Input/Output

1
Input/Output

• The computers response time is no match for ours.

2
Presentation

• dr. Patrick De Causmaecker
• url http//www2.kahosl.be/patdc
• E-mail patdc_at_kahosl.be

3
Books reference

• Modern Operating Systems, A. Tanenbaum, Prentice
  Hall inc. 1992, chapter 5 (main text and exam
  material)
• Operating Systems Internals and Design
  Principles, third edition, Prentice Hall inc.
  1998, chapter 11. (more detailed text for
  reference and further reading)
• http//WilliamStallings.com/OS3e.html

4
The O.S. and the I/O hardware

• Management of I/O devices is a main task for the
  operating system.
• Handle message passing to and from the system
• Handle interrupts and errors
• Offer a simple interface
• Offer device independence (to some degree)
• Viewpoints.
• Users
• Programmers
• Technicians

5
Overview

• I/O Devices
• Principles of I/O Hardware
• Design Objectives
• Disks
• Clocks
• Terminals

6
I/O Devices

• (Classification Stallings)
• Man readable
• Printers, graphical terminals, screen, keyboard,
  mouse, pointing devices,
• Machine readable
• Disks, tapes, sensors, controllers, actuators
• Communication
• Modems

7
I/O Devices

• Differences
• Data transfer rates
• Range from 0,01 kbytes/sec (keyboard) till 30.000
  kbytes/second (graphical screen)
• Disks typically have 500 kbytes/sec (optical)
  till 2000 kbytes/sec (magnetic)
• Application
• Disk for files or for virtual memory
• Influences disk scheduling and caching strategy
• Complexity
• OS is isolated from most of the complexity by an
  I/O module (controller)

8
I/O Devices

• Unit of transfer
• Blocks of characters versus streams of characters
• Representation of data
• Coding conventions, parity,
• Error states
• Kind of errors, reporting modes,
• Need a uniform approach to I/O as seen from the
  user and from the operating system point of view

9
Organisation

• The I/O function can be approached in three ways
• Programmed I/O continuous attention of the
  processor is required
• Interrupt driven I/O processor launches I/O and
  can continue until interrupted
• Direct memory access the dma module governs the
  exchange of data between the I/O unit and the
  main memory

10
Programmed I/O
11
Programmed I/O (Polling)
12
Interrupt
Memory
Databus
CPU
I/O
I/O
Interrupt
13
Interrupt controlled I/O
Program
Program
I/O
I/O
CPU
Interruptroutine
14
Direct Memory Access
Memory
Databus
CPU
hold
I/O
I/O
DMA
15
Direct Memory Access
databus
Hold
CPU
Ram
DMA
I/O
Ack
addressbus
R/W
16
Evolution in I/O organisation

1. Processor controls device directly
2. A controller or I/O module is used separating the
   processor from the details of the I/O device
3. As in 2 but using interrupts, the burden of
   supervising the device continuously disappears
4. I/O module gains access to main memory through
   DMA moving data in and out memory without
   processor attention
5. I/O module becomes a processor - I/O specific
   instruction set to be programmed by the
   processor in main memory
6. I/O module becomes a computer a channel -

17
Direct Memory Access

• I/O module shares the bus with the processor
• It can use the bus only when the CPU does not
  need it
• Or it can steal cycles from the CPU by forcing it
  to free the bus
• Procedure
• Processor sends message to DMA (R/W, where, how
  much)
• Processor continues while I/O proceeds
• At the end, I/O module sends interrupt signal to
  the processor

18
Differs from an interrupt

• DMA can interrupt the processor in the middle of
  an instruction (before fetch, after decoding,
  after execution)
• It does not interfere with the running program
• The CPU is idled (waiting for access to the bus)
• The system is just becoming slower

19
Three implementations

• DMA shares bus with I/O units
• Performance and simplicity in design I/O module

20
Three implementations

• DMA shares bus only with other DMA, CPU, memory
• Performance and simplicity in design I/O module

cpu
dma
I/O
memory
I/O
21
Three implementations

• DMA has a separate I/O bus
• Performance and simplicity in design I/O module

cpu
dma
memory
I/O
I/O
22
Overview

• I/O Devices
• Principles of I/O Hardware
• Design Objectives
• Disks
• Clocks
• Terminals

23
Principles of I/O Hardware

• Block Devices
• Store information in fixed sized blocks
• Size 128-1024 bytes.
• Blocks are the addressing units for reading and
  writing
• Example disks
• More problematic example tapes
• Not randomly accessible
• Rewind takes far more time than a seek on a disk
• Writing in the middle of a tape is not always
  possible
• Discussion is not really a practical one

24
Principles of I/O Hardware (cont)

• Character Devices
• Terminal, printer, network interface, mice,
  rats...
• Token stream in and out
• No addressing possibility, no seek.

25
Principles of I/O Hardware (cont)

• Blocks and character devices are still a basic
  abstraction at the O.S. level (file systems)
• Not everything fits
• Clocks are not addressable, do not produce token
  streams, produce interrupts instead
• memory mapped devices are character addressable
• Physical details and peculiarities are left to
  the Drivers

26
Hardware Principles controllers

• I/O units have electronic and mechanical
  components separated in modular design.
• The electronic component is the device
  controller or adapter
• Print to be plugged into the computer
• Designed independently for many devices
• Standardised interfaces (ANSI,ISO,IEEE,)
• Is the target for the O.S.
• Bus lt-gt I/O channels

27
Principles controllers (cont)

• Controller-device interface
• Very low-level
• Example disk
• Preamble with cylinder, sector no,
• 4096 bits from this sector
• Error correction code
• Controller produces a block of bytes and performs
  error correction if necessary, copies block into
  memory

28
Principles controllers (cont)

• Example video card
• Reads bytes from own memory and generates signals
  to steer the CRT
• Programming the electron rays is clearly
  unfeasible for normal programmers
• Controller must offer an abstract interface
• Controller-CPU interface
• Based on controller registers
• These may be part of the normal address space of
  the computer (memory mapped I/O) (68x0)

29
Principles controllers(cont)

• Specific address space for I/O (Intel ports IN
  and OUT instructions)
• In both cases the decoding logic on the card
  recognizes the addresses
• They are normally served by system calls
  (software interrupts) supporting abstract
  commands such as READ, WRITE, SEEK, FORMAT,
  RECALIBRATE
• CPU passes commands to the controller and
  continues. It will be interrupted when the
  transaction has finished

30
Hardware Principles DMA

• Programmed I/O asks for too much attention of the
  CPU if the device is fast
• Fast devices use Direct Memory Access
• Without DMA
• Controller reads block into an internal buffer
• Checks for errors, corrects eventually
• Causes interrupt
• CPU copies block into memory through card
  registers
• Controller starts reading again

31
Hardware Principles DMA (cont)

• With DMA
• Controller keeps a memory address (called the DMA
  address) and a counter indicating the number of
  bytes to be copied in addition to the disk
  address of the block(s) requested.
• Once block is in the controller buffer, the
  controller copies the bytes one by one to the DMA
  address, decrementing the counter and
  incrementing the DMA address
• Only when the counter becomes zero an interrupt
  is generated

32
Hardware Principles DMA (cont)

• Why a buffer?
• Hardware produces bits at a steady pace
• Controller has to share the system bus with the
  CPU and other devices, unpredictable
• Copying is not time critical
• Controllers with small buffers may go directly to
  the memory, (overrun risk)
• Buffer simplifies the design of the controller
• Controller processing time leads to interleaving

33
Hardware Principles DMA (cont)

• Interleaving on disks
• 3600 rpm, revolution time 16 ms
• This time can be used for error correction and
  (start up of) DMA transfer
• Room between successive sectors can be adjusted
  by interleaving

34
(No Transcript)
35
(No Transcript)
36
Overview

• I/O Devices
• Principles of I/O Hardware
• Design Objecives
• Disks
• Clocks
• Terminals

37
Design objectives

• Efficiency
• I/O is very slow in comparison with the CPU
• Multiprogramming is partly invented to circumvent
  this discrepancy
• Even with a high level of multiprogramming, the
  I/O cannot cope with the CPU
• Swapping is not I/O but it sometimes interferes
  with it
• Disk efficiency is important

38
Design objectives

• Generic
• For simplicity and to avoid errors
• Uniform treatment of all devices
• Due to the diversity of the devices, only layered
  system can offer this uniformity
• Layers depend on lower layers for specific
  services, implement general set of services
  themselves
• Number of layers can be different from one kind
  of devices to another

39
Design objectives three models
40
Design objectives

• Simple case logical device, offering only a
  stream of bytes or records
• Logical I/O has nothing to do with details of
  the device, offers logical I/O functions
• Device I/O translates commands from the layer
  above to sequences of I/O instructions. Buffering
  may be part of this layer
• Scheduling and controlling this level determines
  the order in which the requests can be served.
  This layer interacts directly with the I/O device

41
Design objectives

• Communication network interface, offering
  connection to a network
• Communications layer replaces the logical layer.
  It may be layered itself according to e.g. the
  OSI seven layer model
• Other layers are identical with the logical case

42
Design objectives

• File management
• Only the first layer is different
• It is normally layered itself in
• Directory management
• Symbolic filenames are converted to file
  references
• Supports moving, deleting, creating files
• File management
• Logical file structure for open, close, read,
  write,
• Physical registry
• File in sectors, tracks,

43
Efficiency I/O Buffering

• I/O module may free the process of continuously
  checking by working autonomously
• If the process is swapped out, the dma cannot
  work, so swapping of the complete process becomes
  problematic
• One process can even cause a deadlock
• -gt buffering (single buffer, double buffer,
  circular, buffer)

44
I/O Buffering single buffer

• I/O module copies to a buffer, not directly to
  the memory.
• Once I/O has succeeded, buffer is copied to the
  user memory
• I/O module may anticipate and start reading the
  next block immediately
• Complicates OS
• Has to manage the buffers
• Has to take care while swapping to the same disk
  (swapping out a process has to wait until I/O has
  finished)
• Buffers can contain blocks, lines or bytes

45
I/O Buffering double buffer

• Without buffers, the time per block is
• T Computation Transfer
• The time for reading a block with a single
  buffer
• T maxComputation, Transfer Move
• The Move time to copy the buffer into main memory
  can be recovered if one uses a second buffer,
  keeping the I/O channel busy all the time
• T maxComputationMove, Transfer

46
I/O Buffering circular buffer

• If the computation time in I/O burst phases is
  very small, the two buffers will not be able to
  cope (maxC,T gtgt C)
• Multiple buffers in a ring can solve this problem
  by doing I/O also in the computational phases
• Buffering softens the peaks in the I/O. If the
  demand for I/O is on average above the I/O
  capacity, the system will run out and the process
  will have to wait.

47
Generic Software principles

• Layered architecture allows for
• Hiding of the peculiarities of the hardware
• Presentation of clean interfaces for the users
• Construction of uniform interfaces
• After stating the objectives, we will discuss the
  layers from the interrupt level up to the user
  environment

48
From Mobile Commerce, a new frontier, V.
Upkar, R.J. Vetter, R.Kalakota in Computer,
October 2000
49
(No Transcript)
50
(No Transcript)
51
Software Objectives By Example

• Device independence programs must be able to
  access files through a device independent
  interface
• sort lt input gt output
• Naming conventions cannot depend on the device
• Unix devices can be reached through the directory
  interface (mounting)
• Error handling errors should be taken care of in
  the lowest layer possible (controller-driver-os-us
  er)
• Errors are often volatile, caused by a temporary
  defect
• They can be handled without alarm to the user

52
Software Objectives By Example

• Device independent interface (UNIX/LINUX)
• sort lt input gt output
• (Naming conventions cannot depend on the device)
• /dev/lp
• /dev/d001
• (Unix devices can be reached through the
  directory interface (mounting))

53
Software how to cope with interrupts

• Hard part of the software,
• Should be kept in the basements
• Essentially pseudo parallel
• Should be synchronized with the user process
• Semaphores and monitors can be used to model the
  interaction with the I/O process
• E.g. socket threads
• Messaging.

54
Example City Dataservice
Citizen Service Shop
Governmental Database Server
Task Based Request Handler
Dispatcher
Tasks
WAN interface
LAN interface
55
Software device drivers

• One type or at most one class of closely related
  devices.
• Contains all device dependent code.
• E.g. one terminal driver serving all terminals is
  not feasible complexity of terminals can differ
  too much.
• Is the only part in the OS that knows the
  controllers, their register structure, sectors,
  tracks, cylinders, heads, interleaving, motors,
  ...
• Device driver translates abstract, device
  independent software requests in device dependent
  signals.

56
Software device drivers (cont)

• Example read a block from disk
• If driver is idle when request arrives
• Start immediately
• Else
• Move request to queue
• Execute request
• Do a translation to the disk specifics
• Find position of the block
• Check whether disk is rotating
• Check arm position
• Pass tasks to device one by one
• Some controllers can accept a list of tasks,
  others need assistance of the driver after each
  subtask

57
Software device drivers (cont)

• Once the task(s) have been passed
• Two possibilities
• Driver has to wait until the controller has
  performed the task(s), in which case the driver
  has to block until interrupted
• Example disk I/O, scanner
• Or the controller can finish the job without
  delay
• Example move the graphics over the screen
• Driver has to check on possible errors before
  passing eventual results and/or status to the
  software
• Once all software tasks have been handled the
  driver will block

58
Software Device Independence

• Large part of the I/O software is independent of
  the device. Some of these parts are executed in
  the driver for efficiency (cfr LINUX Apache)
• Independent parts normally include
• Uniform interfaces for the device drivers
• Naming of the devices
• Protection and privacy for devices
• Block size independent of the device
• Buffering
• Memory assignment on block devices
• Assignment of dedicated devices
• Error handling

59
Software Device IndependenceUniform interfaces

• Software should not be aware of detail
  differences between the devices
• Users must be able to handle a disk as a disk and
  a scanner as a scanner, not work with a Brother
  Master Scan or a Sister LaserJet but with an
  A4 scanner and a black and white printer.

60
Software Device IndependenceNaming of the
devices

• How do files and I/O devices get a name
• Symbolic device name is mapped to a driver
• E.g. UNIX/LINUX
• Device name /dev/lp determines I-node for
  special file
• I-node contains
• Major device number to find the driver
• Minor device number to be passed as a parameter
  to the driver

61
Software Device IndependenceProtection and
privacy

• Users access to devices must be regulated
• No limitations
• MS DOS and early versions of Windows
• No access
• Mainframe and certain minicomputer O.S.
• Way between
• UNIX rwx bits

62
Software Device IndependenceDevice independent
block size

• Communication block sizes may differ
• Software provides one size, handling a set of
  sectors as one block
• Devices become abstractions
• Block devices can be represented as character
  devices

63
Software Device IndependenceBuffering

• Block devices
• Hardware delivers one block at a time
• Software reads in varying sizes
• After reading one block, the O.S. keeps the whole
  block in a buffer
• Character devices
• May be slower than the processes
• Delivery of characters may be an independent
  process (keyboard)

64
Software Device Independence Assignment of
dedicated devices

• Some devices cannot be used by two processes at
  the same time
• OPEN system call reports an error in case the
  device is busy
• CLOSE frees the device
• Spooling processes may play an in between role

65
Software Device Independence Error handling

• Primary handling is by the drivers
• It can often react and repair the error before
  the software layer above notices
• Only when, after several tries, repairing fails,
  the higher layers are informed
• Error handling at higher levels depends on the
  environment in which the software is functioning

66
I/O software in user space

• I/O software is not only in the OS, libraries are
  routinely linked with user programs, helper
  programs run outside the kernel.
• count write(fd, buffer, nbytes)
• Library routines typically transfer their
  parameters to the system calls, or do more work
• printf(d s, ld\n, count, person,
  yearly_income)
• cout ltlt count ltlt ltlt person ltlt , ltlt y_i
  ltlt endl
• cin gtgt y_i
• Spooling systems a daemon reads jobs from a
  spooling-directory and sends it to the printer
  (protected device, only spooler has access)

67
I/O software in user space (cont)

• Spooling may be used in networks, mailing
  systems,, spoolers run outside the O.S.
• Overview

user processes Produce I/O call, format, spool
Device independent software Naming, protection, blocking, buffering, allocating
Device drivers Control device registers, status
Interrupt handlers Wake up driver after I/O task
hardware Perform I/O
68
Sketching Interfaces Toward More Human Interface
Design James A. LandayUniversity of
California, BerkeleyBrad A. MyersCarnegie
Mellon University(Computer, march 2001)
69

70
Overview

• I/O Devices
• Principles of I/O Hardware
• Design Objecives
• Disks
• Clocks
• Terminals

71
Disks

• Rationale why an additional memory carrier
• Larger available capacity
• Lower price per bit
• Permanent
• Hardware and algorithms

72
Hardware

• Disks are organized in cylinders, tracks and
  sectors.
• Sectors
• between 8 and 32
• equal number of bytes (1K, 0.5K,0.25K) in the
  middle as well as on the border
• Controller can run a number of seeks on different
  disks at the same time
• Controllers only read/write one disk at the time
• This influences the disk driver

73
Algorithms for the disk arm

• Access time
• seek time time needed to move the arm to the
  cylinder (dominant)
• rotational delay time before the sector
  appears under the head
• transfer time time to transfer the data
• Dominance of seek time leaves room for
  optimisation

74
Example seek time

• Time to get the arm over the track, difficult to
  determine
• Ts mn s
• Ts estimated seek time
• n number of tracks crossed
• s start time
• Cheap m0,3, s20ms
• Better m0,1, s3ms

75
Example rotational latency and transfer time

• 3600 rpm, 16,7 ms/rotation
• Average rotational latency is 8,3 ms
• Ttb/rN
• Tt transfer time
• b number of bytes to be transferred
• N number of bytes per track
• r rotation speed in rotations per second

76
Example case

• Read a file of size 256 sectors with
• Ts 20 ms
• Tt 1 MB/second
• 512 bytes/sector, 32 sectors/track
• Suppose the file is stored as compact as
  possible all sectors on 8 consecutive tracks of
  32 sectors each (sequential storage)
• The first track takes 20 8,3 16,7 45 ms
• The remaining tracks do not need seek time
• Per track we need 8,3 16,7 25 ms
• Total time 45 725 230 ms 0,22 s

77
Example case

• In case the access is not sequential but at
  random for the sectors, we get
• Time per sector 20 8,3 0,5 28,8 ms
• Total time 256 sectors 25628,8 7,37 s
• It is important to obtain an optimal sequence for
  the reading of the sectors

78
Optimisation

• Heavy loaded disk allows for a strategy to
  minimize the arm movement
• Situation is dynamical disk driver keeps a table
  of requested sectors per cylinder
• E.g. while a request for disk 11 is being
  handled, requests for 1, 36, 16, 34, 9 and 12
  arrive.
• Which one is to be handled after the current
  request?

79
Optimisation (cont)

• In the order of arrival (FCFS) the total length
  is
• 11-11-3636-1616-3434-99-12111
• In the order shortest seek time first, SSTF
  (cfr shortest job first) we gain 50
• 11-1212-99-1616-11-3434-3661
• Problem starvation, arm stays in the middle of
  the disk in case of heavy load, edge cylinders
  are poorly served, the strategy is unfair (cfr
  elevators)
• Lift algorithm, SCAN keep moving in the same
  direction until no requests ahead (start Up)
• 11-1212-1616-3434-3636-99-160
• Upper limit 2number of cylinders

80
Optimisation (cont)

• Smaller variance is reached by moving the arm in
  one direction, always returning to the lowest
  number at the end of the road (CSCAN)
• 11-1212-1616-3434-3636-11-968
• Seeks are cylinder by cylinder
• a number of tracks
• It may happen that the arms sticks to a cylinder.

• N-step-SCAN segment the queue into segments of N
  requests which are handled using SCAN
• FSCAN use two queues, while one is being handled
  with SCAN, the other one is being refilled.

81
Optimisation (cont)

• Sector number under the head can be read
• gt optimal order of requests within one cylinder
• More than one drive look for a well positioned
  drive after each transfer
• Rotation speed versus seek time
• RAID (Redundant Array of Inexpensive Disks)
• E.g. 38 bits form a word of 32 bits with Hamming
  code
• Each bit is stored on a separate disk

82
Error handling examples

• Possible errors
• Programming errors (non existing sector)
• User program needs debugging
• Volatile checksum error (dust particle)
• Controller tries again
• Permanent checksum error (bad block)
• Block will be marked bad and replaced by a
  spare block (this my interfere with the
  optimisation algorithm)
• Seek error (arm moves to the wrong sector)
• Mechanical problem, perform RECALIBRATE or ask
  for maintenance
• Controller error
• Controller is a parallel system, can get
  confused, driver may perform a reset

83
Caches

• The driver may cache tracks
• Reading one track does not take a long time, arm
  needs not to be moved and the driver has to wait
  for the sector anyhow
• Disadvantage driver has to copy the data using
  the CPU, while the controller may use DMA
• The controller may build an internal cache
• Is transparent for the driver
• Data transfer uses DMA
• In this case the driver should not do any caching

84
Overview

• I/O Devices
• Principles of I/O Hardware
• Design Objecives
• Disks
• Clocks
• Terminals

85
Clock Hardware

• 50 Hz clocks (1 interrupt (clock tic) per voltage
  cycle)
• Simple, cheap, not very accurate, not very
  functional
• High precision clocks (5-100 MHz, or higher),
• Contain a quarts oscillator
• Steers a counter counting down
• Generates an interrupt when counter reaches 0
• Counter is eventually reloaded from a
  programmable register
• One chip normally implements multiple clocks
• One shot mode clock counts down from register
  value once and waits for software to start it
  again
• Block wave mode counter is automatically
  reloaded (generates clock tics)
• Ranges e.g. 1000 MHz clock with a 16 bits
  register can fix time intervals between 1
  nanosecond and 65,535 microseconds.

86
Clock Software

• Software is responsible for the semantics behind
  the clock tics
• Time of the day
• 1/1/1970
• Is an easy task, just calculate the exact time
  between two tics and adjust the clock on each
  interrupt
• Size of the time register may cause a problem
• 32 bits register overflows after 2 years storing
  60 Hz tics
• 64 bits is more expensive, but lasts forever
• Store seconds in stead of tics (232 seconds is
  136 years)
• Use another reference in stead of 1/1/1970 (start
  time)

87
Clock Software

• Administration of process time slices
• Each running process has time left counter
• This counter is decremented at each interrupt
• Administration of CPU usage
• Counter starts when process starts
• Counter is part of the Process environment
• Is stopped while handling an interrupt
• Field in the process table can be used directly
  (through pointer to running process)
• Interrupts cause problems

88
Clock Software

• SLEEP system call (UNIX)
• E.g. late ack of package sent, sleeping e-student
• Clock driver has a limited number of hardware
  clocks
• Implements virtual clocks
• Uses a table with all times for the hanging
  timers and one variable with the next signal time
• In case of a heavy clock-usage, the signal times
  may be kept in a well ordered linked list (e.g.
  4203,4307,4213)

89
Clock Software

• Watchdog timers
• Floppy disk drive
• Start motor
• Wait for 500 milliseconds
• -gt better to wait for 3 seconds after I/O
  operation, just in case a new request arrives
• Watchdog timers start user specified routine
  after the time has elapsed within the code of the
  caller
• Profiling
• For program performance analysis
• Information where the CPU time is spent on

90
Overview

• I/O Devices
• Principles of I/O Hardware
• Design Objecives
• Disks
• Clocks
• Terminals

91
Terminals, hardware

• Serial RS232 terminals
• (history) hardcopy, glass tty, intelligent
• Industrial applications
• Memory-mapped interfaces
• (history) character oriented
• Bitmapped
• Network computers

92
Terminals, hardware (cont)

• Serial interfaces 25 pins connector (RS232 or
  V24), needed are 3 pins
• From 50 up to 19200 bits/sec
• Interface UART (Universal Asynchronous Receiver
  Transmitter) on RS232 interface cards
• Driver writes characters to interface card which
  transforms them into a bit sequence
• Slow, interrupt will wake up the driver

93
Terminals, hardware (cont)

• Interface cards may have a CPU on board, and be
  able to serve more terminals
• Intelligent terminals may be able to perform
  complicated operations on the screen (e.g.
  X-terminals) while still connected through a
  prehistoric device as the RS UART

94
Terminals, hardware (cont)

• Memory mapped terminals
• Integrated into the computer
• Communicate through a special memory, the video
  RAM, embedded into the address space of the CPU

Video Ram Controller
Monitor
CPU
MEM
bus
95
Terminals, hardware (cont)

• Monitor talks pixels, video controller modulates
  the electron ray or steers the lcs
• Speed is obtained through the memory and the
  electronics
• The ram can be in characters or in bits
• Characters will typically be read 14 times, for
  each line on the screen in which part of the
  character is displayed
• Bits will be stored per pixel
• Input through the keyboard
• Normally passes only a code for the key touched

96
Input software

• Keyboard driver caches keyboard input
• Raw mode
• Driver passes characters unchanged to software
• Buffering is limited to speed differences
• Application receives characters immediately
• Cooked mode
• Driver buffers one line until it is finished
• Driver handles corrections made by the user while
  typing a line
• Often applications have the choice
• Nowadays, window driven applications use raw mode
  at the lowest level and perform buffering at the
  window level

97
Input software (cont)

• Keyboard driver catches characters after
• Interrupts handles character during interrupt
• Messages message may contain the character or
  refer to a small buffer (problem with real time
  level of the driver, safer if the messaging is
  not fail proof)
• Keyboard driver transforms the key number into a
  character according to a table
• Keyboard buffering buffer pool (buffers of equal
  size, e.g. 16 characters) or a separate buffer
  for each terminal (typically 200 characters)
• Echoing is (was) done by the OS, or the shell.
  May be confusing for the user.

98
Input software (cont)

• Handling of tabs, backspaces, were typical
  problems with terminals
• One problem survived end of line
• Logically (from the typists viewpoint) one needs
  a CR to bring the cursor back to the beginning of
  the line and a LF to go to the next one
• These two characters are hidden behind the ENTER
  key
• The OS can decide how to represent end of line
• UNIX Line feed only
• DOS Carriage return and line feed
• LF is ASCII 10, CR is ASCII 13, M
• -gt problems with file transfer

99
Input software (cont)

• Other problems with terminals
• Timing of CR and LF
• Padding
• Definition of the erase character
• Kill character _at_ (\_at_ and \\ conventions)
• Stop output (S) and start output (Q)
• DEL, C, stop process (sent SIGINT)
• \ force core dump (SIGQUIT)
• D, Z end of file
• Implementation was (is) not straightforward
• UNIX telinfo database contains descriptions of
  thousands of terminals (famous example vt100)

100
Output software

• Serial (RS-232) and memory mapped approaches
  differ
• Serial terminals have an output buffer to which
  characters are sent until it is full or until a
  line ends. Once full, the real output is
  initiated and the driver sleeps until
  interrupted.
• Memory mapped terminals can be accessed through
  normal memory addressing procedures. Some
  characters receive a special treatment. The
  driver is doing more screen manipulation.
• Special functions such as scrolling and animation
  may be done through special registers (e.g.
  register with the position of the top line)

101
Example UNIX/LINUX
102
Buffer Cache
Hash Table
Buffers
Hash Pointer
Free List Pointer
Free List
103
Buffered/Unbuffered

• Buffered
• Original UNIX design
• Fast access to disks and other block devices
• Unbuffered
• DMA
• Interferes with system design
• Real time?!

104
Example Windows NT
105
I/O Manager

• Cache Manager
• Whole I/O subsystem (disks, network )
• Dynamic cache size
• Lazy write
• Lazy commit
• Hardware device drivers
• Uniform naming for source code portability

106
Asynchronous/Synchronous I/O

• Both are supported in Windows NT
• Asynchronous messaging happens through
• Device kernel object (indicator, one I/O active)
• Event kernel object (threads wait for event)
• Alertable I/O (thread has a queue of ready I/O
  operations)
• I/O completion ports (Pool of threads on a
  server)

107
Windows software RAID

• Winows supports RAIDS
• In hardware at the controller level
• In software non contiguous diskspace is
  allocated and combined in logical partitions by
  the fault tolerant software disk driver (FTDISK)
  It supports RAID 1 and RAID 5

108
Conclusion

• I/O is complicated because
• of hardware peculiarities (non functional design
  decisions)
• it is a real time interface with a non real time
  operating system
• it must allow for a broad range of I/O devices
• classical terminals, color screens, X-terminals
• hand held devices, mobile phones. PDAs
• printers-scanners, fax
• voice interfaces, Braille systems, sensory
  devices
• face recognition systems with cameras,
  fingerprint sensors,
