Dr' Claude C' Chibelushi

1
Image Processing, Computer Vision, and Pattern
Recognition
Fac. of Comp., Eng. Tech. Staffordshire
University
Statistical Pattern RecognitionPart II
Classical Model
Dr. Claude C. Chibelushi
2
Outline

• Introduction
• Classical Pattern Recognition Model
• Feature Extraction
• Classification
• Applications
• Optical Character Recognition
• Others
• Summary

3
Introduction

• Pattern recognition often consists of sequence of
  processes
• often configured according to classical pattern
  recognition model

4
Classical Recognition Model
Simplified block diagram
Facial image
Example
5
Classical Recognition Model

• Performance issues
• All stages of recognition pipeline, and their
  connection, affect performance
• typical performance measures recognition
  accuracy, speed, storage requirements
• optimisation of components/connections often
  required
• careful selection / design / implementation of
• data capture equipment / environment
• processing techniques

6
Feature Extraction

• Aim to capture discriminant characteristics of
  pattern
• Extracts pattern descriptors from raw data
• descriptors should contain information most
  relevant to recognition task
• descriptors may be numerical (quantitative ) or
  linguistic
• group of numerical descriptors often known as
  feature vector

7
Feature Extraction

• Common features for computer vision
• Shape descriptors
• external (e.g. boundary) internal (e.g. holes)
• Surface descriptors
• texture, brightness, colour, ...
• Spatial configuration descriptors
• arrangement of basic elements
• Temporal configuration descriptors
• deformation or motion of basic elements

8
Feature Extraction

• Example
• Pattern recognition application gender detection
• Classes male, female

9
Feature Extraction

• Example
• Chosen features height, silhouette area

10
Feature Extraction
Graphical representation of feature
distribution Example data set of 5 male and 5
female subjects
11
Feature Extraction

• Graphical representation of feature distribution
• Example (ctd.) Feature plot 2D feature space

12
Classification

• Aim to identify class (category ) to which
  unknown pattern belongs
• Wide variety of classifiers
• Classifier selection is problem-dependent
• use simple classifier if effective

13
Classification

• Some classifiers
• Minimum-distance classifier
• classification based on distance from
  class-prototype (e.g. average) pattern
• closest prototype determines class
• k-nearest neighbour classifier
• classification based on distance from class
  patterns (or clusters)
• closest k patterns (or clusters) determine class

14
Classification

• Some classifiers
• Bayesian classifier
• classification based on probability of belonging
  to class
• most likely class
• Artificial neural network classifier
• classification based on neuron activations (shown
  to relate to class probability)
• most likely class

15
Classification
Minimum-distance classifier
2D feature space
16
Classification

• k-nearest neighbour classifier

2D feature space
17
Classification

• Some distance metrics
• (for distance-based classifiers)
• Measure similarity between unknown pattern and
  prototype pattern
• based on differences between corresponding
  features in both patterns, e.g.
• Euclidean distance sum of squares of differences
• City-block (Manhattan or taxi-cab) distance sum
  of absolute values of differences

18
Classification

• Decision boundary for
• minimum-distance classifier

2D feature space
19
Classification

• Limitations of minimum-distance classifier
• Prone to misclassification for
• high feature correlation
• problems requiring non-linear decision boundary,
  e.g.
• curved decision boundary
• data with subclasses (i.e. clusters)
• intricate decision boundary

20
Classification
2D feature space
Feature correlation
21
Classification
2D feature space
Curved decision boundary
22
Classification
2D feature space
Distinct subclasses
23
Classification
2D feature space
Complex decision boundary
24
Classification

• Classifier training
• Data-driven extraction of salient class
  characteristics
• supervised training
• class labels used during training
• unsupervised training
• class labels not used during training (e.g.
  clustering)

25
Classification

• Classifier testing
• Testing estimation of recognition accuracy
• often uses real data simulation may be used
  (Monte Carlo)
• Accuracy measure
• error rate (often expressed as percentage)
• e.g. correct recognition rate, insertion rate,
  false acceptance rate, false rejection rate, ...

26
Optical Character Recognition
27
Optical Character Recognition
Generic OCR system
28
Optical Character Recognition

• Feature extraction methods
• Spatial domain to frequency domain transform
• Hartley, Fourier, or other transform
• Statistics
• mean, variance projection histograms
  orientation histograms

29
Optical Character Recognition

• Feature extraction methods
• Miscellaneous
• geometric measures
• ratio of width and height of bounding box, ...
• description of skeletonised characters
• graph description comprising line segments (e.g.
  strokes of Chinese characters)
• number of L,T, or X junctions, ...

30
Optical Character Recognition

• Feature extraction methods

Projection histograms
31
Optical Character Recognition

• OCR examples
• (see AALs book)

32
Other Recognition Applications

• Sample
• recognition of faces or facial expressions
• recognition of body movement (gestures, gait)
• recognition of handwriting (text, signature)
• industrial inspection
• autonomous vehicles, traffic monitoring
• ...
• (Exercise identify architectural components for
  these applications, and discuss factors affecting
  performance)

33
Summary

• Classical pattern recognition model
• pre/post-processing
• feature extraction
• classification
• Feature extraction representation of
  discriminant pattern characteristics
• Classification
• wide variety of classifiers
• supervised or unsupervised classifier training

34
Summary

• Components of generic OCR system
• image capture, image pre-processing, feature
  extraction, classification, post- processing
• Wide variety of features for OCR, e.g.
• frequency-domain representation
• statistical or geometric measurements
• skeleton descriptors
• ...
