Measuring, registration and control instruments

1

• Measuring, registration and control instruments
• for power industry

2

• Founded in 1991
• Focus on measuring and control instruments
• 2006 turnover 1 mil
• 13 employees
• 2007 ISO9001 certified

3
Product lines
Measuring and Control Instruments
Measuring and Registration Instruments
Power Factor Controllers and Accessories
Custom Electronics
Voltage Line Fault Detectors
4
NOVAR Power Factor Controllers

• Characteristics
• Automated installation
• Fully free set-up of compensation steps
• Continuous testing and automatic reconfiguration
  of failing steps with alarm
• Voltage and current harmonic evaluation
• Enhanced sensitivity of current measuring
• So far (2006) 18000 Novar PFCs delivered to
  different markets

5
NOVAR PFCs Alternatives
6
NOVAR 5, NOVAR 5

• Price sensitive
• 5 1 relay steps, 6th relay can be set up to
  provide alarm output
• Current input sensitivity 0,05 A
• NOVAR 5 overvoltage alarm, improved
  operational temperature 40ºC 60ºC
• Compact case with front side panel size 96 x 96
  mm

7
NOVAR 106 , NOVAR 114

• 6 or 14 relay steps alarm relay
• Current input sensitivity 0,01 A
• High resistance against electro-magnetic
  interference
• Supply voltage , measuring voltage and output
  relay poles on common terminal simplified
  installation
• Optional communication interfaces

8
NOVAR 1106/1114/1206/1214

• Improved version of previous line of NOVAR-1xx
• Excellent current measurement sensitivity 0,002 A

• Temperature measurement, fan control
• Capacitors are protected against overvoltage and
  harmonic distortion
• Wide variety and ranges of supply voltages
  including DC
• For application where high precision and dynamic
  range plays significant role

9
NOVAR 1xxx Alternatives
10
Fast controller NOVAR 1312

• For compensation of fast power factor variations
  (engine starts etc.)
• 12 transistor outputs for up to 12 thyristor
  switches
• Up to 10 control interventions per second
• Possible combination of fast and slow processes -
  can control both classical contactors and fast
  SSR
• 2 relay steps can be also used to control heating
  or ventilation
• High sensitivity of current input 2 mA

11
Thyristor switching modules KATKA
for fast compensation

• KATKA 20 with passive cooling for steps up to 29
  A
• KATKA 80 with active cooling for steps up to 87 A
• Two and three phase variants

12
Setup and Monitoring of NOVAR
PFCs with RETIS

•
•

•

• on-line remote monitoring and configuration of
  controller
• Archiving and processing of recorded data

13
Components for Power Factor Correction
Systems

• Compensation capacitors, one and
  three phase
• Chokes
• Current transformers
• Contactors

14
Measuring and Registration

• SML, SMM, SMN simple measuring devices
• SMY, SMZ, SMU including advanced measurements and
  internal memory for archives
• Portable recorders SIMON-FLEX

15
Measuring Instruments SML33, SMM33

• Measuring and visualisation of actual values of
  main parameters in three-phase network
• Voltage input 230/400V, current input 5A
• Communication option RS-485 and free software
  RETIS
• DIN-bar or panel mounted housing

16
Measuring Instrument SMN33

• Measurement and visualization of many 3-phase
  network values
• Voltage inputs 230/400V
• Shipped with split-core current transformers
  5-600 A
• 15/30/60-minute maximum active power recording
• RS-485 communication option
• DIN bar mountable

17
Panel Meter and Recorder SMY33

• Front panel 96x96 mm
• Graphic LCD display
• Voltage inputs up to 3x440V (star/delta)
• Current input 5A
• Supply voltage 80-260 V AC
• Internal memory

18
Panel Meter and Recorder SMZ33

• Front panel 144x144mm
• Numerical LED display
• Voltage inputs up to 3x440V (star/delta)
• Current input 5A
• 4-quadrant electricity meter option
• Internal memory for archives

19
Panel Meter and Recorders SMU33, SMU44

• Compact design - 96x96 mm
• SMU44 type additionally measures voltage and
  current in neutral line
• Built-in 4-quadrant electricity meter
• Increased internal memory for measurement
  archives
• Communication USB, option RS485, RS232,
  Ethernet, Wifi, Bluetooth

20
SIMON-FLEX portable network monitor

• Voltage 3x230V (star)?
• Current measurement with clamp-on of flex CTs
• Supply voltage common with measured voltage

21
Flexible CTs A3000

• For portable recorders SIMON FLEX
• Variable scale 100-300-1000-3000A
• Supplied from the measuring device

22
Setup and Data Processing Software RETIS

•
•

•

• Visualisation and processing of recorded values
  in PC
• Retrieval and back-up of actual values

23
MBOX Datalogger

• Periodical readings of actual data from SMM, SML
  and SMN over RS 485
• Values are stored in a file of SD card with
  capacity of up to 2 MB
• Acquired data can be imported into RETIS for
  further processing

24
Measuring Converter PA33

• Voltage inputs 3 x 230V
• Current inputs 3 x 5A
• Outputs
• 2 x current loop 20 mA
• 2 x relay or impulse output
• RS-485 or RS-232 option
• Easy to adapt for measuring of different
  qualities (custom request)

25
Short Current and Ground Connection Indicator
INKA-3

• Identifies failing branch of network
• Evaluates measurements of electro-magnetic field
• Indication of ground connections and short
  currents
• Works with remotely operated circuit breakers

26
INKA K1- Short Current Indicator For Cable Network

• Contact-less installation into transformer
  station
• supplied with 230 VAC, accumulator backup
• Local visual or remote signaling of short current
  condition

27
Portable Indicator of Ground Connection INKA-251

• For localisation of ground connection on high
  voltage lines
• Handheld device for field operation
• Based on evaluation of harmonic distortion in
  electromagnetic field of the line

28
AFR30 Active Protection of Measuring Current
Transformers

• Suppression of ferro-resonance between an
  inductance of transformer and a capacity of lines
• Targeted activation
• In normal conditions does not influence the
  measurement

29
HV Transformer Tap Changer Position Indicator
IPOT-19

• Panel mounted device to display actual state of
  transformer tap changer position
• Inputs for up to 19 signals from switch contacts
  and a change-over signal
• Time control over switching

30
TRAFOSTART Transformer Soft Starter

• Electronic relay for smooth starting of single
  phase transformers
• Controlled magnetisation of transformer core
• Nominal current up to 16A
• Developed in cooperation with TU Liberec
• patented principle

31
Contact
KMB systems, s.r.o. Dr. M. Horakove 559 460 07
Liberec 6 CZECH REPUBLIC phone [phone]
314 email kmb_at_kmb.cz www.kmbsystems.eu
