Title: Virtualization


1
Virtualization
  • Susanta K. Nanda
  • ECSL
  • CSE 502, Fall05

2
Virtualization at the Hardware Level
  • Observation
  • Hardware resources are typically under-utilized
  • Hardware resources directly relate to cost
  • Goal Improve hardware utilization
  • How?
  • Share hardware resources across multiple machines
  • May make sense for network attached storage, but
    what about processor, memory, etc.?
  • Theme
  • Decouple machine from hardware
  • Virtual Machine (VM)
  • A machine decoupled from the hardware, i.e. does
    not necessarily correspond to the hardware
  • Multiple Virtual Machines on the same physical
    host could share the underlying hardware
  • First VM IBM System/360 Model 40 VM 1965

3
Virtual Machine Monitor (VMM)
  • A thin layer of software on top of the bare
    machine to facilitate virtualization of hardware
    resources
  • Mediates between VMs and the hardware
  • Manages VMs
  • Create, Destroy, Power Off/On, etc.
  • Concerns
  • Isomorphism State transitions must be isomorphic
    to a physical nachine
  • Isolation One VM from all others
  • Performance Close-to-native
  • Correctness Exactly same hardware interface to
    the guest OS to support commodity OSes without
    any modification

4
A Stolen Picture
5
VM Additional Advantages
  • Non-existing hardware
  • Virtual devices through emulation via a
    combination of software and other available
    devices
  • Example SCSI-disk using IDE-disks, (virtual)
    timer
  • Use Legacy systems/software
  • Hides heterogeneity of the underlying hardware
  • Ability to switch hardware vendors
  • Mobility
  • Decoupling helps move a VM from one physical host
    to another, just as a file
  • Use Server consolidation, hardware maintenance,
    etc.
  • OS Debugging, Mixed OS, Event monitoring,
    Execution Undo, and Many more

6
Key Concepts Appearance
  • A VM consists of Shared and Dedicated Hardware
  • Shared Disk, Memory, NIC, CPU, Printer, etc
  • Dedicated Keyboard, Mouse, Display, Speakers,
    CD-Drive, etc
  • A server VM may not require some dedicated
    devices
  • Dedicated hardware
  • Per User
  • Sharable across multiple VMs if they belong to
    the same user

7
Key Concepts State Management
  • Each VM would have its own architected state
    information
  • Example registers/memory/disks, page table/TLB
  • Not always possible to map all architected states
    to its natural level in the host
  • Insufficient/Unavailable host resources
  • Example Registers of a VM may be architected
    using main memory in the host
  • VMs keep getting switched in/out by the VMM
  • Isomorphism requires all state transitions to
    be performed on the VM states
  • Performance requires efficient state management
  • State Management Indirection Vs. Copying

8
Key Concepts State Management contd
  • Indirection
  • Hold state for each VM in fixed locations in the
    hosts memory hierarchy
  • A pointer managed by VMM indicating the guest
    state that is currently active
  • Example Register block maintained in memory and
    a processor register pointing to the register
    block of the currently active VM
  • Pros Ease of management
  • Cons Inefficient (mov eax ebx requires 2 inst)
  • Copying
  • Copy VMs state information to its natural level
    in memory hierarchy when switched in
  • Copy them back to the original place when
    switched out
  • Example Copy all the VM registers to the
    processor registers
  • Pros Efficient (most instructions are executed
    natively)
  • Cons Copying overhead

9
Key Concepts Resource Control
  • VMM must maintain overall control of the hardware
    resources
  • Hardware resources are assigned to VMs when they
    are created/executed
  • Should have a way to get them back when they need
    to assigned to a different VM
  • Similar to multi-programming in OS
  • Privileged Resources
  • Certain resources are accessible only to and
    managed by VMM
  • Interrupts relating to such resources must then
    be handled by VMM
  • Privileged resources are emulated by VMM for the
    VM
  • Example interval timer
  • All resource that could help maintain control are
    marked privileged
  • Interval timer is used to decide VM scheduling
  • Page table base register (CR3 on x86) is used
    to isolate VM memory
  • Issues VM scheduling (An ideally fair scheduling
    may not be good)

10
Key Concepts Native/Hosted VMs
  • Native VMs
  • VMM is installed on the bare machine, no host OS
  • All other VMs are then created through the VMM
  • Pros Clean Architecture, Efficient
  • Cons Complicated VMM due to device drivers
  • Example VMware ESX Server
  • Hosted VMs
  • VMM is installed on top of a host OS
  • User-mode VMM runs in non-privileged mode
  • Dual-mode VMM runs partly in privileged mode (as
    a driver on the host OS) and partly in
    unprivileged mode (like an application)
  • Pros VMM uses drivers in the host OS for I/O ?
    Thin VMM
  • Cons Inefficient for I/O intensive applications
  • Example Microsoft Virtual Server

11
Processor Virtualization
  • Privilege Levels/Rings
  • System/User mode
  • System ISA vs. User ISA
  • Emulation
  • Guest ISA may differ from Host ISA
  • Binary translation
  • Slower
  • Native Execution
  • Guest and Host ISA must be the same
  • Some critical instructions may still need to be
    emulated
  • Issues Complexity of discovering and emulating
    critical instructions efficiently

12
ISA Virtualizability
  • Privileged Instructions (PI)
  • Instructions that generate a trap when executed
    in any but most-privileged level
  • Example LIDT (load interrupt descriptor table)
  • Sensitive Instructions (SI)
  • Instructions whose behavior depends on the
    current privilege level
  • Example POPF (pops the stack to EFLAGS)
  • In user mode, the Interrupt Enable bit of the
    ELAGS register is not over-written
  • In system mode, the value is blindly copied
  • Popek/Goldberg Theorem
  • For any conventional third-generation computer, a
    virtual machine monitor may be constructed if the
    set of sensitive instructions for that computer
    is a subset of the set of privileged
    instructions.
  • In other words, ISA is Virtualizable if and only
    if SI is a subset of PI

13
When ISA is not Virtualizable?
  • All is not lost if an ISA violates Popek/Goldberg
    theorem
  • However, it brings in additional complications
    and inefficient in VMM implementation
  • Critical instructions
  • Instructions that are sensitive but not
    privileged
  • X86 has 17 critical instructions
  • All critical instructions must be emulated by VMM
  • VMM Components
  • Binary Scanner Inspects and inserts trap at
    critical instructions
  • Dispatcher Gets control when a trap occurs
  • Allocator Allocates machine resources (e.g. load
    relocation bounds register)
  • Interpreters Each interpreter interprets one
    privileged instruction

14
Memory Virtualization
  • VM support in traditional architectures
  • Architected TLB vs. Architected Page Table
  • Page-fault and Swap
  • One level of indirection Page Table
  • VMM requires two levels of indirection
  • Virtual Memory to Real Memory Page Table (Guest
    OS)
  • Real Memory to Physical Memory Real Map Table
    (VMM)
  • Architected Page Table
  • Additional Data Structures
  • Real Map Table (VMM)
  • Shadow Page Tables (VMM) Used by hardware for
    address translation, directly maps virtual
    address to physical (not real) address
  • Maintenance
  • VMM intercepts and emulates Page table
    modifications, Page table base register
    modifications by the Guest OS

15
Memory Virtualization contd
  • Architected TLB
  • Virtual TLB maintained by guest OS
  • Virtual ASID, Virtual Page, Real Page
  • Real TLB maintained by VMM
  • Real ASID, Virtual Page, Physical Page
  • ASID map table
  • Virtual ASID, Real ASID
  • VMM intercepts/emulates all modifications to TLB
    by the guest OS

16
I/O Virtualization
  • Virtualizing Devices
  • Dedicated Devices Display, Keyboard, Mouse, etc.
  • Partitioned Devices Disk
  • Shared Devices Network adapter
  • Spooled Devices Printer
  • Non-existent Physical Devices virtual network
    adapter
  • Virtualizing I/O Operations
  • Intercepting/emulating IN/OUT, INS/OUTS
  • Map virtual resource ID to physical device ID
  • De-multiplexing the interrupts for the devices
  • Virtualizing I/O in Hosted VMM
  • VMM-driver translates I/O instructions back to
    system calls in the host OS

17
Performance Degradation in VMMs
  • Setup VM State initialization
  • Emulation Emulating critical instructions
  • Interrupt Handling
  • Interrupts generated by a program within a VM has
    to be first handled by VMM even though its not
    required sometimes
  • State Saving During world switches
  • Bookkeeping Timers, etc
  • Time Elongation Memory references take longer

18
VT-x Vanderpool Technology
  • VMX Mode for Processors
  • VMX Root and VMX Non-root
  • All four privilege level (rings) are available in
    both root and non-root in VMX mode
  • Thus, four new less privilege levels than
    Pentiums
  • Guest VMs can run in VMX non-root
  • Host (Hosted VMM) and VMM in VMX root
  • VMX instructions
  • VMX root has access to a new set of instructions
  • Critical shared resources are kept under the
    control of a monitor in VMX root
  • VMX non-root ring 0 does not have access to the
    critical resources
  • An example of a critical resource Memory for
    state management

19
An Example Operation
  • VMXON Switch into VMX mode To VMM
  • VMLAUNCH VM1 Start executing VM1 in VMX non-root
    operation
  • VM1 Exits Go back to VMM
  • VMLAUNCH VM2 Start executing VM2
  • VM2 Exits Go back to VMM
  • VMRESUME VM2 Switch to VM2 again
  • VM2 Exits Go back to VMM
  • VMRESUME VM2 Switch to VM2
  • VMRESUME VM1 VM2 exits, VM1 switched in
  • VM1 exits Go back to VMM
  • VMXOFF Get back to Regular mode

20
Maintenance of State
  • VMCS Data Structure
  • Fully specified, various fields defined
  • Manipulated only by hardware or software in
    VMX-root
  • VMPTR points to the VMCS structure of the current
    executing VM
  • There can be multiple VMs active at any point,
    but one of them would be executing
  • VMWRITE/VMREAD to read contents of VMCS
  • State More than normal, e.g. architecturally
    hidden part of segment registers
  • Control Fields Define under what condition a VM
    exits
  • Example Some specific interrupt/instruction/etc,
    number of model-specific registers (MSRs) that
    need to be saved when VM exits
  • VM exit info
  • Informs the VMM the reason for exit along with
    supporting info

21
Maintenance of State contd
  • State Area
  • Guest State Register state, Interruptibility
    state
  • Host State Register State
  • Control Area
  • VM Execution Controls
  • Pin/Processor-based execution controls, bitmap
    fields, etc
  • VM Exit Controls
  • Control bitmap, MSR Controls
  • VM Entry Controls
  • Control bitmap, MSR Controls, Controls for Event
    Injection
  • VM Exit Information
  • Basic Info VM-Exit Info, Vectoring Event Info
  • Other Exit Info Due to event delivery, due to
    instruction execution
Write a Comment
User Comments (0)
About PowerShow.com
