Clustering Tutorial

1
Clustering Tutorial

• Elias Raftopoulos
• HY539 29/3/06
• Prof. Maria Papadopouli

2
Roadmap

• Math Reminder
• Principle Components Analysis
• Clustering
• ANOVA

3
Standard Deviation

• Statistics analyzing data sets in terms of the
  relationships between the individual points
• Standard Deviation is a measure of the spread of
  the data
• Calculation average distance from the mean of
  the data

4
Variance

• Another measure of the spread of the data in a
  data set
• Calculation
• Var( X ) E(( x µ )2)
• Why have both variance and SD to calculate the
  spread of data?
• Variance is claimed to be the original
  statistical measure of spread of data. However
  its unit would be expressed as a square e.g.
  cm2, which is unrealistic to express heights or
  other measures. Hence SD as the square root of
  variance was born.

5
Covariance

• Variance measure of the deviation from the mean
  for points in one dimension e.g. heights
• Covariance as a measure of how much each of the
  dimensions vary from the mean with respect to
  each other.
• Covariance is measured between 2 dimensions to
  see if there is a relationship between the 2
  dimensions e.g. number of hours studied marks
  obtained
• The covariance between one dimension and itself
  is the variance

6
Covariance Matrix

• Representing Covariance between dimensions as a
  matrix e.g. for 3 dimensions
• cov(x,x) cov(x,y) cov(x,z)
• C cov(y,x) cov(y,y) cov(y,z)
• cov(z,x) cov(z,y) cov(z,z)
• Diagonal is the variances of x, y and z
• cov(x,y) cov(y,x) hence matrix is symmetrical
  about the diagonal
• N-dimensional data will result in nxn covariance
  matrix

7
Covariance

• Exact value is not as important as its sign.
• A positive value of covariance indicates both
  dimensions increase or decrease together e.g. as
  the number of hours studied increases, the marks
  in that subject increase.
• A negative value indicates while one increases
  the other decreases, or vice-versa e.g. active
  social life at RIT vs performance in CS dept.
• If covariance is zero the two dimensions are
  independent of each other e.g. heights of
  students vs the marks obtained in a subject

8
Transformation matrices

• Consider
• 2 3 3 12 3
• 2 1 2 8 2
• Square transformation matrix transforms (3,2)
  from its original location. Now if we were to
  take a multiple of (3,2)
• 3 6
• 2 4
• 2 3 6 24 6
• 2 1 4 16 4

x

x

4
x
2

x

x

4
9
Transformation matrices

• Scale vector (3,2) by a value 2 to get (6,4)
• Multiply by the square transformation matrix
• We see the result is still a multiple of 4.
• WHY?
• A vector consists of both length and direction.
  Scaling a vector only changes its length and not
  its direction. This is an important observation
  in the transformation of matrices leading to
  formation of eigenvectors and eigenvalues.
• Irrespective of how much we scale (3,2) by, the
  solution is always a multiple of 4.

10
eigenvalue problem

• The eigenvalue problem is any problem having the
  following form
• A . v ? . v
• A n x n matrix
• v n x 1 non-zero vector
• ? scalar
• Any value of ? for which this equation has a
  solution is called the eigenvalue of A and vector
  v which corresponds to this value is called the
  eigenvector of A.

11
eigenvalue problem

• 2 3 3 12 3
• 2 1 2 8 2
• A . v ? . v
• Therefore, (3,2) is an eigenvector of the square
  matrix A and 4 is an eigenvalue of A
• Given matrix A, how can we calculate the
  eigenvector and eigenvalues for A?

x

x

4
12
Calculating eigenvectors eigenvalues

• Given A . v ? . v
• A . v - ? . I . v 0
• (A - ? . I ). v 0
• Finding the roots of A - ? . I will give the
  eigenvalues and for each of these eigenvalues
  there will be an eigenvector
• Example

13
Calculating eigenvectors eigenvalues

• If A 0 1
• -2 -3
• Then A - ? . I 0 1 ? 0 0
• -2 -3 0 ?
• -? 1 ?2 3? 2 0
• -2 -3-?
• This gives us 2 eigenvalues
• ?1 -1 and ?2 -2

14
Properties of eigenvectors and eigenvalues

• Note that Irrespective of how much we scale (3,2)
  by, the solution is always a multiple of 4.
• Eigenvectors can only be found for square
  matrices and not every square matrix has
  eigenvectors.
• Given an n x n matrix, we can find n eigenvectors

15
Roadmap

• Principle Components Analysis
• Clustering
• ANOVA

16
PCA

• principal components analysis (PCA) is a
  technique that can be used to simplify a dataset
• It is a linear transformation that chooses a new
  coordinate system for the data set such that
• greatest variance by any projection of the data
  set comes to lie on the first axis (then called
  the first principal component),
• the second greatest variance on the second axis,
  and so on.
• PCA can be used for reducing dimensionality by
  eliminating the later principal components.

17
PCA

• By finding the eigenvalues and eigenvectors of
  the covariance matrix, we find that the
  eigenvectors with the largest eigenvalues
  correspond to the dimensions that have the
  strongest correlation in the dataset.
• This is the principal component.
• PCA is a useful statistical technique that has
  found application in
• fields such as face recognition and image
  compression
• finding patterns in data of high dimension

18
PCA process STEP 1

• Subtract the mean
• from each of the data dimensions. All the x
  values have x subtracted and y values have y
  subtracted from them. This produces a data set
  whose mean is zero.
• Subtracting the mean makes variance and
  covariance calculation easier by simplifying
  their equations. The variance and co-variance
  values are not affected by the mean value.

19
PCA process STEP 1

• DATA
• x y
• 2.5 2.4
• 0.5 0.7
• 2.2 2.9
• 1.9 2.2
• 3.1 3.0
• 2.3 2.7
• 2 1.6
• 1 1.1
• 1.5 1.6
• 1.1 0.9

ZERO MEAN DATA x y .69 .49 -1.31
-1.21 .39 .99 .09 .29 1.29 1.09 .49
.79 .19 -.31 -.81 -.81 -.31 -.31 -.71
-1.01
20
PCA process STEP 1
21
PCA process STEP 2

• Calculate the covariance matrix
• cov .616555556 .615444444
• .615444444 .716555556
• since the non-diagonal elements in this
  covariance matrix are positive, we should expect
  that both the x and y variable increase together.

22
PCA process STEP 3

• Calculate the eigenvectors and eigenvalues of the
  covariance matrix
• eigenvalues .0490833989
• 1.28402771
• eigenvectors -.735178656 -.677873399
• .677873399 -.735178656

23
PCA process STEP 3

• eigenvectors are plotted as diagonal dotted lines
  on the plot.
• Note they are perpendicular to each other.
• Note one of the eigenvectors goes through the
  middle of the points, like drawing a line of best
  fit.
• The second eigenvector gives us the other, less
  important, pattern in the data, that all the
  points follow the main line, but are off to the
  side of the main line by some amount.

24
PCA process STEP 4

• Reduce dimensionality and form feature vector the
  eigenvector with the highest eigenvalue is the
  principle component of the data set.
• In our example, the eigenvector with the larges
  eigenvalue was the one that pointed down the
  middle of the data.
• Once eigenvectors are found from the covariance
  matrix, the next step is to order them by
  eigenvalue, highest to lowest. This gives you the
  components in order of significance.

25
PCA process STEP 4

• Now, if you like, you can decide to ignore the
  components of lesser significance
• You do lose some information, but if the
  eigenvalues are small, you dont lose much
• n dimensions in your data
• calculate n eigenvectors and eigenvalues
• choose only the first p eigenvectors
• final data set has only p dimensions.

26
PCA process STEP 4

• Feature Vector
• FeatureVector (eig1 eig2 eig3 eign)
• We can either form a feature vector with both of
  the eigenvectors
• -.677873399 -.735178656
• -.735178656 .677873399
• or, we can choose to leave out the smaller, less
  significant component and only have a single
  column
• - .677873399
• - .735178656

27
PCA process STEP 5

• Deriving the new data
• FinalData RowFeatureVector x RowZeroMeanData
• RowFeatureVector is the matrix with the
  eigenvectors in the columns transposed so that
  the eigenvectors are now in the rows, with the
  most significant eigenvector at the top
• RowZeroMeanData is the mean-adjusted data
  transposed, ie. the data items are in each
  column, with each row holding a separate
  dimension.

28
PCA process STEP 5
S
R
VT
U

factors
variables
variables
factors
significant
sig.
noise
noise
noise
significant
factors
factors
samples
samples
29
PCA process STEP 5

• FinalData is the final data set, with data items
  in columns, and dimensions along rows.
• What will this give us?
• It will give us the original data solely in terms
  of the vectors we chose.
• We have changed our data from being in terms of
  the axes x and y , and now they are in terms of
  our 2 eigenvectors.

30
PCA process STEP 5

• FinalData transpose dimensions along columns
• x y
• -.827970186 -.175115307
• 1.77758033 .142857227
• -.992197494 .384374989
• -.274210416 .130417207
• -1.67580142 -.209498461
• -.912949103 .175282444
• .0991094375 -.349824698
• 1.14457216 .0464172582
• .438046137 .0177646297
• 1.22382056 -.162675287

31
PCA process STEP 5
32
Reconstruction of original Data

• If we reduced the dimensionality, obviously, when
  reconstructing the data we would lose those
  dimensions we chose to discard. In our example
  let us assume that we considered only the x
  dimension

33
Reconstruction of original Data

• x
• -.827970186
• 1.77758033
• -.992197494
• -.274210416
• -1.67580142
• -.912949103
• .0991094375
• 1.14457216
• .438046137
• 1.22382056

34
Roadmap

• Principle Components Analysis
• Clustering
• ANOVA

35
What is Cluster Analysis?

• Cluster a collection of data objects
• Similar to the objects in the same cluster
  (Intraclass similarity)
• Dissimilar to the objects in other clusters
  (Interclass dissimilarity)
• Cluster analysis
• Statistical method for grouping a set of data
  objects into clusters
• A good clustering method produces high quality
  clusters with high intraclass similarity and low
  interclass similarity
• Clustering is unsupervised classification
• Can be a stand-alone tool or as a preprocessing
  step for other algorithms

36
Group objects according to their similarity
Cluster a set of objects that are similar to
each other and separated from the
other objects. Example green/ red data
points were generated from two different normal
distributions
37
Clustering data
object expression data matrix

• Experiments/samples are given as the row and
  column vectors of an expression data matrix
• Clustering may be applied either to objects
  experiments (regarded as vectors in Ro or Rn).

n experiments
o objects
38
Pattern matrix ? Proximity matrix

• Pattern matrix (nxp)
• pattributes
• n of objects
• Proximity matrix (nxn)
• d(i,j)difference/
• dissimilarity between i and j

39
Proximity matrix

• Clustering methods require that a index of
  proximity, or alikeness, or affinity or
  association be established between pairs of
  patterns
• A proximity index is either a similarity or a
  dissimilarity
• The crucial problem in identifying clusters in
  data is to specify what proximity is and how to
  measure it

40
Proximity indices

• A proximity index between the ith and kth
  patterns is denoted d(i,k) and must satisfy the
  following three properties
• 1. (a) for a dissimilarity d(i,i) 0, all i
• (b) for a similarity d(i,i) max
  d(i,k), all I
• 2. d(i,k) d(k,i), all (i,k)
• 3. d(i,k) 0, all (i,k)

41
Different proximity measures

• r 2(Euclidean distance)
• 42 221/2 4.472
• r 1(Manhattan distance)
• 4 2 6
• r ? 8 (sup distance)
• max4,2 4

42
K-Means Clustering

• The meaning of K-means
• Why it is called K-means clustering K points
  are used to represent the clustering result each
  point corresponds to the centre (mean) of a
  cluster
• Each point is assigned to the cluster with the
  closest center point
• The number K, must be specified
• Basic algorithm

43
The K-Means Clustering Method

• Given k, the k-means algorithm is implemented in
  4 steps
• Partition objects into k non-empty subsets
• Arbitrarily choose k points as initial centers
• Assign each object to the cluster with the
  nearest seed point (center)
• Calculate the mean of the cluster and update the
  seed point
• Go back to Step 3, stop when no more new
  assignment

44
The K-Means Clustering Method (cntd)

• The basic step of k-means clustering is simple
• Iterate until stable ( no object move group)
• Determine the centroid coordinate
• Determine the distance of each object to the
  centroids
• Group the object based on minimum distance

45
The K-Means Clustering Method (cntd)
46
The K-Means Clustering Results

• Example

10
9
8
7
6
5
Update the cluster means
Assign each objects to most similar center
4
3
2
1
0
0
1
2
3
4
5
6
7
8
9
10
reassign
reassign
K2 Arbitrarily choose K object as initial
cluster center
Update the cluster means
47
Weaknesses of the K-Means Method

• Unable to handle noisy data and outliers
• Very large or very small values could skew the
  mean
• Not suitable to discover clusters with non-convex
  shapes

48
Hierarchical Clustering

• Start with every data point in a separate cluster
• Keep merging the most similar pairs of data
  points/clusters until we have one big cluster
  left
• This is called a bottom-up or agglomerative
  method

49
Hierarchical Clustering (cont.)

• This produces a binary tree or dendrogram
• The final cluster is the root and each data item
  is a leaf
• The height of the bars indicate how close the
  items are

50
Hierarchical Clustering Demo
51
Levels of Clustering
52
Linkage in Hierarchical Clustering

• We already know about distance measures between
  data items, but what about between a data item
  and a cluster or between two clusters?
• We just treat a data point as a cluster with a
  single item, so our only problem is to define a
  linkage method between clusters
• As usual, there are lots of choices

53
Average Linkage

• Definition
• Each cluster ci is associated with a mean vector
  ?i which is the mean of all the data items in the
  cluster
• The distance between two clusters ci and cj is
  then just d(?i , ?j )
• This is somewhat non-standard this method is
  usually referred to as centroid linkage and
  average linkage is defined as the average of all
  pairwise distances between points in the two
  clusters

54
Single Linkage

• The minimum of all pairwise distances between
  points in the two clusters
• Tends to produce long, loose clusters

55
Complete Linkage

• The maximum of all pairwise distances between
  points in the two clusters
• Tends to produce very tight clusters

56
Distances between clusters (summary)

• Calculation of the distance between two clusters
  is based on the pairwise distances between
  members of the clusters.
• Complete linkage largest distance between points

• Average linkage average distance between points
• Single linkage smallest distance between points
• Centroid distance between centroids

Complete linkage gives preference to
compact/spherical clusters. Single linkage can
produce long stretched clusters.
57

A B C D E
A 0 1 2 2 3
B 1 0 2 4 3
C 2 2 0 1 5
D 2 4 1 0 3
E 3 3 5 3 0
EXAMPLE
58
More on Hierarchical Clustering Methods

• Major advantage
• Conceptually very simple
• Easy to implement ? most commonly used technique
• Major weakness of agglomerative clustering
  methods
• do not scale well time complexity of at least
  O(n2), where n is the number of total objects
• can never undo what was done previously ? high
  likelihood of getting stuck in local minima

59
Roadmap

• Principle Components Analysis
• Clustering
• ANOVA

60
(M)ANOVA

• The analysis of variance technique in One-Way
  Analysis of Variance (ANOVA) takes a set of
  grouped data and determine whether the mean of a
  variable differs significantly between groups
• Often there are multiple variables and you are
  interested in determining whether the entire set
  of means is different from one group to the next
• There is a multivariate version of analysis of
  variance that can address that problem (MANOVA)
