Title: ECI 2007: Specification and Verification of Object-Oriented Programs


1
ECI 2007 Specification and Verification of
Object-Oriented Programs
  • Lecture 1

2
The Verifying Compiler
  • A verifying compiler uses automated ..
    reasoning to check the correctness of the
    program that it compiles.
  • Correctness is specified by types, assertions,
    .. and other redundant annotations that
    accompany the program. Hoare, 2004

3
Theorem Proving and Software
Meets spec/Found Bug
  • Soundness
  • If the theorem is valid then the program meets
    specification
  • If the theorem is provable then it is valid

4
Spec Approach for a Verifying Compiler
  • As source language we use C
  • As specifications we use method contracts,
    invariants, and also class, field and type
    annotations
  • As program logic we use Dijkstras weakest
    preconditions
  • For automatic verification we use type checking,
    verification condition generation (VCG) and
    automatic theorem proving (ATP)

5
Demo (Spec)
6
Spec Tool Architecture
Spec (annotated C)
Spec Compiler
Boogie PL
VC Generator
Formulas
Automatic Theorem Prover
Z3 SMT solver
7
Lectures
  1. Logic of Object-oriented Programs
  2. Invariants and Ownership
  3. Verification Condition Generation
  4. Proving Verification Conditions

From Spec To BoogiePL
From Boogie PL To Formulas
SMT solvers
8
Programs ! Theorems Axiomatic Semantics
  • Consists of
  • A language for making assertions about programs
  • Rules for establishing when assertions hold
  • Typical assertions
  • During the execution, only non-null pointers are
    dereferenced
  • This program terminates with x 0
  • Partial vs. total correctness assertions
  • Safety vs. liveness properties
  • Usually focus on safety (partial correctness)

9
Hoare Triples
  • Partial correctness A s B
  • When you start s in any state that satisfies A
  • If the execution of s terminates
  • It does so in a state that satisfies B
  • Total correctness A s B
  • When you start s in any state that satisfies A
  • The execution of s terminates and
  • It does so in a state that satisfies B
  • Defined inductively on the structure of statements

10
Hoare Rules
A s1 C C s2 B
A s1 s2 B
A Æ E s1 B A Æ E s2 B
A if E then s1 else s2 B
I Æ E s I I Æ E ) B
I while E do s B
11
Hoare Rules Assignment
  • Example A x x 2 x gt 5 . What is
    A?
  • General rule


BE/x x E B
  • Surprising how simple the rule is !
  • The key is to compute backwards the
    precondition from the postcondition
  • Forward rule is more complicated


A x E 9 x. Ax/x Æ x Ex/x
12
Weakest preconditions
  • Dijkstras idea To verify that A s B
  • Let Pre(s, B) A A s B
  • b) (Pre(s,B), ?) is a lattice
  • - false ? Pre(s,B)
  • - if ??Pre(s,B) and ??Pre(s,B), then
    ????Pre(s,B)
  • - if ??Pre(s,B) and ??Pre(s,B), then
    ????Pre(s,B)
  • c) WP(s, B) lub?(Pre(s, B))
  • d) Compute WP(s, B) and prove A ? WP(s, B)

13
Predicate lattice
Pre(s, B)
14
Weakest preconditions
  • WP(x E, B) BE/x
  • WP(s1 s2, B) WP(s1, WP(s2, B))
  • WP(if E then s1 else s2, B)

    E ) WP(s1, B) Æ E ) WP(s2, B)
  • WP(assert E, B) E ? B

15
Example
returns c requires true ensures c a ? b bool
or(bool a, bool b) if (a) c
true else c b
S
WP(S, c a ? b) (a ? true a ? b) ? (?a ? b
a ? b)
Conjecture to be proved true ? (a ? true a ?
b) ? (?a ? b a ? b)
16
Weakest preconditions (Contd.)
  • What about loops?
  • Define a family of weakest preconditions
  • WPk(while E do S, B) weakest precondition from
    which if the loop terminates in k or fewer
    iterations, then it terminates in B
  • WP0 E ) B
  • WPi1 WPi ? (E ) WP(s, WPi))
  • WP(while E do S, B) Æk 0 WPk glb?WPk k
    0
  • Hard to compute
  • Can we find something easier yet sufficient ?

17
Not quite weakest preconditions
  • Recall what we are trying to do

)
false
true
Pre(s, B)
weak
strong
weakest precondition WP(s, B)
A
  • We shall construct a verification condition
    VC(s, B)
  • The loops are annotated with loop invariants !
  • VC is guaranteed stronger than WP
  • But hopefully still weaker than A A ) VC(s, B) )
    WP(s, B)

18
Desugaring loops
  • WP(havoc x, B) ?x. B
  • WP(assume E, B) E ? B
  • whileI,T E do s ?
  • assert I havoc T assume I
  • if (E) s assert I assume false
  • I is the loop invariant (provided by the
    programmer)
  • T is the set of loop targets (can be approximated
    by scanning the loop body)

19
Example 1
returns c requires b gt 0 ensures c a b int
add(int a, int b) int t t b c
a assert t ? 0 ? c ab-t havoc
c,t assume t ? 0 ? c ab-t if (t gt 0)
c c 1 t t 1
assert t ? 0 ? c ab-t assume false

returns c requires b gt 0 ensures c a b int
add(int a, int b) int t t b c
a invariant t ? 0 ? c ab-t
while (t gt 0) c c 1 t
t 1
A
A
L
Conjecture to be proved b ? 0 ? VC(A, c a b)
20
returns c requires b gt 0 ensures c a b int
add(int a, int b) int t t b c
a assert t ? 0 ? c ab-t havoc
c,t assume t ? 0 ? c ab-t if (t gt 0)
c c 1 t t 1
assert t ? 0 ? c ab-t assume false
  • VC(L, c a b) ?
  • c,t.
  • (t ? 0 ? c a b t ?
  • ? t gt 0 ? t - 1 ? 0 ?
  • c 1 a b (t - 1)
  • ? t ? 0 ? c a b)
  • VC(A, c a b) ?
  • b ? 0 ? a a b b ?
  • c,t.
  • (t ? 0 ? c a b t ?
  • ? t gt 0 ? t - 1 ? 0 ?
  • c 1 a b (t - 1)
  • ? t ? 0 ? c a b)

A
L
Conjecture to be proved b ? 0 ? VC(A, c a b)
21
Example 2
returns c ensures c a b int add(int a, int b)
int t t b c a assert c
ab-t havoc c,t assume c ab-t
if (t ? 0) c c 1 t t
1 assert c ab-t assume
false
returns c ensures c a b int add(int a, int b)
int t t b c a
invariant c ab-t while (t ? 0)
c c 1 t t 1
A
A
L
Conjecture to be proved true ? VC(A, c a b)
22
Invariants Are Not Easy
  • Consider the following code from QuickSort
  • int partition(int a, int L0, int H0, int pivot)
  • int L L0, H H0
  • while(L lt H)
  • while(aL lt pivot) L
  • while(aH gt pivot) H --
  • if(L lt H) swap aL and aH
  • L
  • return L
  • Consider verifying only memory safety
  • What is the loop invariant for the outer loop ?

23
Verification conditions (Contd.)
  • What about procedure calls?
  • Annotate each procedure with a precondition pre,
    a modifies clause M, a postcondition post
  • f() ? assert pre havoc M assume post

24
Program verification
  • Annotate each procedure with a precondition, a
    modifies clause, and a postcondition and each
    loop with an invariant and loop targets
  • Verify each procedure separately

requires pre modifies M ensures post f()
S
Verify that the formula VC(assume pre S assert
post, true) is valid and the targets of S are
contained in M
25
Exponential Verification Conditions
The following two culprits may result in a VC
that is exponential in the size of the program.
  • WP(x E, B) BE/x
  • VC(if E then s1 else s2, B)

    (E ) VC(s1, B)) Æ ( E ) VC(s2, B))

26
s1 ? x x x . . . x x x
VC(s1, x gt 1) has 2n occurrences of x.
n statements
27
Efficient VC Generation
How can we get a formula that is linear in the
size of the (loop-free and call-free) program?
28
Eliminate assignments
  • Dynamic single assignment (DSA) form
  • There is at most one definition for each variable
    on each path
  • Replace defs/uses with new incarnations
  • x x1 with xn1 xn 1
  • Replace havoc x with new incarnations xn1
  • At join points unify variable incarnations
  • Eliminate assignments by replacing
  • x E with assume x E

29
Example
assume x 1 x x 1 if (x 0) x
x 2 else x x 3 assert x
5
assume x0 1 assume x1 x0 1 if (x1 0)
assume x2 x1 2 assume x4 x2
else assume x3 x1 3 assume x4
x3 assert x4 5
30
Efficient VC Generation (I)
  • WP(x E, B) BE/x

compare with
WP(assume x E, B) (x E ? B)
Intuition The decorated variables essentially
give names to sub-expressions in the original
VC. The unique definition of each variable now
occurs as an assumption.
31
Efficient VC Generation (II)
  • VC(if E then s1 else s2, B)
  • E ? VC(s1, B)
  • E ? VC(s2, B)

compare with
VC(if E then s1 else s2, B)
? E ? VC(s1, true) ? B ? E ? VC(s2, true) ? B
  • ? E ? VC(s1, true)
  • E ? VC(s2, true)

B occurs only once in the VC eliminating
the exponential blowup.
? B
32
Unstructured control flow
  • Control flow is not always structured
  • exceptions, goto statements
  • How do we generated verification conditions for
    programs with unstructured control flow?

33
Unstructured control flow
  • Eliminate loops, procedure calls, assignments
  • Passive program with acyclic control flow
  • Eliminate if-then-else statements using goto
    statements
  • Finally, program is a collection of blocks
  • Each block is
  • l A1,,Am goto l1,,ln
  • l is block label
  • A is either assume E or assert E
  • Distinguished start label

34
Example
assume x0 1 assume x1 x0 1 if (x1 0)
assume x2 x1 2 assume x4 x2
else assume x3 x1 3 assume x4
x3 assert x4 5
start assume x0 1 goto l1 l1 assume x1
x0 1 goto l2, l3 l2 assume x1 0 assume
x2 x1 2 assume x4 x2 goto l4 l3
assume x1 ? 0 assume x3 x1 3 assume x4
x3 goto l4 l4 assert x4 5
35
VC Generation for Unstructured Control Flow
  • For each block A l S goto l1,..,ln introduce a
    boolean variable Aok
  • Aok holds iff all executions starting at A do not
    end in a failed assertion
  • Introduce a Block Equation for each block A
    BEA ? Aok ? VC(S, ?B?Succ(A). Bok)
  • VC of entire program
  • (?A. BEA) ? Startok

36
Spec Tool Architecture
Spec (annotated C)
Spec Compiler
Boogie PL
VC Generator
Formulas
Automatic Theorem Prover
Z3 SMT solver
37
Boogie PL Parts
  • Boogie PL source contains
  • a first order theory to encode the background
    semantics of the source language and the program,
    described
  • constants, functions and axioms
  • an imperative part used to encode the traces of
    the source program, described by
  • procedures, pre and postconditions, mutable
    variables, and unstructured code

38
Limits of Boogie PL
  • Boogie PL does not contain
  • structured types
  • a heap
  • expressions with side effects
  • visibility
  • subtyping
  • dynamic dispatch

39
Boogie PL Procedures
  • Declaration
  • procedure Find(xs int int, ct int, x int)
    returns (result int)
  • Implementation
  • implementation Find(xs int int, ct int, x
    int) returns (result int)
  • Call
  • call r Find(bits, 100, 32)

40
Boogie PL Procedure Specifications
proc Find(xs int int, ct int, x int) returns
(result int) requires ct 0 ensures
result 0 ? result lt ct ? xsresult x
ensures result lt 0 ? !(? iint 0 i ? i lt ct
? xsi x)
41
A Bogus Implementation?
  • var xs int int
  • var ct int
  • proc Find(x int) returns (result int)
  • requires ct 0
  • ensures result 0 ? result lt ct ?
    xsresultx
  • ensures result lt 0 ? !(? iint 0 i ? i lt
    ct ? xsi x)
  • impl Find(x int) returns (result int)
    start ct 0 result -1 return

42
More about Postconditions
  • Postconditions
  • must say which variables x might change
  • modifies x
  • variables not mentioned are not allowed to
    change
  • often relate pre-state and post-state
  • ensures x old(x)1

43
proc Find(x int) returns (result int)
modifies ct // would allow the previous
implementation ensures ct old(ct) //
would disallow the change despite modifies clause
About PowerShow.com
