microarchitecture
• Complicates address mapping
• Minimises wasted space within blocks

23
Cache OptimisationSummary

• Cache optimisation is very complex
• Improving one factor may have a negative impact
  on another

24
5.6. Main Memory

• Latency and bandwidth are both important
• Latency is composed of two factors
• Access time
• Cycle time
• Two main technologies
• DRAM
• SRAM

25
5.7. Virtual Memory

• Physical memory is divided into blocks
• Allocated to processes
• Provides protection
• Allows swapping to disk
• Simplifies loading
• Historically
• Overlays
• Programmer controlled swapping

26
Terminology

• Block
• Page
• Segment
• Miss
• Page fault
• Address fault
• Memory mapping (address translation)
• Virtual address ? physical address

27
Characteristics

• Block size
• 4kB 64kB
• Hit time
• 50 150 cycles
• Miss penalty
• 1 000 000 10 000 000 cycles
• Miss Rate
• 0.000 01 0.001

?
?
28
Categorising VM Systems

• Fixed block size
• Pages
• Variable block size
• Segments
• Difficult replacement
• Hybrid approaches
• Paged segments
• Multiple page sizes (2n smallest)

29
Q1 Block placement?

• Anywhere in memory
• Fully associative
• Minimises miss rate

30
Q2 Block identification?

• Page/segment number gives physical page address
• Paging offset concatenated
• Segments offset added
• Uses a page table
• Number of pages in virtual address space
• Save space inverted page table
• Number of pages in physical memory

31
Q3 Block replacement?

• Least-recently used (LRU)
• Minimises miss rate
• Hardware provides a use bit or reference bit

32
Q4 Write strategy?

• Write back
• With a dirty bit

You wont become famous by being the first to try
write through!
33
Fast Address Translation

• Page tables are big
• Stored in memory themselves
• Two memory accesses for every datum!

• Principle of locality
• Cache recent translations
• Translation look-aside buffer (TLB), or
  translation buffer (TB)

34
Alpha 21264 TLB
35
Selecting a Page Size

• Big
• Smaller page table
• Allows parallel cache access
• Efficient disk transfers
• Reduces TLB misses
• Small
• Less memory wastage (internal fragmentation)
• Quicker process startup

36
Putting it ALL Together!

• SPARC Revisited

37
Two SPARCs

• SuperSPARC
• 1992
• 32-bit superscalar design
• UltraSPARC
• Late 1990s
• 64-bit design
• Graphics support (VIS)

38
UltraSPARC

• Four-way superscalar execution
• Two integer ALUs
• FP unit
• Five functional units
• Graphics unit

39
Pipeline

• 9 stages
• Fetch
• Decode
• Grouping
• Execution
• Cache access
• Load miss
• Integer pipe wait (for FP/graphics pipelines)
• Trap resolution
• Writeback

40
Branch Handling

• Dynamic branch prediction
• Two bit scheme
• Every second instruction in cache has prediction
  bits (predicts up to 2048 branches)
• 88 success rate (integer)
• Target prediction
• Fetches from predicted path

41
FPU

• Five functional units
• Add
• Multiply
• Divide/square root
• Two graphics units (add and multiply)
• Mostly fully pipelined (latency 3 cycles)
• Except divide and square root (not pipelined,
  latency is 22 cycles for 64-bit)

42
Memory Hierarchy

• On-chip instruction and data caches
• Data
• 16kB direct-mapped, write-through
• Instructions
• 16kB 2-way set associative
• Both virtually addressed
• External cache
• Up to 4MB

43
Virtual Memory

• 64-bit virtual addresses ? 44-bit physical
  addresses
• TLB
• 64 entry, fully-associative cache

44
Multimedia Support (VIS)

• Integrated with FPU
• Partitioned operations
• Multiple smaller values in 64-bits
• Video compression instructions
• E.g. motion estimation instruction replaces 48
  simple instructions for MPEG compression

45
The End!
