Title: Model Based Software Testing Preliminaries


1
Model Based Software Testing Preliminaries
  • Aditya P. Mathur
  • Purdue University
  • Fall 2005

Last update August 18, 2005
2
Learning Objectives This course
  • Methods for test generation
  • Methods for test assessment
  • The coverage principle and the saturation effect
  • Software test process
  • Tools
  • AETG Test generation
  • xSUDS Test assessment , enhancement,
    minimization, debugging
  • CodeTest Test assessment, performance monitoring
  • VisualTest GUI testing
  • Test RealTime Test assessment, performance
    monitoring
  • Ballista Robustness testing

3
Learning Objectives
  • What is model-based testing? How does it differ
    from (formal) verification?
  • How and why does testing improve our confidence
    in program correctness?
  • What is coverage and what role does it play in
    testing?
  • What are the different types of testing?
  • What are the formalisms for specification and
    design used as source for test and oracle
    generation?

4
Testing Preliminaries
  • What is testing?
  • The act of checking if a part or a product
    performs as expected.
  • Why test?
  • Gain confidence in the correctness of a part or a
    product.
  • Check if there are any errors in a part or a
    product.

5
What to test?
  • During software lifecycle several products are
    generated.
  • Examples
  • Requirements document
  • Design document
  • Software subsystems
  • Software system

6
Test all!
  • Each of these products needs testing.
  • Methods for testing various products are
    different.
  • Examples
  • Test a requirements document using scenario
    construction and simulation.
  • Test a design document using simulation.
  • Test a subsystem using functional testing.

7
What is our focus?
  • We focus on testing programs using formal models.
  • Programs may be subsystems or complete systems.
  • These are written in a formal programming
    language.
  • There is a large collection of techniques and
    tools to test programs.

8
An Abstraction of the MBT Process
Raw requirements
Formal specifications
Tests
Finite State Machines
Behavior
State Charts
Sequence Diagrams
Code, etc.
Modified document
9
A Few Terms
  • Program
  • A collection of functions, as in C, or a
    collection of classes as in java.
  • Specification
  • Description of requirements for a program. This
    might be formal or informal.

10
Few Terms (contd.)
  • Test case or test input
  • A set of values of input variables of a program.
    Values of environment variables are also included.
  • Test set
  • Set of test inputs
  • Program execution
  • Execution of a program on a test input.

11
Few Terms (contd.)
  • Oracle
  • A function that determines whether or not the
    results of executing a program under test is as
    per the programs specifications.
  • Verification
  • Human examination of a product, such as design
    document, code, user manual, etc., to check for
    correctness. Inspections an walkthroughs are the
    generally used methods for verification.
  • Validation
  • The process of evaluating a system or a subsystem
    to determine whether or not it satisfies the
    specified requirements.

12
Correctness
  • Let P be a program (say, an integer sort
    program).
  • Let S denote the specification for P.
  • For sort let S be

13
Sample Specification
  • P takes as input an integer Ngt0 and a sequence
    of N integers called elements of the sequence.
  • Let K denote any element of this sequence,
  • P sorts the input sequence in descending order
    and prints the sorted sequence.

14
Correctness again
  • P is considered correct with respect to a
    specification S if and only if
  • For each valid input the output of P is in
    accordance with the specification S.

15
Errors, defects, faults
  • Error A mistake made by a programmer

Example Misunderstood the requirements.
  • Defect/fault Manifestation of an error in a
    program.

Example Incorrect code if (altb)
foo(a,b) Correct code if (agtb) foo(a,b)
16
Failure
  • Incorrect program behavior due to a fault in the
    program.
  • Failure can be determined only with respect to a
    set of requirement specifications.
  • A necessary condition for a failure to occur is
    that execution of the program force the erroneous
    portion of the program to be executed. What is
    the sufficiency condition?

17
Errors and failure
Inputs
Outputs
18
Debugging
  • Suppose that a failure is detected during the
    testing of P.
  • The process of finding and removing the cause of
    this failure is known as debugging.
  • The word bug is slang for fault.
  • Testing usually leads to debugging
  • Testing and debugging usually happen in a cycle.

19
Test-debug Cycle
20
Testing and Code Inspection
  • Code inspection is a technique whereby the source
    code is inspected for possible errors.
  • Code inspection is generally considered
    complementary to testing. Neither is more
    important than the other.
  • One is not likely to replace testing by code
    inspection or by verification.

21
Testing for correctness?
  • Identify the input domain of P.
  • Execute P against each element of the input
    domain.
  • For each execution of P, check if P generates
    the correct output as per its specification S.

22
What is an input domain ?
  • Input domain of a program P is the set of all
    valid inputs that P can expect.
  • The size of an input domain is the number of
    elements in it.
  • An input domain could be finite or infinite.
  • Finite input domains might be very large!

23
Identifying the input domain
  • For the sort program

N size of the sequence, K each element of the
sequence.
  • Example For Nlt3, e3, some sequences in the
    input domain are

An empty sequence (N0).
0 A sequence of size 1 (N1)
  • 2 1 A sequence of size 2 (N2).

24
Size of an input domain
  • Suppose that
  • The size of the input domain is the number of all
    sequences of size 0, 1, 2, and so on.
  • The size can be computed as

Can you derive this formula?
25
Testing for correctness? Sorry!
  • To test for correctness P needs to be executed on
    all inputs.
  • For our example, it will take an exorbitant
    amount of time to execute the sort program on all
    inputs on the most powerful computers of today!

26
Exhaustive Testing
  • This form of testing is also known as exhaustive
    testing as we execute P on all elements of the
    input domain.
  • For most programs exhaustive testing is not
    feasible.
  • What is the alternative?

27
Formal Verification
  • Formal verification (for correctness) is
    different from testing for correctness.
  • There are techniques for formal verification of
    programs that we do not plan to discuss.

28
Partition Testing
  • In this form of testing the input domain is
    partitioned into a finite number of sub-domains.
  • P is then executed on a few elements of each
    sub-domain.
  • Let us return to the sort program.

29
Sub-domains
  • Suppose that 0ltNlt2 and e3. The size of the
    partitions is
  • We can divide the input domain into three
    sub-domains as shown.

30
Fewer test inputs
  • Now sort can be tested on one element selected
    from each domain.
  • For example, one set of three inputs is
  • Empty sequence from sub-domain 1.
  • 2 Sequence from sub-domain 2.
  • 2 0 Sequence from sub-domain 3.
  • We have thus reduced the number of inputs used
    for testing from 13 to 3!

31
Confidence
  • Confidence is a measure of ones belief in the
    correctness of the program.
  • Correctness is often not measured in binary
    terms a correct or an incorrect program.
  • Instead, it is measured as the probability of
    correct operation of a program when used in
    various scenarios.

32
Measures of Confidence
  • Reliability Probability that a program will
    function correctly in a given environment over a
    certain number of executions.
  • Test completeness The extent to which a program
    has been tested and errors found have been
    removed.

33
Example Increase in Confidence
  • We consider a non-programming example to
    illustrate what is meant by increase in
    confidence.
  • Example A rectangular field has been prepared to
    certain specifications.
  • One item in the specifications is
  • There should be no stones remaining in the
    field.

34
Rectangular Field
Search for stones inside a rectangular field.
35
Testing the Rectangular Field
  • The field has been prepared and our task is to
    test it to make sure that it has no stones.
  • How should we organize our search?

36
Partitioning the field
  • We divide the entire field into smaller search
    rectangles.
  • The length and breadth of each search rectangle
    is one half the expected length and breadth of
    the smallest stone one expects to find in the
    field.

37
Partitioning into search rectangles
38
Input Domain
  • Input domain is the set of all possible valid
    inputs to the search process.
  • In our example this is the set of all points in
    the field. Thus, the input domain is infinite!
  • To reduce the size of the input domain we
    partition the field into finite size rectangles.

39
Rectangle size
  • The length and breadth of each search rectangle
    is one half that of the smallest stone.
  • This is an attempt to ensure that each stone
    covers at least one rectangle. (Is this always
    true?)

40
Constraints
  • Testing must be completed in less than H hours.
  • Any stone found during testing is removed.
  • Upon completion of testing the probability of
    finding a stone must be less than p.

41
Number of search rectangles
  • Let
  • L Length of the field
  • W Width of the field
  • l Expected length of the smallest stone
  • w Expected width of the smallest stone
  • Size of each rectangle l/2 x w/2
  • Number of search rectangles (R)(L/l)(W/w)4
  • Assume that L/l and W/w are integers.

42
Time to Test
  • Let t be the time to peek inside one search
    rectangle. No rectangle is examined more than
    once.
  • Let o be the overhead incurred in moving from one
    search rectangle to another.
  • Total time to search TRt(R-1)o
  • Testing with R rectangles is feasible only if TltH.

43
Partitioning the input domain
  • This set consists of all search rectangles (R).
  • Number of partitions of the input domain is
    finite (R).
  • However, if TgtH then the number of partitions is
    too large and scanning each rectangle once is
    infeasible.
  • What should we do in such a situation?

44
Option 1 Do a limited search
  • Of the R search rectangles we examine only r
    where r is such that (tro(r-1)) lt H.
  • This limited search will satisfy the time
    constraint.
  • Will it satisfy the probability constraint?

Question What do the probability and time
constraints correspond to in a commercial test ?
45
Distribution of Stones
  • To satisfy the probability constraint we must
    scan enough search rectangles so that the
    probability of finding a stone, after testing,
    remains less than p.
  • Let us assume that
  • there are Si stones remaining after i test
    cycles.

46
Distribution of Stones
  • There are Ri search rectangles remaining after i
    test cycles.
  • Stones are distributed uniformly over the field.
  • An estimate of the probability of finding a stone
    in a randomly selected remaining search
    rectangle is pi si / Ri .

47
Probability Constraint
  • We will stop looking into rectangles if

pi lt p
  • Can we really apply this test method in practice?

48
Confidence
  • Number of stones in the field is not known in
    advance.
  • Hence we cannot compute the probability of
    finding a stone after a certain number of
    rectangles have been examined.
  • The best we can do is to scan as many rectangles
    as we can and remove the stones found.

49
Coverage
  • After a rectangle has been scanned for a stone
    and any stone found has been removed, we say that
    the rectangle has been covered.
  • Suppose that r rectangles have been scanned from
    a total of R. Then we say that the (rectangle)
    coverage is r/R.

50
Coverage and Confidence
  • What happens when coverage increases?

As coverage increases (and stones found are
removed) so does our confidence in a stone-free
field.
  • In this example, when the coverage reaches 100,
    (almost) all stones have been found and removed.
    Can you think of situations when this might not
    be true?

51
Option 2 Reduce number of partitions
  • If the number of rectangles to scan is too large,
    we can increase the size of a rectangle. This
    reduces the number of rectangles.
  • Increasing the size of a rectangle also implies
    that there might be more than one stone within a
    rectangle.

Is this good for a tester?
52
Rectangle Size
  • As a stone may now be smaller than a rectangle,
    detecting a stone inside a rectangle is not
    guaranteed.
  • Despite this fact our confidence in a
    stone-free field increases with coverage.
  • However, when the coverage reaches 100 we cannot
    guarantee a stone-free field.

53
Coverage vs. Confidence
54
Rectangle Size (again!)
pProbability of detecting a stone inside a
rectangle, given that the stone is there.
ttime to complete a test.
55
Analogy
  • Field Program
  • Stone Error
  • Scan a rectangle Test program on one input
  • Remove stone Remove error
  • Partition Subset of input domain
  • Size of stone Size of an error
  • Rectangle size Size of a partition

56
Analogy (contd.)
  • Size of an error is the number of inputs in the
    input domain each of which will cause a failure
    due to that error.

Error 1 is larger than Error 2.
Does this imply that failures due to error 1 will
occur more frequently than those due to error 2?
57
Confidence and Probability
  • Increase in coverage increases our confidence in
    a stone-free field.
  • It might not increase the probability that the
    field is stone-free.
  • Important Increase in confidence is NOT
    justified if detected stones are not guaranteed
    to be removed !

58
Types of Testing
Basis for classification
59
Testing Based on Source of Test Inputs
  • Functional testing/specification
    testing/black-box testing/conformance testing
  • Clues for test input generation come from
    requirements.
  • White-box testing/coverage testing/code-based
    testing
  • Clues come from program text.

60
Testing Based on Source of Test Inputs
  • Stress testing
  • Clues come from load requirements. For example,
    a telephone system must be able to handle 1000
    calls over any 1-minute interval. What happens
    when the system is loaded or overloaded?

61
Testing Based on Source of Test Inputs
  • Performance testing
  • Clues come from performance requirements. For
    example, each call must be processed in less than
    5 seconds. Does the system process each call in
    less than 5 seconds.
  • Fault- or error- based testing
  • Clues come from the faults that are injected into
    the program text or are hypothesized to be in the
    program.

62
Testing Based on Source of Test Inputs
  • Random testing
  • Clues come from requirements. Test are generated
    randomly using these clues.
  • Robustness is the degree to which a software
    component functions correctly in the presence of
    exceptional inputs or stressful environmental
    conditions.
  • Robustness testing
  • Clues come from requirements. The goal is to test
    a program under scenarios not stipulated in the
    requirements.

63
Testing Based on Source of Test Inputs
  • OO testing
  • Clues come from the requirements and the design
    of an OO-program.
  • Protocol testing
  • Clues come from the specification of a protocol.
    As, for example, when testing for a communication
    protocol.

64
Testing Based on Item Under Test
  • Unit testing
  • Testing of a program unit. A unit is the
    smallest testable piece of a program. One or more
    units form a subsystem.
  • Subsystem testing
  • Testing of a subsystem. A subsystem is a
    collection of units that cooperate to provide a
    part of system functionality

65
Testing Based on Item Under Test
  • Integration testing
  • Testing of subsystems that are being integrated
    to form a larger subsystem or a complete system.
  • System testing
  • Testing of a complete system.

66
Testing Based on Item Under Test
  • Regression testing
  • Test a subsystem or a system on a subset of the
    set of existing test inputs to check if it
    continues to function correctly after changes
    have been made to an older version.

And the list goes on and on!
67
Test input construction and objects under test
Requirements
Source of clues for test inputs
Code
subsystem
unit
system
Test object
68
Combinatorial Design
  • Context A telephone switch
  • Problem Determine what inputs to use to test the
    switch.

Call Type Billing Access Status
Local Caller Loop Available
Long Dist Collect ISDN Busy
Intl. 800 PBX Blocked
Total parameters 4
Values for each parameter 3
Total number of scenarios 3481
69
Reducing the Input Space
  • Suppose that 81 test is too many for the
    telephone switch under test.
  • An alternative is to select a default value for
    each parameter and then vary each parameter until
    all values are covered.

70
Test Plan with Default Parameter Values
Call Type Billing Access Status
Local Caller Loop Available
Long Dist Caller Loop Available
Total inputs 9
Intl. Caller Loop Available
Coverage 30 of the 54 pair wise interactions.
Local Collect Loop Available
Local 800 Loop Available
Local Caller ISDN Available
Local Caller PBX Available
Local Caller Loop Busy
Local Caller Loop Blocked
71
Another Test Plan
Call Type Billing Access Status
Local Collect PBX Busy
Long Dist 800 Loop Busy
Total inputs 9
Intl. Caller ISDN Busy
Coverage All pair wise interactions covered
Local 800 ISDN Blocked
Long Dist Caller PBX Blocked
Intl. Collect Loop Blocked
Local Caller Loop Available
Long Dist Collect ISDN Available
Intl 800 PBX Available
72
Combinatorial Explosion
  • What if the program under test had 10 parameters
    each with 3 values?
  • Total parameter combinations 310
  • Number of tests using the default value method ?
  • Number of pair-wise combinations covered ?
  • Number of pair-wise combinations ?

73
Answers to Questions
For k parameters each with n possible values
Tests with default value methodn (n-1) x (k-1)
Pair-wise combinations(k x (k-1)/2) x n2
Pair-wise combinations covered(k-1)n(k-1)(n-1)
(k-1)(k-1)
Later we shall discuss how to handle the
combinatorial explosion.
74
Finite State Machines (FSMs)
  • A state machine is an abstract representation of
    actions taken by a program or anything else that
    functions!
  • It is specified as a quintuple
  • A a finite input alphabet
  • Q a finite set of states
  • q0 initial state which is a member of Q.

75
FSMs (contd.)
  • T state transitions which is a mapping
  • Q x A--gt Q
  • F A finite set of final states, F is a subset of
    Q.
  • Example Here is a finite state machine that
    recognizes integers ending with a carriage return
    character.
  • A0,1,2,3,4,5,6,7,8,9, CR
  • Qq0,q1,q2
  • q0 initial state

76
FSMs (contd.)
  • T ((q0,d),q1),(q1,d),q1), (q1,CR),q2)
  • F q2
  • A state diagram is an easier to understand
    specification of a state machine. For the above
    machine, the state diagram appears on the next
    slide.

77
State diagram
d denotes a digit
78
State Diagram-Actions
x/y x is an element of the alphabet and y is an
action.
i is initialized to d when the machine moves from
state q0 to q1. i is incremented by 10d when the
machine moves from q1 to q1. The current value of
i is output when a CR is encountered.
Can you describe what this machine computes?Can
you construct a regular expression that
describes all strings recognized by this state
machine?
79
State Machine Languages
  • Each state machine recognizes a language.
  • The language recognized by a state machine is the
    set S of all strings such that
  • when any string s in S is input to the state
    machine the machine goes through a sequence of
    transitions and ends up in the final state after
    having scanned all elements of s.

Testing state machines? Later!
80
The Unified Modeling Language
  • Unified Modeling Language (UML) is a notation to
    express requirements and designs of software
    systems.
  • Requirements are represented using
  • a collection of use cases, each use case being a
    representative of a collection of scenarios.
  • a collection of system sequence diagrams that
    explain the interaction between a user and the
    application for each use case.

81
UML Design Representation
  • Design of an application is represented in UML by
    a collection of diagrams of the following types
    (not an exhaustive list)
  • Class diagrams capture the relationships amongst
    classes.
  • Sequence (or collaboration) diagrams depict the
    sequence of actions initiated due to an external
    event. This sequence is depicted in terms of
    messages sent from one object to another.
  • Statecharts depict the relationship amongst
    various states of an object.

82
Use Case Diagram (partial)
83
A Sequence Diagram (partial)
Passenger 1 is on floor 6 and 2 on floor 2.
Door closes, E moves, passes floor 2.
Arrives at floor 6.
One sequence diagram for each use case.
84
What else can one indicate on a sequence diagram?
  • Broadcast messages sent by one object and
    received by more than one.
  • Timing marks to show timing constraints m between
    two events.
  • Event identifiers can be attached to an event an
    ID can be referenced in other parts of the
    diagram.
  • State marks are placed on the object timing line
    to indicate state changes for that object.

85
A State Diagram
Behavior of a Message Transaction Object
86
UML State Charts
  • Similar to state diagrams.
  • States can be nested within states. Inner states
    are known as substates.
  • History connector allows the specification of
    default initial state in a super state.

87
UML State Charts
Each state may have entry and exit actions as
well as activities.
Entry (exit) actions are executed in the
(reverse) order of nesting.
88
Transitions in UML Statecharts
  • event name (parameters) guard / action list
    event list
  • event name name of the event triggering the
    transition
  • parameters List of parameters passed with the
    event signal.
  • guard Boolean expression that must evaluate to
    true for the transition to take place.
  • action list List of actions to be executed when
    the transition is taken.
  • event list List of events generated, and
    propagated to other state machines, when the
    transition is taken.

89
Summary
  • Testing and debugging
  • Specification
  • Correctness versus confidence
  • Input domain
  • Exhaustive testing and combinatorial explosion
  • UML artifacts Use cases, FSM, State Charts,
    Sequence diagrams

90

Summary Terms
  • Reliability
  • Coverage
  • Error, defect, fault, failure
  • Debugging, test-debug cycle
  • Types of testing, basis for classification

91
Summary Questions
  • What is the effect of reducing the partition size
    on probability of finding errors?
  • How does coverage effect our confidence in
    program correctness?
  • Does 100 coverage imply that a program is
    fault-free?
  • What decides the type of testing?
Write a Comment
User Comments (0)
About PowerShow.com
