Gated Transport through Carbon Nanotube Membranes NIRT CBET-0709090

1
Gated Transport through Carbon Nanotube
MembranesNIRT CBET-0709090
Sangil Kim1,2, Francesco Fornasiero1, Michael
Stadermann1, Alexander Chernov1, Hyung Gyu Park1,
Jung Bin In3, Ji Zang5, David Sholl5, Michael
Colvin4, Aleksandr Noy1,4, Olgica Bakajin,1,2 and
Costas P. Grigoropoulos3 1 Physical and Life
Sciences, LLNL 2 NSF Center for Biophotonics,
UC Davis 3Mechanical Engineering, UC Berkeley
4School of Natural Sciences, UC Merced,
5Chemical and Biochemical Engineering, Georgia
Tech
CARBON NANOTUBE MEMBRANEA NANOFLUIDIC PLATFORM

• Strongly absorbing gas species (CO2, CH4, and
  C2H4) deviated from the scaled Knudsen permeance
• Weakly absorbing gas species (He, N2, Ar, and
  SF6) did not show the deviation.

• Unique surface properties of carbon nanotubes
  enable very rapid and very efficient transport of
  gases and liquids
• We need to understand
• Fundamental physics of transport through these
  nanoscale channels
• Membrane selectivity and rejection properties
• Fabrication issues associated with making CNT
  membranes with desired geometry and properties
• Control of transport through CNT membranesAre
  artificial ion channels possible?

Rejection declines at larger salt solution
concentrations
CNT
Aquaporin
Gas transport in CNTs and other nanoporous
materials
K channel
K3Fe(CN)6
CH4/N2 and CO2/N2
KCl
K3Fe(CN)6
KCl
CNT MEMBRANE

• Free standing membrane
• Highly aligned DWCNTs
• Inner diameter 1.6 nm
• LPCVD Si3N4 pinhole-free matrix

• Rejection constant when the Debye length is gtgt
  CNT diameter

• At 263 K, the separation factor increased
  because of increased gas solubility at lower
  temperature.

Comparison with atomistic simulations (CH4/N2)

• VA-CNT arrays grow from catalytic decomposition
  of carbon precursor, C2H4, over nanoscale Fe
  catalyst

• Smaller tube has higher separation factor for
  CH4/N2.
• Polydisperse of tube size in CNT membrane
  affects the separation factor.

• Electrostatic interactions dominate the ion
  rejection mechanism
• The largest ion in this series, Ru(bipy)3Cl2,
  permeates freely through the membrane suggesting
  that size effects are less important

• Carbon nanotube membranes support high flux
  transport of liquids and gases
• Nanotube growth kinetics studies allowed
  high-yield, high-quality growth of aligned
  nanotube arrays
• CNT membranes show good ion rejection
  characteristics
• Ion rejection mechanism is based on electrostatic
  repulsion and follows Donnan model predictions
• Strongly absorbing gas species deviated from
  Knudsen permeance due to preferential
  interactions with CNTs side walls.
• At low temperature gas separation factor
  increased because of increased gas solubility
  overall gas separation factors are still lower
  than necessary for practical gas separation

KINETICS OF CARBON NANOTUBE ARRAY GROWTH

• CNT growth rates exhibit a non-monotonic
  dependence on total pressure and humidity.
  Optimal process pressure and water concentration
  produce growth rate of 30?m/min.
• Nanotube growth rate remains essentially constant
  until growth reaches an abrupt and irreversible
  termination.
• We developed a model that predicts termination
  kinetics

• Selectivity ?A/B yA/(yB) / xA/(xB)
  yA/(1-yA) / xA/(1-xA)
• where x the mole fractions of gas species at
  the feed side
• y the mole fractions of gas species
  at the permeate side

• Holt et. al., Science, 312, 1034 (2006)
• Noy et. al., Nano Today, 2, 22 (2007)
• Fornasiero et. al. Proc. Natl. Acad. Sci USA,
  105, 17217 (2008)
• Stadermann et. al., Nano Letters, in revision
  (2008)
