Supervised Learning

1
Lecture 6

• Supervised Learning

2
Unsupervised Learning

• Learning From Unlabeled Data
• Clustering, Correlation, PCA
• Identify relationships between the features

3
Supervised Learning

• Learning From Labeled Data
• Neural Networks, Support Vector Machines,
  Decision Trees
• Identify relationships between the features and
  the categories

4
Supervised Learning

• Given
• Examples whose feature values are known and
• Whose categories are known
• Do
• Predict the categories of examples whose feature
  values are known but whose categories are not

5
4 ways of representing gene-chip data
From Molla, et. aI AI Magaizine 25, 2004
6
Typical Methodology

• N-Fold Cross validation
• Split labeled data into N (usually 10) folds
• Train on All but 1 (N-1) folds of the data
• Test on the left-out fold (ignoring the category
  label)
• Repeat until all N folds have been tested
• Note This methodology can be (and is) used to
  test predictive different statistical models as
  well.

7
Example

• Probe Picking

8
Oligonucleotide Microarrays

• Specific probes synthesized atknown spot on
  chips surface
• Probes complementary to RNA of genes to be
  measured
• Typical gene (1kb) MUCH longer than typical
  probe (24 bases)

9
Probes Good vs. Bad
Blue Probe
Red Sample
good probe
bad probe
10
Probe-Picking Method Needed

• Hybridization characteristics differ between
  probes
• Probe set represents very small subset of gene
• Accurate measurement of expression requires good
  probe set

11
Related Work

• Use known hybridization characteristics
• Lockhardt et al. 1996
• Melting point (Tm) predictions
• Kurata and Suyama 1999
• Li and Stormo 2001
• Stable secondary structure
• Kurata and Suyama 1999

12
Our Approach

• Apply established machine-learning algorithms
• Train on categorized examples
• Test on examples with category hidden
• Choose features to represent probes
• Categorize probes as good or bad

13
The Features
14
The Data

• Tilings of 8 genes (from E. coli B. subtilus)
• Every possible probe (10,000 probes)
• Genes known to be expressed in sample

• Gene Sequence GTAGCTAGCATTAGCATGGCCAGTCATG
• Complement CATCGATCGTAATCGTACCGGTCAGTAC
• Probe 1 CATCGATCGTAATCGTACCGGTCA
• Probe 2 ATCGATCGTAATCGTACCGGTCAG
• Probe 3 TCGATCGTAATCGTACCGGTCAGT

15
Our Microarray
16
Defining our Categories
Low Intensity BAD Probes (45)
Mid-Intensity Not Used in Training Set (23)
High Intensity GOOD Probes (32)
Frequency
0
.05
.15
1.0
Normalized Probe Intensity
17
The Machine Learning Techniques

• Naïve Bayes (Mitchell 1997)
• Neural Networks (Rumelhart et al. 1995)
• Decision Trees (Quinlan 1996)
• Can interpret predictions of each learner
  probabilistically

18
Naïve Bayes

• Assumes conditional independence between features
• Make judgments about test set examples based on
  conditional probability estimates made on
  training set

19
Naïve Bayes
For each example in the test set, evaluate the
following
20
Neural Network(1-of-n encoding with probe length
3)
Weights
A1 C1 G1 T1
Example probe sequence CAG
Good or Bad

A2 C2 G2 T2
ACTIVATION
A3 C3 G3 T3
ERROR

21
Decision Tree
fracC
High
Low
fracT
fracG
Automatically builds a tree of rules
High
Low

fracTC
Low
High
Low
High
fracG

fracAC

High
Low
Low
High
n14


Good Probe
C
G
T
A

Bad Probe
22
Decision Tree
The information gain of a feature, F, is
23
Information Gain per Feature
Probe Composition Features
Normalized Information Gain
Base Position Features
Base Position
Dimer Position
24
Cross-Validation

• Leave-one-out testing
• For each gene (of the 8)
• Train on all but this gene
• Test on this gene
• Record result
• Forget what was learned
• Average results across 8 test genes

25
Typical Probe-Intensity Prediction Across Short
Region
Actual
Normalized Probe Intensity
Starting Nucleotide Position for 24-mer Probe
26
Typical Probe-Intensity Prediction Across Short
Region
Neural Network
Naïve Bayes
Decision Tree
Actual
Normalized Probe Intensity
Starting Nucleotide Position for 24-mer Probe
27
Probe-Picking Results
Perfect Selector
Number of probes selected with intensity gt 90th
percentile
Number of probes selected
28
Probe-Picking Results
Perfect Selector
Neural Network
Number of probes selected with intensity gt 90th
percentile
Naïve Bayes
Primer Melting Point
Decision Tree
Number of probes selected
29
A couple of final notes for the class
30
What is Principal Component Analysis (PCA)?in 1
silde
31
PCA Tutorial

• http//csnet.otago.ac.nz/cosc453/student_tutorials
  /principal_components.pdf

32
Vocal Tract ? Slide Whistle
?
