Title: Ensemble Verification System: Status and Plan


1
Ensemble Verification SystemStatus and Plan
  • Yuejian Zhu and Zoltan Toth
  • Environmental Modeling Center
  • NOAA/NWS/NCEP
  • Acknowledgements
  • Geoff DiMego, Mark Iredell and Stephen Lord EMC
  • Presentation for 3rd Ensemble User Workshop
  • November 1st 2006

2
Contents
  • Design Principles Modularity, Flexibility,
    Portability
  • Allow sharing parts of system across EMC, NWS,
    NOAA, and community
  • Efficiency in development (collaboration with
    ESRL)
  • Scientific compatibility
  • Verification Statistics ()
  • Types, scope and etc..
  • Required diagnostic/verification scores()
  • Deterministic, probabilistic
  • Sample Modularity Design
  • General scripts - inputs
  • Components
  • Required Display Capabilities

3
Design Principles
  • Modularity. The verification system should be
    broken into modules with pre-defined interfaces
    so that different users can work on different
    parts of the code without affecting each other.
    This common shared stream of modules would be
    unified and much of the code would be shared
    across EMC. The design of the verification
    system would be bought into by all EMC groups.
    User groups can make necessary changes for their
    special applications. The VSDB format is an
    example of this kind of interface, but the
    statistic generating codes and the display codes
    could be more modular.
  • Flexibility. New kinds of verification scores
    need to be easily added to the verification
    system without having to ask an expert. We
    cannot readily anticipate ahead of time what
    these new kinds of scores are. Modularity would
    allow users to modify specific parts without
    detailed knowledge about the rest of the
    software. The system should be adaptable to
    other modeling systems ocean, land, cryosphere,
    space, single column, OSSEs, etc.
  • Portability. All codes should be able to run
    efficiently on the CCS or on the EMC
    workstations. GUI menu driven software should be
    able to reach all the way back into the robotic
    tape archives if necessary.

4
Verification Statistics
  • Major types of statistics
  • Diagnostics (depends on forecast only)
  • Verification (depends on comparison of forecast
    to estimate of truth)
  • Scope of statistics
  • Point-wise at a given time (eg, absolute error)
  • Multivariate defined over a set of variables
  • Expanded in space (eg, PAC)
  • Expanded in time (eg., temporal correlation)
  • Expanded over other variables
  • Choice of domain
  • Time
  • Single level
  • Multiple levels
  • Space
  • 3-D grid domain
  • Choice of variable(s)
  • Single
  • Multiple

5
Verification Statistics
  • Types of verifying data all statistics to be
    identically computed for both types
  • Observations
  • NWP analysis
  • Error specification for verifying data
  • Standard deviation
  • Probability distribution
  • Types of forecasts
  • Single forecast
  • Ensemble of forecasts
  • Forecast data format
  • Gridded (single point or lat/lon array)
  • Feature based (eg, position and intensity of
    hurricane generation of this could be considered
    as part of forward model)
  • Forecast data type
  • Operational
  • Parallel
  • User supplied experimental

6
Verification Statistics
  • Event definition for probabilistic scores
  • User defined thresholds
  • Climatological percentiles (based on eg
    global/regional reanalysis)
  • Defined by ensemble members (eg, Talagrand
    statistics)
  • Generation of probabilistic forecasts
  • Based on ensemble forecasts (with user defined
    weights)
  • User supplied pdf (based on statistical or other
    methods)
  • Benchmarks for skill score type statistics
  • Climatology
  • Persistence
  • Choice of other forecast system
  • Manipulation of partial statistics
  • Aggregate in time
  • Aggregate in space

7
Required diagnostic/verification scores
  • Ensemble forecasts
  • Point-wise
  • Ensemble mean statistics
  • RMS error
  • PAC correlation
  • Spread
  • Best member frequency statistics
  • Multivariate (for particular spatial domain,
    cannot be aggregated in space)
  • Perturbation vs. Error Correlation Analysis
    (PECA)
  • Independent degrees of freedom (DOF)
  • Explained error variance
  •  Probabilistic forecasts
  • Point-wise (computed point by point, then
    aggregated in space and time)
  • Brier Skill Score (incl. Reliability Resolution
    components)
  • Ranked Probability Skill Score (incl. Reliability
    Resolution components)
  • Continuous Ranked Probability Skill Score (incl.
    Reliability Resolution components)
  • Relative Operating Characteristics (ROC)
  • Relative Economic Value
  • Information content

8
Sample Modularity Design
  • Input
  • Agree on a list of things that need to be
    provided to define verification (see major points
    above) how all this info would be passed between
    the modules. It would be nice to have a common
    form, but possibly we need different templates
    for unique applications (for verifying gridded
    data hurricane tracks ensemble?) Example
  • Verification statistics Specify
  • Predefine
  • User provided?
  • Volume
  • Space - specify 3D box
  • Time specify period, lead time, time frequency
  • Forecast Choose from
  • Operational
  • Parallel
  • Experimental (define location)
  • Truth Choose from
  • Analysis
  • Observation types
  • Variable Choose one or more in case of
    hurricane track, this for example would not be
    relevant
  • Output format Choose one or both
  • Table (select from pre-designed choices)
  • Graph (select from pre-designed choices)

9
Sample Modularity Design
  • Driver component
  • Runs all modules as needed. Some functions
  • Checks if requested stat has already been
    archived or can be computed from intermediate
    stats in database
  • Prepares main script that calls subscripts of
    data preprocessor, verification engine, and
    database steps for each verification unit (ie,
    one comparison of forecast and truth), if missing
    stats need to be computed
  • Prepares post-processing script for computation
    of final verification stats
  • Prepares and calls display script
  • Input data component
  • read whatever format the raw forecast and
    observations come in and put into objects
    containing data and metadata prepares
    corresponding climatological information if
    needed prepares any other data needed (eg, event
    definitions, etc, for probabilistic forecasting?)
  • Read GRIB or BUFR
  • Requires an input object datatype

10
Sample Modularity Design
  • Forward model component
  • put input objects into the requested verification
    space (grid or observation location)
  • Interpolate to verification grid and time
  • Compute derived quantities (units change,
    vorticity, radiances, etc.
  • Compute anomalies, trends, indices, bias
    corrections
  • Compute probabilistic ensemble quantities??
  • Apply any filters and averaging
  • Feature tracking
  • Partial statistics component
  • compute statistics in the verification space
  • Partial sum
  • Threshold stats
  • Probabilistic stats
  • Output VSDB (mysql)

11
Sample Modularity Design
  • Final statistics component (i.e., FVS)
  • Full sums
  • Interactively selectable
  • Output VSDB-like?
  • Can a commercial package do this?
  • Database
  • Display
  • Menu driven
  • Web resident
  • Reaches all the way back to step (input) if
    necessary
  • Plots output directly from step (driver
    component) if requested
  • Commercial package like IDL?
  • Output format
  • Table
  • Graphics

12
Required Display Capability
  • User interactive statistic selection
  • User interactive display options
  • GUI browser interface
  • Same interface whether operational or own
    experiment
  • Professional output

13
BACKGROUND
14
Required diagnostic/verification scores
  • Single forecast
  • CFS
  • NINO 3.4 anomaly correlation (CFS)
  • Bias-corrected US 2 meter temperature (AC, RMS)
  • Bias-corrected US precipitation (AC, RMS)
  • Weekly, monthly, seasonal, annual, interannual
    stats
  •  GFS
  • Feature tracking
  • Hurricane tracks
  • Raw track errors and compared to CLIPER
  • Frequency of being the best
  • By storm and basin
  • Hurricane intensity
  • Extratropical storm statistics
  • Verification against observations
  • Support both interpolation from pressure levels
    or from native model levels.
  • Horizontal bias and error maps
  • Vertical bias and error by region
  • Time series of error fits

15
Required diagnostic/verification scores
  • Single forecast
  • GFS (continue)
  • Verification against analyses
  • All fields in master pressure GRIB file can be
    compared
  • All kinds of fields, including tracers
  • All kinds of levels, including iso-IPV
  • Single field diagnostics (without a verifying
    field)
  • Mean, mode, median, range, variance
  • Masking capability - Only over snow covered,
    etc.
  • Region selection
  • Anomaly correlation
  • RMS error
  • FHO statistics by threshold
  • Count of difference and largest difference
  • Superanalysis verification
  • GDAS
  • All statistics segregated by instrument type
  • Observation counts and quality mark counts
  • Guess fits to observations by instrument type

16
General Issues
  • Event definition - Must be able to define events
    in 3 different ways
  • Based on reanalysis (global or regional or other)
    climatology. Example definition of event Falling
    between 20 and 30 percentile of climatological
    distribution (or falling below or above a certain
    percentile). Actual range of values to be derived
    automatically from climatological distribution
  • Defined by user. Example range between 2 and 4 C
    temperature. Corresponding climatological
    percentile values to be determined automatically
    by consulting climatological distribution of
    variable
  • Based on ensemble distribution (if verifying
    ensemble-based probabilities). Example range
    between 3rd and 4th ensemble members.
    Climatological percentile values to be determined
    as above.
  • Generation of probabilistic forecasts
  • Based on an ensemble of forecasts user should be
    able to specify unequal weights for various
    members
  • Other methods user supplied cumulative or
    probability density functions
  • Reference scores for computing skill scores and
    similar measures Where appropriate, user must
    be able to select from three alternate
    references
  • Climatological forecast
  • Persistence forecast
  • User specified probabilistic forecast (other
    than the system being tested)
  • Verifying data - User should be able to compute
    scores against either analysis or observations
