Enrollment Update

1
Enrollment Update Address Validation Training

• July 28, 2009

2
Agenda

• SRRTS Functions
• Setup
• Enrollment Update
• Purpose
• Fields
• Process Flow
• Address Validation (AV)
• Purpose
• IST CorrectAddress
• Address Standardization
• Existing Addresses
• Incoming Addresses
• Reports
• Strategies
• Resources
• Demonstration
• Documentation
• Reminders
• What to Do Next

3
SRRTS Functions
PeriodicUpdates
AddressValidation
LocatorDatabase
DirectCertification
4
Setup Step 1DataGate Client Software
5
Java Runtime Install Process

• Go to the CSIS DataGate Setup page
  (http//www.csis.k12.ca.us/setup/) and look at
  PART 1
• Download and follow the First time installation
  instructions- or If you already have Java,
  installed follow the Upgrade Instructions instead

6
Setup Step 2Digital Certificate
7
Digital Certificate Installation

• 128 bit encryption required
• MS Internet Explorer 6.0 or later supported
• May require browser upgrade http//www.microsoft.c
  om/windows/ie
• Browser updates may destroy certificate
• Yearly renewal necessary
• http//certificate.csis.k12.ca.us
• Required to access DataGate or TestGate

8
Digital Certificate Installation Process

• Go to http//www.csis.k12.ca.us/setup/ and look
  at PART 2
• Follow the instructions in the appropriate
  sub-section depending on whether you have ever
  had a CSIS digital certificate

9
Digital Certificate Application Form
7-digit County-District Number
Sign
Fax
Use full 14-digit CDS number if your LEA is a
charter school
10
Setup Step 3Translation Tables
11
Translation Tables

• Used to translate local codes to state codes for
  outgoing data, reverse translation for incoming
  data
• Based on the current school years state codes
• Managed by the LEA via User Preferences

12
Identifier Data Elements Eligible for Translation
State codes are listed in Appendix A of the
SRRTS User Guide
13
Translation Process

• From the Main CSIS Web page click on DataGate
  under the SSID tab.
• Select the Reporting Entity, current School Year,
  and Data Dictionary Version.
• Click User Preferences under Preferences.
• Click on Translation tab.
• Select the Data Dictionary version.
• Select the Code Table that contains the code you
  want to translate.

14
Translation Process (continued)

• 7. Select a Master Code on the left-hand side.
• 8. Enter a Local Code and Description in the
  two white boxes on the right.
• 9. Click Add.
• 10. Repeat steps 7-9 for each code you want to
  translate in the current table.
• 11. Click Apply.
• 12. Repeat steps 6-11 for each code element that
  needs translations entered.

15
Purpose of Enrollment Update

• Submit new and updated student addresses
• Direct Certification matching
• CALPADS preparation
• Address quality improvement via Address Validation

16
Required Extract Fields
Must equal the current date if the student is
active. Must equal the Withdrawal Date if the
student has a Withdrawal Reason.
17
Conditionally Required Extract Fields

• Student Enrollment Status
• Required for concurrently enrolled students at
  each non-primary school (school only providing
  additional services)
• English Language Learner Proficient or Advanced
  for ELA CST
• Required if English Proficiency is R-FEP. Y if
  student scored proficient or advanced on the
  English-Language Arts CA Standards Test for three
  years.
• Withdrawal Date Withdrawal Reason
• Required if student withdrew from a school
• Withdrawal date not required for some no-shows
  (430 470)
• Exit Code 108 not valid for exited students after
  12/31/07
• Exit Code 125 and 165 added this year

18
Conditionally Required Extract Fields (continued)

• UC CSU Course Requirements Met
• Required for graduates
• Independent Study Student
• Required for graduates
• Receiver School
• Required if Withdrawal Reason is 165
• School of Attendance
• Required if Institution ID of school of
  enrollment ends in 0000001 (i.e. student is
  attending a Non-public school)

See Appendix B (p. 55) for steps to look up the
CDS number for a Receiver school or Non-public
school
19
Optional Extract Fields

• Middle Name and Name Suffix (Jr., III, etc.)
• AKA Names (First, Last, Middle, Suffix)
• Birth Place (City, State, Country)
• Other Ethnicities

20
Periodic Enrollment Update Process Flow
Update Records
START HERE
Import Validate
StudentInformationSystem
Enrollment Update Extract (s)
Extract
Send
LocatorDatabase
Address EU Server Validation
Post
DataGate
ReviewReports
21
Purpose of Address Validation (AV)

• Improve address quality
• Direct Certification matching
• CALPADS
• Postal mailings (e.g. report cards)

Reminder Direct Certification compares 4
elements (name, gender, birth date, address)
21
22
IST CorrectAddress

• CSIS Address Validation uses a third party
  software called IST CorrectAddress
• Standard used by other companies
• Validates and corrects addresses based on USPS
  guidelines
• Updated every 60 days to meet USPS certification
  standards

22
23
Address Standardization
Sample Address

• 121 North Hamilton Drive 304
• Beverly Hills, CA 90211

Postal Standard
121 N HAMILTON DR APT 304 BEVERLY HILLS CA
90211-2259
The postal standard uses full uppercase and the
4-digit zip code add-on, but the address can
still be valid without using them
23
24
Address Parts
24
25
Incoming Addresses

• CSIS will validate the incoming addresses
  submitted during a Periodic Enrollment Update
  (DEMO file must be submitted)
• Two reports will be available on the View Status
  tab
• Address Server Validation Report (Addresses
  dropped)
• PDF format only
• Address Correction Report (Addresses
  automatically corrected)
• PDF or CSV format

25
26
Incoming Addresses View Status
26
27
Incoming Addresses - Report Type Selection
27
28

• REPORT DETAILS

28
29
Address Server Validation Report
29
30
Address Correction Report
30
31
CSV File Layout
32
CSV File Layout (continued)
33
Strategies

• Fix the errors on the Address Server Validation
  report first
• Determine how much time will be needed for
  corrections, based on address volume
• Automatically corrected
• Dropped
• Use CSV formatted correction report to sort or
  filter corrected address lists (e.g. sort list by
  site for distribution to schools)

33
34
Resources

• Zip Code Lookup (http//zip4.usps.com/zip4/welcome
  .jsp)
• Validate an individual address
• Address Management System Office Locator
  (http//www.usps.com/ncsc/lookups/ams_office_locat
  or.html)
• To report discrepancies in the USPS database
• USPS Address Standards
• PDF - http//pe.usps.gov/cpim/ftp/pubs/Pub28/pub28
  .pdf
• HTML - http//pe.usps.gov/text/pub28/welcome.htm

34
35
Periodic Enrollment Update Steps

• Populate SIS with required elements.
• Create the Enrollment Update (Enra) Demo
  extract files.
• Import extract files into DataGate.
• Review import reports, correct errors, and
  reimport (if necessary).
• Validate file.
• Review validation reports, correct errors, and
  re-import (if necessary).
• Review data submission summary report.
• Send file.
• Review server validation summary reports.
• Confirm and Post transaction.

36
Initiate EU/AM Transaction

• On the Main Page select the current School Year
  and Data Dictionary Version Number.
• Click the Periodic Enrollment Update button.
• Click New Import.
• Enter Contact Information.
• Click Save Continue.
• Click Find File next to ENRA, select the extract
  file, and click Open.
• Repeat step 6 for the DEMO file.
• Click Import and wait for the import to finish.

37
View Import Reports

• Select the transaction that has been imported.
• Click the View Import Reports button.
• Select the file ENRA file and click View.
• Review the import report, correct errors as
  necessary and re-import.
• Repeat steps 2 3 for the DEMO file.

38
Validate Transaction

• Click the Validate tab.
• Select the transaction you imported.
• Select the file(s) in the bottom box if they are
  not already selected.
• Click Validate Selected File(s).

39
View Validation Reports

• Select the transaction that has been Validated.
• Click the View Validation Reports button.
• Select the file ENRA file and click View.
• Review the validation report, correct errors as
  necessary and re-import.
• Repeat steps 2 3 for the DEMO file.

40
Data Submission Summary Report

• Accessed from validation tab after validation has
  been successful
• Summarizes imported records by gender, ethnic
  group, and grade level
• Must be created in Validation tab prior to
  proceeding to Send Tab

41
View Data Submission Summary Report

• Select the transaction that has been validated.
• Click the View Submission Summary Report button.
• Wait for the report to be generated.

Pop-up blocking software may prevent this
report from appearing. Make sure that any such
software is disabled or is set to allow pop-ups
from the CSIS Web site.
42
Send Process

• Click on the Send tab.
• Select the transaction that has been successfully
  validated.
• Click the Send Selected File(s) button

43
View Status Process

• Click on the View Status tab.
• Select the EU transaction you wish to view in the
  upper half of the screen.
• Click the View Transaction Reports button.
• Review the following reports
• Address Server Validation Report
• Address Correction Report
• Enrollment Update Status Server Summary Report
• EU Validation Error Listing Report - Server
• 5. Click OK.

44
Enrollment Update Summary Report Categories

• Records Sent Number of student records sent
• Records Dropped - Number of records that will
  not be updated if transaction is posted
• Open Enrollments Records without exit dates
• Exits Records with an exit date and exit reason

45
Enrollment UpdateServer Validation Report

• Review even if status is EU Server Validation
  Successful
• Determine error type from first letter of error
  code
• F Fatal must be fixed before transaction can
  be posted
• E Error has been dropped from further
  processing
• W Warning likely to be an error, but will not
  be dropped
• Review warnings carefully as they may cause
  problems if not fixed

46
Enrollment UpdateServer Validation Errors

• Birth Year
• Does not match existing record in locator
  database
• CSIS ID
• Retired SSID - Warning only, CSIS will replace
  Retired SSID with Replacement SSID LEA should
  download replacement file in MID resolution area
  to fix assignments in local student information
  system
• Gender
• Does not match existing record in locator
  database
• Withdrawal date
• Not valid for grade level
• Can not be blank based on exit reason

47
Confirm Process

• Wait for e-mail from DataGate that the
  transaction is ready for confirmation or check
  View Status tab for a status of EU Server
  Validated Successfully.
• Click on the Confirm tab.
• Select a transaction to confirm.
• Click Confirm.
• Review the Summary Report and verify the accuracy
  of the data being submitted.

48
Confirm Process (continued)

• If the summary report is not accurate make
  necessary corrections in your SIS and re-import a
  new extract.
• If the data is correct in your file and the
  locator database was corrected, then re-import
  the same file.
• If the data in your file is incorrect, correct
  the data in your SIS, create a new file, and
  re-import the file.
• Once you are satisfied with the data being
  submitted for updates, click Post.
• After the transaction has been posted, you will
  receive an email notification.
• The status of the transaction can be viewed on
  the View Status tab. If the post was not
  successful contact CSIS support.

49
Enrollment Update Address Validation
Documentation

• http//www.csis.k12.ca.us/services/services-traini
  ng/default.asp
• SRRTS User Guide
• SRRTS Quick Reference Guide
• EU Error Chart
• http//www.csis.k12.ca.us/library/reporting-requir
  ements/
• Data Submission Requirements (DSR)
• EU

50
Reminders

• Determine how local SIS will be updated
• One-by-one
• Mass update (Check with SIS vendor for options)
• For Incoming Addresses, fix Address Server
  Validation errors before Post
• CSIS will provide additional DC Submissions
• August 24, 2009
• September 24, 2009

50
51
What to Do Next

• New Users
• Apply for Digital Certificate (if you do not have
  one already)
• Note certificate expiration date on your calendar
• Perform client setup tasks (if you have not
  already)
• Contact SIS Vendor for data population extract
  documentation
• Obtain SSIDs for any students who do not have one
• Submit enrollment updates in DataGate

52
Where to Get More Information

• Contact CSIS Support at
• Phone [phone]
• E-mail support_at_csis.k12.ca.us
• Web http//www.csis.k12.ca.us/support/ContactSupp
  ort/
• CSIS Website
• http//www.csis.k12.ca.us
• Join the CSIS Listserv
• Go to http//www.csis.k12.ca.us/listserv/
• Click the Subscribe link for CSIS-LS

53
Appendix A Locating Certificate Expiration Date

• Open Internet Explorer
• Click Tools
• Internet Options
• Click Content
• Click Certificates
• Click Personal
• 3rd column displays certificate expiration date
• Make a note to contact CSIS support on renewal
  process 1 month prior to certificate expiration

54
Appendix BCDS Number Lookup Using the CA School
Directory

• Go to http//www.cde.ca.gov/re/sd/
• To lookup schools within a district
• Select the Public Schools option
• Select the county on the left
• Select the district on the right
• To lookup an NPS school
• Select the Nonpublic option
• Type in the school name
• Click Search

If the school is not found, try selecting the
county where the school is located instead of
typing the name.
55
CDS Lookup Using the CA School Directory
56
NPS CDS Lookup Using the CA School Directory
57
CA School DirectorySearch Results
