SI23 Introduction to Computer Graphics

1
SI23Introduction to Computer Graphics

• Lecture 5 Drawing A Line

2
Course Outline

• Vector graphics
• Line drawing
• Area filling
• Graphical interaction

SVG Viewer
graphics algorithms
3
Line Drawing

• Line drawing is a fundamental operation in
  computer graphics
• Demanding applications require very fast drawing
  speeds - say, 1 million lines per second
• Hence the algorithm for converting a line to a
  set of pixels will be implemented in hardware -
  and efficiency is vital
• Want to use integer arithmetic
• Want to use additions rather than multiplications

4
Line Drawing - The Problem

• To draw a line from one point to another on a
  display
• - which pixels should be illuminated?

Suppose pt1 (0,1) and pt2 (5,4)
Where to draw the line? ?
5
Line Drawing - By Hand

• In a simple example, one can do by eye

... but we would like an algorithm!
6
Equation of a Line

• Line equation is
• y m x c
• If line joins (x1,y1) to (x2,y2), then
• m (y2-y1)/(x2-x1) and c y1 - m x1

Suppose pt1 (0,1) and pt2 (5,4)
Then m (4-1)/(5-0) ie 0.6 and c 1 Thus y
0.6 x 1
7
Drawing a Line From Its Equation

• We can use the equation to draw the pixels

y 0.6 x 1
Calculate y for x 0,1,2,3,4,5 and round to
nearest integer
x 0 -gt y 1 y 1 x 1 -gt y 1.6 y 2 x
2 -gt y 2.2 y 2 x 3 -gt y 2.8 y 3 x 4
-gt y 3.4 y 3
8
The Line Drawn
This gives us (after 1 multiplication, 1
addition, and 1 rounding operation per step)
Calculate y for x 0,1,2,3,4,5 and round to
nearest integer
y 0.6 x 1
x 0 -gt y 1 y 1 x 1 -gt y 1.6 y 2 x
2 -gt y 2.2 y 2 x 3 -gt y 2.8 y 3 x 4
-gt y 3.4 y 3
How do we make more efficient?
9
DDA Algorithm

• We can do this more efficiently by simply
  incrementing y at each stage
• y y q where q (y2-y1)/(x2-x1)

Here q 0.6
y 1.0 y 1 y 1.0 0.6 1.6 y 2 y 1.6
0.6 2.2 y 2 y 2.2 0.6 2.8 y 3 y
2.8 0.6 3.4 y 3
One addition, one rounding
10
Slope of Line

• We have assumed so far that slope of line (m)
  lies between -1 and 1
• When slope of line is greater than 1 in absolute
  value, then we increment y by 1 at each step, and
  x by
• d (x2-x1)/(y2-y1)

Exercise calculate the pixels to draw line
from (1,0) to (4,5)
11
Efficiency

• The DDA (Digital Differential Analyser)algorithm
  just described has the problem
• floating point operations (real numbers) are
  expensive - add and round at each step

Yet really all we need to decide is whether to
move horizontally or diagonally (for a line of
slope lt 1). Can we do this in integer arithmetic?
12
Bresenhams Algorithm

• One of the classic algorithms in computer
  graphics is the Bresenham line drawing algorithm
• Published in 1965
• Still widely used
• Excellent example of an efficient algorithm

Jack Bresenham
13
Bresenhams Algorithm - First Step

• Look in detail at first step

We have choice of a move to (1,1) or (1,2) Exact
y-value at x1 is y 0.6 1 1.6 Since
this is closer to 2 than 1, we choose (1,2)
2
d2
d1
1
0
0
1
2
14
Bresenhams Algorithm

• In general, suppose we are at (xk,yk) - slope of
  line, m, is between 0 and 1
• Next move will be to (xk1, yk) or (xk1, yk1)

d1 m(xk 1)c - yk d2 yk 1 - m(xk
1)c d1 - d2 2m(xk 1) - 2yk 2c -1 gt0
indicates (xk1, yk1) lt0 indicates (xk1, yk)
yk1
d2
d1
yk
xk
xk1
15
Bresenhams Algorithm
d1 - d2 2m(xk 1) - 2yk 2c -1 d1-d2 gt0
diagonal Let m Dy/Dx and multiply both sides
by Dx, setting Dx(d1 d2) pk pk 2Dy xk -
2Dx yk b (b a real constant) Decision is still
pkgt0 - but can we work only in integers? How
does pk change at next step to pk1? We
know that xk increases by 1, and yk either
increases by 1 or stays the same. So .
16
Bresenhams Algorithm
pk 2Dy xk - 2Dx yk b pk1 pk 2Dy - 2Dx
- if y increases pk1 pk 2Dy -
if y stays the same Thus we have a decision
strategy that only involves Integers, no
multiplication and no rounding .. we start
things off with p0 2Dy - Dx
17
Bresenhams Algorithm - A Summary

• To draw from A to B with slope 0ltmlt1
• let (x0,y0) A and plot (x0,y0)
• calculate Dx, Dy
• calculate p0 2Dy - Dx
• for k 0,1,2,.. until B reached
• If pk lt 0 then plot (xk1 , yk) and set
• pk1 pk 2 Dy
• If pk gt 0 then plot (xk1, yk1) and set
• pk1 pk 2 Dy - 2 Dx

18
Bresenhams Algorithm - Example

• (x0,y0) (0,1)
• Dx 5, Dy 3

• p0 2Dy - Dx 1 gt 0
• hence plot (1,2)

- p1 p0 2Dy -2Dx -3 lt0 hence plot (2,2)
And so on
19
Bresenhams Algorithm - Other Slopes and Other
Shapes

• There are straightforward variations for lines
  with slopes
• m gt 1
• -1 lt m lt 0
• m lt -1
• There are similar algorithms for drawing circles
  and ellipses efficiently - see Hearn Baker
  textbook

20
Other Ways of Drawing Lines

• Over past 38 years, researchers have strived to
  improve on Bresenhams incremental algorithm
• for example, think how to parallelise the
  algorithm

• Alternative structural approach comes from
  recognition that horizontal (0) and diagonal (1)
  moves come in runs
• We had
• 10101
• One of the moves occurs singly, and is evenly
  spread within the sequence - the other occurs in
  up to two lengths (consecutive numbers)
• 01001000100100010
• ie 1 occurs singly, 0 occurs in twos and threes
• decision is now which length of run

21
Aliasing

• Lines on raster displays suffer from aliasing
  effects - especially noticeable with lines near
  to horizontal

This is caused because we are sampling the
true straight line at a discrete set of
positions. Called aliasing because many
straight lines will have the same raster
representation.
More noticeable on screen than laser printer -
why?
22
Supersampling Bresenham on Finer Grid
Each pixel is divided into 9 sub pixels. Either
0,1,2 or 3 sub-pixels can be set in any
pixel. This can be used to set the
intensity level of each pixel.
2
1
0
0
1
2
3
23
Supersampling
This shows the intensity levels for the pixels
in the previous slide. We are really
using intensity levels to compensate for lack of
resolution.
3
2
2
1
24
Antialiased Line
The end result is a thicker line, with
the intensity spread out over a larger area. To
the eye, the line appears much sharper and
straighter.
25
Bresenhams Algorithm
d1 - d2 2m(xk 1) - 2yk 2c -1 d1-d2 gt0
diagonal Let m Dy/Dx and multiply both sides
by Dx, setting Dx(d1 d2) pk pk 2Dy xk -
2Dx yk b (b a constant) Decision is still pkgt0
- but can we work only in integers? pk1 2Dy
xk1 - 2Dx yk1 b ... So pk1 pk 2Dy -
2Dx(yk1 - yk) - where (yk1 - yk) 0 or 1 Thus
we have a decision strategy that only involves
integers.. we start things off with p0 2Dy -
Dx
