Title: COMS W4156: Advanced Software Engineering


1
COMS W4156 Advanced Software Engineering
  • Prof. Gail Kaiser
  • Kaiser4156_at_cs.columbia.edu
  • http//bank.cs.columbia.edu/classes/cs4156/

2
Topics covered in this lecture
  • Distributed computing overview
  • More on CORBA client-server
  • COM client-server
  • MTS extends COM to 3-tier
  • Note NO materials adapted from slides provided
    by the textbook author/publisher

3
Distributed Computing Overview
4
Distributed Computing 101 Plumbing
  • How does client identify server?
  • How does server make its functionality known and
    available to prospective clients?
  • How does client make its request?
  • How does server return its response?
  • What design-time support is available?
  • What run-time support is available?

5
How does client identify server?
  • One alternative hard-wired solution
  • Tightly coupled code where any change to server
    may require modifications to client and vice
    versa
  • Cannot plug-replace with new server from another
    vendor (better, faster, cheaper), possibly not
    even with a different version of the original
    server
  • System administration nightmare
  • Better alternative employ some standard
    discovery protocol that all prospective vendors
    agree to abide by

6
How does server make its functionality known and
available to prospective clients?
  • Are separately specified interfaces used?
  • If so, how expressive?
  • Are interfaces enforced?

7
How does client make its request? How does server
return its response?
  • Communication protocol
  • How complicated? How (potentially) buggy?
  • Percentage of code and development effort devoted
    to mechanism?

8
What design-time support is available?
  • Quality Assurance
  • Errors caught at runtime after deployment 1000x
    more expensive to fix than at design time
  • Reduce errors in first place through intuitive
    idioms
  • Type-safety checks incredibly useful (do
    parameters supplied by clients match those
    anticipated by server? do responses from server
    match those expected by client?)
  • Interoperability
  • Must client and server use same development
    language?
  • Is third-party code reuse possible?

9
What run-time support is available?
  • Standardized infrastructure crucial
  • Reduced training, design, coding and testing
    costs
  • More reliable and robust
  • But need to consider impact on performance
  • Interoperability (across vendors) essential
  • Countless incompatible proprietary standards

10
Motivation for Component Model Frameworks
  • Provide standard answers to the Distributed
    Computing 101 questions
  • Designing, implementing, testing and deploying
    the plumbing is difficult and error-prone
  • But nearly the same across many applications
  • Put system programmers and distributing computing
    experts effort into doing it once per framework
    rather than once per application
  • Leaves application logic (and business value) to
    application programmers and domain experts

11
CORBA
12
CORBA
  • Common Object Request Broker Architecture
  • Historically, one of the first organized
    frameworks for distributed computing (c. 1991)
  • Specification developed and periodically revised
    by the Object Management Group
  • Extremely influential
  • Used especially as middleware in enterprise and
    business-critical infrastructures
  • Not quite a component model as more recently
    envisioned, but on the way there… (later CCM
    Corba Component Model)

13
CORBA Big Picture
Client
Server
IDL stub
IDL skeleton
ORB Object Request Broker
Request
Response
IDL Interface Description Language
14
CORBA Big Picture
  • Server interface specified in language-independent
    IDL notation
  • Client communicates request to ORB
  • IDL compiler generates stub (in clients
    implementation language) to hide complexity
  • Stub compiled and linked together with client
  • ORB delivers request to Server
  • IDL compiler generates skeleton (in servers
    implementation language) to hide complexity
  • Skeleton compiled and linked together with server
  • Analogous return path for response

15
Objects
  • CORBA terminology can be confusing what
    Distributed Computing 101 calls a Server is
    instead called an Object
  • What CORBA calls a Server is something else, in
    particular a runtime host process for one or more
    Objects
  • CORBA Objects are object-oriented in the sense
    that they are individual units of running
    software that provide interfaces and combine
    functionality and data
  • Typically, there are many instances of an Object
    of a single type e.g., an e-commerce website
    would have many shopping cart object instances
  • For some types, there may be only one instance
    e.g., when a legacy application, such as an
    accounting system, is wrapped as a CORBA Object
    and opened up to clients on the network

16
CORBA Big Picture (Refined)
  • Object type interface specified in
    language-independent IDL notation
  • Client communicates request to ORB
  • IDL compiler generates stub (in clients
    implementation language) to hide complexity
  • Stub compiled and linked together with client
  • ORB delivers request to Server host, which in
    turn delivers request to Object instance selected
    by Server
  • IDL compiler generates skeleton (in servers
    implementation language) to hide complexity
  • Skeleton compiled and linked together with server
  • Analogous return path for response

17
Object Interfaces
  • For each Object type, an interface is defined in
    OMGs IDL (Interface Description Language)
  • The interface is the syntax part of the
    contract that the Object offers to the clients
  • Any client that wants to invoke an operation on
    the Object must use this IDL interface to specify
    the operation it wants to perform, and to marshal
    the arguments that it sends
  • When the invocation reaches the target Object,
    the same interface definition is used there to
    demarshal the arguments so that the Object can
    perform the requested operation
  • And analogously wrt marshalling/demarshalling
    response

18
Object Marshalling/Demarshalling
  • When objects in memory are to be passed across a
    network to another host or persisted to storage,
    their in-memory representation must be converted
    to a suitable out-of-memory format.
  • This process is called marshalling (or
    serializing), and converting back to an in memory
    representation is called demarshalling (or
    deserializing).

19
Object Marshalling/Demarshalling
  • During marshalling
  • Objects must be represented with enough
    information that the destination host can
    understand the type of object being created.
  • The objects state data must be converted to the
    appropriate format.
  • Complex object trees that refer to each other via
    object references (or pointers) need to refer to
    each other via some form of ID that is
    independent of any memory model.
  • During demarshalling
  • The destination host must reverse all that.
  • And must also validate that the objects it
    receives are consistent with the expected object
    type (i.e., it validate that it doesnt get a
    string where it expects a number).

20
CORBA Big Picture (Refined)
Client
Server
IDL stub
IDL skeleton
ORB
Object
Object IDL file
21
IDL Interface Description Language
  • Neutral wrt implementation language
  • IDL notation looks and feels remarkably like C,
    with some Pascal concepts added
  • There are defined (or at least draft) mappings to
    Ada, C, C, Java, C, Python, Perl, Ruby, Lisp,
    XML, numerous others
  • IDL Compilers generate native code in target
    language

22
IDL HelloWorld example
  • module HelloApp
  • interface Hello
  • string sayHello()
  • Module is a scoping unit
  • Interface is set of Object method signatures
  • Base types defined by CORBA include string, int,
    double, float, boolean, etc…

23
More complicated example
  • module StockObjects
  • struct Quote
  • string symbol
  • long at_time
  • double price
  • long volume
  • exception Unknown
  • interface Stock
  • Quote get_quote() raises (Unknown)
  • void set_quote (in Quote stock_quote)
  • readonly attribute string description
  • Exception associated with modules may be raised
    by methods
  • Attribute provides additional information

24
IDL expressiveness
  • Method Signatures
  • Declare arguments as inoutinout
  • Can raise exceptions
  • Can return a value
  • Declarative Attributes
  • readonly attribute type name
  • Equivalent to having _get_att/_set_att(in p)
  • Multiple Inheritance
  • Interface ISpecI1,I2 …

25
CORBA Client-side
  • Connect to ORB
  • Contact NameService (standard service provided by
    any CORBA implementation)
  • Locate (resolve) Object by name
  • Typecast (narrow) to specific Interface
  • Invoke desired method

26
Client-side perspective
Client
  • Client shielded by Interface
  • Client accesses ORB services
  • Client communicates with stub proxy

interface
IDL stub
ORB
27
CORBA Server-side
  • Connect to ORB
  • Contact NameService
  • Register (rebind) Object by name

28
Server-side perspective
  • ORB receives call
  • ORB passes request to Object implementation
    through skeleton
  • Response sent back from Object to skeleton
  • Sent back to client

Server
3. Response
IDL skeleton
1. Call
2. Invoke
4. To Client
ORB
29
Server-side perspective (Refined)
  • ORB receives call
  • ORB activates server
  • Server calls BOAimpl_is_ready
  • BOA instantiates Object in Server
  • BOA passes request to Object implementation
    through skeleton
  • Response sent back from object to skeleton
  • Sent back to client

IDL skeleton
1. Call
BOA
ORB
BOA Basic Object Adapter
30
CORBA Evaluation
  • Strengths
  • Interfaces hide complexities
  • Automatic language interoperability
  • Weaknesses
  • Client must know servers interface(s)
  • Java RMI and other modern language facilities do
    everything CORBA does …
  • And todays component model frameworks do even
    more…

31
CORBA Limitations
  • Before version 3.0, c. 2002, which includes
    CORBA Component Model
  • No common (mandatory) set of services implemented
    by all ORBs
  • No standard way of deploying server Objects
    (adding new server Objects to an ORB)
  • Each ORB infrastructure implementation had
    different approach to IMR (IMplementation
    Repository)

32
CORBA Limitations
  • No support for common programming idioms
  • Most server Objects implemented as factories,
    creating a new Object instance to deal with each
    new client, but new factory code needs to be
    written for each case
  • Every programmer has same choices to make,
    between persistent and transient references,
    Objects identified or not by a primary key,
    Objects maintain persistent state or not, … and
    then has to implement the decisions

33
CORBA Needs Components
  • Binary (executable) units that can really be used
    interchangeably with any ORB
  • Allows graceful evolution by replacing one
    component with another
  • Eases porting to another ORB (better, faster,
    cheaper)
  • Applications can then be built by assembling
    components
  • Components must define what they need and what
    they offer
  • Once assembled, deployment must be semi-automatic
  • Need standard development, deployment and runtime
    environment

34
CORBA Component Model (CCM)
  • Part of CORBA 3.0 specification, June 2002 (most
    recently revised in CORBA 3.1, January 2008)
  • Extends CORBA object model
  • New component meta-type
  • Development by composition
  • Similar to EJB (Enterprise Java Beans)
  • Not widely used

35
COM/DCOM
36
Component Object Model (COM)
  • COM specifies an object (or component) model, and
    programming and compiler requirements, that
    enable COM objects to interact with other COM
    objects
  • A COM object is made up of a set of data and the
    functions that manipulate the data
  • A COM objects data is accessed exclusively
    through one or more sets of related functions
    called interfaces
  • COM requires that the only way to gain access to
    the methods of an interface is through a pointer
    to the interface
  • Interfaces defined in Microsoft Interface
    Definition Language (analogous to CORBA IDL, but
    NOT the same)

37
Component Object Model (COM)
  • COM is a binary standarda standard that applies
    after a program has been translated to binary
    machine code
  • COM methods and interfaces must follow a
    prescribed in-memory layout
  • Objects can be written in different languages,
    including languages that dont have objects
  • COM allows objects to interact across process and
    machine boundaries as easily as within a single
    process
  • Marshalling/demarshalling method parameters and
    return values across process and machine
    boundaries handled by operating system (in
    Windows COM implementation)

38
COM Clients and Servers
  • A COM client is whatever code or object gets a
    pointer to a COM server and uses its services by
    calling the methods of its interface(s)
  • A COM server is any object that provides services
    to clients
  • These services are in the form of COM interface
    implementations that can be called by any client
    that is able to get a pointer to one of the
    interfaces on the server object

39
COM Overview
40
Types of COM Server
  • An in-process server resides in a dynamic link
    library (DLL) and runs in the same address space
    as the COM client
  • A local server resides in its own executable
    (e.g., .exe file), in a different process but on
    the same machine as the COM client
  • A remote server runs on a different machine than
    the client

41
Same Machine
  • For clients and servers on the same machine, the
    CLSID of the server is all the client ever needs
  • On each machine, COM maintains a database (using
    the system registry on Windows) of all the CLSIDs
    for the servers installed on the system
  • This is a mapping between each CLSID and the
    location of the DLL or EXE that houses the code
    for that CLSID
  • COM consults this database whenever a client
    wants to create an instance of a COM class and
    use its services, so the client never needs to
    know the absolute location

42
Different Machines
  • For distributed systems, COM provides registry
    entries that allow a remote server to register
    itself for use by a local client
  • Applications need know only a server's CLSID,
    because they can rely on the registry to locate
    the server
  • However, COM allows clients to override registry
    entries and specify server locations

43
COM vs. DCOM
  • COM client applications do not need to be aware
    of how server objects are packaged, whether they
    are packaged as in-process objects (in DLLs) or
    as local or remote objects (in EXEs)
  • Distributed COM (DCOM) is not separateit is just
    COM with a longer wire

44
COM Limitations
  • Same as CORBA No support for common programming
    idioms (other than RPC)
  • Unlike CORBA Has one main implementation -
    from Microsoft for Windows, so by definition
    compatible
  • Needs component services distributed
    transactions, resource pooling, disconnected
    applications, event publication and subscription,
    better memory and processor (threads) management,
    …
  • COM 1993, DCOM 1996, (D)COM MTS 1998, COM
    2000, partially superseded by .NET 2002 (but
    compatible)

45
COM MTS
46
MTS Microsoft Transaction Server
  • Enables the transactional requirements of each
    component to be set administratively, so
    components can be written separately and then
    grouped together as needed to form a single
    transaction

47
What Transactional Requirements?
  • Many applications write to some database or other
    data repository
  • An application that makes more than one change to
    a database may want to group those changes into a
    single unit called a transaction
  • The goal is to make sure that either all of those
    changes take place or that none of them doa mix
    of success and failure isnt possible

48
What is a Transaction?
  • ACID properties
  • Atomicity (all or nothing)
  • Consistency (no integrity constraints violated)
  • Isolation (no one else sees intermediate states,
    more formally serializability)
  • Durability (persistence failure recovery)
  • Component model frameworks generally only
    concerned with atomicity and durability

49
Handling Transactions within One Data Source
  • If all the data accessed are contained in a
    single database, the database itself probably
    provides transactions
  • The programmer need only indicate when a
    transaction begins and when it ends
  • The database will make sure that all data
    accesses within these boundaries are either
    committed or rolled back

50
Handling Transactions Across Multiple Data Sources
  • The problem gets harder when an application
    accesses data contained in more than one database
    or involves other data resource managers such as
    a message queue
  • Its probably not possible for the transaction
    support built into any one of those systems to
    coordinate the commitment or roll-back of all
    data accesses
  • Need some kind of independent transaction
    coordinating service

51
What does the Transaction Coordinating Service do?
  • Two-Phase Commit
  • First phase transaction coordinator asks every
    resource manager (e.g., database) involved in the
    transaction if its prepared to commit
  • Second phase
  • If every resource manager says yes, then the
    transaction coordinator tells each one to commit
  • If one or more of the resource managers involved
    in this transaction is unable or unwilling to
    commit (or does not respond within a timeout
    period), the transaction coordinator tells all of
    them to roll back the transaction

52
MTS Executive and Distributed Transaction
Coordinator (DTC)
  • Invisible to a client, client sees just an
    ordinary COM object exposing some number of
    interfaces
  • Executive intercepts every call the client makes
    on the objects it controls
  • DTC manages the two-phase commit

53
MTS Application Structure
54
Two-Phase Commit
55
Context Object
  • Every object involved in a transaction is
    associated with a context object
  • If a transaction needs to span the functions of
    multiple different objects, then same context
    object coordinates the activities of all of those
    objects
  • Allows the transaction semantics to be separated
    from the application code

56
Automatic Transactions
  • In traditional transaction systems, the
    application code indicates when a transaction
    begins and ends
  • MTS also supports automatic transactions,
    allowing business logic to remain unaware of when
    transactions start and end

57
Transaction Semantics Defined Declaratively
  • Transaction semantics declared when components
    are assembled into an application package
  • Each component is assigned a transaction
    attribute, one of four values
  • Required
  • Requires New
  • Supported
  • Not Supported

58
Transaction Options
  • REQUIRED - The component must execute within the
    context of a transaction, although it does not
    care where the transaction context originates
  • If the caller has a transaction (context object),
    then the called component will use the existing
    transaction
  • If the caller does not have a transaction, then
    MTS automatically creates a new transaction
    context for the component

59
Transaction Options
  • REQUIRES NEW - indicates that the component must
    always establish its own transaction context
  • Regardless of whether or not the calling
    application has a transaction context, MTS
    automatically creates a new transaction context
    object for the component

60
Transaction Options
  • SUPPORTED - indicates that the component does not
    care whether or not there is a transaction
    context in place
  • NOT SUPPORTED - indicates that the component
    cannot support a transaction

61
Commit or Abort
  • The component operating on the DB can tell the
    MTS executive when its task is complete
  • Everything has gone just fine and the transaction
    is ready to be committed the component calls
    IObjectContextSetComplete (or just returns)
  • Something has gone wrong perhaps one attempt to
    access data resulted in an error and the entire
    transaction should be rolled back the component
    calls IObjectContextSetAbort (or just crashes,
    hangs, etc.)

62
Coordination of Multi-Component Transactions
  • Calling SetComplete does not necessarily mean
    that the transaction will be committed right then
  • If this component implements all the work
    required for an entire transaction, then MTS will
    perform the commit

63
Coordination of Multi-Component Transactions
  • But this component may be part of a group of
    components, all of which collectively participate
    in a single transaction
  • Each component will call SetComplete (or
    terminate) when its work is done, but MTS wont
    begin the commit process until all components
    within the transaction have completed
    successfully
  • The code for the component looks the same in
    either case

64
And a few other services…
65
Just-In-Time (JIT) Activation
  • Also known as deferred activation
  • When a client makes a call to an object to create
    an instance, COM provides that client a
    reference to a context object instead of a
    reference to the object
  • Client gets a real reference to the object, and
    the object is activated, when client calls a
    method of that object
  • Object deactivated when method returns and
    reactivated when next method called
  • Deactivated object releases all resources,
    including locks on data stores
  • Allows server resources to be used more
    productively

66
Object Pooling
  • Recycling of objects
  • When a client releases an object that supports
    object pooling, or such an object is deactivated,
    instead of destroying that object completely,
    COM recycles it
  • When another client requests or reactivates the
    same kind of object, COM gives an instance from
    the pool
  • Since these component instances are already
    loaded in memory (up to maximum size of pool),
    they are immediately available for use
  • If you intend to make only one call at a time on
    a pooled object, it is a good idea to enable JIT
    activation with object pooling if you intend to
    get a reference and make multiple calls on it,
    using object pooling without JIT activation may
    result in better performance.

67
Connection Pooling
  • Opening and closing connections to a database can
    be time-consuming
  • Reuse existing database connections rather than
    create new ones
  • A resource dispenser caches resources such as
    ODBC (Open DataBase Connectivity) connections to
    a database, allowing components to efficiently
    reuse them

68
Role-Based Security
  • Role a logically related group of users that
    share the same permissions to access a defined
    subset of an applications functionalities
  • Assign different permissions for different roles
    on a class, interface or method
  • Can set either administratively or via
    programming
  • Dont need to write security-related logic into
    components (but can do so if desired)

69
So How Does MTS Fit With COM?
70
MTS Extends COM to 3-tier Architecture
71
Client-Server Architecture
Client
Server
72
2-tier Architecture with Basic Component
Middleware
Client
Server
Component middleware
73
3-Tier Architecture with Component Services
Middleware
Document Storage
Client
Database
Application logic components
LDAP
Component services middleware
74
  • Final Notes

75
Reminder Project Concept due soon!
  • Teams posted on the website team page
  • Project concept due September 23rd
  • Each team submits one document as a group
  • Submit on courseworks

76
Upcoming Deadlines
  • Team project concept due September 23th
  • Project concept feedback by September 30th
  • First iteration begins September 30th

77
COMS W4156 Advanced Software Engineering
  • Prof. Gail Kaiser
  • Kaiser4156_at_cs.columbia.edu
  • http//bank.cs.columbia.edu/classes/cs4156/
About PowerShow.com
