Intermediate Representations

1
Intermediate Representations
2
Intermediate Representations

• Front end - produces an intermediate
  representation (IR)
• Middle end - transforms the IR into an equivalent
  IR that runs more efficiently
• Back end - transforms the IR into native code
• IR encodes the compilers knowledge of the
  program
• Middle end usually consists of several passes

3
Intermediate Representations

• Decisions in IR design affect the speed and
  efficiency
• of the compiler
• Some important IR properties
• Ease of generation
• Ease of manipulation
• Procedure size
• Freedom of expression
• Level of abstraction
• The importance of different properties varies
  between compilers
• Selecting an appropriate IR for a compiler is
  critical

4
Types of Intermediate Representations

• Three major categories
• Structural
• Graphically oriented
• Heavily used in source-to-source translators
• Tend to be large
• Linear
• Pseudo-code for an abstract machine
• Level of abstraction varies
• Simple, compact data structures
• Easier to rearrange
• Hybrid
• Combination of graphs and linear code
• Example control-flow graph

Examples Trees, DAGs
Examples 3 address code Stack machine code
Example Control-flow graph
5
Level of Abstraction

• The level of detail exposed in an IR influences
  the profitability and feasibility of different
  optimizations.
• Two different representations of an array
  reference

loadI 1 gt r1 sub rj, r1 gt r2 loadI 10
gt r3 mult r2, r3 gt r4 sub ri, r1 gt r5 add
r4, r5 gt r6 loadI _at_A gt r7 Add r7, r6 gt
r8 load r8 gt rAij
High level AST Good for memory disambiguation
Low level linear code Good for address
calculation
6
Level of Abstraction

• Structural IRs are usually considered high-level
• Linear IRs are usually considered low-level
• Not necessarily true

7
Abstract Syntax Tree

• An abstract syntax tree is the procedures parse
  tree with
• the nodes for most non-terminal nodes
  removed
• x - 2 y
• Can use linearized form of the tree
• Easier to manipulate than pointers
• x 2 y - in postfix form
• - 2 y x in prefix form
• S-expressions are (essentially) ASTs

8
Directed Acyclic Graph

• A directed acyclic graph (DAG) is an AST with a
  unique
• node for each value
• Makes sharing explicit
• Encodes redundancy

z ? x - 2 y w ? x / 2
9
Stack Machine Code

• Originally used for stack-based computers, now
  Java
• Example
• x - 2 y becomes
• Advantages
• Compact form
• Introduced names are implicit, not explicit
• Simple to generate and execute code
• Useful where code is transmitted
• over slow communication links (the net )

push x push 2 push y multiply subtract
Implicit names take up no space, where explicit
ones do!
10
Three Address Code

• Several different representations of three
  address code
• In general, three address code has statements of
  the form
• x ? y op z
• With 1 operator (op ) and, at most, 3 names (x,
  y, z)
• Example
• z ? x - 2 y becomes
• Advantages
• Resembles many machines
• Introduces a new set of names
• Compact form

t ? 2 y z ? x - t
11
Three Address Code Quadruples

• Naïve representation of three address code
• Table of k 4 small integers
• Simple record structure
• Easy to reorder
• Explicit names

The original FORTRAN compiler used quads
load 1 Y
loadi 2 2
mult 3 2 1
load 4 X
sub 5 4 2
load r1, y loadI r2, 2 mult r3, r2, r1 load
r4, x sub r5, r4, r3
RISC assembly code
Quadruples
12
Three Address Code Triples

• Index used as implicit name
• 25 less space consumed than quads
• Much harder to reorder

load y
loadI 2
mult (1) (2)
load x
sub (4) (3)
Implicit names take no space!
13
Three Address Code Indirect Triples

• List first triple in each statement
• Implicit name space
• Uses more space than triples, but easier to
  reorder
• Major tradeoff between quads and triples is
  compactness versus ease of manipulation
• In the past compile-time space was critical
• Today, speed may be more important

load y
loadI 2
mult (100) (101)
load x
sub (103) (102)
(100)
(100)
(101)
(105)
(102)
(103)
(104)
14
Static Single Assignment Form

• The main idea each name defined exactly once
• Introduce ?-functions to make it work
• Strengths of SSA-form
• Sharper analysis
• ?-functions give hints about placement

Original x ? y ? while (x lt k) x
? x 1 y ? y x
SSA-form x0 ? y0 ? if (x0
gt k) goto next loop x1 ? ?(x0,x2) y1
? ?(y0,y2) x2 ? x1 1 y2 ? y1
x2 if (x2 lt k) goto loop next

15
Two Address Code

• Allows statements of the form
• x ? x op y
• Has 1 operator (op ) and, at most, 2 names (x and
  y)
• Example
• z ? x - 2 y becomes
• Can be very compact
• Problems
• Machines no longer rely on destructive operations
• Difficult name space
• Destructive operations make reuse hard
• Good model for machines with destructive ops
  (PDP-11)

t1 ? 2 t2 ? load y t2 ? t2 t1 z ? load x z ?
z - t2
16
Control-flow Graph

• Models the transfer of control in the procedure
• Nodes in the graph are basic blocks
• Can be represented with quads or any other linear
  representation
• Edges in the graph represent control flow
• Example

17
Using Multiple Representations

• Repeatedly lower the level of the intermediate
  representation
• Each intermediate representation is suited
  towards certain optimizations
• Example the Open64 compiler
• WHIRL intermediate format
• Consists of 5 different IRs that are
  progressively more detailed

18
Memory Models

• Two major models
• Register-to-register model
• Keep all values that can legally be stored in a
  register in registers
• Ignore machine limitations on number of registers
• Compiler back-end must insert loads and stores
• Memory-to-memory model
• Keep all values in memory
• Only promote values to registers directly before
  they are used
• Compiler back-end can remove loads and stores
• Compilers for RISC machines usually use
  register-to-register
• Reflects programming model
• Easier to determine when registers are used

19
The Rest of the Story

• Representing the code is only part of an IR
• There are other necessary components
• Symbol table (already discussed)
• Constant table
• Representation, type
• Storage class, offset
• Storage map
• Overall storage layout
• Overlap information
• Virtual register assignments

20
The Procedure as a Control Abstraction

• Procedures have well-defined control-flow
• The Algol-60 procedure call
• Invoked at a call site, with some set of actual
  parameters
• Control returns to call site, immediately after
  invocation

21
The Procedure as a Control Abstraction

• Procedures have well-defined control-flow
• The Algol-60 procedure call
• Invoked at a call site, with some set of actual
  parameters
• Control returns to call site, immediately after
  invocation

int p(a,b,c) int a, b, c int d d
q(c,b) ...
s p(10,t,u)
22
The Procedure as a Control Abstraction

• Procedures have well-defined control-flow
• The Algol-60 procedure call
• Invoked at a call site, with some set of actual
  parameters
• Control returns to call site, immediately after
  invocation

int p(a,b,c) int a, b, c int d d
q(c,b) ...
int q(x,y) int x,y return x y
s p(10,t,u)
23
The Procedure as a Control Abstraction

• Procedures have well-defined control-flow
• The Algol-60 procedure call
• Invoked at a call site, with some set of actual
  parameters
• Control returns to call site, immediately after
  invocation

int p(a,b,c) int a, b, c int d d
q(c,b) ...
int q(x,y) int x,y return x y
s p(10,t,u)
24
The Procedure as a Control Abstraction

• Procedures have well-defined control-flow
• The Algol-60 procedure call
• Invoked at a call site, with some set of actual
  parameters
• Control returns to call site, immediately after
  invocation

int p(a,b,c) int a, b, c int d d
q(c,b) ...
int q(x,y) int x,y return x y
s p(10,t,u)
25
The Procedure as a Control Abstraction

• Procedures have well-defined control-flow
• The Algol-60 procedure call
• Invoked at a call site, with some set of actual
  parameters
• Control returns to call site, immediately after
  invocation
• Most languages allow recursion

int p(a,b,c) int a, b, c int d d
q(c,b) ...
int q(x,y) int x,y return x y
s p(10,t,u)
26
The Procedure as a Control Abstraction

• Implementing procedures with this behavior
• Requires code to save and restore a return
  address
• Must map actual parameters to formal parameters
  (c?x, b?y)
• Must create storage for local variables (,
  maybe, parameters)
• p needs space for d (, maybe, a, b, c)
• where does this space go in recursive
  invocations?
• Compiler emits code that causes all this to
  happen at run time

27
The Procedure as a Control Abstraction

• Implementing procedures with this behavior
• Must preserve ps state while q executes
• recursion causes the real problem here
• Strategy Create unique location for each
  procedure activation
• Can use a stack of memory blocks to hold local
  storage and return addresses
• Compiler emits code that causes all this to
  happen at run time

28
The Procedure as a Name Space

• Each procedure creates its own name space
• Any name (almost) can be declared locally
• Local names obscure identical non-local names
• Local names cannot be seen outside the procedure
• Nested procedures are inside by definition
• We call this set of rules conventions lexical
  scoping
• Examples
• C has global, static, local, and block scopes
  (Fortran-like)
• Blocks can be nested, procedures cannot
• Scheme has global, procedure-wide, and nested
  scopes (let)
• Procedure scope (typically) contains formal
  parameters

29
The Procedure as a Name Space

• Why introduce lexical scoping?
• Provides a compile-time mechanism for binding
  free variables
• Simplifies rules for naming resolves conflicts
• How can the compiler keep track of all those
  names?
• The Problem
• At point p, which declaration of x is current?
• At run-time, where is x found?
• As parser goes in out of scopes, how does it
  delete x?
• The Answer
• Lexically scoped symbol tables
  (see 5.7.3)

30
Do People Use This Stuff ?

• C macro from the MSCP compiler

define fix_inequality(oper, new_opcode)
\ if (value0 lt value1)
\
\ Unsigned_Int temp value0
\ value0 value1
\ value1 temp
\ opcode_name new_opcode
\ temp oper-gtarguments0
\ oper-gtarguments0
oper-gtarguments1 \ oper-gtarguments1
temp \ oper-gtopcode
new_opcode \
Declares a new name
31
Do People Use This Stuff ?

• C code from the MSCP implementation

More local declarations!
static Void phi_node_printer(Block block)
Phi_Node phi_node Block_ForAllPhiNodes(phi_n
ode, block) if (phi_node-gtold_name
lt register_count)
Unsigned_Int i fprintf(stderr, "Phi
node for rd ",
phi_node-gtold_name) for (i 0 i lt
block-gtpred_count i)
fprintf(stderr, " rd", phi_node-gtparmsi)
fprintf(stderr, " gt rd\n",
phi_node-gtnew_name)
else Unsigned_Int2
arg_ptr fprintf(stderr, "Phi node
for s ",
Expr_Get_String(Tag_Unmap( phi_node-gtold_name)))
Phi_Node_ForAllParms(arg_ptr,
phi_node) fprintf(stderr, " d",
arg_ptr) fprintf(stderr, " gt
d\n", phi_node-gtnew_name)
32
Lexically-scoped Symbol Tables
5.7 in EaC

• The problem
• The compiler needs a distinct record for each
  declaration
• Nested lexical scopes admit duplicate
  declarations
• The interface
• insert(name, level ) creates record for name at
  level
• lookup(name, level ) returns pointer or index
• delete(level ) removes all names declared at
  level
• Many implementation schemes have been proposed
  (see B.4)
• Well stay at the conceptual level
• Hash table implementation is tricky, detailed,
  fun

Symbol tables are compile-time structures the
compiler use to resolve references to
names. Well see the corresponding run-time
structures that are used to establish
addressability later.
33
Example

• procedure p
• int a, b, c
• procedure q
• int v, b, x, w
• procedure r
• int x, y, z
• .
• procedure s
• int x, a, v
• r s
• q

B0 int a, b, c B1 int v, b, x,
w B2 int x, y, z . B3
int x, a, v
34
Lexically-scoped Symbol Tables

• High-level idea
• Create a new table for each scope
• Chain them together for lookup

• Sheaf of tables implementation
• insert() may need to create table
• it always inserts at current level
• lookup() walks chain of tables
• returns first occurrence of name
• delete() throws away table for level
• p, if it is top table in the chain
• If the compiler must preserve the table (for,
  say, the debugger ), this idea is actually
  practical.
• Individual tables can be hash tables.

35
Implementing Lexically Scoped Symbol Tables

• Stack organization

• Implementation
• insert () creates new level pointer if needed and
  inserts at nextFree
• lookup () searches linearly from nextFree1
  forward
• delete () sets nextFree to the equal the start
  location of the level deleted.
• Advantage
• Uses much less space
• Disadvantage
• Lookups can be expensive

growth
nextFree
z
y
r (level 2)
x
w
x
b
q (level 1)
v
c
b
p (level 0)
a
36
Implementing Lexically Scoped Symbol Tables

• Threaded stack organization

• Implementation
• insert () puts new entry at the head of the list
  for the name
• lookup () goes direct to location
• delete () processes each element in level being
  deleted to remove from head of list
• Advantage
• lookup is fast
• Disadvantage
• delete takes time proportional to number of
  declared variables in level

growth


z
y
h(x)

x
r
w

x
b
q
v
c
b
p

a
37
The Procedure as an External Interface

• OS needs a way to start the programs execution
• Programmer needs a way to indicate where it
  begins
• The main procedure in most languaages
• When user invokes grep at a command line
• OS finds the executable
• OS creates a process and arranges for it to run
  grep
• grep is code from the compiler, linked with
  run-time system
• Starts the run-time environment calls main
• After main, it shuts down run-time environment
  returns
• When grep needs system services
• It makes a system call, such as fopen()

UNIX/Linux specific discussion
38
Where Do All These Variables Go?

• Automatic Local
• Keep them in the procedure activation record or
  in a register
• Automatic ? lifetime matches procedures lifetime
• Static
• Procedure scope ? storage area affixed with
  procedure name
• _p.x
• File scope ? storage area affixed with file name
• Lifetime is entire execution
• Global
• One or more named global data areas
• One per variable, or per file, or per program,
• Lifetime is entire execution

39
Placing Run-time Data Structures

• Classic Organization

• Better utilization if
• stack heap grow
• toward each other
• Very old result (Knuth)
• Code data separate or
• interleaved
• Uses address space,
• not allocated memory

• Code, static, global data have known size
• Use symbolic labels in the code
• Heap stack both grow shrink over time
• This is a virtual address space

40
How Does This Really Work?

• The Big Picture

virtual address spaces
Compilers view
...
OSs view
0
high
Physical address space_
Hardwares view
41
Where Do Local Variables Live?

• A Simplistic model
• Allocate a data area for each distinct scope
• One data area per sheaf in scoped table
• What about recursion?
• Need a data area per invocation (or activation)
  of a scope
• We call this the scopes activation record
• The compiler can also store control information
  there !
• More complex scheme
• One activation record (AR) per procedure instance
• All the procedures scopes share a single AR (may
  share space)
• Static relationship between scopes in single
  procedure

Used this way, static means knowable at compile
time (and, therefore, fixed).
42
Translating Local Names

• How does the compiler represent a specific
  instance of x ?
• Name is translated into a static coordinate
• lt level,offset gt pair
• level is lexical nesting level of the procedure
• offset is unique within that scope
• Subsequent code will use the static coordinate to
  generate addresses and references
• level is a function of the table in which x is
  found
• Stored in the entry for each x
• offset must be assigned and stored in the
  symbol table
• Assigned at compile time
• Known at compile time
• Used to generate code that executes at run-time

43
Storage for Blocks within a Single Procedure
B0 int a, b, c B1 int v, b, x,
w B2 int x, y, z . B3
int x, a, v

• Fixed length data can always be at a constant
  offset from the beginning of a procedure
• In our example, the a declared at level 0 will
  always be the first data element, stored at byte
  0 in the fixed-length data area
• The x declared at level 1 will always be the
  sixth data item, stored at byte 20 in the fixed
  data area
• The x declared at level 2 will always be the
  eighth data item, stored at byte 28 in the fixed
  data area
• But what about the a declared in the second block
  at level 2?

44
Variable-length Data

• Arrays
• If size is fixed at compile time, store in
  fixed-length data area
• If size is variable, store descriptor in fixed
  length area, with pointer to variable length area
• Variable-length data area is assigned at the end
  of the fixed length area for block in which it is
  allocated

B0 int a, b assign value to a B1
int v(a), b, x B2 int x,
y(8) .
a
b
v
b
x
x
y(8)
v(a)
Variable-length data
Includes variable length data for all blocks in
the procedure
45
Activation Record Basics
Space for parameters to the current routine
Saved register contents
If function, space for return value
Address to resume caller
Help with non-local access
To restore callers AR on a return
Space for local values variables (including
spills)
One AR for each invocation of a procedure
46
Activation Record Details

• How does the compiler find the variables?
• They are at known offsets from the AR pointer
• The static coordinate leads to a loadAI
  operation
• Level specifies an ARP, offset is the constant
• Variable-length data
• If AR can be extended, put it below local
  variables
• Leave a pointer at a known offset from ARP
• Otherwise, put variable-length data on the heap
• Initializing local variables
• Must generate explicit code to store the values
• Among the procedures first actions

47
Activation Record Details

• Where do activation records live?
• If lifetime of AR matches lifetime of invocation,
  AND
• If code normally executes a return
• Keep ARs on a stack
• If a procedure can outlive its caller, OR
• If it can return an object that can reference its
  execution state
• ARs must be kept in the heap
• If a procedure makes no calls
• AR can be allocated statically
• Efficiency prefers static, stack, then heap

Yes! This stack.
48
Communicating Between Procedures

• Most languages provide a parameter passing
  mechanism
• Expression used at call site becomes variable
  in callee
• Two common binding mechanisms
• Call-by-reference passes a pointer to actual
  parameter
• Requires slot in the AR (for address of
  parameter)
• Multiple names with the same address?
• Call-by-value passes a copy of its value at time
  of call
• Requires slot in the AR
• Each name gets a unique location
  (may have same value)
• Arrays are mostly passed by reference, not value
• Can always use global variables

call fee(x,x,x)
49
Establishing Addressability

• Must create base addresses
• Global static variables
• Construct a label by mangling names (i.e., _fee)
• Local variables
• Convert to static data coordinate and use ARP
  offset
• Local variables of other procedures
• Convert to static coordinates
• Find appropriate ARP
• Use that ARP offset

50
Establishing Addressability

• Using access links
• Each AR has a pointer to AR of lexical ancestor
• Lexical ancestor need not be the caller
• Reference to ltp,16gt runs up access link chain to
  p
• Cost of access is proportional to lexical distance

Some setup cost on each call
51
Establishing Addressability

• Using access links
• Access maintenance cost varies with level
• All accesses are relative to ARP (r0 )

• Assume
• Current lexical level is 2
• Access link is at ARP - 4
• Maintaining access link
• Calling level k1
• Use current ARP as link
• Calling level j lt k
• Find ARP for j 1
• Use that ARP as link

52
Establishing Addressability

• Using a display
• Global array of pointer to nameable ARs
• Needed ARP is an array access away
• Reference to ltp,16gt looks up ps ARP in display
  adds 16
• Cost of access is constant (ARP
  offset)

Some setup cost on each call
53
Establishing Addressability

• Using a display
• Access maintenance costs are fixed
• Address of display may consume a register

• Assume
• Current lexical level is 2
• Display is at label _disp
• Maintaining access link
• On entry to level j
• Save level j entry into AR (Saved Ptr field)
• Store ARP in level j slot
• On exit from level j
• Restore level j entry

Desired AR is at _disp 4 x level
54
Establishing Addressability

• Access links versus Display
• Each adds some overhead to each call
• Access links costs vary with level of reference
• Overhead only incurred on references calls
• If ARs outlive the procedure, access links still
  work
• Display costs are fixed for all references
• References calls must load display address
• Typically, this requires a register
  (rematerialization)
• Your mileage will vary
• Depends on ratio of non-local accesses to calls
• Extra register can make a difference in overall
  speed
• For either scheme to work, the compiler must
• insert code into each procedure call return

55
Procedure Linkages

• How do procedure calls actually work?
• At compile time, callee may not be available for
  inspection
• Different calls may be in different compilation
  units
• Compiler may not know system code from user code
• All calls must use the same protocol
• Compiler must use a standard sequence of
  operations
• Enforces control data abstractions
• Divides responsibility between caller callee
• Usually a system-wide agreement
  (for interoperability)

56
Procedure Linkages

• Standard procedure linkage

• Procedure has
• standard prolog
• standard epilog
• Each call involves a
• pre-call sequence
• post-return sequence
• These are completely predictable from the call
  site ? depend on the number type of the actual
  parameters

57
Procedure Linkages

• Pre-call Sequence
• Sets up callees basic AR
• Helps preserve its own environment
• The Details
• Allocate space for the callees AR
• except space for local variables
• Evaluates each parameter stores value or
  address
• Saves return address, callers ARP into callees
  AR
• If access links are used
• Find appropriate lexical ancestor copy into
  callees AR
• Save any caller-save registers
• Save into space in callers AR
• Jump to address of callees prolog code

58
Procedure Linkages

• Post-return Sequence
• Finish restoring callers environment
• Place any value back where it belongs
• The Details
• Copy return value from callees AR, if necessary
• Free the callees AR
• Restore any caller-save registers
• Restore any call-by-reference parameters to
  registers, if needed
• Also copy back call-by-value/result parameters
• Continue execution after the call

59
Procedure Linkages

• Prolog Code
• Finish setting up the callees environment
• Preserve parts of the callers environment that
  will be disturbed
• The Details
• Preserve any callee-save registers
• If display is being used
• Save display entry for current lexical level
• Store current ARP into display for current
  lexical level
• Allocate space for local data
• Easiest scenario is to extend the AR
• Find any static data areas referenced in the
  callee
• Handle any local variable initializations

With heap allocated AR, may need to use a
separate heap object for local variables
60
Procedure Linkages

• Epilog Code
• Wind up the business of the callee
• Start restoring the callers environment
• The Details
• Store return value? No, this happens on the
  return statement
• Restore callee-save registers
• Free space for local data, if necessary (on the
  heap)
• Load return address from AR
• Restore callers ARP
• Jump to the return address

If ARs are stack allocated, this may not be
necessary. (Caller can reset stacktop to its
pre-call value.)
