Implementing High Speed TCP (aka Sally Floyds)

• Gareth Fairey Yee-Ting Li
• 12th September 2002 _at_ Brighton

2
What is High Speed TCP?

• Changes the way TCP behaves at high speed (ie
  large cwnd)
• Standard TCP has two modes
• Slow start (not very slow)
• Congestion Avoidance
• Focuses on Congestion Avoidance Region ie when
  TCP knows (thinks it knows) how well the network
  behaves
• BUT only when we are at high speeds, else do what
  normal Standard TCP does
• Readily deployable 1st step towards Equation
  Based Congestion Control

3
What does it do?

• Standard TCP uses two parameters
• Increase parameter, a
• Decrease parameter, b
• i.e. AIMD( a,b )
• Standard TCP uses
• a1
• b0.5
• High Speed TCP introduces
• a-gta(cwnd)
• b-gtb(cwnd)
• i.e. The value of a and b depends on the current
  congestion window size
• If we increase a more with larger cwnd we can get
  back up to our optimal cwnd size for the
  network path
• If we decrease b less we dont lose as much
  bandwidth due to a small congestion window

4
What exactly does it do?

• Based on the TCP response function
• Relates loss and throughput
• Uses the TCP response function to investigate
  certain parameters
• High_Window, High_Loss largest cwnd needed for x
  throughput and the required loss for that
  throughput
• Low_Window, Low_Loss smallest cwnd when we
  actually switch from Standard TCP and the
  required loss rate for that cwnd size
• High_B the smallest decrease in b when we are at
  a large cwnd
• Equations to transform this information into a
  table for a(cwnd) and b(cwnd)

5
Implementation of High Speed TCP

• It was decided to make this a compile-time
  option, so a corresponding option was added to
  the existing kernel configuration set-up.
• There turned out to be only a few changes
  necessary to make to the kernel source to
  implement this
• Code for calculating the a and b values.
• The existing code for changing the congestion
  window size (cwnd), during the Congestion
  Avoidance phase only.
• The following slides show some details of our
  initial implementation, done against kernel
  2.4.16.

6
Changing cwnd size.

• From our inspection of the source, it became
  apparent that this only happens in the file
  net/ipv4/tcp_input.c, where each case is handled
  in a specific function
• Increasing the cwnd following receipt of an ACK
  happens in the function tcp_cong_avoid (this is
  where a will be used).
• Decreasing the cwnd happens in the function
  tcp_cwnd_down (this is where b will be used).
• On the following slides, I will describe those
  changes.

7
Calculating suitable a and b values.

• To find suitable a and b values for a given cwnd
  at run-time, we use a look-up table, which we
  populate as follows
• We defined a structure, hstcp_entry, (in the file
  include/net/tcp.h) to contain cwnd and the
  corresponding a_val and b_val. Note b is
  between 0 and 1, so it is scaled to be between 0
  and 256 and that value stored instead.
• For a selection of different congestion window
  sizes covering the expected range, we calculated
  the corresponding a_val and b_val.
• We defined an array (in the file
  net/ipv4/tcp_input.c) to contain these
  hstcp_entrys , ordered by cwnd.
• For a given cwnd, since the entries are stored in
  order in the table, we can use binary search to
  find a suitable hstcp_entry from it. This is done
  in the function get_hstcp_entry, defined in the
  file net/ipv4/tcp_input.c

8
Changes to tcp_cong_avoid

• To achieve additive increase of cwnd during
  Congestion Avoidance, the TCP needs to receive
  enough ACKS for a full congestion window before
  cwnd is incremented.
• In the Linux kernel this is achieved by counting
  the ACKs since the last change of cwnd and only
  incrementing it when this counter exceeds cwnd.
• In High Speed TCP, cwnd would be increased by a
  instead alternatively, it could be incremented a
  times as often while ACKs are received.

9
Changes to tcp_cong_avoid

• Original loop code
• static inline void tcp_cong_avoid(struct tcp_opt
  tp)
• if (tp-gtsnd_cwnd lt tp-gtsnd_ssthresh)
• / In "safe" area, increase. /
• if (tp-gtsnd_cwnd lt
  tp-gtsnd_cwnd_clamp)
• tp-gtsnd_cwnd
• else
• / In dangerous area, increase
  slowly.
• In theory this is tp-gtsnd_cwnd
  1 / tp-gtsnd_cwnd
• /
• if (tp-gtsnd_cwnd_cnt gt tp-gtsnd_cwnd)
• if (tp-gtsnd_cwnd lt tp-gtsnd_cwnd_clamp)
• tp-gtsnd_cwnd
• tp-gtsnd_cwnd_cnt0
• else
• tp-gtsnd_cwnd_cnt
• tp-gtsnd_cwnd_stamp tcp_time_stamp

10
Changes to tcp_cong_avoid

• Changed loop code
• static inline void tcp_cong_avoid(struct tcp_opt
  tp)
• if (tp-gtsnd_cwnd lt tp-gtsnd_ssthresh)
• / In "safe" area, increase. /
• if (tp-gtsnd_cwnd lt
  tp-gtsnd_cwnd_clamp)
• tp-gtsnd_cwnd
• else
• / In dangerous area, increase
  slowly.
• In theory this is tp-gtsnd_cwnd
  1 / tp-gtsnd_cwnd
• /
• if ((tp-gtsnd_cwnd_cnt get_hstcp_val(tp-gtsnd_c
  wnd).a_val) gt
• tp-gtsnd_cwnd)
• if (tp-gtsnd_cwnd lt tp-gtsnd_cwnd_clamp)
• tp-gtsnd_cwnd
• tp-gtsnd_cwnd_cnt0
• else
• tp-gtsnd_cwnd_cnt

11
Changes to tcp_cwnd_down

• Once a congestion event has occurred, the cwnd is
  reduced to adapt to the observed state of the
  network.
• Traditionally, it is halved
• With High Speed TCP, it is proposed that the
  proportion of the decrease will depend on cwnd.

12
Changes to tcp_cwnd_down

• Original source
• static void tcp_cwnd_down(struct tcp_opt tp)
• int decr tp-gtsnd_cwnd_cnt 1
• tp-gtsnd_cwnd_cnt decr1
• decr gtgt 1
• if (decr tp-gtsnd_cwnd gt
  tp-gtsnd_ssthresh/2)
• tp-gtsnd_cwnd - decr
• tp-gtsnd_cwnd min(tp-gtsnd_cwnd,
• tcp_packets_in_flight(tp)1)
• tp-gtsnd_cwnd_stamp tcp_time_stamp

13
Changes to tcp_cwnd_down

• Changed source
• static void tcp_cwnd_down(struct tcp_opt tp)
• int decr tp-gtsnd_cwnd_cnt 1
• tp-gtsnd_cwnd_cnt decr1
• decr (int)((decr
• get_hstcp_val(tp-gtsnd_cwnd).
  b_val)gtgt8)
• if (decr tp-gtsnd_cwnd gt
  tp-gtsnd_ssthresh/2)
• tp-gtsnd_cwnd - decr
• tp-gtsnd_cwnd min(tp-gtsnd_cwnd,
• tcp_packets_in_flight(tp)1)
• tp-gtsnd_cwnd_stamp tcp_time_stamp

14
Initial results

• Implemented on a P3 450Mhz
• NOT Gigabit
• Patched with Web100 alpha 1.2
• Conducted tests since. Yesterday!
• WAN tests from UCL to RAL, CERN, Daresbury,
  Amsterdam Manchester
• Early results Basic Analysis

15
Throughput Comparison
16
Web 100 Cwnd Growth
17
What next?

• Need to develop an advanced test program to
  fully explore the HSTCP performance space
• GUY has thorough Network Simulator Analysis of
  stock HSTCP need to compare results
• Need to explore the parameter space with
  different values of Low_Loss, Low_Window
  High_Window, High_Loss High_B
• Implement /proc hooks to enable easy
  configuration of HSTCP parameters
• Investigate into performance issues on hosts of
  lookup table
• More results! Especially on GigE.
• Expand tests to America, esp. SLAC (high delay)
• Investigate into fairness compared to other TCP
  implementations
