Regnet Specification : Technical point of view

1
Regnet Specification Technical point of view

• REGNET

2
Contents

• Technical architecture
• Process
• e-Business architectures
• Regnet Technical Architecture

3
Technical architecture
4
Technical Architecture

• Technical architecture present building blocks of
  software that we used in order to implement
  functions. Two technical architectures
• Engineering point of view independent of the
  technologies
• Technological point of view gives technologies
  used.
• System architecture gives projection of the
  technical architecture on material.

5
Process

• UP Elaboration phase
• Technical Requirement
• Technical architecture
• Risks identification
• Architecture validation

6
Technical Architecture How?

• Objectives
• Have a selection process for your development and
  deployment tools.
• Identify alternative solutions in case problems
  arise.
• Define your selection criteria.
• The independence rule.
• Avoid Software Mainframe Syndrome
• Avoid being locked with proprietary solutions
• Don't try to predict the future.
• Integration is the price to pay for freedom
• Technical Integration is an essential criteria.
• One technology may be the most efficient but
  willnot integrate at all with other technologies
  and inthe overall architecture...

7
Technical Architecture Designing the Integration

• Designing the integration is to define the way
  the system will work as a whole.
• Define collaboration between different products.
• Define at the very beginning the constraints that
  the architecture will put on the model and the
  implementation.
• You will certainly have to define elements that
  will glue the components together
• Interfaces.
• Classes.
• Macros/Templates.
• Modeling and coding standards.
• Development tools with user guides.
• Build management facilities

8
Technical Architecture Prototyping

• Objectives.
• To validate the design of the integration layer
  against requirements.
• To cope with integration risks.
• To build the complete list of constraints that
  architecture puts on detailed design.
• Only trust what you see.
• The architecture prototype must implement
  alimited part of the business model.
• A vertical slice of 5 to 15 classes.
• Validate the Architecture from end to end.
• Apply load tests, fault-tolerance tests, and so
  on
• Define the path from Analysis to Implementation.

9
Technical Requirements

• Data Access.
• Logon/Sessions management
• Concurrency control
• Transaction management
• Security.
• Authentication
• Access control
• System Management.
• Active servers list
• Starting/Stopping servers
• Alarms
• Dynamic load balancing
• Special management protocols SNMP, CMIS/CMIP

• Lifecycle.
• Creation
• Search
• Localization
• Destruction
• Distributed memory management
• Separation between database object lifecycle and
  in-memory object lifecycle
• Trace and debugging.
• Availability, Fault-tolerance and cold/warm
  restart facilities.

10
E-Business architecture
11
Engineering point of view
Desktop Clients Data acquisition ?
Internet Web Clients
Integration and Automation Platform
Web Application Platform
Embedded Clients Wap or PDA ?
e - service
B2B
consumer
Directory and Security Platform
12
Deployment Infrastructure ??
Directory and Security Server
Internet, or Extranet Web Clients
Web App. Cluster
Network
e-Service Clients
Web App. Cluster
Integration and Automation Server
e - service
Web Application Server
consume
Desktop Clients
Central Data Center
Third Party e-Services
Regional Office
13
Component based technical architecture
14
Distributed object structures

• You must write
• your business object
• Integration code
• Services

Business objects
Legacy systems
Infrastructure
DataBase
Name
Trans.
Pers.
Secu.
Event
Technical Services
15
RMI or CORBA distributed structures

• You must write
• your business object
• integration code

Business objects
Legacy systems
Infrastructure
Name
Trans.
Pers.
Secu.
Even.
DataBase
Standard technical services

• This is the case for CORBA and RMI

16
Application servers

• You must write
• Your business object
• a standard technical descriptor

Business logic integration
Business contract
Business contract
Legacy systems
Container
Name
Trans.
Pers.
Secu.
Even.
DataBase
Standard technical services

• Component container (EJB, Servlets/JSP...)

17
Descriptor as a technical contract

• The object implements the business contract
• Published business interface
• Business code
• The descriptor describes the technical contract
• Life Cycle How was I created ? Destroyed ?
  Passivated ? Found ?
• Transactions Are my operational transactional ?
  Who can see my modifications ?
• Concurrent access Can multiple clients access
  me at the same time ?
• Persistence Should my state be saved in a
  persistent storage ?
• Security Who is allowed access my services ?
• This technical contract will be automatically
  implemented
• At deployment-time, and provided to the container

18
Componants and containers

• The component
• distinguishes interface and implementation
• the implementation is instantiated into a server
  side container
• The container
• intercepts the communications between the client
  and the component in order to enable framework
  code automation, such as transactions and
  persistence management
• Communicates with the component by using direct
  function calls

Container automated infrastructure
Services Infrastructure APIs
Server
Client
Directory
network
Transaction
Persistence
Stub (proxy) transparent localization
The container acts as a distributed server
object
Component implementation of the business logic
19
Java 2 Enterprise Edition

• Java Enterprise Platform
• Superset of Java 2 Standard Edition (J2SE,
  ex-JDK)
• Integrates business (EJB), and Web (Servlet/JSP)
  component containers,and several other Java APIs

• J2EE is managed as a full release
• Specification
• Reference Implementation
• Compatibility tests and label

20
Java 2 Enterprise Edition
21
J2EE Application

• What is an J2EE application ?
• A set of component modules
• An application is deployed into a J2EE server
• It can also be directly deployed as an
  "standalone" module

Component
Module
Application
Enterprise Archive (ear)
A
Description
A B A?B
Application description
Description assembly instructions
B
22
The EJB standard

• Model for business components
• Java Standard
• Specifies interfaces provided by a business
  component container
• The vendors provides compliant implementations
• No link with JavaBeans (GUI components) !
• More than 35 editors provide containers compliant
  with the EJB specification
• Objectives
• Allow business components reuse without code
  access
• Simplify components and applications development
• Let IS suppliers manage complex enterprise IT
  issues
• Standardize Java application servers
• The heart of the Java enterprise platform
• Since 1998
• Defined by Sun in partnership with IBM, Oracle,
  BEA and many others

23
J2EE today

• Industry key needs for the future
• Compliance to the J2EE platform
• Vertical components
• Component-based development cycle (tooling)
• J2EE simplifies project development but
• e-business projects are getting more complex
• Internet/Web, transactions, workflow, B2B, EAI,
  persistence
• Design phase is critical
• Blindly following the standard can lead to an
  dead-end
• The experience of J2EE applications is an
  advantage
• Choosing a product is critical
• Variable support for standards (amount of
  support, versions...).
• A significant part of e-business projects does
  not rely on standards only (personalization,
  portals)

24
Regnet technical architecture
25
TOOLS (1)

• Presentation
• WebServer Apache
• Server Page JSP (Tomcat), PHP
• WAP, PDA
• Data and MetaData acquisition
• MetaData
• XML editor
• Harvester
• 2D or 3D data Applet Java 2D or 3D upload
  servlet
• Application server
• Jboss
• Enhydra
• Data access
• DataBase MySQL (transaction ?), PostgreSQL
• O/R Mapping Castor

26
TOOLS (2)

• Connectors
• Legacy
• Z39.50
• B2B infrastructure Web services
• ebXML cf. Task 1.3
• JBOSSSoap Zero-Effort Object Access Package
  (ZOAP)
• B2B sophisticated functionalities
• Workflow engine WFTK (Open-source workflow
  toolkit)
• Development tools
• Java IDE SUN/Forte for Java
• ?
