Project 2 Part 1 Technology Development for MR
Assessment of Small Animal PhysiologyBrian
Rutt, PhD
2
MR Gradient Coil Insert Design and
ConstructionAndrew Alejski, PhDCarl
Gazdzinski, BSc Yuteng Chen, MSc
3
(No Transcript)
4
300 mT/m 3-layer rabbit coil (Rcoil)
5
Micro-Imaging
7T, 3D Spin Echo 100 micron isotropic 7 hour scan
1.5T, 3D FIESTA 100 micron in-plane 200 micron
slices 30 minute scan
6
Next Generation Insert Coil (Scoil)

• 18 cm inner diameter
• Designed specifically for ultra-high-performance
  mouse, rat, rabbit imaging using GE Signa Lx and
  EXCITE at 1.5T and 3T
• Gmax 500 mT/m, SlewRate 2400 T/m/s
• Completed manufacturing of three identical Scoil
  prototypes
• 1) GE-ASLW / Stanford Research Institute
• 2) GE-GRC / Albany Medical Center
• 3) Robarts

7
Installation and Early Results from GE-ASLW /
SRIYuteng Chen, MScElfar Adalsteinsson,
PhDDolf Pfefferbaum, MD
8

• Sunday
• Feb. 22 2004
• Cable cutting crimping

9
Monday Feb. 23 2004 Twin switch installation
10
Monday Feb. 23 2004 Twin filter installation
11

• Tuesday Feb. 24 2004 Magnet room custom cable
  installation

12
Wednesday Feb. 25 2004 Insert coil calibration
13
Completed / Installed Scoil (3T _at_ GE-ASLW)
Clinical Insert Peak gradient 40 mT/m 500
mT/m Slew rate 150 T/m/s 2000 T/m/s Resolution 0.8
mm 50-100 microns
14
Thursday Feb. 26 2004 First imaging by Dr.
Pfefferbaum
15
(No Transcript)
16
Thiamine-deficiency induced lesion in rat thalamus
17
Thermal Engineering of Gradient Insert
CoilsYuteng Chen, MSc
18
(No Transcript)
19
(No Transcript)
20
Zigzap cooling line (copper tube) design
21
(No Transcript)
22
Novel Design Concepts for Gradient CoilsCarl
Gazdzinski, BSc
23
Concept The Harmonic Gradient Coil

• A multilayered gradient coil with each layer
  contributing a spatial harmonic of field
• Drive layers in variable proportions to obtain
  variable resulting fields/DSVs
• Amounts to a Fourier Series approximation of the
  desired field

24
Continuously Variable DSVs
DSV 17cm G 80 mT/m
DSV 33cm G 39 mT/m
DSV 48cm G 29 mT/m
Coil Specs ID 40cm Inductance 300 ?H/layer Max
Current 300 Amps Unshielded
25
Conclusions To Date

• High performance insertable gradient coils
  feasible on clinical 1.5T and 3T GE scanners
• 10 minute, simple switch-over
• Performance increase 10 - 20 fold over best
  whole-body gradients
• Spatial resolution lt 100µm isotropic
• Advanced clinical pulse sequences (eg. 3DFIESTA,
  FSE, DTI) immediately available
• Advanced hardware (eg. 8-16 fast receivers)
  immediately available
